INSTRUCTION MANUAL
MODEL 2015-58T Upconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
1.3 Monitor & Control Interface 5
1.4 Environmental Use Information 7
2.0 Installation 8
2.1 Mechanical 8
2.2 Rear Inputs & Outputs 9
2.3 Front Panel Controls & Indicators 9
2.4 Operation 10
2.5 Menu Settings 11
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies, Inc.’s
obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s option,
replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall not be
liable for any special, indirect, or consequential damages. This warranty does not cover parts
or equipment which have been subject to misuse, negligence, or accident by the customer
during use. All shipping costs for warranty repairs will be prepaid by the customer. There are
not other warranties, express or implied, except as stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2015-58T Manual_Rev. D Page 2 11/29/12

MODEL 2015-58T Upconverter
1.0 General
1.1 Equipment Description
The 2015-58-T Upconverter converts 70 ±18 MHz to 5.845 to 6.725 GHz in 125 kHz steps with low group
delay and flat frequency response. Synthesized local oscillators (LO) provide low phase noise and ±1.0 ppm
stability frequency selection. Push button switches select the RF frequency, gain, and other parameters. Front
panel LEDs provide indication of DC power (green), remote operation (yellow), PLL alarm (red), or the TX
carrier is muted (yellow). Variable attenuators for the IF input and RF output provide a gain range of 0 to +20
dB as adjusted by the front panel pushbutton switches. Remote operation allows selection of frequency and
gain. Parameter selection and frequency and gain settings appear on the LCD display. Connectors are BNC
female for IF input and 10MHz reference input and output, and Type N female for the RF output (other
connector configurations available). The 2015-58T is powered by a 100-240 ±10% VAC power supply; and
housed in a 1.75” X 19” X 16” rack mount chassis.
MENU
EXECUTE
MODEL 2015
CROSS TECHNOLOGIES INC.
F = 5950.000
G = +10.0
MUTE
REMOTE POWER ALARM
UPCONVERTER
IF MONITOR RF MONITOR
FRONT
GND
J4J3J18
10 MHZ REF 10 MHZ IF IN
EXT REF
OUTPUT INPUT
RF OUT
J5
J20
J10
AND
MONITOR
CONTROL
15 234 6789
AC
Optional
Ethernet
Ct
REAR
FIGURE 1.1 Model 2015-58T Front and Rear Panels
5.85
to
6.425
GHz
OUT
70
MHz
IN
CONTROLLER F = 5950.0000
G = +10.0
VAR
ATT
EXT
10 MHz
INT/EXT
10 MHz
VAR
ATT
INT
10 MHz
FIGURE 1.2 Model 2015-58T Upconverter Block Diagram
2015-58T Manual_Rev. D Page 3 11/29/12

1.2 Technical Characteristics
Channel Characteristics
S
y
nthesizer Characteristics
125 kHz minimumFre
q
uenc
y
Ste
p
Non-invertin
g
Fre
q
uenc
y
Sense
0.1 de
g
/dB maximum for -15 dBm out
p
utAM/PM Conversion
1.5dB, 5.845 - 6.725 GHz; Slope 0.05 dB/MHz max.; 36 MHz BW;
±0.5 dB
,
36MHz BW
Fre
q
uenc
y
Res
p
onse
<-45 dBC for two carriers each at -5 dBm outIntermodulation
+3 dBm ± 3 dB10 MHz In/Out Level
±0.01
pp
m
(
1x10E-8
)
internal ref.
(
1x10E-9
p
er da
y)
External ref. in
p
ut availableFre
q
uenc
y
Accurac
y
0.015 ns/MHz2
p
arabolic
;
0.05 ns/MHz linear
;
1 ns ri
pp
leGrou
p
Dela
y,
maximum
<-50 dBCS
p
urious Res
p
onse +10.0 to +30.0 dB, 0.5 dB ste
p
s / ±0.25 dB/da
y
max. stabilit
y
Gain Ran
g
e / Stabilit
y
BNC
(
female
),
75Ω
,
works with 50 ohms10 MHz Connectors
Other
100-24 ±10% VAC
,
47-63 Hz
,
45 watts max.Power 19 inch
,
1RU Standard Chassis - 1.75” hi
g
h X 16.0” dee
p
Size DB9
(
female
)
- NO or NC contact closure on AlarmAlarm/Remote Connector
-20 dBC Levels
;
Connectors RF - SMA female
;
IF - 75ΩBNC female
,
(
front
p
anel
)
RF / IF Monitor Ports RF - T
yp
e N
(
female
)
/ IF - BNC
(
female
)
RF / IF Connectors
-110-95-80-75-70 1MHz100kHz10kHz1kHz100 MHz dBC/Hz
Phase Noise @ Fre
q
uenc
y
Controls
,
Indicators
RS232C, 9600 baudRemote
Direct readout LCD;
p
ush-button switches or remote selectionFre
q
uenc
y
/ Gain Selection Green LED
,
Red LED
,
Yellow LED
,
Yellow LEDPower
,
Alarm
,
Remote
,
Mute
TABLE 1.1 2015-58-T Upconverter Specifications*
-30 to -10 dBmIn
p
ut Level
20 dB typical; 25 dB maximum, +30 dB gainNoise Figure
70 ±18 MHzFre
q
uenc
y
+10 dBmOut
p
ut 1 dB Com
p
ression -20 to 0 dBmOut
p
ut Level
Out
p
ut Characteristics
In
p
ut Characteristics
5.845 to 6.725 GHzFre
q
uenc
y
50Ω/ 20 dB T
yp
ical, 18 dB min.Im
p
edance / Return Loss
75Ω/ 20 dBIm
p
edance / Return Loss
- M 50ΩT
yp
e N
(
RF
)
, 50ΩBNC
(
IF
)
Connector / Im
p
edance
Remote M&C Interfaces LO1 / LO2 Monitor Ports
(
Rear
)
- W12
Available O
p
tions
Ethernet with Web Browser & SNMP
Ethernet with Web Browser
(
WB
)
- W18
- W8 RS485 Remote Interface-
Q
*+0 to +50 degrees C; Specifications subject to change without notice.
2015-58T Manual_Rev. D Page 4 11/29/12

