Artiglio Master 28 Operator’s manual 85
EN
TRANSLATION FROM THE ORIGINAL LANGUAGE
Copyrighted material. All rights reserved.
The included information may be changed without notice.
Thank you for selecting our tyre changer
CORGHI
Dear Customer,
Thank you for purchasing a Corghi tyre changer.
Your Tyre Changer has been designed to provide years of safe and reliable service, as long
as it is used and maintained in accordance with the instructions provided in this manual.
Anyoneusingand/orcarryingoutmaintenanceonthisTyreChangermustread,understand
and follow all warnings and instructions provided in this manual, and be properly trained.
This Instruction Manual should be considered an integral part of your Tyre Changer and
should remain with the Tyre Changer. However, nothing in this manual, and none of the
devices installed on the Tyre Changer, can replace proper training, correct operation,
careful evaluation of procedures and safe working practices.
AlwaysbesurethatyourTyreChangerisinexcellentworkingorder. In case any malfunction
or possible dangerous situation are observed, immediately shut down the Tyre Changer
and resolve the situation before you proceed.
For any question related to the correct tyre changer use or maintenance, contact your
local official Corghi dealer.
Sincerely,
Corghi
USER INFORMATION
Name
User________________________________________________________________________
Address
User________________________________________________________________________
Model
number_____________________________________________________________________
Serial
number_____________________________________________________________________
Date of
purchase____________________________________________________________________
Date of
installation __________________________________________________________________
Service
and spare parts manager_______________________________________________________
Phone
number_____________________________________________________________________
Sales
manager_____________________________________________________________________
Phone
number_____________________________________________________________________

86 Artiglio Master 28 Operator’s manual
TRAINING CHECK
Qualified Rejected
Safety measures
Warning and caution labels
High risk areas and other potential hazards
Operative safety procedures
Checking maintenance and performance
Head mounting inspection
Adjustment and lubrication
Maintenance and instruction messages
Clamping
Steel/alloy rims
Reverse rims
Closed rims
Bead breaking
Standard wheels
Low profile wheels
Demounting
Bead lubrication when removing the low profile tyres
Reverse rims
Mounting
Standard wheels
Mounting of stiff, low profile tyres
Wheels with reverse rim
Bead lubrication for proper mounting
WDK procedure
Accessories
Instructions for correct use of the accessories
Inflatron user instructions (optional)
Inflating procedure
Safety measures
Lubrication and removal of the valve insert
Tubeless tyre inflation

Artiglio Master 28 Operator’s manual 87
EN
Personnel and training dates
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________

88 Artiglio Master 28 Operator’s manual
Contents
1. COMMISSIONING ................................................................................... 90
1.1 INTRODUCTION ...........................................................................................90
1.1.A. PURPOSE OF THE MANUAL .........................................................................90
1.2 FOR YOUR SAFETY ......................................................................................90
1.2.A. GENERAL WARNINGS AND INSTRUCTIONS ..............................................91
1.2.B. LABELS PLACEMENT.....................................................................................94
1.2.C. ELECTRICAL AND PNEUMATIC CONNECTIONS.........................................99
1.2.D TECHNICAL DATA ..........................................................................................100
1.2.E. AIR PRESSURE ...............................................................................................101
1.3. ADDITIONAL RIM/TYRE INFORMATION ................................................101
1.4. INTENDED MACHINE USE ......................................................................101
1.5. PERSONNEL TRAINING ...........................................................................102
1.6. PRELIMINARY CHECKS............................................................................102
1.7. DURING USE..............................................................................................102
2. TRANSPORT, STORAGE AND HANDLING......................................... 103
2.1. UNPACKING...............................................................................................103
3. ASSEMBLY/HANDLING........................................................................ 104
3.1. LIFTING/HANDLING.................................................................................105
3.2. INSTALLATION ..........................................................................................105
4. INSTALLATION AREA ........................................................................... 108
5. ARTIGLIO MASTER 28 DESCRIPTION ................................................ 109
5.1. OPERATOR POSITION...............................................................................109
5.2. OVERALL DIMENSIONS...........................................................................110
5.3. EQUIPMENT COMPONENTS (MAIN WORKING OPERATING
ELEMENTS OF THE MACHINE) .....................................................................110
5.4. CONTROLS.................................................................................................112
5.4.A. ON/OFF SWITCH............................................................................................112
5.4.B. CONTROL CONSOLE.....................................................................................113
5.4.C. PEDAL UNIT ...................................................................................................114
PEDAL UNIT (“AUTOMATIC” VERSION) ................................................................114
5.4.D. WHEEL LIFTER PEDAL UNIT (FIG. 23) (OPTIONAL) ................................115
5.4.E. PRESSURE GAUGE WITH DEFLATION PUSH-BUTTON (FIG. 24) ...........115
6. BASIC PROCEDURES - USE ................................................................. 115
6.1. PRELIMINARY CHECKS............................................................................116
6.2. TURNING THE MACHINE ON..................................................................116
6.3. DECIDING FROM WHICH SIDE OF THE WHEEL THE TYRE MUST
BE REMOVED ...................................................................................................117
6.4. WHEEL LOADING .....................................................................................118
6.5. CLAMPING THE WHEEL ON THE TURNTABLE ....................................119
6.5a. CLAMPING THE WHEEL ON .......................................................................
THE TURNTABLE .............................................................................................120

