Cornelius VIPER 3 FLAVOR User manual

FRUTISTA VIPER (E) 3 FLAVOR
Installation Manual
Release Date: April 02, 2010
Publication Number: 621360041TBINS
Revision Date: April 26, 2016
Revision: F
Visit the Cornelius web site at www.cornelius.com for all your Literature needs.

The products, technical information, and instructions contained in this manual are subject to change without notice.
These instructions are not intended to cover all details or variations of the equipment, nor to provide for every possible
contingency in the installation, operation or maintenance of this equipment. This manual assumes that the person(s)
working on the equipment have been trained and are skilled in working with electrical, plumbing, pneumatic, and
mechanical equipment. It is assumed that appropriate safety precautions are taken and that all local safety and con-
struction requirements are being met, in addition to the information contained in this manual.
This Product is warranted only as provided in Cornelius’ Commercial Warranty applicable to this Product and is sub-
ject to all of the restrictions and limitations contained in the Commercial Warranty.
Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting
from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal
service conditions with respect to the Product, (2) improper voltage, (3) inadequate wiring, (4) abuse, (5) accident, (6)
alteration, (7) misuse, (8) neglect, (9) unauthorized repair or the failure to utilize suitably qualified and trained persons
to perform service and/or repair of the Product, (10) improper cleaning, (11) failure to follow installation, operating,
cleaning or maintenance instructions, (12) use of “non-authorized” parts (i.e., parts that are not 100% compatible with
the Product) which use voids the entire warranty, (13) Product parts in contact with water or the product dispensed
which are adversely impacted by changes in liquid scale or chemical composition.
Contact Information:
To inquire about current revisions of this and other documentation or for assistance with any Cornelius product con-
tact:
www.cornelius.com
800-238-3600
Trademarks and Copyrights:
This document contains proprietary information and it may not be reproduced in any way without permission from
Cornelius.
This document contains the original instructions for the unit described.
CORNELIUS INC
101 Regency Drive
Glendale Heights, IL
Tel: + 1 800-238-3600
Printed in U.S.A.

TABLE OF CONTENTS
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Read and Follow ALL Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Different Types of Alerts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Qualified Service Personnel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Shipping And Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CO2(Carbon Dioxide) Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Mounting in or on a Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Viper Machine Usage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Decommissioning and/or Transporting the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Storage within the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Dispensed Product Conditions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Overrun, as Applied to Carbonated Beverages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Overrun Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Overrun is a Variable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Specific Product Ingredients Affect Overrun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
BRIX Affects Overrun. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Low Dispensing Volume Affects Overrun. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Carbonation Level in Liquid Product Affects Overrun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Freezing Affects Overrun . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Delivery, Inspection & Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Counter Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Backroom Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Supply Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Line Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Water Supply Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Water Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CO2Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
CO2Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Syrup Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Syrup Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Testing Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installing The Drip Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Cart Information and Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Control Panel Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting Up the Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting the System Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Options Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Events Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting Viscosity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CO2Setup Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Commissioning the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Unit Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Pressurizing the CO2System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Pressurizing the Water System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Pressurizing the Syrup System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Setting BRIX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Testing BRIX Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting BRIX Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Filling the Barrels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Calibrating a Motor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Security Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Noise Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 1 - Publication Number: 621360041TBINS
SAFETY INSTRUCTIONS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
Safety Overview
• Read and follow ALL SAFETY INSTRUCTIONS in this manual and any warning/caution labels on the
unit (decals, labels or laminated cards).
• Read and understand ALL applicable OSHA (Occupational Safety and Health Administration) safety
regulations before operating this unit.
Recognition
Different Types of Alerts
!
DANGER:
Indicates an immediate hazardous situation which, if not avoided, WILL result in serious injury, death or
equipment damage.
!
WARNING:
Indicates a potentially hazardous situation which, if not avoided, COULD result in serious injury, death, or
equipment damage.
!
CAUTION:
Indicates a potentially hazardous situation which, if not avoided, MAY result in minor or moderate injury or
equipment damage.
SAFETY TIPS
• Carefully read and follow all safety messages in this manual and safety signs on the unit.
• Keep safety signs in good condition and replace missing or damaged items.
• Learn how to operate the unit and how to use the controls properly.
• Do not let anyone operate the unit without proper training. This appliance is not intended for use by
very young children or infirm persons without supervision. Young children should be supervised to
ensure that they do not play with the appliance.
• Keep your unit in proper working condition and do not allow unauthorized modifications to the unit.
NOTE: The dispenser is not designed for a wash-down environment and MUST NOT be placed in
an area where water jet could be used.
QUALIFIED SERVICE PERSONNEL
!
WARNING:
Only trained and certified electrical, plumbing and refrigeration technicians should service this unit. ALL WIRING
AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD
RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE.
Recognize Safety Alerts
This is the safety alert symbol. When you see it in this manual or on the unit, be alert
to the potential of personal injury or damage to the unit.
!

