Connect Tech COM Express 6 User manual

1
COM Express Type 6
PMC/XMC Carrier
Users Guide
Connect Tech Inc.
42 Arrow Road
Guelph, Ontario
N1K 1S6
Tel: [phone]
Toll: 800-426-8979 (North America only)
Fax: [phone]
Email: [e-mail]
[email protected]
Web: www.connecttech.com
CTIM-00115 Revision: 0.03, July 12, 2017

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
2
Table of Contents
Customer Support Overview .......................................................................................................................... 4
Contact Information........................................................................................................................................ 4
Limited Product Warranty.............................................................................................................................. 5
Copyright Notice ............................................................................................................................................ 5
Trademark Acknowledgment ......................................................................................................................... 5
Revision History............................................................................................................................................. 5
Introduction .................................................................................................................................................... 6
ESD Warning............................................................................................................................................................ 6
Product Features and Specifications............................................................................................................... 7
Block Diagram ............................................................................................................................................... 8
Connector Locations....................................................................................................................................... 9
Connector Summary......................................................................................................................................10
Jumper Summary...........................................................................................................................................11
Detailed Feature Pinouts and Functional Descriptions..................................................................................12
COM Express Module Connector........................................................................................................................... 12
CPU Fan Connector................................................................................................................................................ 12
Input Power............................................................................................................................................................. 13
Input Power Diagram.......................................................................................................................................13
Active Input Power Protection Details.............................................................................................................14
Input Power Connector Details........................................................................................................................14
Video Outputs......................................................................................................................................................... 15
HDMI and Display Port ...................................................................................................................................15
DVI ..................................................................................................................................................................16
LVDS Video ....................................................................................................................................................17
Description....................................................................................................................................................17
LVDS Video Header.....................................................................................................................................17
LVDS Backlight Power Connector...............................................................................................................18
LVDS Backlight Power Jumper....................................................................................................................18
LVDS Panel LEDADJ Selection Jumper......................................................................................................19
VGA.................................................................................................................................................................19
VGA Pinouts.................................................................................................................................................19
USB 3.0................................................................................................................................................................... 20
Connector......................................................................................................................................................20
10/100/1000 Ethernet.............................................................................................................................................. 21
10/100/1000 Ethernet RJ Connector.............................................................................................................21
Software Support for the Intel 82574...............................................................................................................21
USB 2.0................................................................................................................................................................... 22
USB 2.0 External Connectors.......................................................................................................................22
USB 2.0 Internal Connector..........................................................................................................................22
Audio Interface ....................................................................................................................................................... 23
Audio Connectors ............................................................................................................................................23
Software Support for the CS4207 ....................................................................................................................23
External SATA Ports .............................................................................................................................................. 24
SATA HDD Connectors ...............................................................................................................................24
SATA HDD Power Connectors ....................................................................................................................24

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
3
miniPCIe & mSATA Slots...................................................................................................................................... 25
Dual Function miniPCIe mSATA Slots...........................................................................................................25
Half and Full Length mini PCIe / mSATA module Installation.......................................................................26
miniPCIe / mSata Connector Pinout ................................................................................................................27
8 x Asynchronous Serial Ports................................................................................................................................ 28
Software Support for the Exar 17V358............................................................................................................28
Serial Connectors RS-232/RS-485 Pinout........................................................................................................28
Pinout Mapping on PCB 0.1” Headers.............................................................................................................29
8 x Serial Port Jumper Configuration...............................................................................................................29
8 x Serial Port Cabling Details.........................................................................................................................30
PMC / XMC Expansion Slots................................................................................................................................. 31
GPIO and Console Serial Port................................................................................................................................. 32
Connector......................................................................................................................................................32
SD Card .................................................................................................................................................................. 33
Micro SD Card Connector ............................................................................................................................33
System Control Header........................................................................................................................................... 34
Typical Hardware Installation Procedure......................................................................................................35
On-Board “ATX” Power Supply ...................................................................................................................36
Current Consumption Details........................................................................................................................37
PCI Express Allocation Details.....................................................................................................................38
USB Allocation Details.................................................................................................................................38
Mechanical Details........................................................................................................................................39
Enclosure Details...........................................................................................................................................40
Cables & Interconnect...................................................................................................................................41