Artiglio Master 28 Operator’s manual 89
EN
6.6. CONFIGURATION OF WHEEL DATA.......................................................121
6.7. TYRE DEFLATION ....................................................................................122
6.8. BEAD BREAKING ......................................................................................122
6.9. DEMOUNTING...........................................................................................125
6.10. MOUNTING..............................................................................................127
6.11. APPROVED UHP AND RUN FLAT TYRE DEMOUNTING AND
MOUNTING PROCEDURE ..............................................................................130
6.12. TYRE INFLATION.....................................................................................131
6.12.A. SAFETY REGULATIONS ..............................................................................131
6.12.B. TYRE INFLATION .........................................................................................132
6.12.C. SPECIAL PROCEDURE (TI VERSION)........................................................132
6.13 UNCLAMPING AND UNLOADING THE WHEEL...................................136
6.13.A. WHEEL UNCLAMPING................................................................................136
WHEEL UNCLAMPING (“AUTOMATIC” VERSION)...............................................136
6.13.B WHEEL UNLOADING ...................................................................................137
7. TROUBLESHOOTING ........................................................................... 137
7.1 LIST OF DISPLAY SIGNALS.......................................................................137
8. MAINTENANCE..................................................................................... 138
Scheduled maintenance: ................................................................................139
9. INFORMATION ABOUT DEMOLITION ............................................... 141
10. ENVIRONMENTAL INFORMATION................................................... 141
11.INFORMATION AND WARNINGS ABOUT OIL .................................. 142
12. INFORMATION AND WARNINGS ABOUT TYRE LUBRICATING FLUID ..143
13. FIREFIGHTING EQUIPMENT TO BE USED...................................... 143
14. GLOSSARY ........................................................................................... 144
TABLE FOR USING CENTRING AND CLAMPING ACCESSORIES
ACCORDING TO RIM TYPE...................................................................... 148
WIRING DIAGRAM .................................................................................... 156
PNEUMATIC DIAGRAM ............................................................................ 163