Viper Installation Manual
Publication Number: 621360041TBINS - 2 - © 2010-2016, Cornelius Inc.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER, ITS SERVICE
AGENT OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
SAFETY PRECAUTIONS
This unit has been specifically designed to provide protection against personal injury. To ensure continued
protection, observe the following:
!
WARNING:
Disconnect power to the unit before servicing following all lock out/tag out procedures established by the user.
Verify all of the power is off to the unit before any work is performed.
Failure to disconnect the power could result in serious injury, death or equipment damage.
!
CAUTION:
Always be sure to keep area around the unit clean and free of clutter. Failure to keep this area clean may result in
injury or equipment damage.
SHIPPING AND STORAGE
!
CAUTION:
Before shipping, storing, or relocating the unit, the unit must be sanitized and all sanitizing solution must be
drained from the system. A freezing ambient environment will cause residual sanitizing solution or water
remaining inside the unit to freeze resulting in damage to internal components.
CO2(CARBON DIOXIDE) WARNING
!
DANGER:
CO2displaces oxygen. Strict attention MUST be observed in the prevention of CO2gas leaks in the entire CO2
and soft drink system. If a CO2gas leak is suspected, particularly in a small area, IMMEDIATELY ventilate the
contaminated area before attempting to repair the leak. Personnel exposed to high concentrations of CO2gas
experience tremors which are followed rapidly by loss of consciousness and DEATH.
MOUNTING IN OR ON ACOUNTER
!
WARNING:
When installing the unit in or on a counter top, the counter must be able to support a weight in excess of 450 lbs.
to insure adequate support for the unit. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH
OR EQUIPMENT DAMAGE.
NOTE: Many units incorporate the use of additional equipment such as ice makers. When any
addition equipment is used you must check with the equipment manufacturer to
determine the additional weight the counter will need to support to ensure a safe
installation.
VIPER MACHINE USAGE
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction con-
cerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
This appliance is not intended to be used in household and similar applications such as:
• Staff kitchen areas in shops, offices and other working environments
• Farm houses and by clients in hotels, motels and other residential type environments

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 3 - Publication Number: 621360041TBINS
• Bed and breakfast type environments
• Catering and similar non-retail applications
THE APPLIANCE HAS TO BE PLACED IN A HORIZONTAL POSITION
DECOMMISSIONING AND/OR TRANSPORTING THE UNIT
Whenever the viper unit is going to be removed from service and/or transported, the unit must be completely
drained of product and rinsed out to remove residual product.
When transporting the unit, make sure that the product bowl is removed from the top of the unit and stored in a
safe place for shipment. The unit must be carefully tied down or stored in such a manner that the unit will not
move during shipment.
STORAGE WITHIN THE MACHINE
!
CAUTION:
Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.

