Congratulations on your purchase of the laser level XLiner Pento 360
/ Quattro 360 G / Pento 360 G CONDTROL. Safety instructions can
be found in the end of this user manual and should be carefully read
before you use the device for the first time.
SAFETY INSTRUCTIONS
Attention! This user manual is an essential part of this product.
The user manual should be read carefully before you use the product
for the first time. If the product is given to someone for temporary
use, be sure to enclose user manual to it.
- Do not misuse the product
- Do not remove warning signs and protect them from abrasion,
because they contain information about safe operation of the
product.
- Do not look into the laser beam or its reflection, with unprotected
eye or through an optical device. Do not point the laser beam at
people or animals without the need. You can dazzle them.
- To protect your eyes close them or look aside.
- Always install the product in such a way, so that laser line is below
or above eye level.
- Do not let unauthorized people enter the zone of product operation.
- Store the product beyond reach of children and unauthorized
people.
- Do not disassemble or repair the product yourself. Entrust product
repair to qualified personnel and use original spare parts only.
- Do not use the product in explosive environment, close to flammable
materials.
LASER RADIATION!
Do not stareinto beam
Class 2 laser
<1 mW, 635/515 nm
IEC 60825-1: 2007-03

user manual
EN
55
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G
- Laser intensive glasses are used for better recognition of the laser
beam; do not use them for other purposes. Laser glasses do not
protect from laser radiation as well as ultraviolet radiation and reduce
color perception.
- Avoid heating the battery to avoid the risk of explosion and
electrolyte leakage. In case of liquid contact with skin, wash it
immediately with soap and water. In case of contact with eyes, flush
with clean water during 10 minutes and consult the doctor.
PRODUCT DESCRIPTION
Cross line lasers XLiner Pento 360 / Quattro 360 G / Pento 360 G
CONDTROL are intended to project vertical and horizontal planes and
lines as well as the laser dot (zenith and nadir). The laser levels are
suitable for use at both indoor and outdoor building areas.
The cross line laser has 2 operating modes:
- Automatic leveling to compensate irregularities within self-
leveling range of ± 3.5°;
- Locked compensator, to project inclined planes and lines.
Pulse mode allows using laser receiver to increase the working range
of the laser level or to work when laser is hard to define in bright
lighting conditions.

user manual
LASER LEVEL
EN
66
Pento 360 / Quattro 360 G / Pento 360 G
1 - Laser exit windows
2 - Control panel
3 - Battery cover
4 - Thread 1/4’’ for mounting on a tripod
5 - Thread 5/8’’ for mounting on a tripod
6 - Switch bar
7- Hole for mounting on a screw/nail
1
4 - Thread 1/4’’ for mounting on a tripod
5 - Thread 5/8’’ for mounting on a tripod
3
45
6
LASER LEVEL
2
7

user manual
EN
77
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G
Control panel
1. Switch on/off:
- the laser level;
- laser planes.
2. Switch on/off pulse mode
3. Power indicator
4. Locked mode indicator
5. Pulse mode indicator
DELIVERY PACKAGE
XLiner Pento 360/Quattro 360 G/Pento 360 G
Laser level, battery (7.4V 2600mAh Li-Ion) 2 pcs, charger, user manual,
bag.
XLiner Pento 360 Kit/Quattro 360 G Kit/Pento 360 G Kit
Laser level, battery (7.4V 2600mAh Li-Ion) 2 pcs, charging cable,
magnetic target, wall mount, clamp, user manual, plastic case.
1 2
3 5
4

user manual
LASER LEVEL
EN
88
Pento 360 / Quattro 360 G / Pento 360 G
TECHNICAL SPECIFICATIONS
XLiner
Pento 360 XLiner Quattro 360 G XLiner Pento 360 G
Working range/with
receiver 30/80 m* 40/80 m*
Accuracy ±0,2 mm/m
Self-leveling range ± 3,5°
Continuous operating time >18 hours >8 hours
Operating temperature -10°C ... +50°C
Storage temperature 
Relative humidity 90%
Dust and water protection
rate IP54
Thread for mounting on
a tripod 1/4’’ and 5/8’’
Laser
Class II
635 nm
< 1 mW
Class II
515 nm
< 1 mW
Power supply 7.4V 2600 mAh Li-Ion
Dimensions 155x85x132 mm
Weight:
without battery
with battery 0,63 kg 0,73 kg
* The operating range may differ from the declared depending on the
lighting conditions.

