Coway AIRMEGA Icon User manual
Find out the application pairing guide with the link provided below :https://iocare.coway.com/manual/us/air/airmegaicons.html
∗Coway air puriers have been proven to trap dust, pollen, dander, viruses and bacteria in the air based on KCL(Korea Conformity Laboratories)
testing. They have been tested in a 30m3 size chamber according to the Korea Air Cleaning Association standard (SPS-KACA 002-132:2018
Modied) to measure the 0.01size of particle removal rate. It was tested on maximum fan speed in normal room temperature and humidity
conditions. The performance may vary in the actual living environment of customers.
FRONT/전면/前
2
2
1
1
Removes large dust particles, mold, hair, and pet hair.Activated Carbon captures and reduces VOCs and odors such as NH3, CH3CHO. Also Green True HEPATM reduces airborne particles, allergens, and contaminants.
Wireless Charging
Location Guide ∗Use the wireless charging location guide if the device
has a smooth surface. Vibration may cause the device
to stray away from the charging station.
Find out the application pairing guide with the link provided below :https://iocare.coway.com/manual/us/air/airmegaicons.html
The following symbols are used in this manual to explain procedures, restrictions, handling precautions, and instructions that should be observed for safety.Read and follow all the safety tips and warnings before using the product.Death or serious injury may occur if the instruction is not followed.Severe injury or property damage may occur if the instruction is not followed.Minor injury or property damage may occur if the instruction is not followed.• Do not use a damaged power plug or loose power outlet.• Make sure to connect the power plug to a grounded 120 V~ 60 Hz outlet.• Do not pull on the power cord to move the product.• Do not touch the power plug with wet hands.• Do not bend the power cord excessively or put it under a heavy object to avoid damage or deformation.• Do not plug and unplug the power cord repeatedly.
• When the power area comes into contact with water, unplug the power plug and dry it thoroughly before use.
Power
• Do not pull on the power cord to unplug it.• Plug the product into an outlet connected to an electric leakage breaker (sensitivity current less than 30 mA).• Do not remove or move the power plug during operation.• If there is any strange noise, smell, or fumes from the product during operation, remove the power plug immediately and contact the service center.• Do not install the product near an electric heating device.• Do not install the product in a location that is highly humid, dusty, or exposed to splashes of water (rain).• Do not use or store flammable gas or substance near the product.• Do not install too close to the wall.Installation• Make sure to unplug the power cord before repairing or inspecting the product or changing its parts.• Completely wipe off dust, water, etc. on the power plug’s pins and areas of contact with the pins.• Do not connect multiple electronic devices to one power outlet. Always use a separate outlet for the product.• Leave the power cord unplugged when not using the product for a long time.• If the power cord is damaged, do not attempt to replace the cord. Instead, contact the service center to replace it.
• If there is any strange noise, burning smell, or smoke from the product, immediately unplug the power cord and contact the service center.• Never immerse the product in water.• Do not spray flammable substances, such as pesticide or air freshener, into the air inlet.• Do not arbitrarily open, repair, or improve the product.• Do not place a bowl filled with water, chemicals, food, small metals, or flammable substances on top of the product.• Unplug the power cord before cleaning the product.• If the product falls during use and gets wet, be sure to have it inspected by the service center before using it again.
• Do not spray water or use benzene or thinner on the product to clean it.
• Do not insert a sharp object such as drill into the air quality sensor.During Use• Do not apply excessive force or shock to the product.• Use the product at a distance of not less than 20cm from the walls and surrounding objects.• Install the product where there is no obstruction in its front, rear, left, or right to allow smooth air circulation.• Maintain at least 2 m from electronic appliances such as television.
• Do not use the product in a place where there is much odor, smoke, or grease around it such as in a restaurant or barbecue place.
• Do not use the product under direct sunlight.• Install the product on a flat floor.• Do not use the product in a place where it can be in direct contact with water, such as public bathroom, shower room, or swimming pool.