Viper Installation Manual
Publication Number: 621360041TBINS - 4 - © 2010-2016, Cornelius Inc.
INTRODUCTION
SYSTEM OVERVIEW
Introduction
The Frutista Viper system is a state-of-the-art FCB/FUB machine. The Frutista Viper machine provides improved
drink availability, reliability and reduced complexity in a compact, reduced footprint machine.
Viper provides the highest quality in drink appearance and consistency while keeping operation and maintenance
simple and straightforward.
The unit consists of multiple freeze barrels that each contain an internal beater driven by an electric motor, a
refrigeration system, a timer-controlled, intelligent defrost system and interconnecting tubing and controls
required to dispense the product.
DISPENSED PRODUCT CONDITIONS
Overrun, as Applied to Carbonated Beverages
Overrun Definition
Overrun is defined as product expansion that takes place in the frozen carbonated drink. It is caused primarily by
CO2 gas breakout and secondarily by freezing.
Overrun is a Variable
The percentage or degree of overrun depends on a number of factors. The specific syrup, BRIX, low dispensing
volume, carbonation level in the liquid product and freezing of the product. These items all affect overrun. After
these factors have been considered, desired viscosity (product consistency) adjustment may be made on the
unit. The viscosity adjustment adjusts product texture from very wet to light.
Specific Product Ingredients Affect Overrun
Each syrup has its own specific formulation of makeup. Fruit flavors contain citric acids that colas do not. Colas
also differ in ingredients from one brand to another. Each product formulation has its own peculiarities regarding
the way the product absorbs carbonation and the way it releases carbonation.
BRIX Affects Overrun
Sugar in carbonated drinks is like anti-freeze in water. The higher the BRIX, the greater the resistance of the
product to freezing. Conversely, in products with lower BRIX, freezing takes place at higher temperatures than for
high-BRIX products. Thus, BRIX affects overrun because the amount of sugar in a drink has a direct bearing on
the product’s freezing characteristics.
Figure 1.
Low Dispensing Volume Affects Overrun
When a unit sits idle for a period of time with no drinks being dispensed, CO2gas in the system takes a “set”.
When the first few drinks are drawn off after an idle period, CO2gas has less tendency to break out as the drink
is dispensed. The result is that these first drinks have less overrun than drinks dispensed during peak-use
periods.

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 5 - Publication Number: 621360041TBINS
Carbonation Level in Liquid Product Affects Overrun
The higher the specific carbonation level in a given product, the greater the potential for carbonation breakout in
frozen carbonated form of that drink. For example, drinks with 3.0 volume of carbonation have more gas breakout
in frozen carbonated form and more overrun than drinks that contain 2.0 volumes of CO2gas.
Freezing Affects Overrun
Freezing causes approximately a 5-7 percent expansion in dispensed frozen carbonated drinks. The degree of
freezing is limited because the finished drink is intended to be sipped through a straw. This is not possible if the
product is too “solid”.