user manual
EN
99
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G
BEFORE START OPERATION
Power supply
The laser level is powered via a 7.4V 2600mAh Li-Ion battery included
in the delivery package.
Install/charge the Li-Ion battery
Install the battery in the battery compartment, observing the polarity.
Use the battery included in the delivery package only.
If the power indicator on the control panel starts flashing red, the
battery must be charged.
The charging procedure is as follows:
1) Remove the battery from the laser level.
2) Connect the battery to the power source by a charging cable,
included in the delivery package. The power indicator on control
panel will be red while charging.
3) The battery charging time is about 3 hours.
4) Once the power indicator on control panel turns green, disconnect
the charger and install the battery in the battery compartment.
OPERATION
Place the laser level on a firm and stable surface or a tripod.
Move switch bar to select required operating mode:
1) Automatic leveling:
Move the switch bar to position ON.
The laser level will switch on.
Short press to switch on required lines. If the laser level is out
of the range of automatic compensation laser lines will flash 1 time
per second.
Short press to switch on/off the pulse mode.
To switch off the laser level move the switch bar to position OFF.

user manual
LASER LEVEL
EN
1010
Pento 360 / Quattro 360 G / Pento 360 G
2) Projection of inclined planes
The switch bar is in position OFF.
Press and hold during 2 seconds to switch on the laser.
Long press during 2 seconds to switch on required laser lines.
Switched on laser lines will flash each 5 seconds.
After all possible combinations of lines are switched on, the next long
press will switch off the laser level.
Long press during 2 seconds to switch on/off the pulse mode.
Attention! To increase operating time and avoid the risk of
unintentional blindness switch the laser on only when you are ready
to work.
If operated near objects or air streams with the temperature different
from the environment the laser line may tremble due to heterogeneity
of the atmosphere. The longer the distance, the more trembling of the
laser line can be observed.
The width of the laser line increases as soon as operating distance
increases as well. The layout should be made along the axis of the laser
line. For maximum accuracy, use the middle portion of the laser line.
It should be noted that the shape of the laser line on the object’s
surface (e.g., walls, ceilings, etc.) depends on the curvature and tilt of
the surface relative to the laser line.

user manual
EN
1111
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G
Bluetooth
Bluetooth is always on by default. Switch on the laser level. Activate
Bluetooth at your portable device and start the app “XLiner Remote”.
Perform connection via Bluetooth. The app allows switching on and
off the laser lines and dots, receiver mode, as well as adjust the
brightness of the laser for optimal visibility and energy saving and
control the battery charge level without touching the laser level.
ACCURACY CHECK
Check of horizontal line
Use 2 parallel vertical walls which are located opposite each other at
a distance of 5 m.
1. Set the instrument close to the wall A (see Fig. A). Switch on the
vertical and horizontal laser emitters, unlock the compensator. Turn
the instrument in such a way so that the laser lines intersecting each
other are projected on the near wall A opposite the instrument. Mark
the point where laser lines intersect each other as A1.
A
5m

user manual
LASER LEVEL
EN
1212
Pento 360 / Quattro 360 G / Pento 360 G
2. Turn the instrument by 180°, mark the point where laser lines

B
3. Move the instrument to the opposite wall B and set it in such a way
so that the point where laser lines intersect each other would be on the
same level with point B2. (see Fig. C).
C

user manual
EN
1313
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G



D

distance exceeds 2 mm, please contact service center.

