Cornelius Energize 1 HC Series User manual

Operator manual
Undercounter cooler
Energize 1 HC

Legal notice
Operator manual (Original)
Document no. TD1001000
Undercounter cooler
Unit ID no. 221001100
Energize 1 HC
Version
Date of issue: 01/10/2019
Revision status: Index 4
www.cornelius-emea.com Cornelius Deutschland GmbH
Carl-Leverkus-Str. 15
40764 Langenfeld
Germany
Tel.: [phone]
Fax: [phone]
E-Mail: [e-mail]
Protection notices (in accordance with DIN ISO 16016:2017-08)
The reproduction, distribution and utilisation of this document as well as the communication of
its contents is prohibited, unless expressly permitted. Violations shall result in an obligation to
pay damages. All rights reserved with regard to filing for/registering patents, utility models or
design patents.
Obligation to preserve records
Please keep this Operator Manual and the Declaration of Conformity in a safe place and trans-
fer them to the subsequent owner/operator if the unit is transferred or sold.
If you lose the Operator Manual or the Declaration of Conformity, you can download them from
the website below or request a printed copy from the address below.

Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
1
Operator manual
Undercounter cooler
Table of contents
1 Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Improper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3 Staff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3.1 Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3.2 User . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.3.3 Expert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.4 Presentation of warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5 Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5.1 Disclaimer of liability and warranties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.5.2 Safety information to prevent personal injury and equipment damage. . . . . . . 8
2 Handling the Unit Prior to Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 Unpacking the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.3 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3 Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Assemblies and components. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Functions within the dispensing system. . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.3 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3.1 Undercounter cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3.2 Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.3.3 Labelling positions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
3.3.4 CO2 working pressures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4Operation
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.1 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.2 Changing product containers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.3 Shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.1 Maintenance table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.2 Visually inspecting the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.3 Cleaning the unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
2
6 Errors and malfunctions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.1 Troubleshooting table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
7 Applicable documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.1 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.2 Handover certificate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
3
1Safety
1.1 Intended use
By using the unit as intended you will not only protect yourself, but also prevent damage oc-
curring to the unit and its components!
The intended use of undercounter coolers from the Energize 1 HC series (referred to as “unit”
in the following) is to refrigerate and convey non-alcoholic beverages and their basic ingredi-
ents. CO2 or electric pumps are used as conveying equipment for the brands.
The unit is only suitable for stationary installation in a closed room. Stationary installation is to
be carried out by an expert in compliance with all of the specifications given in the installation
and service manual; see the document “Undercounter cooler installation and service manual”,
document no. TD1001100.
The unit may only be operated in locations and ambient conditions which meet all of the re-
quirements of an installation location; see the document “Undercounter cooler installation and
service manual”, document no. TD1001100.
In particular, intended use means that you will carry out all activities with and on the unit to the
specifications provided in this document.
This unit is only to be operated by those who meet the requirements set out in this document;
see chapter 1.3.2.
Work on the unit and its components not included in the activities described in this document
may only be performed by experts; see chapter 1.3.3.

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
4
1.2 Improper use
Improper use of the unit and unauthorised modifications to the unit and its components may
cause personal injury and equipment damage for which Cornelius Deutschland GmbH shall
assume no liability. Improper use of the unit is prohibited.
The following in particular is regarded as improper use:
– Mobile operation of unit
– Use by persons (including children) with physical, sensory or mental disabilities or those
with insufficient experience and knowledge, unless they are supervised by a person re-
sponsible for their safety, or this person has instructed them in the use of the unit.
– Use, operation and maintenance by children under 8 years.
– Children are not to play with the unit. Cleaning and maintenance work must not be carried
out by children unattended.
– Use by those under the influence of medication, alcohol, drugs or other substances which
impair their physical, sensory or mental abilities.
– The refrigeration of non-specified liquids and those above the maximum supply tempera-
tures as this may cause unacceptably high pressures to build up in the refrigeration circuit;
see chapter 1.1.
– Operating the unit below the minimum and above the maximum ambient temperatures
(minimum and maximum temperatures; see chapter 3.3).
– Operating the unit with conveying media other than those defined in this document; see
chapter 1.1.
– Operating the unit in locations and ambient conditions which do not fully meet the require-
ments of the installation and service manual; see the document “Undercounter cooler in-
stallation and service manual”, document no. TD1001100.
– Operation of the unit by untrained staff.
– Carrying out cleaning and other types of maintenance work on the unit which contradict
this document or are not included in it.