1.3 Monitor and Control Interface
A) Remote Serial Interface
Protocol - RS-485, RS-422 or RS-232C (selectable), 9600 baud rate, no parity, 8 data bits, 1 start bit, 1 stop bit.
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Female DB-9
PC Com Port Male DB-9
2015/16/17 M&C Port
M&C Cable Diagram - Cross Technologies Frequency Converters
RX RX
TX TX
DTR
SG
DSR
RTS
CTS
SG
Connector - Rear panel, DB-9 female
Pinouts (RS-485/422/232C)
Pin Description
1 Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5 Ground
6 Alarm Relay - Common
7 Alarm Relay - Normally Open
8 Not Used
9 Alarm Relay - Normally Closed
2015-58T Manual_Rev. D Page 5 11/29/12

B) Commands - Table 1.2 lists the commands for the 2015-58T and briefly describes them. After a command
is sent the 2015-58T sends a return “>” indicating the command has been received and executed.
General Command Format - The general command format is {aaCND...}, where:
{ = start byte
aa = Address (RS-485 only)
C = 1 character, either C (command) or S (status)
N = 1 character command of status request
D = 1 character or more of data (depends on command)
} = stop byte
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485, (OPTION-Q), is selected.
Table 1.2 2015-58T Comma
n
nds
Commands
Command Syntax Description
Set Transmitter Frequency {aaC1xxxxxxx}* where:
• xxxxxxx = 7 characters
• Range: 5845000 to 6725000 kHz, 1kHz steps
Set Input Level {aaCIxx}* where:
• xx = 2 characters
• Range: 10 to 30 (-10 dB to -30 dB, in 1 dB steps)
Set Transmit Gain {aaC3xxx}* where:
• xxx = 3 characters
• Range: 100 to 300 (10.0 dB to 30.0 dB, in 0.5 dB steps)
Enable Tx {aaCAx}* where x =:
• 0 to disable Tx signal
• 1 to enable Tx signal
Enable External 10MHz {aaCEx}* where x =:
• 0 to disable External 10MHz ref signal
• 1 to enable External 10MHz ref signal
Enable Remote # Just # sign
Disable Remote {aaCR0}* {CR and zero}
C) Status Requests - Table 1.3 lists the status requests for the 2015-58T and briefly describes them.
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485, (OPTION-Q), is selected.
Table 1.3 2015-58T Status Reequests
Status Requests
Command Syntax Description
Command Status {aaS1}* Returns {aaS1bbbbbbbccddddMEA} where:
• bbbbbbb = Tx frequency
• ddd = Tx Gain
• cc = Input Level
• A = Alarm Status (0 = NO Alarm, 1 = Alarm)
• M = Tx RF Status (1 = Normal, 0 = Muted)
10 MHz Reference Status {aaS2}* Returns {aaS2x} where:
• X = 1 - external 10 MHz switched in
2015-58T Manual_Rev. D Page 6 11/29/12

