INTRODUCTION
Connect Tech’s Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i brings a low-cost deployable Jetson™
TX2/TX2i Solution to the market. Designed to match the NVIDIA® Jetson™ TX2 or TX2i module form
factor, the Orbitty’s design includes Gigabit Ethernet, HDMI Video, USB 3.0, USB 2.0 (w/ OTG
functionality), 2 x UART ports and 4-bits of GPIO.
Product Features and Specifications
Specifications
Module Compatibility
NVIDIA Jetson TX2 or TX2i
Datasheet Downloads: Module Datasheet - SoC Datasheet
Mechanical Dimensions
X/Y Footprint: 87mm x 50mm
-Tallest Component Height: 13.42mm (From Top PCB Surface of
Orbitty)
-Total Stack Height: 30.18mm (Orbitty + TX2/TX2i/TX1 Module +
TX2/TX1 Flat Heatplate)
3D STEP Model: Download Here
Video Output
1x HDMI 2.0 (Supports up to HDMI 2.0 UHD 4K [2160p] at 60Hz)
Ethernet
1x Gigabit Ethernet
10/100/1000 BASE-T
USB
1x USB 3.0 (5Gbps, 1A Maximum Current Sourcing)
1x USB 2.0 (w/ OTG functionality)
Audio Output
HDMI Integrated
UART
2x 3.3V UART Ports
TX/RX lines only
GPIO
4-bits GPIO
-3.3V CMOS Level
-Configurable as inputs or outputs
SD Card
1x microSD Card Slot
-4-bit Data
-Support for SD 4.0 Specification without UHS-II
Video Inputs
Video Inputs can be accessed through any of the of the following interfaces:
-USB 3.0 / 2.0
-Gigabit Ethernet
I2C
1x I2C (Master Controller)
-Pullup Level: 1k ohm
-Operation Speeds: 100kbit/s, 400kbit/s, 1Mbit/s, 3.4Mbit/s
Misc Interfaces
User Power Output Pins: +3.3V and +5V
Fan Connection: 4-pin, +5V, PWM Capability
On-board and External Button Interfaces: Reset, Power, Recovery

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 8 of 31 Date: 2021-10-05
External RTC Battery Connection
Power Requirements
Input Voltage Range: +9V to +14V DC
TX2i Module Consumption: 20W; TX2 Module Consumption: 6.5W to 15W
(dependent on CPU/GPU utilization)
Orbitty Carrier Consumption: 2W to 6W (dependent on draw of peripheral
ports)
Temperature
TX2 Module Operating Temperature Range: -25C to +80C
TX2 SoC Junction Temperature Range: -25C to +105C
TX2i Module & Orbitty Carrier Operating Temperature Range: -40C to +85C
Weight
41g
Warranty and Support
1 Year Warranty and Free Support
Part Numbers / Ordering Information
Part Number
ASG003
Orbitty Carrier for NVIDIA® Jetson™ TX2 & TX2i
ENC001
OrbittyBox - Enclosure

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 9 of 31 Date: 2021-10-05
PRODUCT OVERVIEW
Block Diagram
Connector Locations (Top Side)
FAN / SYS PWR
SWITCH (S1)
POWER
BUTTON (SW1)
RESET
BUTTON (SW3)
RECOVERY
BUTTON (SW2)
POWER
INPUT (P9)
MICRO SD (P6)
SYS LED
PWR LED
Gigabit Ethernet (P6)
USB 3.0 (P7)
USB OTG (P8)
HDMI
(P2)
EXPANSION IO
HEADER (P4)

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 10 of 31 Date: 2021-10-05
Connector Summary
Designator
Connector
Description
P1
TX2/TX2i Module Connector
NVIDIA Jetson TX2/TX2i/TX1 Module Board-to-Board
Connector
P2
HDMI
HDMI 2.0 Maximum: 6Gbps, 24bpp, 4096x2160@60Hz
P4
Expansion IO Header
Expansion IO Header Interfacing to all Misc IO
P5
Gigabit Ethernet
Gigabit Ethernet 10/100/1000 BASE-T Connection
P6
Micro SD Card Slot
Micro SD Card Slot (4-bit Data, Support for SD 4.0)
P7
USB 3.0
USB 3.0 Type-A Host Connection
P8
USB OTG
USB OTG (Host Mode and Client Mode capable)
P9
Power Input
DC Power Input (+9V to +14V)
Switch Summary & Locations
Designator
Function
Description
S1
Fan / Power Control
Power Start-up Control, FAN PWM / Always ON Control
SW1
Power Button
Power Button, Press to Power ON or OFF
SW2
Reset Button
Reset Button, Press to initiate Reset Sequence
SW3
Recovery
Use to initiate a recovery mode, and flash new image via USB OTG

