Coway AP-3008FH User manual

Coway Air Purier AP-3008FH
• This product is for domestic use only. It cannot be used in an overseas country where the power
voltage is dierent.
• Warranty card is included in this user’s manual.
• Read and save these instructions.

1. Excellent Air Purication Performance
The HEPA lter treated with organic antibacterial materials, and
which has a powerful anti-bacterial/anti-mold eect, is used to
eliminate ne indoor particles and germs suspended in the air. The
unit’s lter system has been optimized to remove indoor pollutants
fast and eectively.
2. Custom Filter
A customized lter system has been adopted so that customers can
select one of 3 types of custom lters: anti-micro-organisms, ozone
or oil mist lters.
3. 4-step Auto Operating Dust and Odor Sensors
The dust and odor sensors check the indoor air quality in real time
enabling the automated control of the airow speed depending
on the air pollution level when auto mode is selected in order to
maximize purication while minimizing power consumption.
4. Various Operating Modes
The following convenient deodorization modes are provided, oering
improved deodorization performance: Auto mode which operates
automatically by detecting odor and dust pollution levels, A3 power
saving mode minimizes power consumption, and Swing mode
circulates air three-dimensionally.
FEATURES

FOR INFORMATION
MAINTENANCE
HOW TO USE
OTHERS
| 03 |
SAFETY INFORMATION
Danger
Warning
Caution
| 06 |
PARTS NAME
| 08 |
AIR PURIFIED PROCESS
| 09 |
PREPARATIONS
How to Install Filter
| 10 |
HOW TO USE
| 12 |
ADJUST PARTICLE SENSOR
| 13 |
CLEANING METHOD
| 15 |
FILTER REPLACEMENT
| 17 |
TROUBLESHOOTING
| 18 |
SPECIFICATION
| 21 |
WARRANTY CARD
CONTENTS
- Please keep the User’s Manual where it can be readily reached or found. -
Thank you for using the coway air purier.
Please read the user’s manual to use and maintain the product correctly.
If you encounter a problem while using the product, you may easily solve the problem by referring
to the user’s manual. As this manual contains the product warranty card,
please keep it in a safe place.
DEAR CUSTOMERS
2
1
FEATURES / CONTENTS
Coway

SAFETY INFORMATION
The following information is for user
safety that should be observed.
It is to ensure user safety and prevent property damage.
Please read the precautions carefully and use the
product correctly.
for 220 V - 240 V use only for 120 V use only
Danger : Failing to follow the precautions below may result
in may lead serious injury or even death.
• Do not use a damaged power plug or loose electric outlet.
• Please connect the power plug to a dedicated grounded
electrical outlet for 220 V - 240 V~ 50 Hz / 60 Hz.
• Do not move the product by pulling only the power cord.
• Do not handle the power plug with wet hands.
• Do not forcefully bend the power cord or place it under a heavy
object to prevent it from being damaged or deformed.
• Do not repeatedly connect and disconnect the power plug.
• If the electric outlet is wet, carefully unplug the product and let
the electric outlet dry completely before subsequent use.
• Make sure to unplug the product before repairing, inspecting or
replacing a part.
• Remove any dust or water from the power plug.
• Do not plug the product into an electrical outlet or power strip
that is being used by several other appliances. Use an electrical
outlet dedicated to the product.
• Unplug the system if it is not used for a long time.
• Do not attempt to repair or modify the power cord yourself.
• If the power cord is damaged, do not replace the cord yourself.
Call a service center to have it replaced.
• Do not install the product near a heating device.
• Do not install the product in locations exposed to moisture or
water (rainwater).

4
3
• Do not use the product in areas where ammable gases or
combustible materials are used or stored.
• Do not insert sharp objects such as a gimlet into the pollution
sensor.
• If the product produces a strange noise, burning smell or smoke,
unplug it from the electrical outlet immediately and call our
service center.
• Never place the product in water.
• Do not spray any ammable materials such as insecticides or air
fragrances near or into the air inlet.
• Do not disassemble, repair, or modify the product at your own
discretion.
• Do not place any containers with water, medicine, food, metallic
objects or ammable material on top of the product.
• Unplug the system before cleaning it.
• Clean Clean by spraying water directly and do not clean the
product using benzene or thinner.
• Use the product for home or business use according to the
model.
• Do not use the air purier in a factory or industrial setting where
machine oil may be present in the air.
SAFETY INFORMATION | Danger
For Information

