Cross Technologies 2015-05 User manual

Instruction Manual Model 2015-05
Upconverter
May 2010 Rev F
MENU
EXECUTE
MODEL 2015
CROSS TECHNOLOGIES INC.
F=1525 G=+00.0
MUTEREMOTE POWER ALARM
UPCONVERTER
Data, drawings, and other material contained herein are proprietary to Cross Technologies, Inc.,
but may be reproduced or duplicated without the prior permission of Cross Technologies, Inc.
for purposes of operating the equipment.
When ordering parts from Cross Technologies, Inc., be sure to include the equipment
model number, equipment serial number, and a description of the part.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]

INSTRUCTION MANUAL
MODEL 2015-05 Upconverter
TABLE OF CONTENTS PAGE
Warranty 2
1.0 General 3
1.1 Equipment Description 3
1.2 Technical Characteristics 4
1.3 Monitor & Control Interface 5
1.4 Use Information 8
2.0 Installation 9
2.1 Mechanical 9
2.2 Rear I/O’s 10
2.3 Front Panel Controls, Indicators 11
2.4 Operation 12
2.5 Menu Settings 13
WARRANTY - The following warranty applies to all Cross Technologies, Inc. products.
All Cross Technologies, Inc. products are warranted against defective materials and
workmanship for a period of one year after shipment to customer. Cross Technologies,
Inc.’s obligation under this warranty is limited to repairing or, at Cross Technologies, Inc.’s
option, replacing parts, subassemblies, or entire assemblies. Cross Technologies, Inc. shall
not be liable for any special, indirect, or consequential damages. This warranty does not
cover parts or equipment which have been subject to misuse, negligence, or accident by the
customer during use. All shipping costs for warranty repairs will be prepaid by the
customer. There are not other warranties, express or implied, except as stated herein.
CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2015-05 Manual, Rev F Page 2 05/20/10

MODEL 2015-05 Upconverter
1.0 General
1.1 Equipment Description
The 2015-05 L-band Upconverter converts 140 ± 36 MHz to 950 to 1525 MHz in 1 MHz steps with low group
delay and flat frequency response. Synthesized local oscillators (LO) provide frequency selection. Multi-
function push button switches select the RF frequency, gain, and other parameters. Front panel LEDs provide
indication of DC power (green), PLL alarm (red), Remote operation (yellow) or the TX carrier is Muted
(yellow). Variable attenuators for the IF input and output provide a gain range of -10 to +30 dB as adjusted by
the front panel multi-function pushbutton switches. Remote operation allows selection of frequency and gain.
Parameter selection and frequency and gain settings appear on the LCD display. Connectors are BNC (female)
for IF input and the optional 10 MHz external reference input and output (option -E), and type F (female) for
the RF output. The 10 MHz option includes a 10 MHz output connector which contains either the internal or
external 10 MHz reference signal. Table 2.2 shows other connector options. The 2015-05 is powered by a 100-
240 ±10% VAC power supply and is contained in a 1 3/4” X 19 “ X 16” rack mount chassis.
MENU
EXECUTE
MODEL 2015
CROSS TECHNOLOGIES INC.
F=1525 G=+00.0
MUTEREMOTE POWER ALARM
UPCONVERTER
FRONT PANEL
AC
RF OUT
SSPB FUSE
GND
J4 J5J3J18
10 MHZ REF 10 MHZ IF IN
EXT REF F2
OUTPUT INPUT
DS7
VDC on RF
J10
AND
MONITOR
CONTROL
15 234 6789
REAR PANEL
FIGURE 1.1 Model 2015-05 Front and Rear Panels
.95
to
1.53
GHz
OUT
140
MHz
IN
.95 to 2 GHz
BP
CONTROLLER F=1525 G=+00.0
1750 MHz
BP
1890
MHz
2.7
to
3.3
GHz
var
atten
10MHz*
+24VDC*
EXT
10MHz*
*OPTIONAL
var
atten
INT
10MHz
FIGURE 1.2 Model 2015-05 Upconverter Block Diagram
2015-05 Manual, Rev F Page 3 05/20/10