90 Artiglio Master 28 Operator’s manual
1. COMMISSIONING
1.1 INTRODUCTION
1.1.a. PURPOSE OF THE MANUAL
The purpose of this manual is to provide the instructions necessary for optimum operation,
use and maintenance of your machine. If you sell this machine, please deliver this manual
to the new owner. Furthermore, ask the new owner to fill out the ownership transfer module
attached to the previous page in the manual and send it to Corghi, so that Corghi will be
able to provide the customer with all necessary safety information. Alternately, the new
owner can send an email to [email protected].
This manual presumes that the technicians have a thorough understanding of rims and
tyre identification and maintenance. He/she must also have a thorough knowledge of the
operation and safety features of all associated tools (such as the rack, lift, or floor jack) being
utilized, and have the proper hand and power tools necessary to work in a safe manner.
The first section explains the basic information regarding the safe operation of the Master
28 tyre changer family. The following sections contain detailed information regarding the
equipment, procedures and maintenance. Italics are used to refer to specific parts of this
manual that offer additional information or clarifications.
These references must be read in order to obtain information additional to the instructions
provided.
The owner of the tyre changer is the only person responsible for the observance of the
safety procedures and the organisation of technical training. The tyre changer must only be
used by qualified, specifically trained technicians. The owner or management is exclusively
responsible for storing the documentation relative to qualified personnel.
The range of Master 28 tyre changers is designed for mounting, demounting and inflating
tyres for light vehicles (cars, not trucks nor motorcycles) with a maximum external diameter
of 40 inches and a maximum width of 14 inches.
Additional copies of this manual and the documentation enclosed with the machine can be
requested from Corghi, specifying the machine type and serial number.
CAUTION: Design details are subject to change. Some illustrations may vary slightly in
appearance from the machine you have.
1.2 FOR YOUR SAFETY
DESCRIPTION OF THE HAZARD
These symbols identify situations that could be detrimental to your safety and/or cause
equipment damage.

Artiglio Master 28 Operator’s manual 91
EN
DANGER: It indicates an imminent dangerous situation that, if not
avoided, could lead to serious injury or death.
DANGER
CAUTION: It indicates a potentially dangerous situation that, if not
avoided, could lead to serious injury or death.
CAUTION
WARNING: It indicates a potentially dangerous situation that, if not
avoided, could cause slight or mild injuries.
WARNING
CAUTION: Used without the safety hazard symbol indicates a potential
situation of hazard that, if not avoided, could cause material
damage.
CAUTION
1.2.a. GENERAL WARNINGS AND INSTRUCTIONS
Proceed with caution to prevent any injuries. Carefully read, understand and follow
the warnings and instructions given in this manual. This manual is an integral part of
the product. For future reference, store it together with the machine in a safe place.
CAUTION
1. Accidents could occur if the maintenance procedures described in this manual are not
executed correctly, or if the other instructions it contains are not observed. This manual
makes continuous reference to the possibility that accidents can occur. Any accident could
lead to serious or fatal injuries to the operator or people nearby, or cause material damage.

92 Artiglio Master 28 Operator’s manual
2. Overinflated tyres can explode, producing hazardous flying debris that may result in
an accident.
3. Tyres and rims that do not have the same diameter “do not correspond”. Never attempt
to mount or inflate tyres and rims that do not correspond. For example, never mount a
16.5” tyre on a 16” rim and vice versa. It is very dangerous. Tyres and rims that do not
correspond could explode and cause accidents.
4. Neverexceedtheinflationpressureforthetyreindicated
bythe manufacturerontheside of thetyreitself.Carefully
check that the air hose is well inserted in the valve
5. Never bring your head or other body parts close to a
tyre during inflation or bead insertion operations. This
machine is not a safety device against the possible risk
of explosion of tyres, air chambers or rims.
6. Maintain a suitable distance from the tyre changer while
inflating. Do not approach it.
A bursting tyre can cause projections of its parts in surrounding areas with a force
sufficient to cause serious injury or death.
Do not mount a tyre if its dimensions (indicated on the side) do not correspond
exactly to the rim dimensions (printed inside the rim) or if the rim or the tyre is
defective or damaged.
Never exceed the pressure recommended by the tyre manufacturer.
The tyre changer is not a safety device and does not prevent tyres and rims from
exploding. Keep all persons not working on the machine out of the working area.
DANGER
7. Risk of crushing. Presence of moving parts. Contact with moving
parts can cause accidents.
The machine can only be used by one operator at a time.
• Keep bystanders away from the tyre changer.
• Keep your hands and ngers away from the rim edge during the
demounting and mounting process.
• Keep hands and ngers clear of mount/demount head during
operation.
• Keep your hands and other body parts away from moving parts.
• Do not use tools other than those supplied with tyre changer.
• Use lubricant that is specic for tyres in order to prevent tyre
seizure.
• Pay attention while handling the rim or the tyre and while using the lever