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 11 of 31 Date: 2021-10-05
DETAILED FEATURE DESCRIPTION
Jetson™ TX2/TX2i Board-to-Board Connector
With the NVIDIA Jetson™ TX2 or TX2i, the processor and chipset are implemented on the Jetson™
TX2/TX2i Module. This connects to the Orbitty Carrier via a Samtec SEARAY™ Board to Board Connector.
Function
NVIDIA Jetson™ TX2/TX2i Interface
Location
P1
Type
Samtec SEARAY™ Connector
Carrier
Connector
Part Number: SEAM-50-03.0-S-08-2-A-K-
TR (8.0mm stacking height)
Manufacturer: Samtec
Mating
Connector
Part Number: SEAF-50-05-S-08-02-A-K
(Installed on Jetson™ TX2/TX2i)
Manufacturer: Samtec
Pinout
Refer to NVIDIA’s Jetson™ TX2/TX2i
System-on-Module datasheet for pinout
details
Board-to-Board
Standoff Height
8.0mm height M3 Standoffs Required
between NVIDIA Jetson TX2/TX2i Module
and Orbitty (ASG003) Carrier
System Expansion IO Connector
The System Expansion header has numerous interfaces to connect external peripherals and IO. As well
as the ability to provide external connection to the Recovery, Reset and Power Buttons. The System
Expansion IO Connector also has 2 voltage output pins to allow powering of external devices.
Function
System Connector
Location
P4
Type
0.1” / 2.54mm Pitch IDC Header (DIL)
Carrier
Connector
Part Number: TSW-110-07-L-D
Manufacturer: Samtec
Mating
Connector
Any IDC / DIC 0.1” Cable, Socket or Jumper Wire
Assemblies
Pinout
Pin
Description
Pin
Description
1
+3.3V OUTPUT
2
+5V OUTPUT
3
UART0 TX
4
UART0 RX
5
UART1 TX
6
UART1 RX

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 12 of 31 Date: 2021-10-05
7
GPIO-0
8
GPIO-1
9
GPIO-2
10
GPIO-3
11
I2C CLK
12
I2C SDA
13
RECOVERY
14
RTC BAT INPUT
15
RESET
16
GND
17
POWER BUTTON
18
GND
19
GND
20
GND
System Expansion IO Connector – Detailed Signal Descriptions
Signal Name Description Type
Pin
Number(s)
+3.3V OUTPUT
+3.3V Power Output Pin
-Max output should be limited to 1A
-Please note there is no external fuse.
Output 1
+5V OUTPUT
+5V Power Output Pin
-Max output should be limited to 1A
-Please note there is no external fuse.
Output 2
UART0 TX
UART 0 Transmit Pin
-This signal is the UART port 0 output from
the TX2/TX2i/TX1 Module
-This is level shifted on the Orbitty carrier
to support 3.3V logic.
-Under L4T this port will show up as
/dev/ttyS0
Output
3.3V CMOS 3
UART0 RX
UART 0 Receive Pin
-This signal is the UART channel 0 input on
Input
3.3V CMOS
4