1.2 Technical Characteristics
TABLE 1.0 2015-05 Upconverter Specifications*
Input Characteristics
Impedance/Return Loss 75 /18 dB (see TABLE 2.2 for connector options)
Frequency 140 ± 36 MHZ
Input Level -40 to -10 dBm
Output Characteristics
Impedance/Return Loss 75 /12 dB (see TABLE 2.2 for connector options)
Frequency 950 - 1525 MHz
Output level 0 to -20 dBm
Output level/1 dB +5 dBm
Channel Characteristics
Gain range (adjustable) -10 to +30.0 dB
Spurious Response <-50 dBC, with input level set correctly
Frequency Response ±1.5 dB, 950 -1525 MHz; ± 0.5 dB, 72 MHz BW
Group Delay, max 0.0035 ns/MHz2parabolic; 0.025 ns/MHz linear; 1 ns ripple
Frequency Sense Non-inverting
Synthesizer Characteristics
Frequency Accuracy ± 1.0 ppm max over temp (± 0.01 ppm option H) internal reference
Frequency Step 1.0 MHz minimum
10 MHz level 3 dBm, ± 3 dB (option E)
-110-95-80-70-70
1MHz100kHz10kHz1kHz100 Hz
dBC/Hz
Phase Noise
@
Fre
q
Controls, Indicators
Frequency Selection direct readout LCD; pushbutton switches or remote selection
Gain Selection direct readout LCD; pushbutton switches or remote selection
Power Green LED
Alarm Red LED
Remote Yellow LED; RS232C (RS485, option Q), 9600 baud
Mute Yellow LED
Other RF Connector Type F (female) (see TABLE 2.2 for other options)
IF Connector BNC (female) (see TABLE 2.2 for other options)
Ext 10 MHz Conn. (In/Out) BNC (female), 50/75 (option E)
Alarm/Remote Connector DB9 - NO or NC contact closure on Alarm
Size 19 inch, 1RU standard chassis 1.75”high X 16.0” deep
Power 100-240 ±10% VAC, 47-63 Hz, 45 watts max
Options
-E Allows ext. 10 MHz ref input, 10 MHz ref can be inserted on the RF in
-H High Stability (± 0.01 ppm) internal reference
-Q RS-422/RS-485 Remote capability
-T Temperature Sensor
-V SSPB +24 VDC, 2.5 Amps max, with readout of current
-X 125 kHz step size
-W8 Ethernet M&C Remote Interface
-Z Attenuator 0.1 dB step size
Connector options see TABLE 2.2
*+10 to +40 degrees C; Specifications subject to change without notice
2015-05 Manual, Rev F Page 4 05/20/10

1.3 Monitor and Control Interface
A) Remote serial interface
Protocol: RS-232C, 9600 baud rate, no parity, 8 data bits, 1 start bit, and 1 stop bit.
(RS-232C, RS-422, or RS-485 - option -Q)
1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
Female DB-9
PC Com Port Male DB-9
2015/16/17 M&C Port
M&C Cable Diagram - Cross Technologies Frequency Converters
RX RX
TX TX
DTR
SG
DSR
RTS
CTS
SG
Connector: Rear panel, DB-9 female
J10 Pinouts
Pinouts (RS-232C/422/485)
Pin Function
1Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8NotUsed
9 Alarm Relay: Normally Closed
2015-05 Manual, Rev F Page 5 05/20/10

B) Status Requests
Table 1.1 lists the status requests for the 2015-05 and briefly describes them.
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485, (OPTION-Q), is selected.
TABLE 1.1 2015-05 Status Reequests
Requests
Command Syntax * Description
Command Status {aaS1} Returns {aaS1bbbbcccddAM} where:
• bbbb = Tx frequency
4 characters - standard (7 characters - Option-X)
• ccc = Tx gain
• dd = Tx input level (10 to 40 => -10 to -40 dBm)
• A = summary alarm; 1 = alarmed, 0 = normal
• M = Tx RF Status (1 = Normal, 0 = Muted)
10 MHz Reference Status {aaS2} Returns {aaS2ER} where:
(option E only) • E = Ext 10MHz Status (1 = on, 0 = off)
• R = 10MHz RF insertion status (1 = inserted, 0 = NOT inserted)
SSPB Current {aaS4} Returns {aaS4bbb} where:
(option V only) • bbb = SSPB current, range 000 to 250 (0 to 2500 mA)
2015-05 Manual, Rev F Page 6 05/20/10

C) Commands Table 1.2 lists the commands for the 2015-05 and briefly describes them. After a command is
sent the 2015-75 sends a return “>” indicating the command has been received and executed.
General Command Format - The general command format is {CND...}, where:
{ = start byte
C = 1 character, either C (command) or S (status)
N = 1 character command or status request
D = 1 character or more of data (depends on command)
} = stop byte
*PLEASE NOTE: The two character {aa}(00-31) prefix, in the table below,
should be used ONLY when RS-485, (OPTION-Q), is selected.
Table 1.2 2015-05 Comman
d
ds
Commands
Command Syntax* Description
Set Transmitter Frequency {aaC1xxxx} where:
• xxxx = 4 characters standard (7 characters -Option-X)
• Range: 0950 to 2150 MHz, in 1 MHz steps
0950.000 to 2150.000 in 1 kHz steps (option-X)
Set Input Level {aaCIxx} where:
• xx = 2 characters
• Range: 10 to 40 (-10 to -40 dBm, in 1 dB steps)
Set Transmit Gain {aaC3xxx} where:
• xxx = 2 characters (0 to 30dB), 3 characters (-10 to -1dB)
• Range: -10 to 30 (-10 dB to +30 dB, in 1 dB steps)
Enable 10MHz RF Insertion {aaC5x} where x =:
(option E only) • 0 to disable 10MHz RF insertion
• 1 to enable 10MHz RF insertion
Enable Tx {aaCAx} where x =:
• 0 to disable Tx signal
• 1 to enable Tx signal
Enable External 10MHz {aaCEx} where x =:
(option E only) • 0 to disable External 10MHz ref signal
• 1 to enable External 10MHz ref signal
Enable Remote # Just # sign
Disable Remote {aaCR0} {CR and zero}
2015-05 Manual, Rev F Page 7 05/20/10