Warning : Failing to follow the precautions below may
result in considerable physical injury or property
damage.
• Do not insert ngers or foreign objects into the air inlet or outlet.
• Do not let children hang on to the product or climb on it.
• When removing the front cover, exercise caution that a part of
your body or any kind of object does not become stuck in the
top part of the product.
• This appliance can be used by children aged from 8 years and
above.
Caution : Failing to follow the precautions below may result
in slight physical injury or property damage.
• Do not install the product on a sloped surface.
• Do not apply force or impact to the product.
• When the product is in use, maintain a distance of at least 20 cm
from the walls or adjacent objects and 30 to 60 cm above the
product.
• Install the product so that no obstacles block the circulation of
air around the product.
• Install the air purier away from strong articial lighting or direct
sunlight.
• Install the air purier at least 2 m away from electronic appliances
such as a TV.
• Do not install the air purier in a location exposed to direct
sunlight.
• Replace the lters according to the lter replacement cycles.
• Clean the Pre-lter with water regularly and dry it completely
before use.
SAFETY INFORMATION

6
5
PARTS NAME
1
2
3
4
5
Front / Rear
Operation Part
1 Display
2 Buttons
3 Pollution
sensor
4 Handle
5 Front cover
6 Air inlet
1 Swing air
outlet
2 Air outlet
3 Product
support
4 Wheel
5 Power cord
6
4
5
3
2
1
1 2 3 4
Shows the indoor air pollution level measured by the dust and odor sensors in real time.
The color changes depending on the pollution level. (Blue → Light Purple → Dark Purple → Red)
1 Air quality indicator
The indicator corresponding to the selected operating mode is turned on.
In Manual mode, all mode indicators are turned off.
3 Mode indicators
When the filter replacement cycle is reached, the indicator is turned on.
5 Filter replacement indicator
Whenever the Airflow speed button is pressed, the indicator changes in the following order:
Step 1
→
Step 2
→
Step 3
→
Step 4
→
Turbo.
In the Auto, Deodorization and A3 power saving modes, the airflow speed is automatically controlled by the air
pollution level.
2 Speed indicator
When the Swing function is selected, this indicator is turned on.
∗
Swing function : A function that distributes purified air uniformly into the room to reduce the pollution
density in a short time.
4 Swing indicator
5
For Information SAFETY INFORMATION | Warning | Caution / PARTS NAME

Indication Part
PARTS NAME
1
5
1 2 3 4
Filer Replacement Airow Speed Display
When the 4-month lter needs
to be replaced.
When the 12-month lter
needs to be replaced.
*
Press and hold down the Filter Replacement button for 2 seconds after replacing the filter to reset the filter replacement
cycle timer.
Use it to turn the air purifier on or off.
6 Power button
The light sensor detects the surrounding ambient light and turns the air purifier to Silent mode
at night. This applies to AUTO and A3 modes only.
1 Light sensor
Use it to select an operating mode.
Whenever the Mode button is pressed, the operating mode changes in the following order:
Auto → Deodorization → Silent → A3 Power Saving.
3 Mode button
If the Filter replacement cycle indicator is turned on, press and hold the reset button for approximately 2
seconds so that the indicator for the filter corresponding to the replacement cycle is turned on.
5 Filter reset button
Use it to select an airflow speed.
Whenever the Airflow speed button is pressed, the airflow speed changes in the following order: Step 1
→ Step 2 → Step 3 → Step 4 → Turbo.
2 Airflow speed button
Use it to activate or deactivate the swing function.
The swing function moves the swing grill of the rear air outlet forwards and backwards so that the
direction of the air is changed.
4 Swing button
Odor sensor