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
4
Customer Support Overview
If you experience difficulties after reading the manual and/or using the product, contact the
Connect Tech reseller from which you purchased the product. In most cases the reseller can help
you with product installation and difficulties.
In the event that the reseller is unable to resolve your problem, our highly qualified support staff
can assist you. Our support section is available 24 hours a day, 7 days a week on our website at:
www.connecttech.com/sub/support/support.asp. See the contact information section below for
more information on how to contact us directly. Our technical support is always free.
Contact Information
Mail/Courier
Connect Tech Inc.
Technical Support
42 Arrow Road
Guelph, Ontario
Canada N1K 1S6
Email/Internet
[email protected]m
[email protected]m
www.connecttech.com
Note:
Please go to the Download Zone or the Knowledge Database in the Support Center on the Connect
Tech website for product manuals, installation guides, device driver software and technical tips.
Submit your technical support questions to our customer support engineers via the Support Center
on the Connect Tech website.
Telephone/Facsimile
Technical Support representatives are ready to answer your call Monday through Friday, from
8:30 a.m. to 5:00 p.m. Eastern Standard Time. Our numbers for calls are:
Toll Free: 800-426-8979 (North America only)
Telephone: [phone] (Live assistance available 8:30 a.m. to 5:00 p.m. EST,
Monday to Friday)
Facsimile: 519-836-4878 (on-line 24 hours)

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
5
Limited Product Warranty
Connect Tech Inc. provides a two-year Warranty for the COM Express Type 6 PMC/XMC Carrier
Board. Should this product, in Connect Tech Inc.'s opinion, fail to be in good working order
during the warranty period, Connect Tech Inc. will, at its option, repair or replace this product at
no charge, provided that the product has not been subjected to abuse, misuse, accident, disaster or
non-Connect Tech Inc. authorized modification or repair.
You may obtain warranty service by delivering this product to an authorized Connect Tech Inc.
business partner or to Connect Tech Inc. along with proof of purchase. Product returned to
Connect Tech Inc. must be pre-authorized by Connect Tech Inc. with an RMA (Return Material
Authorization) number marked on the outside of the package and sent prepaid, insured and
packaged for safe shipment. Connect Tech Inc. will return this product by prepaid ground
shipment service.
The Connect Tech Inc. Limited Warranty is only valid over the serviceable life of the product.
This is defined as the period during which all components are available. Should the product prove
to be irreparable, Connect Tech Inc. reserves the right to substitute an equivalent product if
available or to retract the Warranty if no replacement is available.
The above warranty is the only warranty authorized by Connect Tech Inc. Under no
circumstances will Connect Tech Inc. be liable in any way for any damages, including any lost
profits, lost savings or other incidental or consequential damages arising out of the use of, or
inability to use, such product.
Copyright Notice
The information contained in this document is subject to change without notice. Connect Tech
Inc. shall not be liable for errors contained herein or for incidental consequential damages in
connection with the furnishing, performance, or use of this material. This document contains
proprietary information that is protected by copyright. All rights are reserved. No part of this
document may be photocopied, reproduced, or translated to another language without the prior
written consent of Connect Tech, Inc.
Copyright

2016 by Connect Tech, Inc.
Trademark Acknowledgment
Connect Tech, Inc. acknowledges all trademarks, registered trademarks and/or copyrights referred
to in this document as the property of their respective owners.
Not listing all possible trademarks or copyright acknowledgments does not constitute a lack of
acknowledgment to the rightful owners of the trademarks and copyrights mentioned in this
document.
Revision History
Revision
Date
Changes
0.00
04/02/2013
Original
0.01
04/30/2013
Added Scew / Standoff Assembly Drawing
0.02
06/07/2016
Revised Warranty Policy
0.03
07/12/2017
Added cable drawing links