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 13 of 31 Date: 2021-10-05
TX2/TX2i/TX1 Module
-This is level shifted on the Orbitty carrier
to support 3.3V logic.
-Under L4T this port will show up as
/dev/ttyS0
UART1 TX
UART 1 Transmit Pin
-This signal is the UART channel 1 output
from the TX2/TX2i/TX1 Module
-This is level shifted on the Orbitty carrier
to support 3.3V logic.
-Under L4T this port will show up as
/dev/ttyTHS2
Output
3.3V CMOS 5
UART1 RX
UART 1 Receive Pin
-This signal is the UART channel 1 input on
TX2/TX2i/TX1 Module
-This is level shifted on the Orbitty carrier
to support 3.3V logic.
-Under L4T this port will show up as
/dev/ttyTHS2
Input
3.3V CMOS 6
GPIO-[0:3]
GPIO Bits 0 to 3
-This signal is the GPIO Bit 0 and can be
configured as an Input or an Output
-This is level shifted on the Orbitty carrier
to support 3.3V logic.
Please reference our GPIO KDB for TX2/TX2i/TX1
values.
Input/Output
Configurable
3.3V CMOS
7,8,9,10
I2C CLK
I2C Clock Signal
-This is clock signal on the I2C bus
-This signal has a pull up on the
TX2/TX2i/TX1 module to +3.3V
-Under L4T this is I2C bus # 1
Output
+3.3V
Open Drain
11
I2C SDA
I2C Data Signal
-This is data signal on the I2C bus
-This signal has a pull up on the
TX2/TX2i/TX1 module to +3.3V
-Under L4T this is I2C bus # 1
Bidirectional
+3.3V
Open Drain
12
RECOVERY
System Recovery Pin
-Shorting this signal to Ground will
initialize a system recovery procedure
Input 13
RTC BAT INPUT
RTC Battery Input
-Use this pin to connect a backup battery
source (Coin Cell or other) to sustain the
RTC clock on the TX2/TX2i/TX1 module.
-The voltage should be provided from a 3V
source
Input 14
RESET
External Reset Button Source
Input
15

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 14 of 31 Date: 2021-10-05
-Pulse / Short this signal to GND to initiate
a reset sequence
POWER BUTTON
External Power Button Source
-Pulse / Short this signal to GND to initiate
a power sequence
Input 17
GND
Ground / Reference Connection
-This pin is connected to the Orbitty
Carrier’s main digital ground connection
-Use this pin as a reference/return for any
externally connected peripherals to the
Expansion IO Connector
Reference 16,18,19,20
HDMI Connector
Function
HDMI Connector
Location
P2
Type
HDMI Type-A Connector (Female)
Carrier
Connector
Part Number: A35071TR-ND
Manufacturer: TE Connectivity
Mating
Connector
Any HDMI Type-A Cable Assembly
Pinout
Pin
Description
Pin
Description
1
TMDS Data2+
2
TMDS Data2 GND
3
TMDS Data2-
4
TMDS Data1+
5
TMDS Data1 GND
6
TMDS Data1-
7
TMDS Data0+
8
TMDS Data0 GND
9
TMDS Data0-
10
TMDS Clock+
11
TMDS Clock GND
12
TMDS Clock-
13
CEC
14
No Connect
15
DDC clock
16
DDC data
17
DDC GND
18
+5V Power
19
Hot Plug Detect

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 15 of 31 Date: 2021-10-05
NVIDIA Jetson TX2/TX2i Fan
Function
NVIDIA Jetson TX2/TX2i Fan Control
Location
P4
Type
Molex PicoBlade Header
P/N
Part Number: 53261-0471
Manufacturer: Molex
Mating
Part Number: 51021-0400
Manufacturer: Molex
Pinout
Pin
Description
1
GND
2
+5V
3
TACH
4
PWM
NOTE: Please note that Fan PWM (speed control) is NOT natively supported by the stock L4T builds.
If users wish to use the native builds you must enable the S1 DIP Switch to put the Fan into the Always
ON mode.
To enable PWM functionality (speed control) users must deploy CTI-L4T BSP and enable the S1 DIP
Switch to put the Fan into the PWM Enabled mode.
10/100/1000 Ethernet (GBE)
Function
Gigabit Ethernet Connector
Location
P5
Type
RJ-45 8p8c
Carrier
Connector
Part Number: 1RJMG14-220LNL
Manufacturer: Unicom
Mating
Connector
Any RJ-45 Plug with Cat5, Cat5e, Cat6 Type Cabling
Pinout
Pin
Description
Pin
Description
1
TP0+
2
TP0-
3
TP1+
4
TP2+
5
TP2-
6
TP1-
7
TP3+
8
TP3-