8
7
AIR PURIFIED PROCESS
Air Puried System
▶ ▶
1. Pre-lter 2. Non-woven fabric lter 3. Custom lter
▶
4. Deodorization lter 5. HEPA lter
▶
It removes relatively large dust and mold, human hair, pet hair, and so on.
(Treated with the antibacterial material)
Pre-filter
Located in front of the Custom filter, the Non-woven fabric filter removes dust and hair and protects the Custom
filter and Deodorization filter.
Non-woven fabric filter
Customers can select one of 3 types of custom filters according to their requirements:
anti-microorganism, ozone or oil mist filters.
Custom filter
The activated carbon particles of the Deodorization filter effectively eliminate food odors and unpleasant
household smells.
Deodorization filter
The high-performance composite HEPA filter effectively removes fine dust and cigarette smoke while the
antibacterial and anti-mold functions of the organic antibacterial materials eliminate germs and mold.
HEPA filter
For Information PARTS NAME / AIR PURIFIED PROCESS

How to install lter
Tips
- Make sure to remove each filter’s plastic packaging before installing the filters.
- Select the product model depending on your requirements.
- Use the product only within a single room.
- When the unit is not in use, disconnect the power plug from the electric outlet.
- Check the front part of the filter when installing it.
▶ The filter order: Pre-filter → Non-woven fabric filter → Custom filter →
Deodorization filter → HEPA filter
PREPARATIONS
▶
▶
▶
▶
▶
'30/5
'30/5
'30/5
▶ ▶ ▶
1. Open the front cover.
Turn the lock at the bottom part of the product
counterclockwise while pressing it using a coin or
flat-head screwdriver, pull the front cover forwards,
and then lift the cover upwards to separate it.
2. Remove Remove the filter case.
Separate the first filter case from the product by
pressing the catches on both sides and pulling it
forwards. Separate the second filter case from the
product by pulling it forwards after removing the
top and bottom screws.
3. Remove the plastic packaging from the Custom,
Deodorization and HEPA filters and insert them
into the filter case in this order.
4. Install the filter cases into the product and close the front cover.
∗
After installing the second filter case, make sure to fasten the top and bottom screws.
∗
After closing the front cover, close the lock at the bottom part of the product by turning it clockwise while pressing it.
▶
01&/
$-04&

Tips
- Connect the power plug to the electrical outlet before operating the product.
- When the air purifier is turned on, it automatically operates in Auto mode.
Do not insert a pin, foreign object or water into the air outlet or into the unit.
This may result in physical injury or a product malfunction.
When moving the product, move the product using the wheels while holding both
handles.
10
9
HOW TO USE
To Operate the Manual Mode
To Select the Auto Mode
Turn the product on by pressing the Power
button and select an airflow speed by pressing
the Airflow speed button. Step 1 → Step 2 →
Step 3
→ Step 4 → Turbo
∗
If the Airflow speed button is pressed during an
operating mode (Auto / Deodorization / Silent / A3 Power Saving), the unit immediately turns to manual mode.
Turn the product on by pressing the Power button
and select a mode by pressing the Mode button.
Auto → Deodorization → Silent → A3 Power
Saving
▶
Automatically controls the airow speed (Step 1, 2, 3 and 4) according to the air pollution level detected by the dust
and odor sensors in order to purify the air more eectively. This operating mode is appropriate for general users.
Increases the odor sensor sensitivity by 50%. Controls the airow speed according to a higher pollution level from
among the levels detected by the dust and the odor sensors to purify the air more eectively.
Decreases the airow speed to under Step 1 for a quiet, pleasant atmosphere.
When the pollution level remains at level 1 for 10 minutes, the product switches to A3 power saving mode. A3
power saving mode is cancelled if the pollution level rises to level 2 or higher. When A3 power saving mode
continues for 30 successive minutes, A3 power saving mode is temporarily cancelled and the airow speed is set to
Step 1 to circulate the surrounding air. When the product operates in A3 power saving mode, all indicators except
for the A3 mode indicator are turned o.
▶ Auto mode
▶ Deodorization mode
▶ Silent mode
▶ A3 power saving mode
Pollution level 1 Pollution level 2 Pollution level 3 Power saving mode
Airow speed Step 1 Step 2 Step 3 The fan stops.
PREPARATIONS / HOW TO USE
How to Use

To Run Swing Mode
Silent mode (Auto / A3 power saving)
▶
If the Swing button is pressed, the airflow direction
is changed as the swing grill moves forwards and
backwards. To fix the swing grill, press the Sing button
again.
∗
When the Swing function runs, the Swing indicator on the
control panel is turned on.
∗
The swing function is automatically turned off
6 hours after activation.
▶
When it becomes dark when the air purifier operates in
AUTO/A3 power saving mode, it automatically switches
to Silent mode with a low airflow speed, low noise, and
low power consumption.
When the surroundings become light again, Silent mode
switches back to Auto / A3 power saving mode.
∗
When Silent mode runs, the Silent mode indicator
on the control panel is turned on.
HOW TO USE