Artiglio Master 28 Operator’s manual 93
EN
8. Danger of electric shock.
• Do not clean electric parts with water or high pressure air jets.
• Do not operate the machine in the presence of a damaged electrical
cable.
• If an extension is necessary, use a cable with rated features equal to
or greater than those of the machine. Cables with rated features that
are lower than those of the machine could overheat and cause a fire.
• Make sure that the cable is positioned so that it cannot be pulled and the risk of tripping
is avoided.
9. Risk of eye injuries. During the bead insertion and inflation phase,
debris, dust and fluids could be projected into the air. Remove
any debris present on the tyre tread and on the tyre surface. Wear
protectivegoggleswithOSHA, CE approval or othercertifieddevices
during all work phases.
10. Always carefully inspect the machine before using it. Missing,
damaged or worn equipment (including the hazard adhesive labels) must be repaired
or replaced before start-up.
11. Never leave nuts, bolts, tools or other materials on the machine. They could be
entangled in moving parts and cause malfunctions or be ejected.
12. Do NOT mount or inflate tyres that are cut, damaged, decayed or worn. Do NOT mount
tyres on damaged, bent, rusted, worn, warped or deformed rims.
13. Should the tyre get damaged during the mounting phase, do not try to complete
the mounting operation. Remove it, take it away from the service area and mark it as
damaged.
14. Inflatetyresingradualsteps,while continuously monitoringthepressureandobserving
the tyre itself, the rim and the bead. NEVER exceed the pressure limits indicated by
the manufacturer.
15. Theinternal parts in this equipment could create contacts or sparks
if exposed to flammable vapours (petrol, paint thinners, solvents,
etc.). Do not install the machine in a narrow area or position it below
floor level.
16. Do not operate the machine while under the influence of alcohol,
medicines and/or drugs. If you are taking prescription or non-
prescription medicines, contact a physician to be aware of the side
effects that they might have on the ability to operate the machine
safely.
17. AlwaysuseOSHA,CEapprovedandauthorisedpersonalprotective
equipment(PPE)orequipment with equivalent certifications while
operating the machine. Consult your supervisor for additional
instructions.
18. Do not wear jewellery, watches, loose clothing, ties and tie up long
hair before using the machine.
19. Wear protective, non-slip footwear while using the tyre changer.
20. While positioning, lifting or removing wheels from the tyre changer,
wearan appropriate backsupportandusea correctliftingtechnique.

94 Artiglio Master 28 Operator’s manual
21. Onlyappropriatelytrained personnel can use,serviceand repair the machine.Repairs
must only be performed by qualified personnel. Corghi technicians are the most
qualified individuals. The employer must determine if an employee is qualified to
carry out any machine repair safely if the operator has attempted to make the repair.
22. Before starting the machine, the operator must pay close attention to the warnings
of the adhesive labels affixed to the equipment.
23. Clamp the rim on the wheel support plate during inflation.
1.2.b. LABELS PLACEMENT
No. Code Adhesive Description
1 446429 LABEL, INPUT PRESSURE
MAX. 16 BAR
2 446429 LABEL, ATTENTION TANK
PRESSURISED
3 418135 LABEL, ROTATION
DIRECTION
4 425211 LABEL, DANGER OF
ELECTRIC SHOCK
5 - ISO9001
Code
Serial N.
X-XXXXXXXX/XX - XX
XXXXXXXXX
QUAL. SYS. CERTIFIED
ANNO DI COSTRUZIONE /
MANUFACTURED
Mod.
V
A
kW
Hz
Ph
bar7psi
Port.max
LABEL, MODEL SERIAL
NUMBER
6 4-105844 LABEL, MOTOR-INVERTER
7 460384 LABEL, CORGHI
8A 4-137513 LABEL, ARTIGLIO
MASTER 28 AUTOMATIC
8B 4-137512 LABEL, ARTIGLIO
MASTER 28
9 446598 ELECTRIC DISCONNECTION

Artiglio Master 28 Operator’s manual 95
EN
No. Code Adhesive Description
10 4-104346 UP-DOWN PED. LIFTER
(OPTIONAL)
11 461932 PLATE ROTAT.
12 461933 INFLATION PED.
13 446436 DEFLATION PRESSURE
GAUGE
14 461936
PROHIBITION OF TWO
OPERATORS WORKING
SIMULTANEOUSLY
15 346855 ADHESIVE SAFETY STRIP Y/B
50X130
16 462081 RISK OF CRUSHING
17 461930 RISK OF CRUSHING
18 462080 HEARING PROTECTION
PLATE
19
461931 INFLATION WARNING PLATE
462778 USA HAZARD PLATE