1.4 Environmental Use Information
A.Rack-Mounting - To mount this equipment in a rack, please refer to the installation instructions
located in the user manual furnished by the manufacturer of your equipment rack.
B. Mechanical Loading - Mounting of equipment in a rack should be such that a hazardous condition
does not exist due to uneven weight distribution.
C.Elevated Operating Ambient Temperature - If installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack may be greater than room ambient temperature.
Therefore, consideration should be given to Tmra.
D. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised. Additional space between unit
may be required.
E. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of circuits could have on over current protection and supply wiring.
Appropriate consideration of equipment name plate rating should be used, when addressing this concern.
F. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connection to the
Branch (use of power strips).
G. Top Cover - There are no serviceable parts inside the product so, the Top Cover should not be removed.
If the Top Cover is removed the ground strap and associated screw MUST BE REINSTALLED
prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS
emission problems.
2015-58T Manual_Rev. D Page 7 11/29/12

2.0 Installation
2.1 Mechanical
The 2015-58T consists of one RF/Controller PCB which is housed in a 1 RU (1 3/4 inch high) by 16 inch deep
chassis. A switching, ± 12, +24, +5 VDC power supply provides power for the assembly. The 2015-58T can
be secured to a rack using the 4 holes on the front panel. Figure 2.1 shows how the 2015-58T is assembled.
POWER
SUPPLY
PCB
FIGURE 2.1 2015-58T Mechanical Assembly
2015-58T Manual_Rev. D Page 8 11/29/12

2.2 Rear Panel Input / Output Signals - Figure 2.2 shows the input and output connectors on the rear panel.
AC
GND
J18
10 MHZ REF
OUTPUT
J10
AND
MONITOR
CONTROL
5 4 3 2 1
9 8 7 6
J10 - MONITOR AND CONTROL
DB9 female connector.
see Table 2.1.
RF OUT
J4
J5
J3
10 MHZ IF IN
EXT REF
J5 - RF OUT
5845 to 6725 MHz
-20 to 0 dBm output
J4 - IF IN
70 MHz
-30 to -10 dBm input
INPUT
J3 - 10 MHz EXT REF INPUT
10 MHz external reference input,
3 ± 3 dBm, 50/75 ohms,
BNC (female) connector.
J18 - 10 MHz REF OUTPUT
10 MHz reference output,
3 ± 3 dBm, 50/75 ohms
BNC (female) connector.
AC - POWER IN
AC input for switching power supply.
100-240 VAC, 47-63 Hz.
J20 - Ethernet Connection
RJ45 Ethernet Connector
(optional)
J20
FIGURE 2.2 2015-58T Rear Panel Inputs and Outputs
Table 2.1 J10 Pinouts
Table 2.1 J10 Pinouts (RS-485/RS-422/RS-232C)*
Pin Description
1 Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5 Ground
6 Alarm Relay - Common
7 Alarm Relay - Normally Open
8 Not Used
9 Alarm Relay - Normally Closed
*Interface: DB-9 Female; Protocol: RS-485, RS-422, or RS-232C (selectable), 9600 baud rate, no
parity, 8 data bits, 1 start bit, 1 stop bit
2.3 Front Panel Controls and Indicators - Figure 2.3 shows the front panel controls and indicators.
MENU
EXECUTE
F = 5950.000
MUTEREMOTE POWER
LCD DISPLAY
Display shows Frequency in MHz and
Gain in dB. Is used during Program
Mode to change settings.
S1 - MENU/EXECUTE BUTTON
Press this to get into Program mode
and to execute any changes.
DS6 - POWER LED
Green LED indicates
presence of DC power.
DS1 - REMOTE LED
Yellow LED indicates
remote operation.
S2 - VERT. TOGGLE
Vertical toggle switch that controls
values in the Menu items when in
program mode. Does not function in
the normal display mode
S3 - HORIZ. TOGGLE
Horizontal toggle switch that
controls which values are being
adjusted. Does not function in the
normal display mode
ALARM
G = +10.0
DS5 - UP MUTE LED
Red LED indicates
upconverter mute.
DS2 - UP ALARM LED
Red LED indicates
upconverter alarm.
FIGURE 2.3 2015-58T Front Panel Controls and Indicators
2015-58T Manual_Rev. D Page 9 11/29/12

