Converters.TV 15222 User manual

HDBaseT HDMI over Single CAT5e/6/7
Transmitter and Receiver with
AN/PoE/RS-232/IR - # 15222 / #15223
Operation Manual

Introduction
The CH-2507 Transmitter and Receiver set can send uncompressed
audio/video and IP data over a single run of C T5e/6/7 cable at a distance
of up to 100 meters with the added benefit of control through the built-in RS-
232 and IR ports and a bidirectional L N serving connection. The transmitter
(PD) can be powered by the PoE (48V) function of the receiver (PSE),
allowing for greater flexibility in installations.
Features
• HDMI with 3D, 4K×2K support, HDCP and DVI compliant
• Simultan ous transmission of uncompr ss d data ov r a singl
CAT5 /6/7 cabl up to 100m/328ft
• HDBas T™ 5Play™ conv rg nc : uncompr ss d high d finition
Vid o and Audio, LAN s rving, Pow r ov r Eth rn t and RS-232/IR control
• Uncompr ss d vid o support up to 1080p@60 Hz/36-bit
• High d finition audio support up to LPCM 7.1CH, Dolby
Tru HD, Dolby Digital Plus and DTS-HD Mast r Audio
• Supports audio sampling rat s of 32kHz to 192kHz
• Support standard 48V pow r from R c iv r (PSE) to Transmitt r (PD)
• Supports CEC bypass
• Installation fri ndly
Not :
1. This syst m was t st d with CAT5 /6/7 cabl s, r sults may vary
with cabl s of a diff r nt sp cification.
2. Th standard 48V PoE function is d sign d for pow ring
compatibl Transmitt r units only—non-PoE Transmitt rs will n d
th ir own pow r supply. Transmitt rs from oth r brands may not
b compatibl .
3. For playback of 4K×2K HDMI sourc signals, a 4K×2K capabl
display and High Sp d HDMI cabl s ar r quir d.
Applications
•48V PoE from Receiver (PSE) to Transmitter (PD)
•Household entertainment sharing and control
•Lecture room display and control
•Showroom display and control
•Meeting room presentation and control
•Classroom display and control
System
Requirements
HDMI source equipment such as a DVD/Blu-ray player and HDMI equipped
output display (TV or monitor).

Operation Controls
and Functions
Transmitter Front and Rear Panels
1. HDMI IN:
Connect to HDMI source equipment such as a DVD or Blu-ray player.
2. LAN:
Connect to an active network for L N serving. This allows network access
(including internet access if available) to be shared to any device (e.g. a
smart TV or games console) connected to the L N port of the receiver
Warning: DO NOT connect the L N connection to the C T5e/6/7
output, doing so may trigger a power shut down and may damage the
device.
3. RS-232 IN:
Connect to a PC or laptop with D-Sub 9 pin male cable for the transmission
of RS-232 commands.
4. POWER LED:
This blue LED will illuminate when the device is connected to a power
supply.
5. IR1 BLASTER:
Connect an IR Blaster cable for IR signal transmission.
IR signals received by an IR extender connected to the receiver unit will be
transmitted by this blaster. Place the IR Blaster in direct line-of-sight of the
equipment to be controlled.
6. IR2 EXTENDER:
Connect an IR Extender cable for IR signal reception.
Signals received will be transmitted from any IR blaster connected to the
receiver unit. Ensure that the remote being used is within the direct line-of-
sight of the IR Extender.
7. LINK LED:
The yellow LED will illuminate when both the source connected to the
transmitter and the display connected to the receiver are connected. The
LED will blink regularly to indicate that no signal is being received from the
display and irregularly to indicate that an error has occurred.
8. CAT5e/6/7 OUT:
Connect to the receiver unit with a Single C T5e/6/7 cable for transmission
of all data signals.

Receiver Front and Rear Panels
1. HDMI OUT:
Connect to a HDMI equipped TV/monitor for display of the HDMI input
source signal.
2. LAN:
Connect to a L N equipped device (such as a smart TV or games console)
to share the network access (including internet access if available)
3. RS-232 OUT:
Connect to the device that is to be controlled (via D-Sub 9 pin female cable)
by RS-232 commands.
4. POWER LED:
This blue LED will illuminate when the device is connected to a power
supply.
5. DC 8V:
Connect the 48 V DC power supply to the receiver and plug the adaptor into
an C outlet.
6. IR2 BLASTER:
Connect an IR Blaster cable for IR signal transmission.
IR signals received by an IR extender connected to the transmitter unit will
be transmitted by this blaster. Place the IR Blaster in direct line-of-sight of
the equipment to be controlled
7. IR1 EXTENDER:
Connect an IR Extender cable for IR signal reception.
Signals received will be transmitted from any IR blaster connected to the
tranmitter unit. Ensure that the remote being used is within the direct line-of-
sight of the IR Extender
8. LINK LED:
The yellow LED will illuminate when both the source connected to the
transmitter and the display connected to the receiver are connected. The
LED will blink regularly to indicate that no signal is being received from the
display and irregularly to indicate that an error has occurred
9. CAT5e/6/7 IN:
Connect to the transmitter unit with a Single C T5e/6/7 cable for
transmission of all data signals

IR Cable Pin Assignment
D-Sub 9-Pin Definitions
PIN DEFINE TX/RX
1 N/C
2 TxD/RxD
3 RxD/TxD
4 N/C
5 GND
6 N/C
7 N/C
8 N/C
9 N/C

Connection
Diagram

Specifications
Video Bandwidth 300MHz / 10.2Gbps
Ethernet Speed 100Mbps
Transmitter
Input Ports 1×HDMI, 1×IR Ext nd r,1×RS-232, 1×LAN
Output Ports 1×CAT5 /6/7, 1×IR Blast r
Receiver
Input Ports 1×CAT5 /6/7, 1×IR Ext nd r
Output Ports 1×HDMI, 1×RS-232, 1×IR Blast r, 1×LAN
HDMI In Cable Distance 15m/1080p@8-bit or 6m/1080p@12-bit
HDMI Out Cable Distance 15m/1080p@8-bit or 10m/1080p@12-bit
CAT6 Cable Distance Up to 100m
HDMI Resolutions Support 480i~1080p@50/60, 1080p@24, 3D,
4K×2K@24/25/30 & VGA~WUXGA
IR Frequency 30~50kHz
ESD Protection Human Body Mod l:
±8kV (air-gap discharg )
±4kV (contact discharg )
Power Supply 48 V/0.83 A DC (US/EU Standards, CE/FCC/
UL c rtifi d)
Dimensions 102mm (W)×107mm (D)×25mm (H)/TX
102mm (W)×113.5mm (D)×25mm (H)/RX
Weight 252g/TX, 272g/RX
Chassis Material Aluminum
Chassis Color Silv r
Power Consumption 15 W
Operating Temperature 0 °C~40 °C/32 °F ~104 °F
Storage Temperature −20 °C~60 °C/−4 °F~140 °F
Relative Humidity 20~90% RH (non-cond nsing
CAT5e/6/7
Cable Specification
Cable Type Range Pixel
Clock Rate
Video Data
Rate
Supported Video
CAT5 /6/7 100 m ≤225 MHz ≤5.3 Gbps
(HD Vid o)
Up to 1080p, 60Hz,
36bits, 3D (data rat s
low r than 5.3 Gbps or
b low 225MHz TMDS
clock)
70 m >225 MHz > 5.3 Gbps
(Ultra HD
Vid o)
4K×2K, 30Hz
vid oformats