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
5
1.3 Staff
1.3.1 Operator
The operator is the natural or legal person who uses the unit or on whose behalf the unit is
used. The operator must ensure that the unit is only used as intended, in observance of the
safety instructions set out in this document.
The operator must ensure that all users read and understand the safety information. The op-
erator is responsible for the planning and proper implementation of regular safety inspections
and maintenance work.
With regard to operating the unit, Cornelius Deutschland GmbH recommends observing the
national regulations of the country of use which govern the operation of beverage-dispensing
systems.
1.3.2 User
The operator specifies who will operate this unit. Cornelius recommends the following:
– If this unit is only to be operated by employees, they are to be instructed in its use, demon-
strate their abilities to use it to the operator or their authorised representative, and be ex-
pressly charged with its use. This document is to be available to staff at all times.
– If this unit is openly accessible and set up so that untrained staff can use it, the operator
is to provide instructions for use directly at the unit; these must be clearly understood by
this group of people, therefore ensuring that the unit will be handled safely.
1.3.3 Expert
An expert in terms of this document refers to someone who has the relevant training, experi-
ence and information and knowledge of relevant standards, laws, regulations, accident pre-
vention regulations, generally accepted safety-related regulations and operating conditions to
be able to perform the required activities as well as recognise potential risks and avert them.
For assignments requiring expert knowledge, e.g. in electrical engineering, mechanics or fluid
technology, only skilled workers with the right qualifications are to carry these out.
An expert must also have received technical training in the unit-specific special features of
Cornelius products. The assigned tasks are always to be carried out in compliance with the
relevant installation and service manual for the unit concerned; see the document “Under-
counter cooler installation and service manual”, document no. TD1001100.

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
6
1.4 Presentation of warnings
The classification of warnings is based on ISO 3864-2 and ANSI Z535.6, using the key terms
of1
– “Danger”, “Warning” and “Caution” in the case of personal injury,
– “Attention” in the case of equipment damage and
– “Notice” to impart general information.
This document classifies and presents the various pieces of safety information as follows:
DANGER!
marks a danger with a high risk2 which results in serious injuries or death
if not avoided.
WARNING!
marks a danger with a medium risk2, which may result in serious injury or
death if not avoided.
CAUTION!
marks a danger with a low risk2, which may result in minor to moderate in-
jury if not avoided.
ATTENTION!
marks a potentially damaging situation in which the product or objects may
be damaged if not avoided.
NOTICE!
marks tips for use and other particularly useful information that may not be
recognised at first glance.
SAFETY INFORMATION!
marks safety information which must be observed in the stated operating
situation.
1Not every one of following key terms is necessarily used in this documentation.
2Risk = extent x likelihood of occurrence

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
7
1.5 Safety information
Any work on the unit and its components which goes beyond the operation and servicing and
maintenance that the operator is authorised for, may only be performed by experts (for a defi-
nition of experts, see chapter 1.3.3). Furthermore, it is crucial that when performing work on
the unit all safety information is observed; this information is set out in the following sections.
Some of the tasks may have additional safety information which highlights the specific dangers
or hazards associated with such work.
1.5.1 Disclaimer of liability and warranties
If work is undertaken on the unit which is not described in this document, Cornelius Deutsch-
land GmbH shall not assume any liability for any resulting hazards and damages. The same
applies to described work which is partly or not fully performed in compliance with the regula-
tions set out in this document.
WARNING!
Risk of personal injury and equipment damage due to improperly ex-
ecuted work!
Improperly executed work at the unit will cause dangers to persons and
damage to the unit.
• Have all work at the unit carried out by Cornelius Deutschland GmbH
or by a service partner.
WARNING!
Risk of personal injury and equipment damage due to the use of non-
approved spare parts and accessories!
Using spare parts and accessories that are not recommended by the man-
ufacturer may lead to personal injury and equipment damage.
• For your own safety and to protect your warranty, only use original
spare parts.

