Crosley CF3008-NA User manual

RootsRackKitchenCart
CF3008-NA

1pc 2pcs
Top
PART LIST
LeftdiagonalLeg
2pcs
ABC
HARDWARE LIST
28pcs
J
Short Bolt(M6*28mm)
2
I
Q
4pcs
1pc
AllenKey(M4mm)
Long Bolt(M6*38mm)
N
L8pcs16pcs
HandleWasher(M6mm)
K16pcs
FlatWasher(M6mm)
SpringWasher(M6mm)
M
F
2pcs
2pcs
TowelBar
Drawerhandle
P1pc
Wrench(M17mm)
O
G
12pcs
2pcs
WoodDowel(M8mm)
LockingCaster
RightdiagonalLeg
D1/D2
Shelf
2pcs E2pcs
Rod(M8mm)
H2pcs
Caster

Step1.
Step2.
AttachTowelBar(F)&HandleWasher(N)toLegs(B&C)using
LongBolts(I)&AllenKey(Q).
Repeatthisstepfortheremaining twolegs.
B
C
I
F
N
N
I
pressup
press down
PlaceTop(A) facedownonflatsurface,pressupand downthe slide joint ,
topullout the drawer.
X2
3
pressup

Step3.
Step4.
Setlegs(B&C)intoplaceonTop(A)usingWood Dowels(O).
J
J
AttachLegs(B&C)toTop(A)usingFlatWashers(K),Spring
Washers(L),ShortBolt(J)andAllen Key(Q).
A
4
NOTE:Donot fullytightenall bolts inthis step.

Step5. AlignShelf(D1)withLegs(B&C)asshownbelow.Insertfourwood dowelsthrough
theouterholesintheshelf(D1)intotheLegs(B&C)tohelp hold the shelf in place.
InstallFlatWashers(K),SpringWashers(L)andShortBolt(J)through the inner
holesinthe shelfintothe Legs(B&C).TightenwithAllenKey(Q).
5
NOTE2:.Once both shelves areinplace, fully tightenall bolts.
Once tight, remove wood dowels.
NOTE1:Donot fullytightenbolts atthis time.
RepeatthisforShelf (D2).
Insert fourWood Dowels (O)
intothe fourlegs(B&C)
through the shelf first.
Bolt the shelf intoplace
byusing Flat Washers(K),
Spring Washers(L),
Short Bolt (J)and Allen Key(Q).

Step7.
Step6.
AttachLockingCasters(G)&Casters(H)usingwrench(P).
AttachRod(E)toLegs(B&C),usingshortBolts(J)and Allen Key(Q).
C
Carefullyturncabinetrightsideup,withcasterson the floor.
6

Step8.
7
Left drawer
hasabrand init .
Q
AttachDrawerHandleWashers(N)andDrawerHandles(M)to
drawersusingShortBolts(J)andAllen Key(Q).
Step9. Insertdrawersintocabinet .