2.4 Installation / Operation
2.4.1 Installing and Operating the 2015-58T Upconverter
1. Connect a -30 dBm to -10 dBm, 70 MHz signal to IF IN, J4 (Figure 2.2)
2. Connect RF OUT, J5, to the external equipment.
3. Connect 100- 240 ±10% VAC, 47 - 63 Hz to AC input on the back panel.
4. Set the desired output frequency (See Section 2.5 Menu Settings).
5. Set the input level (See Section 2.5 Menu Settings).
6. Set the gain so that the output level is always within the range of -20 to 0 dBm. The firmware will
prevent setting gain and input level outside this range. (See Section 2.5 Menu Settings).
7. Be sure DS6 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.3).
8. AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot in the
drawer below the AC input as shown in Figure 2.4. There is a spare fuse in the near slot. If a fuse
continues to open, the power supply is most likely defective.
AC Fuse - 2 amp slow blow (Type T),
5 mm X 20 mm
FUSE DRAWER
SPARE FUSE
~
INPUT
100-240± 10%VA
C
47-63 Hz
2A MA
X
FUSE
TYPE T 2A GDC
250 VOLT
FOR 100 - 240 V~
~
FIGURE 2.4 Fuse Location and Spare Fuse
2015-58T Manual_Rev. D Page 10 11/29/12

2.5 Menu Settings
2.5.1 Functions - This section describes operation of the front panel controls. There are three operator
switches, the LCD display and alarm indicator LEDs. All functions for the equipment are controlled by these
components. The functions are (see Figure 2.5):
Power Up
Normal Display
Menu 1 Frequency in MHz
Menu 2 Input Level in dBm (-30 to -10)
Menu 3 Gain in dB (+10.0 to +30.0)
Menu 4 Mute TX Signal
Menu 5 Set Unit to Remote Operation
Menu 6 Select External 10 MHz Reference
Menu 7 Select RS232, RS422, or RS485 Remote Operation (option Q)
Menu 8 Select RS485 Remote Address for Unit (option Q)
Save Menu When “R” is selected in any of the above menus or when operator reaches the end
Alarm indications appear on the LEDs (see figure 2.2).
All program changes must start with the operation of the Menu/Execute switch and must also end with the
operation of the Menu/Execute switch verified by the “Save Settings?” Menu. If this sequence is not followed,
none of the changes will take effect. If programming is initiated and no operator action takes place for
approximately 12 seconds (before the final press of the Menu/Execute switch) the display will revert to its
previous status and you will need to start over.
2015-58T Manual_Rev. D Page 11 11/29/12

2.5.2. Power On Settings
NOTE: The last status of a unit is retained even when power is removed. When power is restored, the unit
will return to it's previous settings.
When power is first applied, the LCD display goes through three steps.
1.The LCD goes black to show all segments are functioning.
2.The software version will be displayed.
REV 1.00
3.The present frequency, gain, and selected RF output of the upconverter is shown.
F = 5950.000
G = +10.0
The unit is now operational and ready for any changes the operator may desire.
2.5.3 Control Switches
1. Menu/Execute - Any change to the programming of the unit must be initiated by pressing the
Menu/Execute switch and completed by pressing the Menu/Execute switch.
2. Horizontal Switch - This switch is mounted so its movement is horizontal and moves the cursor left or
right.
3. Vertical Switch - This switch is mounted so its movement is vertical and has two functions:
A) During frequency, gain changes, the vertical movement will raise or lower the number in the
direction of the arrows.
B) For other functions such as Mute on/off, the vertical switch will alternately turn the function
on or off regardless of the direction operated.
2015-58T Manual_Rev. D Page 12 11/29/12

2.5.4 Frequency Changes
At any time during the modification process, if you have made a mistake and do not wish to save the changes
you have made, do not press the Menu/Execute switch; simply do nothing for approximately 12 seconds,
and the system will return to the normal operating mode or scroll to “R” and push the menu/Execute switch
and select “NO” in the “SAVE SETTINGS?” window.
To change the FREQUENCY:
1.Operate the Menu/Execute switch until you get to the menu item you want to change see Figure 2.5 for
the sequence of menu options. The following display is for changing the upconverter frequency:
F = 5950.000 R
Pressing the Up/Down switch down will toggle the display to:
F = 5850.000 R
By using the horizontal rocker switch the cursor can be moved left or right .
F = 5850.000 R
NOTE: CHANGES DO NOT TAKE PLACE ON FREQUENCY UNTIL YOU GO TO THE SAVE
MENU AND INDICATE YOU WANT TO SAVE THE CHANGES. THE CARRIER IS MUTED
WHEN FREQUENCY IS CHANGED.
When the display indicates the value desired you can push the Menu/Execute switch to the next item:
INLVL = -20R
OR you can scroll to “R”, push the Menu/Execute switch to get to:
SAVE SETTINGS? Y N
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings.
Pushing the Menu/Execute switch then takes you to the default display:
F = 5850.000
G = +10.0
Figure 2.5 shows all the menu items and how to make changes.
2015-58T Manual_Rev. D Page 13 11/29/12