Viper Installation Manual
Publication Number: 621360041TBINS - 6 - © 2010-2016, Cornelius Inc.
INSTALLATION
DELIVERY, INSPECTION & UNPACKING
NOTE: Cornelius is not responsible for damaged freight. If damage is found, you must save all
packaging material and contact the freight carrier. Failure to contact the carrier within 48
hours of receipt may void your claim.
1. Inspect the carton and note any damage, regardless if it appears minor. If the carton is damaged,
note on the consignee copy of the freight invoice “exterior carton damage – concealed damage
possible” and contact the freight company immediately.
2. Remove any staples along the bottom edge of the carton and lift the carton off the pallet.
3. Remove the exterior carton sleeve, internal fillers and plastic bag around the unit. Carefully inspect
the unit for damage.
4. Remove the bolts holding the dispenser to the pallet.
5. Remove the packing fillers from the top of the unit.
6. Inspect the dispenser cabinet and make sure it has no scratches, dents or any other cosmetic
defects.
7. Make sure that the glass or plastic merchandiser panels are not scratched or cracked.
8. Open the packages of loose parts and inspect all of the parts for damage or missing parts. Check
the parts received against the packing list to insure receipt of all parts.
NOTE: If unit is installed more than three months from date of production, replace the seals
according to the instructions accompanying the spare seals supplied with the unit. Unite
date of manufacture is included in the unit serial no. as follows: The date code follows the
first letter of the serial number. The next four numbers reflect the date of manufacture.
The first two represent the year, the next two the week. For example, 62A0815xxxxxx
would be a unit produced during the 15th week of 2008.
COUNTER LOCATION
Select a location in a well ventilated area, close to a grounded electrical outlet and backroom connections. The
counter must be capable of supporting a minimum of 400 pounds. If possible do not place the unit close to hot
and/or steaming machines.
The minimum clearance is: 2 in. (5.08 cm) in back and 12 in. (30.48 cm) on top of the unit. If both sides have a
minimum clearance of 2” (5.08 cm), then the unit may be flush to the wall in the back.
NOTE: Condenser air is drawn in from the sides or back and discharged out the top. Failure to
maintain clearance space will reduce the capacity of the unit and cause premature
compressor failure.
BACKROOM REQUIREMENTS
Typically the supplies for the unit are located in a backroom adjoining the service area. Syrup, water and CO2
lines are then run from the backroom to the service area. The backroom supplies (syrup boxes, CO2, water filters
and pumps) are typically installed on a rack system that sits on the floor, as shown in Figure 2. The CO2cylinder
is normally mounted against the wall.

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 7 - Publication Number: 621360041TBINS
Figure 2.
SUPPLY CONNECTIONS
All of the electrical and supply connections to the unit are typically located near the bottom rear of the unit. There
are alternate locations for the electrical and supply connections on the bottom of the unit, below the rear
locations. The bottom connection locations may be used if the unit is located directly against a wall.
The electrical connection is located at the left side of the rear panel and the tubing supplies are located on the
right side, as shown in Figure 3.
Figure 3.
Electrical Requirements
Refer to the nameplate to determine the power requirements before connecting electrical power to the unit. All of
the power cords shall comply with safety requirements outlined in the EC Standards (EN60335-1 1 Clause 24.1)
in countries where CE compliance is required. All cords must be HD 21 or HD 22.
Power Cord Syrup, Water and CO2
Input Lines

Viper Installation Manual
Publication Number: 621360041TBINS - 8 - © 2010-2016, Cornelius Inc.
Line Voltage
The recommended line voltage range for the Viper unit is 215 to 245VAC. Measure the voltage at the wall outlet to
verify proper wiring of the outlet before plugging the Viper unit in.
Power
The power circuit must have some sort of overload protection, such as a circuit breaker or fuse that meets local
and national electrical codes. Table 1. shows the power requirements for the various types of units.
Electrical Connections
To connect AC power to the unit, perform the procedure in Table 2. 60Hz units are supplied with the power cord
attached. Skip installation information in Table 2. and begin with the Water Supply Requirements section.
Strain Relief
Terminal
Block
Figure 4.
Table 1.
3-Barrel 60Hz 3-Barrel 50Hz
30 A. Circuit 30 A. Circuit
Table 2.
Step Action
1 Insure that power to the unit is off. DO NOT plug the power cord into the wall
outlet at this time.
2 Remove the right side and rear panel from the unit.
3 Remove the cover from the electrical box.
4 Feed the power cord through the strain relief, as shown in Figure 4.
5 Pull the slack out of cable and tighten the strain relief (see Figure 4.).
6 Connect the colored wire to the appropriate terminal on the terminal block.
7 Connect the black wire to the appropriate terminal on the terminal block.
8 Connect the green wire to the ground terminal next to the terminal block.
9 Replace the power box cover. DO NOT TURN ON THE POWER at this time.