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
6
Introduction
Connect Tech’s COM Express Carrier Boards are small feature rich, super flexible carrier boards
that integrate with any industry standard Type 6 COM Express module. These bus-independent
carrier boards offer easy connection to SATA HDD, USB 2 and USB 3, Audio, Dual Ethernet,
HDMI , Display Port Video, LVDS Video, VGA video, RS232 and RS485 serial.
Connect Tech’s COM Express carrier boards are ideal for compact and high performance
computing applications in mobile entertainment, kiosks, digital signage, automation, ROVs and
gaming applications.
ESD Warning
Electronic components and circuits are sensitive to
ElectroStatic Discharge (ESD). When handling any circuit
board assemblies including Connect Tech COM Express
carrier assemblies, it is recommended that ESD safety
precautions be observed. ESD safe best practices include,
but are not limited to:
Leaving circuit boards in their antistatic packaging
until they are ready to be installed.
Using a grounded wrist strap when handling circuit
boards, at a minimum you should touch a grounded
metal object to dissipate any static charge that may
be present on you.
Only handling circuit boards in ESD safe areas,
which may include ESD floor and table mats, wrist
strap stations and ESD safe lab coats.
Avoiding handling circuit boards in carpeted areas.
Try to handle the board by the edges, avoiding
contact with components.

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
7
Product Features and Specifications
Feature
Part Number: CCG007
PCB Size / Overall Size
15.000” x 7.500”
Maximum Top Side Component Height: 1.259”
3D STEP Model: download here
Gigabit Ethernet
2
LVDS Video &
Backlight power
Y
HDMI Video
Y
DisplayPort Video
Y
DVI Video
Y
VGA
Y
3.5mm Audio Connector
1 Stereo Input / 1 Stereo Output
PMC / XMC Slots
2
Dual mode mSATA/MiniPCIe
2
MiniPCIe Only Slots
2
SIM Card Slots
4
USB 3.0 Ports
4
USB 2.0 Ports
6
SATA HDD connector
2
SATA HDD power connector
2
GPIO or Micro SD
Y [1]
Power Connector
4 Position screw terminal
Standard Serial
8 x RS-232/485 [1]
Console Serial Port
1x RS232 basic port [1]
CMOS / RTC 3.3V Battery
Y
Accessories
Optional Cable Kit ( SATA HDD/Power Cable, VGA, Serial)
Operating Temperature
-40 to +85 Celsius
Power Input
Wide Input (+6V to +36V)
Warranty and Support
Limited two-year warranty and free technical support
[1] Jumper Selectable.

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
8
Block Diagram
DVI
DisplayPort
10/100/1000
Ethernet Port-0
10/100/1000
Ethernet Port-1
USB 3.0 Port-0
USB 3.0 Port-1
USB 3.0 Port-2
USB 3.0 Port-3
+9V to +36V Input
Audio
Input / Output
8 x RS-422/485
RS-232
Console Port
COMExpress
Type-6
mSATA / mini PCIe
Slot-0
GBE Controller
Intel 82574L
HD Audio Codec
Cirrus Logic CS4207
PCIe UART
Exar 17V354
On-Board
ATX Compliant PSU
HDMI
USB 2.0 Port-0
USB 2.0 Port-1
USB 2.0 Port-2
USB 2.0 Port-3
VGA
LVDS
USB 2.0 Port-4
USB 2.0 Port-5
mSATA / mini PCIe
Slot-0
mini PCIe
Slot-2
mini PCIe
Slot-3
SIM Card
Socket
SIM Card
Socket
SIM Card
Socket
SIM Card
Socket
PCIe x1
PLX 8112
PCIe-to-PCI Bridge
PMC / XMC
Slot-0
PMC / XMC
Slot-1
PCIe x8
PCIe x8
PCIe x1 PCI
PCIe x1
SATA
USB2.0
PCIe x1
SATA
USB2.0
PCIe x1
USB2.0
PCIe x1
USB2.0
PCIe x1
PCIe x1
SATA 0
SATA 1
DIL Header
SD Card
SDIO
GPIO
GPIO
DDI-1
DDI-2
DDI-3