2.5.5 Gain Changes
When you get to this menu note that the gain changes will be made as you make them but if you do not wish to
save the changes you have made, scroll to “R” and push the menu/Execute switch and select “NO” in the
“SAVE SETTINGS?” window or do not press the Menu/Execute switch; simply do nothing for
approximately 12 seconds, and the system will return to the normal operating mode.
To change the GAIN, first push the Menu/Execute switch to get to the gain setting:
Operate the Menu/Execute switch until you get to the menu item you want to change (see Figure 2.5 for
the sequence of menu options). The following display is for changing the upconverter input level. This
is an important setting to optimize spurious and should be made as accurately as possible:
INLVL = -20R
NOTE: CHANGES TAKE PLACE ON LEVEL AND GAIN IMMEDIATELY BUT DO NOT GET
SAVED UNTIL YOU GO TO THE SAVE MENU AND INDICATE YOU WANT TO SAVE THE
CHANGES.
Press the Up/Down switch to change the level in 1 dB steps and then push the Menu/Execute switch to
get to the Gain setting:
G = +10.0 R
Press the Up/Down switch to change the gain in 0.1, 1 or 10 dB steps:
G = +20.0 R
By using the horizontal rocker switch the cursor can be moved left or right. Pressing the Up/Down
switch down will toggle the display digit selected until you have the desired gain.
NOTE: THE GAIN WILL BE CHANGED AS YOU ADJUST THE NUMBERS. HOWEVER, THE
VALUE WILL NOT BE STORED UNTIL YOU INDICATE YES IN THE SAVE SETTINGS
WINDOW. DO NOT SET A GAIN THAT WOULD EXCEED 0 dBm OR HAVE LESS THAN -20 dBm
OUTPUT LEVEL. THE FIRMWARE PREVENTS YOU FROM THIS.
When the display indicates the value desired you can push the Menu/Execute switch to the next item
OR you can scroll to “R”, push the Menu/Execute switch to get to:
SAVE SETTINGS? Y N
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings.
Pushing the Menu/Execute switch then takes you to:
F = 5850.000
G = +20.0
Figure 2.5 gives the menu items and how to make changes
2015-58T Manual_Rev. D Page 14 11/29/12

2.5.5 Alarm Indications
An alarm condition for will occur if the local oscillator phase lock loop (PLL) comes out of lock. The Mute
LED will light if you select to mute the Tx Signal and the Remote LED will light when you select the Remote
mode.
ON POWER UP
NORMAL DISPLAY
PUSHING MENU/EXECUTE SEQUENCE
REV 1.00
F = 5950.000
G = +10.0 PUSH BUTTON
Power Up
Normal Display
Menu 1 Set Frequency
Menu 2 Set Input Level (from
-40 to -10)
Menu 3 Set Gain (-10 to +30)
Menu 4 Mute TX signal
Menu 5 Set Unit to Remote
Operation
Menu 6 Select External 10 MHz
Reference
Menu 7 Set Remote Mode
(option -Q)
Menu 8 Set RS-485 Address
(option -Q)
Save Settings? At the end or
when “R” is selected from any of
the above menus
SAVE SETTINGS? Y N
SCROLL <>
PUSH BUTTON
F = 5950.000
SCROLL <>
SCROLL
PUSH BUTTON
R
SCROLL <>
SCROLL
PUSH BUTTON
INLVL = -20 R
G = +10
SCROLL <>
SCROLL
PUSH BUTTON
R
MUTE OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
REMOTE OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
RS485
SCROLL <>
SCROLL
PUSH BUTTON
R
PUSH BUTTON
ADDRESS = 00
SCROLL <>
SCROLL
PUSH BUTTON
R
EXT REF OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
FIGURE 2.5 Menu Display and Sequence
2015-58T Manual_Rev. D Page 15 11/29/12

CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
Printed in USA
2015-58T Manual_Rev. D Page 16 11/29/12