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 9 - Publication Number: 621360041TBINS
Water Supply Requirements
NOTE: Water connections require 1/2” I.D. tubing. All hoses must reach the back of the unit plus
an adequate amount of extra tubing to allow the unit to be pulled out for servicing.
The Viper unit is designed as a high throughput unit. It is very important that the incoming water line is dedicated
to the unit. This line should not have any other machines connected which could cause a water surge, such as
coffee makers or ice machines.
!
IMPORTANT:
The water supply should be consistent with proper water quality standards (neutral pH of 7.0 to 8.0), and should
not be connected to a water softener. Drink quality may be affected by poor water conditions. Water connections
should be sized, installed and maintained according to federal, state and local laws.
NOTE: Size, install, and maintain the water pipe, connections, and fixtures directly connected to
a potable water supply in accordance with Federal, State, and Local codes. It is the
installer’s responsibility to ensure that the potable water supply is equipped with
protection against backflow. This protection can be an air gap as defined by ANSI/ASME
A112.1.2-1979 or by an approved vacuum breaker or other approved method. If the
flowing water pressure at the back of the unit is less than the specified 25 psi and 100
GPH flowrate (per 2 barrels) a water pressure booster is required. It is recommended that
a water shutoff valve and water filter be installed in the water supply line.
Water Connections
Use the appropriate fittings and clamps to connect the water line to the unit. Run the tubing for the water (1/2 in.
ID, Min.) from the water source in the backroom to the unit and make all appropriate connections. Do not turn on
the water supply to the unit.
CO2Requirements
!
WARNING:
CO2displaces oxygen. Persons exposed to high concentrations of CO2will experience tremors, followed by loss
of consciousness and death. It is very important to prevent CO2leaks, especially in small unventilated areas. If a
CO2leak occurs ventilate the area before fixing the leak.
NOTE: There are two CO2delivery systems available: 
• High pressure Cylinder requires a Primary Regulator with a minimum inlet pressure of
500 psi.
• Low Pressure Bulk System requires a Secondary Regulator with a Maximum inlet
pressure of 200 psi.
NOTE: CO2connections require 3/8” I.D. tubing. All hoses must reach the back of the unit plus an
adequate amount of extra tubing to allow the unit to be pulled out for servicing.
NOTE: Two secondary regulators are required after the CO2supply. The dedicated secondary
regulator adjusted to 75 +/- 1 psig to supply the unit. It is highly recommended that this be
within 10 ft. of the unit and that the CO2source is not shared.
CO2Connections
Use a source-dedicated secondary regulator, fittings and clamps to connect the CO2line to the unit, as shown in
Figure 5. Set the regulator for 75 +/- 1 psig at the unit. Run the tubing for the CO2from the secondary regulator to
the unit and make all appropriate connections. Ideally, locate the regulator within 3 ft. of the unit. Another
secondary regulator is to be used to supply the Bag in Box pumps. It is to be set to 75 psig, not lower. Do not turn
on the CO2supply to the unit.

