Creative Muvo V200_QSG User manual

1
Your Player At A Glance
Liquid Crystal
Display (LCD)
Play/Pause
Microphone
Scroller
Volume
Increase
Volume
Decrease
Front View Side View
Earphone
connector
Volume
Increase
EN
MuVo TX_CLE.book Page 1 Wednesday, December 17, 2003 2:06 PM

2
Getting Started
Install the Software
Your Creative NOMAD MuVo TX comes with software that helps you create audio tracks,
manage your music library and use your player.
1. Make sure that your player is not connected to your computer.
2. Insert the Installation CD into your CD-ROM drive.
3. The disc supports Windows AutoPlay mode and starts running automatically. If not, click
Start -> Run. In the Open box, type d:\ctrun\ctrun.exe (replace d:\ with the drive letter
of your CD/DVD-ROM drive), and then click the OK button.
4. Click the Install software for NOMAD MuVo TX to select it.
5. Click the OK button.
6. Follow the instructions on the screen.
7. When prompted, restart your system.
For Windows 2000/XP users:
To install the software, you must log in as the computer administrator. For more
information, refer to your operating system's online Help.
Step 1
MuVo TX_CLE.book Page 2 Wednesday, December 17, 2003 2:06 PM

3
Connect the USB Flash Drive to your computer
Do not press the buttons on your USB Flash Drive while connecting it to your computer.
Step 2
USB port
Battery
module
USB port
USB Flash
Drive
a
b
MuVo TX_CLE.book Page 3 Wednesday, December 17, 2003 2:06 PM

4
Transferring tracks or files.
1. After connecting the USB Flash Drive to your computer, you will see
Figure 1 on the player's LCD screen.
2. On your Desktop, right-click the My Computer icon, and then click
Explore. The USB Flash Drive appears as a removable disk icon
(Figure 2).
3. Drag and drop files into your player. During the transfer, Figure 3
appears on the LCD screen.
You can use other applications such as Creative MediaSource (included with the Installation
CD) to manage the music tracks in your player.
You must install the software (Step 1) before transferring tracks or files.
For Windows 98 SE users only:
Do not remove the USB Flash Drive until Figure 1 appears on the screen again for at least
five seconds.
For other Windows operating system users only:
Make sure you stop your player properly, using the Eject or Safely remove USB Mass
Storage Device option, before disconnecting it from your computer. Failure to
disconnect the player properly can result in corrupted files or music tracks. See the
“Troubleshooting” section in this booklet for details.
Music tracks in the root directory are played back first, followed by music tracks in each
folder. They are played back in alphanumeric order. Your player can recognize tracks
stored in the root directory and in only one level of sub folders.
Step 3
Figure 1
Figure 2
Figure 3
MuVo TX_CLE.book Page 4 Wednesday, December 17, 2003 2:06 PM

5
Formatting Your Player
If you need to format your player, backup the files in your player first. When you format your
player, all songs and files will be deleted. By default, your player is already formatted.
1. Connect your player to your computer's USB port.
2. Launch Windows Explorer on your computer. Your player is recognized as a Removable
Disk in Windows Explorer.
3. Right-click the Removable Disk icon and
click the Format option. The Format F:\
dialog box appears (replace F:\ with the
drive letter of your player).
4. Follow the instructions on the screen to
format your player.
5. After the formatting is complete, make sure you stop your player before disconnecting it
from your computer.
For more information about using Windows Explorer, refer to its online Help.
Your player does not support the FAT32 (32-bit File Allocation Table) file system. Format
your player with the FAT file system only.
Windows 98 SE users must install the NOMAD MuVo TX drivers before formatting the
player.
Windows 2000 and Windows XP users must select FAT, instead of FAT32, in the Format
F:\ dialog box before formatting the player.
MuVo TX_CLE.book Page 5 Wednesday, December 17, 2003 2:06 PM