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
8
1.5.2 Safety information to prevent personal injury and equip-
ment damage
Please always observe the following safety information in order to prevent personal injury oc-
curring:
DANGER!
Risk of death from electric shock!
Touching live electrical parts will result in a risk of electric shock!
• Do not carry out any work on the electrical system.
WARNING!
Risk of burns when touching hot parts of the unit!
Touching parts of the unit after it has been in continuous use over an ex-
tended period of time will result in a risk of burns.
• Take appropriate safeguard measures, such as by wearing heat-resis-
tant protective gloves.
DANGER!
Risk of poisoning and risk of explosion due to improper handling of
CO2 cylinders!
Risk of death from CO2!
• Observe all information on occupational safety for the safe operation
of dispensing systems as applicable in the relevant country of installa-
tion.
WARNING!
Risk of personal injury and equipment damage due to improper oper-
ation!
Risk of death from improper operation!
• Make sure that only users who are users as defined in the user section
use the unit; see chapter 1.3.2.
• Children must be supervised to ensure that they do not play at or with
the unit.

Safety
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
9
DANGER!
Risk of personal injury and equipment damage due to leaking refrig-
erant!
In accordance with DIN EN 378 standard, part 1, the refrigerant used with
this unit, R290 (propane), is classified as safety group A3. It is not poison-
ous and not caustic or corrosive. However, it is combustible and highly
flammable. As a result, a potentially explosive atmosphere may occur in the
case of leaks. The refrigerant is heavier than air and, consequently, accu-
mulates at the bottom and may enter lower lying areas (e.g. sewage sys-
tems). At high concentrations, this may lead to a lack of oxygen, resulting
in a risk of suffocation. Lower concentrations may have a narcotic effect.
The refrigerant has a very slight, somewhat sweet smell.
• Avoid any damage to components that carry the refrigerant.
• If you suspect any leaks, however small, shut down the unit, air the
room well and inform your service partner.
• Do not allow direct contact with the skin of any leaking refrigerant.
• Fire, open flames and smoking are prohibited.
• If you begin to notice any smell, leave the room and alert the fire ser-
vice.
NOTICE!
In particular, safety standards are to be observed in their scope of validity
(e.g. EN 60335-2-75).

Handling the Unit Prior to Installation
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
10
2 Handling the Unit Prior to Installation
2.1 Unpacking the unit
NOTICE!
Cornelius Deutschland GmbH is not responsible for damaged deliveries. If
any damage is found, all packaging material is to be kept and the freight
carrier is to be contacted. If the freight carrier is not contacted within 48
hours of receipt of delivery, the warranty claim might be rendered void.
NOTICE!
The unit is thoroughly checked ex works before being shipped. The freight
carrier has confirmed and acknowledged receipt. All damage or irregulari-
ties are to be noted at the time of delivery and reported immediately to the
freight carrier delivering. Please request a written inspection report from the
claims inspector to substantiate any claim.
1. Inspect the cardboard box and make a note of any damage however minimal this may
seem. If the cardboard box is damaged, please make a note of the following on the copy
of your freight invoice: “exterior cardboard box damage – concealed damage possible”.
Please contact the freight company immediately.
2. Open the cardboard box, packaging material and plastic bag in which the unit is packed.
Check the unit thoroughly for damage and to make sure it is complete in accordance with
table 2-1.
3. Remove the packaging material from the top of the unit.
4. Check the unit housing and make sure that there are no scratches, dents or other super-
ficial defects.
5. Make sure that the glass or plastic has no scratches or cracks.
6. Open the package with the loose individual parts and check all parts for damage and com-
pleteness. Check that the received parts correspond with the packing list and make sure
that you have received all parts.
NOTICE!
Do not put the unit down on its front or sides without the packaging as this
may damage the housing. This will render the warranty claim void.