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
9
Connector Locations
Top View
Front View

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
10
Connector Summary
Designator
Connector
Description
J11A, J12A
PMC
PMC Slot-0 Connector
J11B, J12B
PMC
PMC Slot-1 Connector
J15A
XMC
XMC Slot-0 Connector
J15B
XMC
XMC Slot-1 Connector
P1
440-pin Board Stacking Connector
COM Express Type-6 Connector
P2A
SATA Vertical Locking
SATA Channel 2
P2B
SATA Vertical Locking
SATA Channel 3
P3A
4-pin 0.1" keyed header
SATA Power Channel 2
P3B
4-pin 0.1" keyed header
SATA Power Channel 3
P4
DVI D-Sub
DVI Video
P5
2 x 3.5mm Phono Jack
Audio Input/Output
P6
20-pin 1mm pitch Hirose DF19G
LVDS Video Connector
P7
2-pin JST SM02B
LVDS Backlight Power Connector
P8
3-pin 0.1" keyed header
Case Fan-1 (+12V)
P9A
SIM Card Socket
miniPCIe Slot-2 SIM Card Socket
P9B
SIM Card Socket
miniPCIe Slot-3 SIM Card Socket
P10A
SIM Card Socket
miniPCIe Slot-0 SIM Card Socket
P10B
SIM Card Socket
miniPCIe Slot-1 SIM Card Socket
P11
2 x 20-pin 0.1" header
RS-232/485 - PORTS 1-4
P12
2 x 20-pin 0.1" header
RS-232/485 - PORTS 5-8
P13
2 x 5-pin 2mm header
VGA Video Connector
P14
2 x 10-pin 2mm header
GPIO / RS-232 Console Connector
P16
4-pin 5mm Pitch Terminal Block
Input Power Connector
P17
2032 Coin Batter Socket
RTC Battery Socket
P18
3-pin 0.1" keyed header
CPU Fan Connector (+12V)
P20
2 x 5-pin 0.1" header
Internal USB 2.0 Ports 6 & 7
P21A
USB / RJ45
USB3.0 Ports 0&1 and GBE 0
P21B
USB / RJ45
USB3.0 Ports 2&3 and GBE 1
P22
DP / HDMI
Display Port and HDMI
P23A
USB
USB 2.0 Ports
P23B
USB
USB 2.0 Ports
P24
3-pin 0.1" keyed header
Case Fan-2 (+12V)
U11A
miniPCIe
miniPCIe-2 Connector
U11B
miniPCIe
miniPCIe-3 Connector
U13A
miniPCIe
miniPCIe-0 / mSATA-0 Connector
U13B
miniPCIe
miniPCIe-1 / mSATA-1 Connector

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
11
Jumper Summary
Designator
Jumper
Description
J1A
7-position 2mm Jumper Block
RS-232/RS-485 Port 1 Settings
J1B
7-position 2mm Jumper Block
RS-232/RS-485 Port 2 Settings
J1C
7-position 2mm Jumper Block
RS-232/RS-485 Port 3 Settings
J1D
7-position 2mm Jumper Block
RS-232/RS-485 Port 4 Settings
J1E
7-position 2mm Jumper Block
RS-232/RS-485 Port 5 Settings
J1F
7-position 2mm Jumper Block
RS-232/RS-485 Port 6 Settings
J1G
7-position 2mm Jumper Block
RS-232/RS-485 Port 7 Settings
J1H
7-position 2mm Jumper Block
RS-232/RS-485 Port 8 Settings
J3
2 x 2 2mm Jumper Block
LVDS Backlight Power Enable
J4
1 x 3 2mm Jumper Block
LVDS Backlight Control Enable
J6A
2mm Jumper
miniPCIe / mSATA Slot-0 Selection
J6B
2mm Jumper
miniPCIe / mSATA Slot-1 Selection
J7
2mm Jumper
PCIe UART EEPROM Enable
J8
2mm Jumper
PCIe UART Line Tri-State Control
J9
2mm Jumper
SD / GPIO Selection
J10
2mm Jumper
SD Card Write Enable
J13
2mm Jumper
S3 State Shutdown Enable
J14
1 x 3 2mm Jumper Block
Power Good Selection
J16
2mm Jumper
Internal USB2.0 Port 7 Power Enable
J17
2mm Jumper
Internal USB2.0 Port 6 Power Enable