6
How To Use Your Player
Remember to unplug the USB Flash Drive from your computer and insert it into the battery
module before turning on the player. For more usage information, refer to the PDF User's
Guide. Go to d:\manual\<language>\manual.pdf (replace d:\ with the drive letter of your
CD\DVD-ROM drive and <language> with the language the document is in).
Inserting the battery
The life of a battery depends on the type of battery used. It is recommended that you use
an alkaline battery. With an alkaline battery, you can play up to fourteen hours worth of
.MP3 files or eleven hours of .WMA files.
abc
MuVo TX_CLE.book Page 6 Wednesday, December 17, 2003 2:06 PM

7
Using Your Scroller
"Scroll Select", indicates that you should use the Scroller to scroll through options, and then
select the option by pressing the Scroller.
Using Your Player
Turning on the player
Press and hold the Play/Pause button for a few seconds. The Creative logo appears
on the screen, followed by the MuVo TX logo, and there is music playback.
If your player contains no audio tracks, the message "No Music" or "No Voice" will appear
onscreen, depending on whether you are in Music or Voice mode.
Turning off the player
Press and hold the Play/Pause button for a few seconds until after the Power off
message disappears
1. Use the Scroller to scroll through
options.
3. Press the Scroller to select the option.
2. Scroll to an option. 4. The selection appears.
MuVo TX_CLE.book Page 7 Wednesday, December 17, 2003 2:06 PM

8
Stopping/Pausing a music track
Press the Play/Pause button .
Skipping folders (Albums)
1. Press the Scroller.
2. Scroll Select Skip Folder (Figure 4).
3. The Skip Folder menu appears.
4. Scroll to the folder that you want to skip to.
5. To resume normal playback, press the Scroller again.
Making a voice recording
1. Press the Scroller. Scroll Select Recording (Figure 5).
2. The recording bar appears onscreen.
3. Press the Play/Pause button to start the recording.
4. Press the Play/Pause button again to end the
recording.
5. A name is automatically assigned to your recording and is saved in your player. The naming
convention typically used is: VOC [Current File Number].
For easy navigation, store your albums as folders in the root directory.
When recording, the available recording time is determined by:
- available memory space in your player.
- battery power remaining in your player.
Figure 4
Figure 5
MuVo TX_CLE.book Page 8 Wednesday, December 17, 2003 2:06 PM

9
Software Included
Creative MediaSource
Creative MediaSource allows you to rip CDs and create high quality digital audio files, play and
organize media files on your computer as well as transfer music tracks or files seamlessly to
and from your player. Special features such as SMARTFIT, using intelligent track management
and WMA compression, enables you to transfer a higher number of music tracks to your
player. For more information, refer to the Creative MediaSource online Help.
Go to Start -> Programs/All Programs -> Creative -> Creative MediaSource ->
Creative MediaSource Organizer.
MuVo TX_CLE.book Page 9 Wednesday, December 17, 2003 2:06 PM

10
Troubleshooting
When you turn on the player, an error message “File system error”
appears before the player turns off.
Try formatting your player. See section "Formatting Your Player".
After playing the first few music tracks, the player skips a music track.
The player will only play .MP3, .WMA or .WAV recordings. Other files will be skipped.
Files or music tracks are corrupted when transferred to the player.
After the transfer is complete, make sure you stop your player before disconnecting it from
your computer.
To stop your player in Windows 98 SE, do not remove the USB Flash
Drive until Figure 1 appears on the LCD screen again for at least five
seconds.
To stop your player in Windows 2000, Windows Me or Windows XP, click the Safely
Remove Hardware icon on the Taskbar, click Safely remove USB Mass Storage
Device, and disconnect your player when you are prompted to do so.
The player turns off immediately after it is turned on.
Check that the battery is not depleted.
I have to change the battery quite often. Is there anything I can do to
make it last longer?
Some operations consume more battery power:
• a long backlight timeout setting. A shorter timeout conserves battery power.
• too much use of fast forward/reverse.
• turning the player on/off too many times.
• use of passive speakers or high-powered headphones.
• playback of .WMA files.
MuVo TX_CLE.book Page 10 Wednesday, December 17, 2003 2:06 PM