Handling the Unit Prior to Installation
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
11
Tab. 2-1 Cardboard box content
2.2 Storage
Avoid excessive temperature fluctuations as condensate may form, which in turn may cause
damage to the unit or to the components.
The permissible storage temperature is -10 °C to +50 °C.
The acclimatisation period is 6 hours.
ATTENTION!
Damage due to improper storage!
Dirt or moisture entering a unit, as well as certain weather conditions (e.g.
condensate forming in the unit, sunlight) will cause damage to the unit and
its components.
• Protect the unit and its components by storing the unit in a clean and
dry place, and by ensuring stable ambient conditions.
• If possible, store the unit in its original packaging. Unpacked units must
be covered with a dustproof cover. No condensate must form under
the cover.
ATTENTION!
Risk of electrostatic charge!
Improper handling or storage may result in electrostatic charges.
• If possible, store units and/or any electronic components in their origi-
nal packaging.
• Keep units and/or electronic components away from charged objects,
fields and insulators.
• Avoid electrostatic charges when removing packaging and/or handling
electronic assemblies and components by working at an ESD-protect-
ed workstation or work area.
• When working at the unit or its components, wear a grounding (anti-
static) wrist strap at the very least and wear antistatic gloves if neces-
sary.
No. Description Qty/amount
1 Operator manual 1
2 Installation and service manual or information sheet on installa-
tion and service manual
1
3 Undercounter cooler 1
4 Mains power cable 1

Handling the Unit Prior to Installation
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
12
ATTENTION!
Component damage due to material ageing!
Material can age due to long storage periods, thereby affecting the materi-
al’s properties (e.g. plastics and seals may become brittle). The properties
of lubricants may change due to long storage periods.
• Check the assemblies and components for damage before each use/
before installing them. Do not install assemblies or components that
show visible signs of ageing.
ATTENTION!
Component damage due to freezing liquids!
Ambient temperatures that are below freezing will lead to the freezing of
any water or cleaning agent residue remaining inside the unit. This will lead
to damage to internal components.
• Before shipment, storage or relocation of the unit, the unit is to be
cleaned and the cleaning solution is to be fully drained from the unit.
2.3 Disposal
Disposal of the units must be carried out in compliance with the applicable local and/or national
and international regulations. Units must not be disposed of with household waste.
If the unit contains fuels or lubricants in liquid, paste-like or gaseous form, such as oil, grease,
cooling agents etc., such fuels or lubricants are to be collected using appropriate measures
and disposed of in compliance with the applicable local and/or national and international reg-
ulations. Such fuels or lubricants must always be prevented from seeping into the ground, the
sewage system and any bodies of water, and must always be prevented from entering the at-
mosphere.

Description
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
13
3 Description
3.1 Assemblies and components
The unit comprises the following assemblies:
Fig. 1
1 2
3
4
6
5
1 Cover
2 Connecting plate with tube connections
3 Control and indicator panel
4 Cooling unit with refrigerator and car-
bonator
5 Water level gauge
6 Line supply

Description
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
14
3.2 Functions within the dispensing system
The unit refrigerates and conveys non-alcoholic drinks from the storage section of the dispens-
ing system to the tower on the counter. The pressure-reduced, filtered water, syrup, and CO2
required is supplied as illustrated in the flowchart (Fig. 2).
Fig. 2
The beverage components are chilled to the right temperature in the housing. Drinking water
is also carbonated. This means that still water, soda and chilled syrup are available at the re-
frigerator outlets for postmix beverages.
When requested at the tower, they are conveyed to the tower via the python. Only the soda is
continuously circulated.
CO2 or electrically operated syrup pumps are used to convey the brands (syrup).
S
F
HO
2
CO2
CO
230 V/50 Hz
230 V/50 Hz
230 V/50 Hz
2
CO2
CO2
4
555
2
3
7
6
CWSW
1
2
1 Tower
2 Syrup/BIB
3 Flavour shot (optional)
4 Undercounter cooler
5 Pressure-reducing valve
6CO
2
7 Water filter (optional)
S = syrup
SW = still water
CW = carbonated water
H2O = tap water
F = Flavour

