Cross Technologies 2005 User manual

Instruction Manual Model 2005-10-01
Upconverter
October 2013, Rev. A
DC ALARM
CROSS TECHNOLOGIES, INC.
2005 TEST CONVERTER
CKU
LO
70 140
IF FREQUENCY
GHz 1MHz10MHz100MHz
CROSS TECHNOLOGIES, INC.
DC POWER
RF
IF
J1 J3 J2
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc.,
but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc.
for purposes of operating the equipment. Printed in USA.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment
model number, equipment serial number, and a description of the part.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB: www.crosstechnologies.com
E-MAIL: [email protected]

INSTRUCTION MANUAL
MODEL 2005-10-01 Upconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
2.0 Installation 5
2.1 Mechanical 5
2.2 Front Panel Controls/Indicators 5
2.3 Rear Panel Input/Output Signals 5
2.4 Accessing the PC Card 6
2.5 Installation/Operation 6
3.0 Environmental Use Information 5
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies,
Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies,
Inc.’s option, replacing parts, subassemblies, or entire assemblies. Cross Technologies,
Inc. shall not be liable for any special, indirect, or consequential damages. This warranty
does not cover parts or equipment which have been subject to misuse, negligence, or
accident by the customer during use. All shipping costs for warranty repairs will be
prepaid by the customer. There are not other warranties, express or implied, except as
stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2005-10-01 Manual, Rev. A Page 2 10/30/2013

MODEL 2005-10-01 Upconverter
1.0 General
1.1 Equipment Description
The 2005-10-01 Test Upconverter for loop-back applications converts a 70 MHz or 140 MHz IF signal
to 2000 to 2500 MHz in 1 MHz steps with selection of high side LO (C = inverted) or low side LO
(Ku = non-inverted) and 70 or 140 MHz input over the 2.0 - 2.5 GHz range. The 2005-10-01 allows for
an input level range of +10 to -15 dBm.
Featuring low phase noise, these units are used to loop 70 or 140 MHz modulators to 2.0 - 2.5 GHz receivers
for test purposes and the output consists of the LO and both upper and lower sidebands. The 70 or 140 MHz
carrier input is mixed with a synthesized local oscillator (LO) signal. The output frequency is selected and
indicated by the four BCD switches which control the synthesized LO. Front panel LEDs light when DC
power is applied (green) and when a PLL alarm occurs (red). The mixer output is applied to the output
amplifier providing a nominal gain of -10 dB. Connectors are 50ΩBNC (female) for the IF input and for
the RF output (other connector options are available). Powered by a 120 VAC wall power supply (100-240
±10%VAC, option -P4). The 2005 can be mounted on a 1 3/4” X 19 “ rack mount panel (option -R).
2000
to
2500
MHz OUT
70
or
140
MHZ IN
1860
to
2640
MHz
2. 338
CONTROLLER
Block Diagram
ATTEN
FIGURE 1.1 Block Diagram
DC ALARM
CROSS TECHNOLOGIES, INC.
2005 TEST CONVERTER
CKU
LO
70 140
IF FREQUENCY
GHz 1MHz10MHz100MHz
CROSS TECHNOLOGIES, INC.
DC POWER
RF
IF
J1 J3 J2
FIGURE 1.2 Front and Rear Panel
2005-10-01 Manual, Rev. A Page 3 10/30/2013

1.2 Technical Characteristics
TABLE 1.0 2005-10-01 Upconverter Specifications*
Input Characteristics
Impedance 50Ω
Return Loss 15 dB
Frequency 70 or 140 MHz center, ±20 MHz
Level +10 to -15 dBm
1dB compression +15 dBm
Output Characteristics
Impedance 50Ω
Return Loss 12 dB
Frequency Range 2.0 to 2.5 GHz
Channel Characteristics
Gain -10 dB ± 3 dB
Spurious Response <-40dBC max, < -45dBC typ for Fc ±20MHz;
OUTPUT NOT FILTERED, Lo<=RF nominal
Frequency Response ± 2 dB, 2.0 - 2.5 GHz; ± 0.5 dB, any 10MHz increment
Synthesizer Characteristics
Frequency Accuracy ± 25 kHz max; Option -HT for ±0.1ppm Internal Reference
Frequency Step 1.0 MHz minimum
-100-90-80-70-70
1MHz100kHz10kHz1kHz100 MHz
dBC/Hz
Phase Noise
@
Fre
q
Indicators
DC Power Green LED
PLL Alarm Red LED
Other
RF, IF Connectors 50ΩBNC (RF), 50ΩBNC (IF)
Size, Bench Top 4.7” Wide X 1.75” High X 6.5” Deep
Size, Rack Mount 19 inch standard chassis 1.75”High X 7.0” Deep (option -R)
Power, standard 120 ± 10% VAC, 60 Hz, 10W max wall mount power supply
AC Power 100-240 ±10% VAC, 47-63 Hz, wall mount power supply (option -P4)
*+10 to +40 degrees C; Specifications subject to change without notice
2005-10-01 Manual, Rev. A Page 4 10/30/2013