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
12
Detailed Feature Pinouts and Functional Descriptions
COM Express Module Connector
The processor and chipset are implemented on the COM Express Type 6 CPU module, which connects to
the COM Express carrier via a Tyco fine pitch stacking connector.
Function
COM Express interface
Location
P1
Type
Tyco fine pitch stacking connector
Part Number: 3-5353652-6
8mm stack height.
Pinout
Refer to COM Express R2.0
specification, Type-6.
CPU Fan Connector
Function
Fan Power
Location
P18
Type
Molex: 22-23-2031
Pinout
Pin
Signal
1
Fan Tach
2
+V
3
GND

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
13
Input Power
The COM Express Type-6 PMC/XMC Carrier is designed to be powered from any DC input power source
in the rage of +6V to +36V DC, which is ideal for many vehicle or rugged applications, but also many
industrial power solutions as well.
Input Power Diagram
Below is diagram of the flow of the input power on the COM Express Type-6 PMC/XMC Carrier. The
input power goes through various protection, safety and filtering components before connecting to the main
on board regulators.

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
14
Active Input Power Protection Details
A benefit to using the COM Express Type-6 PMC/XMC Carrier is that it protects loads from high voltage
input transients. It regulates the output during an overvoltage event, such as load dump in vehicles, by
controlling the gate of an external N-channel MOSFET. The output is limited to a safe value allowing the
loads to continue functioning.
The COM Express Type-6 PMC/XMC Carrier also monitors the voltage drop to protect against overcurrent
faults. In either fault condition, a timer is started inversely proportional to MOSFET stress. If a fault
condition persists, the supply is turned off.
Two precision comparators monitor the input supply for overvoltage (OV) and undervoltage (UV)
conditions. When the potential is below the UV threshold, the external MOSFET is kept off. If the input
supply voltage is above the OV threshold, the MOSFET is not allowed to turn back on. Back-to-back
MOSFETs are used for reverse input protection, reducing voltage drop and power loss.
Input Power Connector Details
Function
Main Input Power
Location
P5
Range
+6 VDC to +36 VDC
Type
4 Position 5mm pitch terminal connector
Mating Connector PN: 20020003-G041B01LF
Pinout
Pin
Signal
Description
1
+VIN
Power In
2
+VIN
Power In
3
GND
Ground / Return
4
GND
Ground / Return

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
15
Video Outputs
The COM Express Type-6 PMC/XMC Carrier features up to 5 video outputs, VGA, HDMI, DisplayPort,
DVI and LVDS. The availability of the graphics interfaces depends on your Type 6 COM Express module.
The configuration of either interface as the primary or secondary or tertiary display depends on the COM
Express module’s BIOS capabilities and settings. Refer to the COM Express module’s documentation for
more details.
HDMI and Display Port
Function
HDMI and Display Port
Location
P3
Type
DisplayPort
Standard 4-lane connection
HDMI
Standard 3 pairs of TMDS Data, and 1 clock
pair

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
16
DVI
The DVI output on the carrier provides a Single-Link DVI connection. Where four pairs are connected
back to the host COM Express module, Three of the pairs correspond to the RGB components of the video
signal: red, green, blue (for a total of 24 bits per pixel.) The fourth link carries the pixel clock.
No dual-link signals are routed to this DVI Connector.
No analog signals are routed to this DVI Connector.
Function
HDMI and Display Port
Location
P3
Type
Pin
Signal
1
TMDS Data Channel 2-
2
TMDS Data Channel 2+
3
Shield for TMDS Data 2/4
4
NC
5
NC
6
DDC Clock
7
DDC Data
8
NC
9
TMDS Data Channel 1-
10
TMDS Data Channel 1+
11
Shield for TMDS Data 1/3
12
NC
13
NC
14
Power (+5V)
15
Ground
16
Hot Plug Detect
17
TMDS Data Channel 0-
18
TMDS Data Channel 0+
19
Shield for TMDS Data 0/5
20
NC
21
NC
22
TMDS Clock Shield
23
TMDS Clock+
24
TMDS Clock-
C1
NC
C2
NC
C3
NC
C4
NC