Description
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
15
Apart from the daily check and the connection of new syrup containers and BIBs as and if
needed (see chapter 4.2), the undercounter cooler requires no operation by the user or oper-
ator.
3.3 Technical data
3.3.1 Undercounter cooler
3.3.2 Connections
NOTICE!
The applicable installation and service manual contains the diagram and
description of the connections for this unit; see the document “Undercount-
er cooler installation and service manual”, document no. TD1001100.
Description Parameter Value Unit
Dimensions Height 510/20.1 mm/in.
Width 341/13.4 mm/in.
Depth 590/23.2 mm/in.
Dispensing capacity At a dispensing rate
of 2 drinks of 0.3 li-
tres a minute1
105 Unit
Ice build-up size Weight 5.4 kg
Ice build-up capacity 432 kcal/h
Power supply Supply voltage 230 V
Frequency 50 Hz
Power input max. 360 W
Current consumption max. 1.6 A
Python length max. 2 m
Syrup Quantity 6 Unit
Shipping weight 40 kg
1. with 10 m SC python

Description
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
16
3.3.3 Labelling positions
Fig. 3
3.3.4 CO2 working pressures
NOTICE!
When using Cornelius pythons, heat loss of 8-15 kcal/h is to be calculated
for each consecutive metre.
2
3
4
5
1
1 Dangerous voltage warning sign
2 Python connection warning sign
3 Refrigerant warning sign
4 Carbonator type plate
5 Unit type plate
Circuit Pressure1 Unit
Syrup 3.5-4.0 bar
CO2 pressure 4.5-5.5 bar
Light product 0.5-1.0 bar
Tap water flow pressure > 2 bar
1. Changes reserved

Operation
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
17
4 Operation
NOTICE!
The unit is set up and commissioned by the service partner. Once com-
plete, you will receive initial instruction on how to operate and maintain the
unit. The following describes the operating sequences and will help famil-
iarise you with how the unit works.
DANGER!
Risk of personal injury and equipment damage due to non-compli-
ance with safety information!
Failure to observe the safety information will result in a risk of bringing
about operating conditions at the unit, which may cause personal injury or
equipment damage.
• Please always strictly observe all safety measures and information/in-
structions; see chapter 1.
The unit has been designed for continuous operation. Apart from the daily check and the con-
nection of new syrup containers and BIBs as and if needed (see chapter 4.2), the undercounter
cooler requires no operation by the user or operator.
4.1 Commissioning
NOTICE!
The following describes how the operator or user can put the unit back into
service following temporary shutdown (< 24 hours).
If the unit has to be put back into service after a long shutdown
(> 24 hours), this may only be carried out by an expert, see chapter 1.3.3,
as the unit has to be cleaned.
NOTICE!
To prevent algae building up in the water, the disinfectant Molco (PN 14-
9670-150) can be added. The container size with 150 ml disinfectant is suf-
ficient for 30 litres of water.

Operation
Cornelius Deutschland GmbH
Document no. TD1001000
Version 01/10/2019, Index 4
Operator manual Undercounter cooler
Energize 1 HC
18
4. Only for types with CO2-operated syrup pumps: Check the second pressure-reducing
valve on the CO2 bottle to make sure the CO2 pressure for pressurising the syrup pumps
is set as specified (for the setpoint, see chapter 3.3).
5. Check that the CO2 shut off valves are open; see documentation on the CO2 system.
If necessary, open the CO2 shut off valves.
6. Check that the water supply valve is open; see documentation on the water supply valve.
If necessary, open the water supply valve.
7. Check the pressure-reducing valve on the water pip to make sure the water pressure is
set as specified (for the setpoint, see chapter 3.3).
8. Check the fill level and the connection of the syrup containers and BIBs and replace the
empty containers with full ones; see chapter 4.2.
9. Check that the tower is fully operational; see the document “Tower operator manual”.
Once the unit has been switched off and only then:
1. Check the water level gauge to make sure the water pan
is filled up with tap water.
Make sure the water level is between minimum and max-
imum.
If necessary, fill up the water bath with tap water.
2. Check that the CO2 bottle valve is open; see documenta-
tion on the CO2 system.
If necessary, open the valve on the CO2 bottle.
3. Check the pressure-reducing valve on the CO2 bottle to
make sure CO2 pressure for carbonation is set as speci-
fied (for the setpoint, see chapter 3.3).
Fig. 4
1. Plug the mains plug into the earthed socket, if applicable.
Fig. 5
