CONDTROL Octoliner Servo User manual

3
CONDTROL Octoliner Servo
EN CONTENTS
SAFETY INSTRUCTIONS 4
INTENDED USE 5
PRODUCT DESCRIPTION 6
TECHNICAL SPECIFICATIONS 8
SET 8
BATTERY CHARGING 9
OPERATION 9
ACCURACY CHECK 11
CARE AND MAINTENANCE 13
UTILIZATION 14
WARRANTY 14
RU
                            


 






 

4 5
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
INTENDED USE
Multiline laser CONDTROL Octoliner Servo is intended to build
vertical and horizontal laser lines and planes. The product projects

dots – zenith and nadir. The product is equipped with electronic
compensator with servo units, that help to reduce the risk of damage
and increase accuracy of the product.
The product base with leveling screws, adapter for mounting on a
tripod 5/8’’ makes operation easy.
Pulse mode allows using laser receiver to increase working range of
the product or to work when laser is hard to define in bright lighting
conditions.
The product is suitable for use at both indoor and outdoor building
areas.
SAFETY INSTRUCTIONS
Attention! This user manual is an essential part of this product.
The user manual should be read carefully before you use the product
for the first time. If the product is given to someone for temporary
use, be sure to enclose user manual to it.
- Do not misuse the product
- Do not remove warning signs and protect them from abrasion,
because they contain information about safe operation of the
product.
-Do not look into the laser beam or its reflection, with unprotected
eye or through an optical instrument. Do not point the laser beam at
people or animals without the need. You can dazzle them.
-To protect your eyes close them or look aside.
- Always install the product in such a way, so that laser line is below
or above eye level.
- Do not let unauthorized people enter the zone of product operation.
- Store the product beyond reach of children and unauthorized
people.
- It is prohibited to disassemble or repair the product yourself. Entrust
product repair to qualified personnel and use original spare parts
only.
- Do not use the product in explosive environment, close to flammable
materials.
- Laser intensive glasses are used for better recognition of the laser
beam, do not use them for other purposes. Laser glasses do not
protect from laser radiation as well as ultraviolet radiation and reduce
color perception.
- Avoid heating the batteries to avoid the risk of explosion and
electrolyte leakage. In case of liquid contact with skin, wash it
immediately with soap and water. In case of contact with eyes, flush


6
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
Control panel
1. Turn on/off

3. Turn on/off vertical planes
4. Pulse mode
5. Power indicator
6. Pulse mode indicator


1
33
4
56
1. Control panel


4. Horizontal limb
5. Fine adjustment screws
6. Adjustable feet

8. Battery fixator
9. Battery charge indicator
PRODUCT DESCRIPTION
1

33


9
5
4 5
8
6
6

8 9
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
TECHNICAL SPECIFICATIONS
Working range 
Working range with receiver 
Accuracy 
Self-levelling electronic
Self-levelling range 
Operation temperature 
Waterproof and dustproof IP54
Continuous working time up to 8 h
Laser type Class II, 635 nm, <1 mW
Power supply 
rechargeable
Dimensions 
Weight 1,535 kg
SET
1. Laser level - 1 pc.

3. Adapter for mounting on a tripod 5/8” – 1 pc.
4. Battery charger – 1 pc.
5. Laser target - 1 pc.
6. User manual – 1 pc.

BATTERY CHARGING
For charging use battery charger included in the set.
If power indicator starts flashing while operation, please charge the
batteries.
Full charging takes approximately 4 hours. While charging battery
charge indicator will be red. As soon as it has become green, battery
charger can be unplugged.
OPERATION
Place the product on a solid and flat surface or tripod. Adjust the tilt of
the product by fine adjustment screws or position of tripod.
Turn on the product by pressing button ON/OFF. Red power
indicator will be on. Self-levelling indicator will flash green until the
product finishes self-levelling. As soon as self-levelling is finished
– indicator is steady green. Press buttons V1, V2, Hto turn on/off
necessary laser planes. The laser lines flash if the product is out of the

Press button to switch to pulse mode which allows working
with laser receiver.
OUT
DOOR

 11
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
To facilitate rotation of the product
about its axis slightly pull and hold
the left screw of fine adjustment

Press ON/OFF to turn off the
product.
Attention! To increase the
operating time and avoid the risk of
unintentional blindness switch the
laser on only when you are ready to
make measurements.
If operated near objects or air
streams with different from the
environment temperature the
laser line may tremble due to
heterogeneity of the atmosphere.
The longer is the distance, the more
trembling can be observed.
The width of the laser line increases with the increasing of the
operating distance. The layout should be made along the axis of the
laser line. For maximum accuracy, use the middle portion of the laser
line.
It should be noted that the shape of the laser line on the object’s

the surface relative to the laser plane.
ACCURACY CHECK
Check of horizontal lines


1. Put the product as close as possible to one of the walls. Turn on
horizontal planes. Mark location of horizontal line on the distant wall
as A1.
            

    
the distant wall as A3.

on the distant wall as A4.

If deviation exceeds 1 mm – please contact service center.
Figure 1

 13
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
Check of vertical lines
Use a plumb bob as a reference of a vertical. Place the product at
distance of 1,5m from the plumb bob.
1. Switch on vertical plane and align vertical laser line with the low
point of plumb bob.



Check of 90° angle between vertical lines
Place the product on a solid and flat surface.
Switch on vertical planes. Measure a 1 m distance along each of 4



Make sure that bottom plumb dot doesn’t move. Compare position of
all laser lines with previously made marks. If any of laser lines doesn’t

CARE AND MAINTENANCE
This product is a high-precision instrument and requires careful

carry out accuracy check.
Observation of the following recommendations will extend the life of
the device:

children and unauthorized people.

only.

dust and dirt resistant, but long-time exposure to these elements may
damage internal moving parts of the product.

but precipitate, humidity and liquids containing minerals may damage
the electrical circuits of the product. Do not try to dry the unit by fire
or a hairdryer.


damage batteries, deform or melt some plastic parts.
           


14 15
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
user manual
CROSS
LINE LASER
EN
CONDTROL Octoliner Servo
After storage in low temperature conditions and subsequent transfer
to a warm room, the device is heated, causing moisture condense
inside the product and damage the chip.

lead to loss of accuracy.
        

             
chemicals, cleaning solvents or detergents.
          
isopropyl alcohol.
UTILIZATION
Expired tools, accessories and package should be passed for waste
recycle. Please send the product to the following address for proper
recycle:
Condtrol GmbH
Wasserburger Strasse 9

Germany
Do not throw the product in municipal waste!

and their components must be collected separately and submitted to
environmentally friendly recycle of wastes.
WARRANTY
All Condtrol GmbH products go through post-production control and
are governed by the following warranty terms. The buyer’s right to
claim about defects and general provisions of the current legislation
do not expire.
          
discovered during the warranty period, that represent the defect in
material or workmanship in full volume and at its own expense.
            


or improper use, malfunction of the product caused by failure to
observe the instructions of this user manual, untimely maintenance
and service and insufficient care, the use of non-original accessories
and spare parts. Modifications in design of the product relieve the
seller from responsibility for warranty works. The warranty does not
cover cosmetic damage, that doesn’t hinder normal operation of the
product.
          
repair of the device.


not renewed or extended.
           
associated with a defect of the device, the rental cost of alternative
equipment for the period of repair.
This warranty applies to German law except provision of the United
Nations Convention on contracts for the international sale of goods

In warranty case please return the product to retail seller or send it
with defect description to the following address:
Condtrol GmbH
Wasserburger Strasse 9

Germany

16 