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
17
LVDS Video
Description
The COM Express carrier provides dual 18 or 24 bit LVDS display channels via P4, which are connected
directly from the COM Express module. LVDS panel supply power is selected with jumper J1 and
backlight power is selected with jumper J2. Both are current limited to 500 mA with Raychem resettable
ploy fuses.
LVDS Video Header
Function
LVDS Graphics
Location
P13
Type
Hirose DF19G-20P-1H(54) connector
Pinout
Pin
Signal
Description
1
+3.3 VCC_PNL
Panel Power
2
+3.3 VCC_PNL
Panel Power
3
GND
Digital ground
4
GND
Digital ground
5
LVDS_A0_N
Channel A Data
6
LVDS_A0_P
Channel A Data
7
GND
Digital ground
8
LVDS_A1_N
Channel A Data
9
LVDS_A1_P
Channel A Data
10
GND
Digital ground
11
LVDS_A2_N
Channel A Data
12
LVDS_A2_P
Channel A Data
13
GND
Digital ground
14
LVDS_CLK_N
Channel A Data
15
LVDS_CLK_P
Channel A Data
16
GND
Digital ground
17
+5 VCC_PNL
Backlight Power
18
+5 VCC_PNL
Backlight Power
19
GND
Digital ground
20
BKLT Control / GND
LED ADJ

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
18
LVDS Backlight Power Connector
Function
LVDS backlight Inverter power
Designed to power HDA700LPT-GHL (or
similar screen type) which has 13 parallel
strings of 3 series white LEDS. Each white
LED has a Vf of around 3.3V.
Location
P7
Type
JST SM02B-BHSS-1-TB(LF)(SN) connector
Pinout
Pin
Signal
1
VA LED
2
VK LED
LVDS Backlight Power Jumper
Function
LVDS backlight power select
You can optionally connect +5V to pins 17 &
18 of the LVDS Video connector. Some
LVDS displays require this for backlight
powering, others require external backlight
power to be sourced from P7.
Location
J3
Type
2x2 2mm jumper block
Pinout
Position
Description
J3A / J3B
+5V BKL
Default
off

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
19
LVDS Panel LEDADJ Selection Jumper
Function
LVDS panel power select
Location
J4
Type
1x3 0.100” jumper block
Pinout
Position
Description
J4A
Disable / (or off)
J4B
Enable Control
Default
Off or position A
VGA
The carrier boards brings the VGA video output to a 2x5 2mm header. This header can be mated to
Connect Tech’s CBG070 cable which then terminates to a standard DB-15 VGA connector which is panel
mountable.
VGA Pinouts
Function
Standard VGA
Location
P11
Type
2x5 2mm pitch header
Pinout
Pin
Description
1
Red
2
GND
3
Green
4
NC
5
Blue
6
SC DDC
7
HSYNC
8
SD DDC
9
VSYNC
10
GND
Optional
Cable
CBG070

Connect Tech - COM Express Type-6 PMC/XMC Carrier Board - User Manual
Revision 0.03
20
USB 3.0
The COM Express carrier implements four USB 3.0 connections via two USB connectors. Over current
protection, power supply filtering and ESD protection is provided.
Each USB 3.0 port is capable of bitrates of up to 5Gbps, as well as accepting USB2.0 and below
connections.
Connector
Function
USB 3.0
Locations
P21A, P21B
Type
Standard Dual USB 3.0 jacks
Pinout
Pin
Description
1
VBUS
2
D−
3
D+
4
GND
5
SSRX−
6
SSRX+
7
GND
8
SSTX−
9
SSTX+