ADJUST PARTICLE SENSOR
1. While the air purifier is in operation, press and hold the Airflow speed and
Mode buttons at the same time for 2 seconds or more.
2. The Airflow speed indicator blinks at an interval of approximately 0.5 seconds.
3. Adjust the sensor sensitivity by pressing the Airflow speed button. The sensitivity
of the sensor is represented by the blinking airflow speed indicator.
4. When the Airflow speed and Mode buttons are pressed and held
simultaneously for 2 seconds or more, the system returns to normal operation,
saving the sensitivity setting.
∗
If no button is pressed for 10 seconds, the current sensitivity is automatically saved.
When the product is shipped, the pollution sensor is set to normal sensitivity. If the pollution level stays at
the highest level after 2 hours of operating or stays at the lowest level for more than 1 hour when the air
does not appear clean, users can adjust the sensitivity of the sensor.
Step 1 Step 2 Step 3
Sensitive Normal Insensitive
12
11
HOW TO USE / ADJUST PARTICLE SENSOR
How to Use

CLEANING METHOD
Tips
- Always unplug the unit before cleaning it.
- Do not use detergents that contain organic solvents (solvent, thinner, etc), bleach,
chlorine, or abrasives.
- Do not place the unit into water or spray water onto it.
Cleaning Air Inlet and Outlet (every 2 months)
Cleaning Particle Sensor (every 2 months)
Cleaning front cover
Cleaning the Unit
Clean the air inlet and outlet using a soft brush or vacuum cleaner.
∗
Take care that dust does not enter the air purifier.
1. Clean the air inlet and outlet of the pollution sensor using a soft brush or
vacuum cleaner.
∗
Take caution that dust does not enter the air purifier.
Air outlet Air inlet
▶
▶
2. Open the pollution sensor cover on the right
side of the product. Use a damp cotton
swab and clean the lens, dust inlet, and
dust outlet. Use a dry cotton swab to
remove any remaining moisture.
∗
Without regular cleaning the performance
of the pollution sensor will deteriorate.
Air outlet Dust outlet
Dust inlet
Air inlet
▶
▶
▶
▶
▶
Separate the front cover from the unit and remove any dust attached to the
surface with a soft cloth or brush. Use a damp cloth if the contamination is serious.
(However, do not use abrasives.)
␙ᇎ⽾⛺⛚␙ᇎ⽾⛺⛚
Use a dry, soft cloth to clean the product body. Use a damp cloth if the
contamination is serious. (However, do not use abrasives.)

Tips
- Always unplug the unit before cleaning the filters.
- The Pre-filter is reusable by removing dust or cleaning it with water.
- If the Pre-filter is not cleaned for a long time, the product performance may deteriorate.
- The Non-woven fabric, Multifunctional, Deodorization and HEPA filters cannot be reused even when cleaned.
- Do not clean them with water.
14
13
Cleaning Pre-lter (every 2 - 4 weeks)
1. Turn the lock at the bottom of the product
counterclockwise using a coin or flat-head
screwdriver, pull the front cover forwards, and
then lift the cover upwards to separate it.
∗
Take caution that dust does not enter the air purifier.
2. Separate the first filter case from the product by pulling it forwards while
pressing the catches on both sides.
3. Separate the Pre-filter by pulling it to the right.
∗
To prevent dust from falling from the filter, remove the filter carefully.
4. Clean the filter with a vacuum cleaner or with water depending on the
level of contamination.
5. When the moisture has completely dried, install the Pre-filter by pushing it into the product
completely.
∗
Install the front cover onto the product.
▶
01&/
$-04&
▶▶
CLEANING METHOD
Maintenance

