Crosley CO7179 User manual

5 Piece Wicker Sofa Set
CO7179

PART LIST
A B C
2
Seat Panel
1 PC
Side Panel
4 PCS
Back Panel
1 PC
Seat Cushion
3 PCS
Back Cushion
3 PCS
D
Seat Panel
2 PCS
E
Arm Panel
2 PCS
Back
2 PCS
Panel
FG
Wicker Top
1 PC
H
Long Side Panel
2 PCS
I
Short Side Panel
2 PCS
J
Wicker Top
1 PC
K
Long Side Panel
2 PCS
L
Short Side Panel
2 PCS
S
Glass Top
1 PC
TU
Seat Cushion
1 PC
V
Pillow
2 PCS
W
(armless chair)
(armless & corner
chair) (armless chair) (corner chair) (corner chair)
(corner chair) (ottoman) (ottoman) (ottoman) (coffee table)
(armless & corner
chair)
(armless & corner
chair)
(coffee table) (coffee table) (coffee table)
(ottoman)

HARDWARE LIST
Bolt
40 PCS 28 PCS
Hex Nut
28 PCS
M6*30mm M6mm
2 PCS
M6mm
M6*50mm
Long Bolt Allen Wrench
M6mm
Flat Washer
96 PCS
Wrench
2 PCS
M6mm
M N O P Q
R
M6mm
EXTRA HARDWARE LIST
Bolt
4 PCS 3 PCS
Flat Washer
6 PC
M6*30mm M6mmM6mm
M6*50mm
Long Bolt Hex Nut
3 PCS
M6mm
M N O P
3

Step 1. Lay seat panel (part A) upside down on a soft flat surface, such as carpet, as shown below.
Attach side panels (part B) to seat panel (part A) using bolts (part M), flat washers (part O)
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Ox6
Qx1
Mx6
Step 2. Attach back panel (part C) to seat panel (part A) and side panels (part B) using long bolts
(part N), flat washers (part O), hex nuts (part P), allen wrench (part Q) and wrench (part R).
NOTE: Please fully tighten all bolts at this time.
Nx6
Ox12
Px6
4
Qx1
and allen wrench (part Q).
Rx1

Step 3. Carefully turn the assembled unit upright. Add seat cushion (part T) and back cushion
5
T
U
(part U) as shown below.

Step 4. Lay seat panel (part D) upside down on a soft flat surface, such as carpet, as shown below.
Attach side panel (part B) to seat panel (part D) using bolts (part M), flat washers (part O)
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Ox3
Qx1
Mx3
Step 5. Attach back panel (part F) to arm panel (part E) using long bolts (part N), flat washers
(part O), hex nuts (part P), allen wrench (part Q) and wrench (part R).
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Nx3
Ox6
Px3
6
Qx1
and allen wrench (part Q).
Rx1

Step 6. Attach assembled unit (parts B & D) to arm panel (part E) and back panel (part F) using
long bolts (part N), flat washers (part O), hex nuts (part P), allen wrench (part Q) and
NOTE: Please fully tighten all bolts at this time.
Step 7. Carefully turn the assembled unit upright. Add seat cushion (part T) and back cushion
Nx8
Ox16
Px8
7
Qx1
wrench (part R).
Rx1
T
U
(part U) as shown below. Repeat steps 4-7 to assemble remaining corner chair.

Step 8. Lay wicker top (part G) upside down on a soft flat surface, such as carpet, as shown below. Attach
long side panels (part H) to wicker top (part G) using bolts (part M), flat washers (part O)
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Ox4
Qx1
Mx4
Step 9. Attach short side panels (part I) to wicker top (part G) and long side panels (part H) using
bolts (part M), flat washers (part O) and allen wrench (part Q).
NOTE: Please fully tighten all bolts at this time.
8
and allen wrench (part Q).
Ox10
Qx1
Mx10

Step 10. Carefully turn the assembled unit upright. Add seat cushion (part V) as
9
V
shown below.

Step 11. Lay wicker top (part J) upside down on a soft flat surface, such as carpet, as shown below.
Attach long side panels (part K) to wicker top (part J) using bolts (part M), flat washers (part O)
NOTE: Please do not fully tighten bolts until unit is fully assembled.
Ox4
Qx1
Mx4
Step 12. Attach short side panels (part L) to wicker top (part J) and long side panels (part K) using
bolts (part M), flat washers (part O) and allen wrench (part Q).
NOTE: Please fully tighten all bolts at this time.
10
and allen wrench (part Q).
Ox10
Qx1
Mx10

Step 13. Carefully turn the unit upright. Place glass top (part S) on wicker top (part J).
11
Step 14. Add pillows (part W) as shown below.
W
W