96 Artiglio Master 28 Operator’s manual
No. Code Adhesive Description
20 4-135325 LABEL “TECHNOLOGY
PARTNER”
21 4-137859 LABEL, MASTER 28
22 461934
LABEL, WHEEL LOCKING/
UNLOCKING PEDAL
(AUTOMATIC VERSION ONLY)
HAZARD LABELS KEY
code 462081 Risk of crushing
part n. 461930 Risk of crushing
Part n. 461936. Never stand behind the machine.
Only one operator may operate and use the machine
part n. 446442. Danger - pressurised container
part n. 425211A. Risk of electrocution.
part n. 425083. Earth ground terminal.

Artiglio Master 28 Operator’s manual 97
EN
2120 18
16
19
16
9
4
17
14 615
7
2
1
5

98 Artiglio Master 28 Operator’s manual
10
8
7
13
22 1112
3
15

Artiglio Master 28 Operator’s manual 99
EN
1.2.c. ELECTRICAL AND PNEUMATIC CONNECTIONS
The electric connection used must be
suitably sized:
• for the electric power absorbed by the
machine, indicated on its data plate
(Fig. 1);
• the distance between the operating
machineandthepowersupplyconnection
point, to ensure that the voltage drop
under full load does not exceed 4% (10%
duringstart-up) oftheratedvoltagevalue
specified on the plate.
- User must:
• t a power plug in compliance with current
regulations on the power supply lead;
• connect the machine to its own electrical
connection - A, Fig. 2 - equipped with a
differentialautomaticcircuitbreakerwith
30mA sensitivity;
• install protection fuses on the power line
that are suitably sized in accordance with
the indications provided on the machine
data plate (Fig. 1);
• connect the machine to an industrial
socket; the machine must not be
connected to domestic sockets.
A good earth connection is essential for correct operation of the machine.
CAUTION
Make sure that the available pressure and performance of the compressed air system
are compatible with what is necessary for correct machine operation - see the section
“Technical data”. For correct machine operation, the compressed air supply line must
provide a pressure range from no less than 8.5 bar to no more than 16 bar and guarantee
an air flow rate greater than the average consumption of the machine, which is equal to
140 Nl/min (see technical data).
For correct equipment operation, the air produced must be suitably treated
(not above 5/4/4 according to standard ISO 8573-1).
CAUTION
A
2
ISO9001
Code
Serial N.
X-XXXXXXXX/XX - XX
XXXXXXXXX
QUAL. SYS. CERTIFIED
ANNO DI COSTRUZIONE /
MANUFACTURED
Mod.
V
A
kW
Hz
Ph
bar7psi
Port.max
1

100 Artiglio Master 28 Operator’s manual
1.2.d TECHNICAL DATA
- Type of tyres CONVENTIONAL–LOWPROFILE-
RUN FLAT - BALLOON - BSR
- Wheel size range:
• rim diameter ................................................................................................ from 13” to 28”
• maximum tyre diameter .............................................................................. 1100 mm (40”)
• maximum tyre width ..................................................................................... 360 mm (14”)
- Turntable: ¹
• automatic positioning in relation to .......................................................................... tools
• resting side................................................................................................................flanged
• centring..................................................................................................................... on cone
• clamping ..................................................manual (automatic for “AUTOMATIC” version)
• drive system.................................................................................. 2-speed motor-inverter
- Bead breaker:
• bead breaking force ................................................................................................... 7600N
- Supply:
• operating pressure: ...............................................................................................8 -10 bar
•minimum air flow rate: ...................................................................................... 140 Nl/min
- Drive systems
Motor rating kW Rotation speed
(rpm)
Torque
Nm
Weight of electric/
electronic parts (kg)
230V/1ph 50/60Hz MI 0.98 7 - 18 1100 10.2
110V/1ph 50/60Hz MI 0.98 7 - 18 1100 10.2
- Lifter:
• max capacity..................................................................................................................85 kg
- Weight........................................................................................ 470 kg (T.I version 480 kg)
- Noise level:
• A-weighted sound pressure level (LpA) at the working position ................< 70 dB (A)
The noise levels indicated correspond to emission levels and do not necessarily represent
safe operating levels. Although there is a relationship between emission levels and exposure
levels,
this cannot be used reliably to establish whether or not further precautions are necessary. The
factors which determine the level of exposure to which the operator is subject to include the
duration of the exposure, the characteristics of the workplace, other sources of noise, etc. The
permitted exposure levels may also vary according to the country. In all cases, this information
will enable machine users to better assess the danger and risks involved.