user manual
LASER LEVEL
EN
1414
Pento 360 / Quattro 360 G / Pento 360 G
Check of vertical line
Use a plumb bob as a reference of a vertical line. Place the instrument
at distance of 1,5m from the plumb bob.
1. Unlock the compensator, switch on the vertical laser line and align it
with the low point of plumb bob.
2. If deviation between the laser line and the plumb bob line exceeds
±0.2 mm per 1m of the plumb bob length (for a 2.5m plumb bob
deviation shouldn’t exceed 0.5 mm) please contact service center.
3. Turn the instrument by 180° and align the vertical laser line with the
low point of plumb bob once again.
1,5m

user manual
EN
1515
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G
CARE AND MAINTENANCE
Attention! The laser level is an accurate optical mechanic device
and requires careful handling. Check the accuracy before using.
Maintenance of the following recommendations will extend the life
of the device:
- Keep the laser level, spare parts and accessories out of the reach of
children and unauthorized people.
- Transport the laser level with locked compensator only.
- Protect the device from shock, falls, and strong vibrations; do not
allow moisture, construction dust, and foreign objects to get inside
the laser level.
- In case moisture gets inside the laser level, first of all, remove the
battery, and then contact the service center.
- Do not store or use the laser level for a long time in high humidity
conditions.
- Arrange the accuracy check of the laser level occasionally (see the
paragraph «Accuracy check»).
- Clean the laser level with a soft damp cloth. Do not use harsh
chemicals, cleaning solvents or detergents.
- Wipe the laser aperture with a soft, lint-free cloth with isopropyl
alcohol.
Failure to comply with the following rules may result in leakage of
the electrolyte from the batteries and damage the laser level:
- Remove the battery from the laser level if it is not used for a long
time.
- Do not leave discharged battery in the device.
- Do not heat the battery.

user manual
LASER LEVEL
EN
1616
Pento 360 / Quattro 360 G / Pento 360 G
UTILIZATION
Expired tools, accessories and package should be passed for waste
recycle. Please send the product to the following address for proper
recycle:
CONDTROL GmbH
Im Wiegenfeld 4
85570 Markt Schwaben
Germany
Do not throw the product in municipal waste!

and their components must be collected separately and submitted to
environmentally friendly recycle of wastes.
WARRANTY
All CONDTROL GmbH products go through post-production control
and are governed by the following warranty terms. The buyer’s
right to claim about defects and general provisions of the current
legislation do not expire.
1) CONDTROL GmbH agrees to eliminate all defects in the product,
discovered while warranty period, that represent the defect in
material or workmanship in full volume and at its own expense.
2) The warranty period is 24 months and starts from the date of
purchase by end consumer (see the original supporting document).
3) The Warranty doesn’t cover defects resulting from wear and tear
or improper use, malfunction of the product caused by failure to
observe the instructions of this user manual, untimely maintenance
and service and insufficient care, the use of non-original accessories
and spare parts. Modifications in design of the product relieve the
seller from responsibility for warranty works. The warranty does not
cover cosmetic damage, that doesn’t hinder normal operation of the
product.
4) CONDTROL GmbH reserves the right to decide on replacement or
repair of the device.

user manual
EN
1717
LASER LEVEL
Pento 360 / Quattro 360 G /Pento 360 G
5) Other claims not mentioned above, are not covered by the warranty.
6) After holding warranty works by CONDTROL GmbH warranty period
is not renewed or extended.
7) CONDTROL GmbH is not liable for loss of profit or inconvenience
associated with a defect of the device, rental cost of alternative
equipment for the period of repair.
This warranty applies to German law except provision of the United
Nations Convention on contracts for the international sale of goods
(CISG).
In warranty case please return the product to retail seller or send it
with description of defect to the following address:
CONDTROL GmbH
Im Wiegenfeld 4
85570 Markt Schwaben
Germany