Viper Installation Manual
Publication Number: 621360041TBINS - 10 - © 2010-2016, Cornelius Inc.
Figure 5. Cylinder CO2Connection
Syrup Requirements
NOTE: Syrup connections require 3/8” I.D. tubing. All hoses must reach the back of the unit plus
an adequate amount of extra tubing to allow the unit to be pulled out for servicing.
Syrup Connections
Use the appropriate fittings and clamps to connect the syrup line to the unit. Run the tubing for the syrup (3/8 in.
ID, Min.) from the backroom to the unit and make all appropriate connections. Do not turn on the syrup supply to
the unit.
FCB Unit
ylppuS2O
C
BIB Syrup
BIB Syrup
BIB Pump
C
E
D
A
F
I
Water Filter
Connections
Tubing
1/2 Inch Beverage Tubing
3/8 Inch Beverage Tubing
1/4 Inch Beverage Tubing
3/8 Inch Tygon Tubing
A
B
C
D
E
F
1/2 Inch Hose Barb to 3/4 NPT
1/4 Inch Female Flare Nut and Barb (1/4)
Direct Connection to Syrup
Outlet on Syrup Pump
Direct Connection to CO2
Inlet on Syrup Pump
Direct Connection to Syrup
Inlet on Syrup Pump
1/2 to 3/8 Inch Fitting Reducer
Water Inlet
Syrup Line 1 Syrup Line 2
CO2 Inlet
BIB Syrup
BIB Syrup BIB Pump
C
E
D
G
BIB Pump
C
E
D
BIB Pump
C
E
D
Syrup Line 3 Syrup Line 4
G¼ Inch Cross Barb
K
H
J
HCO2 Regulator
I3/8 Inch TEE Barb
J3/8 Inch Flare Nut and Barb (3/8)
K3/8 to 1/4 Inch Fitting Reducer
H
H
B
Max 3 Feet
J
K
K
K
K
F
3 Feet Typical
115 Psig
75 Psig
75 Psig

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 11 - Publication Number: 621360041TBINS
Testing Power
The following procedure provides a minimal operational test of the power to the unit. Perform the procedure in
Table 3.
INSTALLING THE DRIP TRAY
Slide the drip tray into the two brackets protruding from the bottom of the unit until the tray contacts the two
detents in the brackets. See Figure 6.
Drip Tray
Mounting
Brackets
Figure 6.
CART INFORMATION AND MOUNTING
The Viper unit may be mounted on a mobile cart (Cornelius part no. 620043075 for 2-barrel unit, 620053990 for
3-barrel unit and 620046556 for 4-barrel unit) which allows some movement of the unit for service and cleaning.
There are four captive nuts on the bottom of the Viper to accommodate four 3/8-16 bolts. These bolts must be
installed to secure the unit to the cart.
These carts are also designed with movable wheels that act as outriggers to provide stability to the unit when it is
being moved.
!
WARNING:
The above listed mounting bolts must be installed and the wheels extended and locked in the outboard position
prior to moving the unit.
FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE.
This completes the initial installation of the unit. The following sections describe the control panel operation and
commissioning the unit.
Table 3.
Step Action
1 Verify the voltage being supplied to the unit. It should be between 215 and
245 Volts, measured at the wall outlet.
2 Plug in the unit power cord and turn on power to the unit.
3 The barrels are off when the unit is initially powered up and the unit displays
the “Water Out” message.
4 Unit powers up with Do Not Drink and Out of Product lights on.
5 If the unit displays normal startup operation, proceed to “Setting Up the
Control Panel” on page 12.

Viper Installation Manual
Publication Number: 621360041TBINS - 12 - © 2010-2016, Cornelius Inc.
CONTROL PANEL OVERVIEW
Behind the merchandiser is the control panel which includes the LCD display, shown in Figure 7. This panel
controls all the functions of the unit including defrost cycles, viscosity control, sensing of supply pressures and the
incoming line voltage as well as other functions and features.
BARREL
STATUS
12:51P
MAR 04
#1 FREEZE 65
#2 FREEZE 96
MENU OFF ON DFRST SPIN
Figure 7.
SETTING UPTHE CONTROL PANEL
When the unit is initially powered up, the Main Check menu, shown in Figure 8. is displayed.
INITIALIZING
PLEASE STAND BY
FLASH:
EEPROM:
Figure 8.
The software runs tests on the flash memory and the EEPROM. If they pass, PASS is displayed to the right of the
appropriate line and the system displays the System Check State screen, shown in Figure 9.
SW REV UI 000.003
I/O 000.002
MOTOR 000.001
STATUS 000.001
Figure 9.
Once the System Check State verification is complete, the display automatically displays the Barrel Status menu.
This is the normal or home screen for the system when the unit is running properly. It shows the status of all
barrels in the system, as shown in Figure 10. During initial power up, the barrel status is off, indicating that the
unit is in idle mode, with refrigeration off, product delivery off and the barrel motor off.