2.0 Installation
2.1 Mechanical
The 2005-10-01 is packaged in an aluminum extrusion. The -R option is mounted on a 1 3/4” X 19” panel
that can be mounted to a rack using the 4 holes at the ends. The unit derives +DC from the wall power supply
(+15V unregulated, or regulated universal -P4). See Figure 2.3.
2.1.1 Cleaning Instructions
Wipe the exterior with a dry, soft cloth. Use no detergent or cleaning chemicals.
2.2 Front Panel Controls/Indicators - Fig. 2.1 shows front panel controls and indicators for the 2005-10-01.
SW6 - LO SELECT
Slide switch selects high side (C)
or low side (Ku) local oscillator.
DS1 - POWER LED
Lights green when DC
power is present
SW1 to SW4 - FREQUENCY BCD SWITCHES
Select the desired output frequency which is the LO
frequency - 70, -140, +70, or +140 MHz in GHz.
DS2 - ALARM LED
Lights red when PLL
comes out of lock
SW5 - IF SWITCH
Slide switch selects 70 or 140 MHz IF In
DC ALARM
CROSS TECHNOLOGIES, INC.
2005 TEST UPCONVERTER
CKU
LO
70 140
IF FREQUENCY
GHz 1MHz10MHz100MHz
FIGURE 2.1 2005-10-01 Front Panel Controls and Indicators
2.3 Rear Panel Input/Output Signals - Figure 2.2 shows the input and output signals to the 2005-10-01.
J1 - IF INPUT
70 or 140 MHz input.
+10 dBm max level
BNC (female)
50Ωconnector.
(Option -SS, 50ΩSMA)
J3 - DC POWER
The unregulated DC voltage from the
wall power supply (option P, P4).
15 VDC, 200 ma.
J2 - RF OUT
Output selected and
indicated by four
BCD switches.
BNC (female)
50Ωconnector.
(Option -SS, 50ΩSMA)
+15GND
CROSS TECHNOLOGIES, INC.
DC POWER RF
J1 J3 J2
IF
FIGURE 2.2 2005-10-01 Rear Panel Inputs and Outputs
2005-10-01 Manual, Rev. A Page 5 10/30/2013

2.4 Accessing the PC Card
There are NO USER JUMPERS or other on-card controls. ALTHOUGH IT IS NOT RECOMMENDED AND
MAY VOID THE WARRANTY the following shows how to remove the printed circuit board (PCB) from the
extrusion:
1. ALWAYS REMOVE POWER when installing or removing the PCB from the extrusion
2. Remove four (4) rear panel screws (see Figure 2.3).
3. GENTLY pull the rear panel and PCB assembly completely out of the extrusion.
4. To install the PCB, GENTLY push the rear panel and PCB assembly completely into the extrusion
Make sure the shield goes in the lower channel and the PCB in the next channel above that in the
extrusion and that the front panel controls go through the front panel holes.
5. Install four (4) rear panel screws.
EXTRUSION
FRONT SCREWS (4EA)
FRONT PANEL
RACK MOUNT PANEL (FOR -R MODELS ONLY)
REAR SCREWS (4EA)
PCB
ASSEMBLY
REAR PANEL
WALL
POWER
SUPPLY
(-P and -P4 ONLY)
2005 TEST CONVERTER
CROSS TECHNOLOGIES, INC.
DC
100MHz
FREQUENCY
10MHz 1MHzGHz
LO IF
CKU 70140
ALARM
FIGURE 2.3 2005 Assembly Drawing
2.5 Installation / Operation
2.5.1 Installing and Operating the 2005-10-01
1. If using the receiver LNB voltage to power the 2005-10-01, be sure +14 to +24 VDC is on the RF
center conductor. If using the wall power supply (options -P or -P4), connect the power supply to
the DC POWER connector and either 120 ±10% (-P) or 100-240 ±10% VAC (-P4) (Figure 2.2)
2. Select either C or KU band (SW6) and either 70 or 140 MHz IF (SW5) using the
front panel switches (Figure 2.1).
3. Connect a +10dBm max signal to IF In, J1 (Figure 2.2).
4. Connect the RF OUT, J2, to the receiver under test (Figure 2.2).
5. Set BCD switches, SW1 to SW4, to the desired frequency (Figure 2.1).
6. Be sure DS1 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.1).
2005-10-01 Manual, Rev. A Page 6 10/30/2013

3.0 Environmental Use Information
A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions
located in the user manual furnished by the manufacturer of your equipment rack.
B. Mechanical Loading - Mounting of equipment in a rack should be such that a hazardous condition
does not exist due to uneven weight distribution.
C.Elevated Operating Ambient Temperature - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack may be greater than room ambient temperature.
Therefore, consideration should be given to Tmra.
D. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised. Additional space between unit
may be required.
E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of circuits could have on over current protection and supply wiring.
Appropriate consideration of equipment name plate rating should be used when addressing this concern.
F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connection to the
Branch (use of power strips).
G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.
If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED
prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS
emission problems.
2005-10-01 Manual, Rev. A Page 7 10/30/2013

CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB: www.crosstechnologies.com
E-MAIL: [email protected]
Printed in USA
2005-10-01 Manual, Rev. A Page 8 10/30/2013