Bedienungsanleitung
KREUZLINIENLASER
DE
1818
Pento 360 / Quattro 360 G / Pento 360 G
SICHERHEITSHINWEISE
Bitte lesen und befolgen Sie für die sichere Verwendung Ihres
Gerätes alle Anweisungen. Warnschilder müssen stets sichtbar
und erkennbar sein. Bewahren Sie diese Bedienungsanleitung auf
und werfen Sie sie nicht weg. Bei nicht fachgerechter Anwendung
können Sie Laserstrahlung ausgesetzt sein.
Sie erhalten Ihr Gerät mit einem Warnschild in Englisch. Bitte
beachten Sie das hier abgebildete Warnschild in Deutsch.
LASERSTRAHLUNG!
Nicht in den Strahl blicken
Laserklasse 2
<1 mW 635/515 nm
EN60825-1: 2007-03
Richten Sie den Laserstrahl niemals auf Personen oder Tiere. Blicken
Sie nicht in den Laserstrahl, auch nicht mit optischen Instrumenten.
Sie gefährden Ihr Augenlicht. Ihr Gerät erzeugt Laserstrahlung
der Klasse 2 gemäß EN60825-1. Die Laserbrille dient nicht als
Schutzbrille, sondern zur besseren Sichtbarkeit des Laserstrahls. Sie
bietet keinen Schutz vor Laserstrahlung. Die Laserbrille kann nicht
als Sonnenbrille verwendet werden. Der Einsatz im Straßenverkehr
ist verboten. Die Laserbrille schützt nicht vor UV-Licht und
verringert die Wahrnehmung von Farbunterschieden. Reparatur
und Wartung dürfen nur durch Fachpersonal mit Qualifikation
erfolgen, das originale Ersatzkomponenten einsetzt. Kinder dürfen
aus Sicherheitsgründen das Gerät nur unter Aufsicht benutzen.
Verwenden Sie das Gerät nicht in der Nähe von brennbaren Stoffen,
da im Gerät Funken entstehen können. Die Halterung des Gerätes
beinhaltet Magnete. Verwenden Sie sie daher nicht in der Nähe von
Herzschrittmachern, da deren Funktion durch Magnetfelder gestört
werden kann. Vermeiden Sie ebenso die Nähe zu magnetischen
Datenträgern oder Geräten, die auf Magnetfelder reagieren. Die
Folge können Datenlöschungen oder –zerstörung sein.

Bedienungsanleitung
DE
1919
KREUZLINIENLASER
Pento 360 / Quattro 360 G /Pento 360 G
BESTIMMUNGSGEMÄßER GEBRAUCH
Der Multiline –Kreuzlinienlaser Xliner Pento 360 / Quattro 360 G /
Pento360 G sollen vertikale und horizontale Ebenen und Linien sowie
den Laserpunkt (zenith und nadir) projizieren. Er ist fuer den Innen-
und Außenbereich geeignet.
Das Geraet hat zwei Betriebsarten:
- Mit Nivellierautomatik der Gehaeuseneigung bis zu ±3,5° zum
Erzeugen waagerechter und senkrechter Laser- Linien und –Ebenen.
- Zum Erzeugen von Laser- Linien und –Ebene mit jeglichen
Neigungen.
Der Pulsiermodus ist dazu bestimmt, die Reichweite mit dem
Handempfaenger zu erweitern oder die Laserstrahlen des Linienlasers
bei ungünstigen Umgebungsbedingungen zu lokalisieren.

Bedienungsanleitung
KREUZLINIENLASER
DE
2020
Pento 360 / Quattro 360 G / Pento 360 G
1 - Austrittsöffnung Laserstrahl
2 - Bedienfeld
3 - Batteriefachdeckel
4 - 1/4’’ Stativaufnahme
5 - 5/8’’ Stativaufnahme
6 - Pendelsperre
7 - Befestigungsmoeglichkeit fuer Nagel oder Schraube
1
1 - Austrittsöffnung Laserstrahl
3
45
6
KREUZLINIENLASER
2
7