BARREL
STATUS
12:51P
MAR 04
#1 OFF
#2 OFF
MENU OFF ON DFRST SPIN
Viper Installation Manual
© 2010-2016, Cornelius Inc. - 13 - Publication Number: 621360041TBINS
Figure 10.
From this screen, all the other screens may be accessed. The following procedures are required for initial setup of
the unit.
• Set the Options
• Set the Clock
• Set the Sleep and Wake Times
• Set the Viscosity
Setting the System Options
The first items that should be set are the formatting options. These formatting options are located in the Option
Setup menu. To access the Option Setup menu, press the MENU button on the Barrel Status menu. This displays
the MAIN menu, shown in Figure 11. Then press the SETUP button to display the Option Setup menu, shown in
Figure 12.
SELECT
12:51P
MAR 04
UNIT DATA
ERROR STATUS
ERROR LOG
BACK MAIN SETUP MAINT GO
Figure 11.
Use the up and down arrows on the right side of the control panel to move between the various choices on the
display. When the OPTION SETUP selection is highlighted, press the GO button to access the menu. The Option
Setup menu (Figure 12.) is displayed.
SELECT
12:51P
MAR 04
CLOCK SETUP
EVENTS SETUP
VISC SETUP
BACK MAIN SETUP MAINT GO
OPTION SETUP
CO2 SETUP
BARREL MAINT
Figure 12.

Viper Installation Manual
Publication Number: 621360041TBINS - 14 - © 2010-2016, Cornelius Inc.
Setting the Clock
Highlight the CLOCK SETUP field from the Select menu, shown in Figure 12. This displays the Clock Setup
menu, shown in Figure 13. To set the time, perform the procedure in Table 4.
Figure 13.
To set the date, perform the procedure in Table 5. and refer to Figure 13.
Table 4.
Step Action Procedure
1 Set clock time Use the up and down arrows on the right side of
the control panel to highlight the TIME display on
the screen.
2 Select hour field Use the left and right arrows to select the hour
field
3 Set correct hour Use the + or - buttons at the bottom of the display
to set the proper hour.
4 Select minute field Use the left and right arrows to select the minute
field.
5 Set correct minute Use the + or - buttons at the bottom of the display
to set the proper minute.
6 Select AM/PM field If the 12 hour clock option is selected, use the left
and right arrows to select the AM/PM field.
7 Set AM/PM Use the + button at the bottom of the display to
set the AM/PM setting, if using 12 hour format.
Table 5.
Step Action Procedure
1 Set date Use the up and down arrows on the right side of
the control panel to highlight the DATE display on
the screen.
2 Select month field Use the left and right arrows to select the month
field
3 Set correct month Use the + or - buttons at the bottom of the display
to set the correct month.
4 Select day field Use the left and right arrows to select the day
field.
5 Set correct day Use the + or - buttons at the bottom of the display
to set the correct day.
6 Select year field Use the left and right arrows to select the year
field.
7 Set correct year Use the + or - buttons at the bottom of the display
to set the correct year.
CLOCK
SETUP
12:51P
MAR 04
TIME: 11:00 AM
DATE: 01/01/00
BACK CLOCK DST - +

