Courtyard Creations TGS38HS User manual

5
1
222
2
FIGURE 1
PAGE 1 OF 2 COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!
Attention:
Make sure that each bolt needed for all steps match
the corresponding figure to ensure proper assembly.
STEP 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with the underside facing upwards.
Fasten the legs (#2) to the plastic holders attached
on the table top rim by using screws (#5).
See Figure 1.
NUT WRENCH 10&13MM
HEX.KEY WRENCH 6MM
BOLT CAP M6
PLASTIC NUT M6*P1.0
WASHER d6.5*D13*1.0
BOLT M6*60
BOLT M6*40
SCREW ST4.2*12
U-SHAPED WASHER
CENTER
CONNECTOR WITH RING
LEG
TABLE TOP
17KAB1101----Y4
1800337002
17KAA0201----Y4
1800C23001
17FA05040301-Y4
17C01A0721091Y4
17C01A0714003Y4
17C17A0403001Y4
27LA09076
62TGS38HSY101
TGS36HY-CS02
TGS38HS-CS01
1
1
8
8
16
4
11
10
12
9
8
7
4
4
4
1
6
1
4
5
4
2
3
Q’TY Q’TY
1
PART PART
MATERIAL CODE MATERIAL CODE
PART
NO. PART
NO.
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
TGS38HS-WM
PARTS LIST
You will need the following tools:
- Phillips Screwdriver (Not included)
- Nut Wrench (See Part #12)
- Hex. Key Wrench (See Part #11)
Do not sit or stand on this table.
A weighted umbrella base must be used when using an umbrella with this table.
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
Keep children away during assembly. This item contains small parts which can be swallowed by children.
Children should always be under direct adult supervision while using the product.
Retain the assembly instructions for future reference.
Please quote following FQC NO. when contacting service center.
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
!
!
!
!
!
!

FIGURE 3
#7 BOLT M6*60
#6 BOLT M6*40
40
60
2
2
3
22
3
9
9
8
8
4
8
8
10
610
FIGURE 2
Cleaning and Maintenance
•Wash frame parts with mild soap and water, rinse thoroughly, and dry frame completely. Do not use bleach,
acid, or other solvents on the frame parts.
•Wash glass with mild soap and water, rinse thoroughly, and dry glass completely.
•Please inspect and tighten all bolts and fasteners on a regular basis to ensure proper performance and
safety of your table.
•When moving the table, remove the umbrella. Do not drag.
•We recommend the use of furniture covers when not in use.
•In order to prolong the life and beauty of your table, we recommend it be stored in a dry and protected area
during off season periods.
• Tempered glass has been used for increased strength and safety of your table. However, during windy
conditions the umbrella should be lowered and/or removed.
NOTE:
To use an umbrella with this table, please remove the
plastic center plug and put the umbrella pole through
the table top and center connector ring.
STOP DON’T RETURN TO STORE!
PAGE 2 OF 2
STEP 3:
Turn the table to its upright position. See Figure 3.
STEP 2:
Fasten the center connector with ring (#3) to the middle
of the legs (#2) by using bolts (#6 and #7), washers (#4
and #8) and plastic nuts (#9). Make sure that all of the
bolts have been tightened completely, and then cover
them with bolt caps (#10). See Figure 2.