Read and follow all the safety tips and warnings before using the product.Wireless Charging• Use devices with the wireless charging function of international standards only. Charging speed may vary depending on the charging item.• Do not place cards and metallic objects between the wireless charging area and the phone. It may stop charging or cause the metallic material to heat up and overheat.• Do not place a separate wireless charging patch or wireless charging cover alone in the wireless charging area. It may generate excessive heat in the product, which may cause burns, malfunction, or fire.• If you place a tempered glass on the wireless charging area, it may not be charged.• The device's protective case may prevent it from charging.• Metal material, holder, and smart ring may delay or stop charging.• Depending on the thickness of the protective case, charging may be delayed or stopped.• When using a wallet/card-type case, charging may delay or stop due to the card's thickness.• Remove the card from the case before charging. Magnetic materials such as credit cards may cause information damage.• Place the user's device in the wireless charging area and check whether charging is proceeding normally through the device.
• Do not apply force on the product.• Do not touch the device or the wireless charging area with wet hands while charging the device.• If water is spilled on the wireless charging area, unplug the power cord and wipe with a dry towel to dry.• If the wireless charging area is damaged, do not use it in a damaged state and get an A/S for use.• Please level the product before use.Wireless ChargingLocation GuideMobile Phone
• Do not spill colored liquids or scribble on the product's front cover (fabric). It may cause stains and contamination.• If you frequently touch the fabric on the front of the product with your hands, it may cause contamination. For dust removal and cleaning, lightly wipe with a duster or soft cloth.• If the front cover (fabric) is dirty, do not wash it with water. It may cause discoloration and spread of contamination.• Staining and contamination of the cover (fabric) due to the customer's negligence are subject to service at cost.• Do not place the front cover near high temperatures or fire. It may deform the cover and may cause a fire.Front Cover (Fabric)
Check the parts of the product (exterior in the front and top view and control panel) and how they function.Check the parts and functions of the exterior of the product.
Check the parts of the product (exterior in the front and top view and control panel) and how they function.After 30 seconds, the control panel buttons will switch off automatically. Please press any control panel buttons to reactivate the control panel light.1
1
2
2
3
3
6
6
4
4
5
5
1
Use the button to turn the product on and off.3
When the filter replacement indicator is turned on, press the corresponding button for more than 3 seconds after cleaning and replacing the filter.
5
Touch the Wi-Fi button to connect to a Wi-Fi network.When connected to Wi-Fi, the status indicator's light will turn on.5
Touch this button to automatically turn off after an hour, 4 hours, or 8 hours.Touch the timer button until the indicator light displays the desired time.
6
The concentration of the ultra-fine dust (PM 2.5) is displayed at the top and bottom.2
Press the Mode button to switch the mode in the order of SMART, SLEEP, and ECO.4
Toggle the air quality and other indicators on and off by pressing the light button.
Make sure that the power cord is unplugged before opening the covers.
FRONT/전면/前
2
1
1
2
This product is for 120 V~ 60 Hz use only. Make sure your power supply meets these requirements.Find out the application pairing guide with the link provided below :https://iocare.coway.com/manual/us/air/airmegaicons.htmlWhile the product is operating, press and hold the mode button for about 3 seconds to enter the bluetooth pairing mode.While the product is operating, press the Wi-Fi button to turn on Wi-Fi.While the product is operating, press and hold the light and Wi-Fi buttons at the same time for about 3 seconds to access the AP Mode.While the product is operating, press and hold the Wi-Fi button for about 3 seconds to turn off Wi-Fi.
When your filters are prepared, connect the power and turn on the air purifier.
When pressing the mode button during an operation, it switches to manual mode.
When set to Eco mode and the indoor air quality level is kept clean for more than 10 minutes, the fan stops operating for up to 30 minutes. If the indoor air quality worsens by continuously detecting particles, the fan will operate immediately even when the fan has stopped to purify the indoor air quality. After the fan re-operates, if the indoor air quality remains clean for more than 10 minutes, the fan repeats on and off.
If the mode button and the light button are not pressed for 10 seconds, the selected sensitivity of the sensor is automatically entered.
When the product is operated for the first time, the air quality sensor is set to default sensitivity. If the air quality level remains high after running the air purifier for more than 2 hours, or if the air quality level stays clean after operating the air purifier for more than 1 hour, increase or decrease the sensor sensitivity.
