CORNING Crimplok+ Connector 8700 APC SM 250/900 mm User manual

P/N 78-0015-3873-1
Issue 2
Standard Recommended Procedure 78-0015-3873-1 | Issue 2 | September 2019 | Page 1 of 4
related literature | Search corning.com/opcomm. Click on “Resources/Standard Recommended Procedures.”
Crimplok™+ Connector 8700 APC SM 250/900 μm
Quick Reference Guide
SAFETY PRECAUTIONS
Protective Eyewear
CAUTION
Safety glasses should be worn when handling chemicals and cleaving the optical ber.
Chemical Precautions
CAUTION
Storage, use and disposal of isopropyl alcohol and methanolwater solution should be per your company health, safety and environmental
instructions. Refer to Safety Data Sheet (SDS) for health hazards, safe handling, proper use and control measures.
Bare Fiber Handling
CAUTION
Cleaved glass bers are sharp and can pierce the skin. Use tweezers when handling shards and dispose of them properly per your company health
and safety instructions.
Fiber Cable Handling
NOTICE
Optical ber can be damaged by excessive tensile, compressive and bending forces. Consult the manufacturer’s specications for proper handling
instructions.
Laser Safety
CAUTION
Take the proper precautions when working with optical ber because invisible laser light may be present. The principal laser hazard when working
with ber optics is injury to the eye. Never look directly into the end of a ber or connector using the naked eye, a view scope or a microscope when
connected to a laser source.

Standard Recommended Procedure 78-0015-3873-1 | Issue 2 | September 2019 | Page 2 of 4
1 2 3
4 5 6
7 8 9
10 11 12
Tool is set for 900 μm ber.
For 250 μm ber rotate ber
holder pad to the 250 mark. Insert Crimplok™+ Connector
Strip ber 40 mm
900 μm coating
edge, 24 mm
cleave length
250 μm coating
edge, 19 mm
cleave length
Optional– place
mark on buer at
edge of cleaver.
Insert ber
Ensure cap is still right justied
during insertion.
12
3
020 mm 40 mm
40 mm
IPA or
cleaner
Test ber to
ensure no
nick damage.
Ensure cap is aligned all the way to the right
╳
✓
Hold Crimplok+ connector
with thumb and rotate the
lever up to 90° and back
down to seat connector
and set cap to the right.

Standard Recommended Procedure 78-0015-3873-1 | Issue 2 | September 2019 | Page 3 of 4
13 14 15a
15b16 17
18 19 20
21 22 23
Check tension
Press rmly
Check for bow lift before
actuation arm is vertical
Apply and center lapping lm to
orange pad.
Spray distilled water
2X on lapping lm
Push down
until it clicks
Push button
Turn until
stop
Need to
re-clean
Thread caught,
re-clean with
a twist
Remove Crimplok+
connector & clean
1. Dry o water
2. Clean with alcohol
or cleaner
3. Dry o & twist
Top image activated, bottom image
not activated
Remove Crimplok™+ Connector
from tool
Buer mark will move left
during bow lift
╳
✓

Standard Recommended Procedure 78-0015-3873-1 | Issue 2 | September 2019 | Page 4 of 4
Corning Optical Communications LLC • 4200 Corning Place • Charlotte, NC 28216 USA
800-743-2675 • FAX: [phone] • International: [phone] • www.corning.com/opcomm
Corning Optical Communications reserves the right to improve, enhance, and modify the features and specications of Corning Optical Communications products without
prior notication. A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other trademarks are
the properties of their respective owners. Corning Optical Communications is ISO 9001 certied. © 2019 Corning Optical Communications. All rights reserved.
Caution reminder: Never look directly
into the end of a fiber or connector
when connected to a laser light source
using the naked eye or a microscope.
╳
✓✓
Ideal clean ber end face
Thin black line is visible
Light grey Dark grey
No line, just grey to white
Chips or cracks inside the ½ diameter circle are not allowed.
Fiber is missing, strip,
go to step 3
Acceptable chip