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 16 of 31 Date: 2021-10-05
microSD Card Slot
Function
microSD Card Slot
Location
P7
Type
Molex microSD Memory Card Connector
Carrier
Connector
502570-0893
Pinout
Pin
Description
Pin
Description
1
SDIO_DATA2
2
SDIO_DATA3
3
SDIO_CMD
4
SDIO_VCC
5
SDIO_CLK
6
GND
7
SDIO_DATA0
8
SDIO_DATA1
9
GND
10
SDIO_CD
USB 3.0
The Orbitty Carrier provides one external USB 3.0 Port with an integrated USB 2.0 Port. The USB 3.0
signals are sourced directly from the Jetson TX2/TX2i Module. Over current protection, power supply
filtering and ESD protection is provided on-board. The current limit on this port is set to 1A, if more
current capacity is required, please contact [e-mail].
NOTE: Please note that USB3.0 support is NOT natively supported by the stock L4T builds. For USB3.0
support users must deploy CTI-L4T BSP
Function
USB 3.0
Location
P7
Type
USB 3.0 Type-A
Carrier
Connector
Part Number: 1932258-1
Manufacturer: TE Connectivity
Mating
Connector
Any USB 3.0 Type-A Cable
Pinout
Pin
Description
Pin
Description
1
VBUS
2
USB 2.0 D-
3
USB 2.0 D+
4
GND
5
SSRX-
6
SSRX+
7
GND
8
SSTX-
9
SSTX+

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 17 of 31 Date: 2021-10-05
USB OTG
Function
USB OTG
Location
P8
Type
USB 2.0 Micro-AB
Carrier
Connector
Part Number: 47589-0001
Manufacturer: Molex
Mating
Connector
Any USB 2.0 Micro A or Micro B or Cable
Pinout
Pin
Description
Pin
Description
1
VBUS
2
USB 2.0 D-
3
USB 2.0 D+
4
USB ID
5
GND
USB OTG – Host Mode
To put the USB OTG port into HOST mode, the USB ID pin needs to be left floating. Most USB Micro-A to
Type-A (Female) cables will do this internally.
USB OTG – Client Mode (Used for Image Flashing)
To put the USB OTG port into CLIENT mode, the USB ID pin needs to be tied to GND. Most USB Micro-B
cables will do this internally. Once in Client mode this port can then be connected to a Host PC. This is
required for software image flashing. Please see the Software Section of this manual for more details.

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 18 of 31 Date: 2021-10-05
Input Power
The Orbitty Carrier accepts a single power input to power all on-board devices.
A power input range of +9V to +14Vis recommended.
Function
Input Power
Location
P9
Type
3.5mm Pitch Wire-to-Board Screw
Terminal
P/N
Texas Instruments 1546551-2
Mating
Stripped and Tinned 8-22 AWG Wire
Cable
MSG064, MSG072
Pinout
Pin
Description
1
+VIN
2
GND
Input Power - Wiring
The positive wire should be connected to the +VIN terminal, and the negative wire should be connected
to the GND terminal.

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 19 of 31 Date: 2021-10-05
SWITCH DETAILS
DIP Switch Details (S1)
The Orbitty Carrier has a 2 position DIP switch block which controls the PWM Fan Control and the main
Power-up / Start-up Control.
Position No. Position Description Switch ON Switch OFF
1PWM Fan Control FAN PWM Enabled (SW Controlled) FAN Always ON
2Power-Up / Start-up Control "AT Mode" - Automatic Start-up Enabled "ATX Mode" - Power Button Press Required
S1 Usage Examples

Orbitty Carrier for NVIDIA® Jetson™ TX2/TX2i
Users Guide
www.connecttech.com
Document: CTIM-00471
Revision: 0.14
Page 20 of 31 Date: 2021-10-05
Push Button Details (SW1, SW2, SW3)
The Orbitty Carrier has a 3 tactile push buttons - Power (SW1), RESET (SW3) and RECOVERY (SW2).
Switch Designator
Description
SW1
Power Button
-When Orbitty is in “ATX Mode” a button press will initiate boot-
up sequence
-When Orbitty is ON, a button press will initiate a power down
sequence in the Operating System
-When Orbitty is ON and button is held for 5 seconds the system
will do a hard power off (power down ungracefully)
Note: Due to the changes done to the PMIC circuitry of the TX2i Jetson
Module the Orbitty Carrier will always remain ON when in AT (Automatic
Power ON) and ATX (Push Power button) modes. This will cause the
Orbitty Carrier to automatically power ON when voltage is applied to the
system. The system will in addition be unable to shut down in software
(Soft Shutdown), due to the characteristics of the TX2i power circuitry as
such the system will perform a Reset/Reboot function.
SW3
Reset Button
-When button is pressed the system will initiate a Reset sequence
SW2
Recovery Button
-Use this button to perform the Force Recovery Procedure
detailed in the Software Section of this manual.
-This is required when flashing a new image onto the TX2/TX2i
module via the USB OTB port.