Viper Installation Manual
© 2010-2016, Cornelius Inc. - 15 - Publication Number: 621360041TBINS
Setting Daylight Savings Time
Once the date and time are set properly, the daylight savings time settings can be done. Display the Daylight
Savings Time menu (Figure 14.) by pressing the DST button at the bottom of the display. To set daylight savings
time, perform the procedure in Table 6.
Figure 14.
When the daylight savings settings are complete, press the BACK button to save the settings and return to the
Select menu, shown in Figure 12.
Options Setup Menu
The Option Setup menu allows the user to set the various options available in the system. These options are
listed in Table 7. The functions of the display buttons change, depending on the highlighted selection on the
Option Setup screen. The Option Setup menu is shown in Figure 15.
Table 6.
Step Action Procedure
1 Set daylight savings
time
Press the DST button at the bottom of the display
to open the daylight savings time display, shown
in Figure 14..
2 Select DST Use the up and down arrows to select DST.
3 Set DST on Use the + button to turn on daylight savings time.
4 Select SPRING
MONTH
Use the up and down arrows to select SPRING
MONTH.
5 Set SPRING
MONTH
Use the + or - buttons at the bottom of the display
to set the correct month.
6 Select SPRING
WEEK
Use the up and down arrows to select SPRING
WEEK.
7 Set SPRING WEEK Use the + or - buttons at the bottom of the display
to set the correct week. The choices are 1, 2, 3 or
L.
8 Select FALL MONTH Use the up and down arrows to select FALL
MONTH.
9 Set FALL MONTH Use the + or - buttons at the bottom of the display
to set the correct month.
10 Select FALL WEEK Use the up and down arrows to select FALL
WEEK.
11 Set FALL WEEK Use the + or - buttons at the bottom of the display
to set the correct week. The choices are 1, 2, 3 or
L.
CLOCK
SETUP
12:51P
MAR 04
DST: ON
SPRING MONTH: MAR
SPRING WEEK: 1
FALL MONTH: OCT
FALL WEEK: L
BACK CLOCK DST - +

Viper Installation Manual
Publication Number: 621360041TBINS - 16 - © 2010-2016, Cornelius Inc.
Figure 15.
When all the options are set to the desired settings for the unit, press the BACK button to store these settings and
return to the Select menu, shown in Figure 12.
Setting the Temperature Format
The temperature format displayed by the unit may be set to either Centigrade or Fahrenheit. Press the oF button
to display readings in Fahrenheit and press the oC button to display readings in Centigrade.
Setting the Date Format
The date format can be displayed in either United States or European format. To display U.S. date format, press
the USA button. This displays the date in mm/dd/yy format. Press the EURO button to display the date in dd/mm/
yy format.
Setting the Time Format
Time format can be displayed in either 12 or 24 hour format. To display the clock settings in 12 hour format (1:08
P), press the 12 HR button. To display settings in 24 hour format (23:05), press the 24 HR button.
Setting the POS Lighting
POS Lighting is controlled by the POS LIGHTING field on the Option Setup menu (Figure 15.). To turn off the
merchandiser lighting, press the OFF button while the POS LIGHTING field is highlighted. To turn on the
merchandiser lighting permanently, press the ALWAYS button. To turn the merchandiser lighting on and off with
the Sleep settings, press the SLEEP button.
Setting the Type of Syrup
Syrup type for each barrel may be selected by highlighting the desired barrel and pressing the appropriate button,
FCB, FCB-L, FUB or FUB-L. FCB is for Frozen Carbonated Beverage, FCB-L is for Frozen Carbonated
Beverages - Light (diet), FUB is for Frozen Un-carbonated Beverages and FUB-L is for Frozen Un-carbonated
Beverages - Light (diet). Each of these settings provides the proper viscosity and temperature settings for the
type of syrup being used.
Table 7.
Option Button 2 Button 3 Button 4 Button 5
Temp Format oFoC
Date Format USA EURO
Time Format 12 HR 24 HR
POS Lighting OFF ALWAYS SLEEP
#1 SYRUP TYPE FCB FCB-L FUB FUB-L
#X SYRUP TYPE FCB FCB-L FUB FUB-L
OPTION
SETUP
12:51P
MAR 04
BACK oF oC
#1 SYRUP TYPE: FCB
TEMP FORMAT oF
DATE FORMAT USA
TIME FORMAT 12 HR
POS LIGHTING ALWAYS
#2 SYRUP TYPE: FCB