FILTER REPLACEMENT
Tips
- Replace the filters referring to “Installing the filters” on page 9.
- Check that the ‘front’ of each filter is facing in the correct direction.
- To maintain the optimal performance of the product, use the original Coway filters.
- Always unplug the unit before replacing the filters.
Replacing the Non-Woven Fabric lter (every 4 months)
Replacing the Custom lter (every 4 months)
1. Open the front cover, separate the filter case from the product, and then remove the Custom filter from the filter
case.
2. Separate the Non-woven fabric filter attached to the Custom filter and
replace the filter.
3. Install the Custom filter into the filter case so that the Non-woven fabric filter is facing forwards. Reassemble the
filter case and the product, close the front cover and then close the lock.
▶ ▶▶
'30/5
01&/
$-04&
▶▶
1. Open the front cover, separate the first filter case from the product, and then remove the Custom filter from the
filter case.
▶ ▶▶
'30/5
01&/
$-04&

2. Remove the plastic packaging from the new
Custom filter and install the filter into the filter
case so that the Non-woven fabric filter is
facing forwards. Reassemble the filter case with
the product, close the front cover, and then
close the lock.
▶
01&/
$-04&
16
15
Replacing the Deodorization lter / HEPA lter (every 12 months)
Filter cleaning and replacement cycle
1. Open the front cover, and separate the first filter case from the product. Remove the top and bottom
screws from the second filter case and then pull it forwards to separate it from the product.
2. Separate the first filter case from the product by pulling it forwards while pressing the catches on both sides.
Reassemble the filter case and the product, close the front cover, and then close the lock.
'30/5
'30/5
▶▶
▶ ▶▶
01&/
$-04&
Filter Filter cleaning and replacement cycle Cleaning / Replacement
Pre-lter Every 2 ~ 4 weeks Cleaning and washing
Non-Woven Fabric lter/Custom Filter Every 4 Months Replacement
Deodorization lter/HEPA lter Every 12 Months Replacement
Each service life is based on 24-hour use in Auto mode.
The filter replacement cycle is a recommendation and may differ depending on the operating environment.
FILTER REPLACEMENT
Maintenance

TROUBLESHOOTIONG
The air purifier may operate abnormally because of a minor issue or because the user is unfamiliar with the
product and not because of a product malfunction. In such a case, problems can be solved easily without
help from the Service Center by checking the following. If the problem remains unsolved, please call our
Service Center.
Symptom Check Measures to take
No air is
blowing.
• Is the power cord connected?
Connect the power cord to an electric outlet for
220 V - 240 V~ 50Hz / 60 Hz.
• Is the display completely turned o? Press the power button and then select a function.
• Has the power gone o? Use the air purier after the power has turned on
again.
• Is the front cover closed? Close the front cover properly.
• Is the Swing grill in the right position? Use the air purier after turning the power o and
then on again.
The airow
speed does not
change.
• Is the Auto indicator turned on? The airow speed can only be selected in manual
mode (normal).
• Is the room dark? The airow speed cannot be selected in Silent
mode (normal).
The airow is
signicantly low.
• Have the lter cleaning and replacement times
passed?
Check the lter cleaning and replacement cycle and
then clean or replace the lter(s) if necessary.
The pollution
level does not
change.
• Is the pollution sensor contaminated by dust? Clean the pollution sensor (refer to p.13).
• Does the pollution level keep indicating a high
level?
Set the pollution sensor sensitivity to Insensitive or
Normal (refer to p. 12).
• Does the pollution level keep indicating a low
level?
Set the pollution sensor sensitivity to Sensitive or
Normal (refer to p. 12).
A bad smell is
coming from the
air outlet.
• Have the lter cleaning and replacement times
passed?
Check the lter cleaning and replacement cycle and
then clean or replace the lter(s) if necessary.
The pollution
level indicator
blinks.
• Request service or contact our Service Center.
When
other functional
problems are
detected.
• Check the symptoms, unplug the product, and then request service or contact our Service Center.

18
17
SPECIFICATION
The specifications are subject to minor changes to improve the product performance.
Product Name Air Purier
Model AP-3008FH
Rated Power Source Reverse Osmosis
Rated Voltage 220 V - 240 V~ 50 Hz / 60 Hz
Phase Single Phase
Power Consumption 106 W
Product Insulation Grade Grade 2 Device
Dust collecting method Mechanical dust trapping (HEPA lter)
Safety Devices Power is cut o when the door is opened or closed.
Installation location For indoors
Dimensions 600 mm(W) X 420 mm(D) X 956 mm(H)
Weight 25 kg
Others TROUBLESHOOTING / SPECIFICATION

MEMO