Artiglio Master 28 Operator’s manual 101
EN
1.2.e. AIR PRESSURE
The machine is equipped with an internal pressure limiting valve to minimize the risk
of over inflating the tyre.
•RISK OF EXPLOSION
•Never exceed tyre pressure recommended by
tyre manufacturer. Always match the tyre and rim
dimensions.
•Take care to avoid any injuries.
DANGER
1. Never exceed these pressure limitations:
• The supply circuit pressure (from the compressor) is 220 psi (15 bar).
• The operating pressure (indicated on the regulator) is 150 psi (10 bar).
• The tyre ination pressure (displayed on the pressure gauge) must never exceed the
pressure indicated by the manufacturer on the sidewall of the tyre itself.
2. Activate the air inflation jets only when inserting the bead.
3. Discharge the air pressure system before disconnecting the power supply or other
pneumatic components. Air is stored in a reservoir to operate the inflation jets.
4. Activate the air inflation jets only if the rim is correctly clamped on the tyre changer
(if required) and the tyre is completely mounted.
1.3. ADDITIONAL RIM/TYRE INFORMATION
Wheels equipped with pressure sensors and special rims or tyres could require
particular work procedures. Consult wheels and tyre manufacturer’s service
manuals.
CAUTION
1.4. INTENDED MACHINE USE
This machine must only be used to demount and mount vehicle tyres from/on the rims,
using the provided tools. Any other use is improper and may result in injury.
The machine is not designed for working with motorcycle wheels.

102 Artiglio Master 28 Operator’s manual
1.5. PERSONNEL TRAINING
1. Employers are responsible for providing a training program for all employees who work on
the wheels concerning the hazards deriving from maintenance and the safety procedures
to be observed. Service or maintenance refer to mounting and demounting wheels and all
the correlated activities, such as inflation, deflation, installation, removal and handling.
• Employers are required to make sure that operators do not work on the wheels unless they
have received suitable training regarding the correct maintenance procedures for the type
of wheel being serviced and the operative safety procedures.
• Information to be used for the training program includes, as a minimum, the information
contained in this manual.
2. Employers are required to make sure that every employee demonstrates and maintains the
ability to work on the wheels safely, including the performance of the following activities:
• Demounting of tyres (including deation).
• Inspection and identication of the rim wheel components.
• Tyre mounting.
• Use of any restraint device, cage, barrier, or other systems.
• Handling of wheels with rims.
• Tyre ination.
• Move away from the tyre changer while inating the tyre and do not lean forward when
inspecting the wheel during inflation.
• Wheel installation and removal.
3. Employers must evaluate the ability of their employees to carry out these tasks and work
on the wheels in absolute safety and must provide additional training as required to make
sure that all employees maintain their skills.
1.6. PRELIMINARY CHECKS
Before starting to work, carefully check that all machine components, particularly rubber or
plastic parts, are in place, in good condition and operate correctly. If the inspection reveals any
damage or excessive wear, no matter how slight, immediately replace or repair the component.
1.7. DURING USE
If strange or unusual noises are heard or any unusual vibration is detected, if a component
or system is not operating correctly or if you observe anything unusual, immediately stop
using the machine.
• Identify the cause and implement all the necessary corrective measures.
• Contact your supervisor if necessary.
Make sure that all other people are standing at least 6 metres (20 feet) from the machine.
To switch off the machine in case of emergency:
• disconnect the power supply plug;
• interrupt the compressed air supply by disconnecting the supply pipe.
