Crestron ST-BTPN Quick start guide

Crestron ST-BTPN
Rechargeable Battery Pack
Operations and Installation Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON

Crestron ST-BTPN Rechargeable Battery Pack
Contents
Rechargeable Battery Pack: ST-BTPN 1
Introduction......................................................................................1
Functions and Features ..........................................................1
Specifications.........................................................................2
Physical Description ..............................................................3
Industry Compliance..............................................................4
Handling ................................................................................5
Storage ...................................................................................5
Charging...........................................................................................6
Installation........................................................................................6
Removal.................................................................................8
Further Inquiries ....................................................................9
Future Updates.......................................................................9
Return and Warranty Policies ........................................................10
Merchandise Returns / Repair Service ................................10
CRESTRON Limited Warranty ..........................................10
Operations and Installation Guide - DOC. 6088 Contents •i

Crestron ST-BTPN Rechargeable Battery Pack
Rechargeable Battery Pack:
ST-BTPN
Introduction
Functions and Features
The Crestron rechargeable battery pack, ST-BTPN, is designed to supply
power to Crestron ST and STX Series (1550C and 1700C) wireless
touchpanels. The ST-BTPN offers the touchpanel user the freedom to
roam without being confined to a stationary power source (i.e., external
battery pack or docking station). The ST-BTPN can be charged when it is
mounted on the ST-DSN docking station. The ST-BTPN can also be
charged when mounted on the older ST-DS docking station.
NOTE: For related information on the docking stations, consult the ST-
DSN and ST-DS Operations Guides (Doc. 6095 and Doc. 5738,
respectively) The latest versions of the guides can be obtained from the
Downloads | Product Manuals section of the Crestron website
(www.crestron.com).
Functional Summary
• Powers wireless touchpanels
• Unique design allows it to be installed only one way
• Fast charging Nickel Metal Hydride battery
Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN •1

Rechargeable Battery Pack Crestron ST-BTPN
NOTE: For related information on the wireless touchpanels, consult the
latest version of the ST-1550C Operations Guide (Doc. 6096), the STX-
1550C and STX-1550CW Operations Guides (Doc. 5812 and Doc. 5849,
respectively), the ST-1700C Operations Guide (Doc. 6051) and the STX-
1700C and STX-1700CW Operations Guides (Doc. 6049 and Doc. 6103,
respectively). The latest versions of the guides which includes their
respective international versions are available from the Downloads |
Product Manuals section of the Crestron website (www.crestron.com).
Specifications
The following table provides specifications for the ST-BTPN.
Specifications for the ST-BTPN
SPECIFICATION DETAILS
Output Voltage 4.8 VDC
Capacity 4.1 Ah, typical
Composition Nickel Metal Hydride (NiMH)
Estimated Operating Time* Up to 5 hours of continuous use (20-22 hours in
standby)
Estimated life 500 charge/discharge cycles (min.)
Optimal Operating Temperature Approximately 50oF to 104oF (10oC to 40oC)
Optimal Storage Temperature Approximately -4oF to 113oF (-20oC to 45oC)
Charging Temperature Approximately 50oF to 95oF (10oC to 35oC)
Weight 0.79 lb (0.36kg)
*Approximate battery operation for battery pack in touchpanels:
Worst case battery operation – 3.0 hours (STX -1700C at full backlight)
Best case battery operation – 4.3 hours (ST-1550 at full backlight)
Approximate battery charge times in touchpanels:
Worst case charge time – 6 hours (STX-1700C at full backlight)
Best case charge time – 2.7 hours (All units with power off)
2•Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack
NOTE: The battery will not charge when above maximum charging
temperature. To cool the battery, either turn off power to the touchpanel
by pressing the power down button on the touchscreen (or use the power
down timeout), or remove the battery from the touchpanel (refer to
“Removal” on page 8). The battery can also be mounted on the docking
station to cool and then charge. The docking station begins charging the
battery once the battery has cooled.
Physical Description
The ST-BTPN (refer to illustrations below and on the next page) is
housed in a black plastic enclosure with its electrical contacts on the top
and bottom of the unit.
Physical View
Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN •3

Rechargeable Battery Pack Crestron ST-BTPN
Physical View (continued)
Crestron Electronics, Inc.
CRESTRON
4.245 in
(10.782 cm)
4.083 in
(10.371 cm)
Rockleigh, NJ 07647
ST-BTPN
Rechargeable
Power Pack
Z A 1 1 6 5 5
ZA11655
ST-BTPN
C000000
1
.
8
0
0
.
8
2
2
.
8
8
3
7
E
L
C
Y
C
E
R
RECHARGEABLE NICKEL METAL HYDROXIDE BATTERY MUST BE RECYCLED OR
DISPOSED OF PROPERLY
1.159 in
(2.944 cm)
2.280 in
(5.791 cm)
CRESTRON
EXTERNAL
FACE
TOP VIEW
BOTTOM VIEW
INTERNAL
FACE
Industry Compliance
As of the date of manufacture, the ST-BTPN has been tested and found to
comply with specifications for CE and C-Tick markings.
(N11785)
4•Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088

Crestron ST-BTPN Rechargeable Battery Pack
Handling
NOTE: The ST-BTPN contains a NiMH battery. When the unit can no
longer retain a charge, it must be recycled or disposed of properly. Refer
to the recycle label on the unit for disposal information.
To prevent short-circuiting, use care when handling the ST-BTPN.
NiMH cells have extremely low internal resistance and will discharge at
high current levels when shorted. As a result, the high temperatures can
damage the rechargeable battery pack and may cause personal injury.
Avoid accidental shorting from uninsulated workbenches, tools,
bracelets, rings, and coins.
Storage
The ST-BTPN can be stored in a temperate dry place (removed from the
touchpanel and docking station) indefinitely without significant
irreversible degradation in its performance. The self-discharge rate is a
function of temperature and internal resistance. High temperature storage
reduces charge retention. Best results occur if the ST-BTPN is stored at
an optimal temperature of 32°to 104°F (0°to 40°C). After an extended
storage, initiate a few charge/discharge cycles to restore full capacity.
Recharge the ST-BTPN after storage prior to use.
Operations and Installation Guide - DOC. 6088 Rechargeable Battery Pack: ST-BTPN •5

Rechargeable Battery Pack Crestron ST-BTPN
Charging
NOTE: Typically, the battery pack is good for 500 charge/discharge
cycles.
To charge the ST-BTPN:
• Use the powered ST-DSN docking station with battery guide; or
• Install the ST-BTPN in a ST-1550C or 1700C and mount
touchpanel on a powered ST-DSN docking station.
CAUTION: Internal damage to battery pack may occur if it is mounted
by itself on the ST-DSN without the battery guide.
NOTE: The battery pack may take up to 6 hours to charge in a powered
touchpanel. Refer to Specifications on page 2 for charging information.
For further information, consult the ST-DSN Operations Guide (Doc.
6095). The latest version of the guide is available from the Downloads |
Product Manuals section of the Crestron website (www.crestron.com).
Installation
The unique design of the ST-BTPN prevents it from being installed
improperly. The rechargeable battery pack fits only one way in the
battery compartment of the touchpanel.
Although the ST-BTPN can be installed in several Crestron wireless
touchpanel models, the ST-1700C and STX-1700C are the most common
models to use the battery pack. These models have the same shape and
battery compartment location. Therefore, as an example, the illustration
on the next page shows the ST-BTPN properly seated in the ST-1700C.
Complete the steps on the next page to install the battery.
6•Rechargeable Battery Pack: ST-BTPN Operations and Installation Guide - DOC. 6088