1.4 Use Information
A.Elevated operating ambient temperature - if installed in a closed or multi-unit rack assembly,
the operating ambient temperature of the rack may be greater than room ambient temperature.
Therefore, consideration should be given to Tmra.
B. Reduced air flow - Installation of the equipment in a rack should be such that the amount of air flow
required for safe operation of the equipment is not compromised. Additional space between unit
may be required.
C. Mechanical loading - Mounting of equipment in a rack should be such that a hazardous condition
does not exist due to uneven weight distribution.
D. Circuit Overloading - Consideration should be given to the connection of the equipment to the supply
circuit and the effect that overloading of circuits could have on over current protection and supply wiring.
Appropriate consideration of equipment name plate rating should be used, when addressing this concern.
E. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained. Particular
attention should be given to supply connections other than direct connection to the Branch
(use of power strips).
F. Top Cover - There are no servicable parts inside the product so, the Top Cover should not be removed.
If the Top Cover is removed the ground strap and associated screw MUST BE RE-INSTALLED
prior to Top Cover screw replacement. FAILURE TO DO this may cause INGRESS and/or EGRESS
emission problems.
2015-05 Manual, Rev F Page 8 05/20/10

2.0 Installation
2.1 Mechanical
The 2015-05 consists of one RF/Controller PCB housed in a 1 RU (1 3/4 inch high) by 16 inch deep chassis. A
switching, ± 12, +24, +5 VDC power supply provides power for the assemblies. The 2015-05 can be secured to
a rack using the 4 holes on the front panel. Figure 2.0 shows how the 2015-05 is assembled.
POWER
SUPPLY
FIGURE 2.0 2015-05 Mechanical Assembly
2015-05 Manual, Rev F Page 9 05/20/10

2.2 Rear Panel Input/Output Signals - Figure 2.1 shows the input and output connectors on the rear panel.
AC
GND
J18
10 MHZ REF
OUTPUT
AC1 - POWER IN
AC input for switching
power supply.
100-240 ±10% VAC,
47-60 Hz.
J10
AND
MONITOR
CONTROL
J10 - MONITOR AND CONTROL
DB9 female connector. see Table 2.1.
RF OUT
J4 J5J3
10 MHZ IF IN
EXT REF
J3 - 10 MHz EXT REF INPUT (Option -E)
10 MHz external reference input, 0 ± 3 dBm, 75
ohms, BNC female connector.
J5 - RF OUT
950-1525 MHz,
0 to -20 dBm output
see Table 2.2.
J4 - IF IN
140 MHz,
-10 to -40 dBm input
see Table 2.2.
SSPB FUSE
F2
F2 - SSPB FUSE (option -V)
2.5A, Fast Blo, 1/4” Fuse; installing fuse places +24
VDC, 2.5 amp, max on the RF OUT (J5 center pin).
DS7
VDC on RF
INPUT
DS7 - SSPB ALARM LED (option -V)
Lights yellow when +24 VDC SSPB
voltage is present on RF OUT, J5,
center pin.
J18 - 10 MHz REF OUTPUT (option -E)
10 MHz reference output. 75BNC
female connector.
15 234
678
9
FIGURE 2.1 2015-05 Rear Panel I/Os
TABLE 2.1 JJ10
J10 Pinouts (RS-232C/422/485*)
Pin Function
1Rx-
2 Rx+ (RS-232C)
3 Tx+ (RS-232C)
4Tx-
5GND
6 Alarm Relay: Common
7 Alarm Relay: Normally Open
8NotUsed
9 Alarm Relay: Normally Closed
*Remote Serial Interface
Interface: DB-9 Male
Protocol: RS-232C (RS-232C/422/485 option Q), 9600 baud rate, no parity, 8 data bits,
1 start bit, 1 stop bit.
TABLE 2.2
I
IF/RF
IF/RF Connector Optionns
Options
Option IF RF
STD BNC, 75Type F, 75
BBNC,75BNC, 75
CBNC,75BNC, 50
DBNC,50BNC, 50
F Type F, 75Type F, 75
JBNC,50Type F, 75
KBNC,50BNC, 75
MBNC,50Type N, 50
NBNC,75Type N, 50
2015-05 Manual, Rev F Page 10 05/20/10

2.3 Front Panel Controls and Indicators - The following are the front panel controls and indicators.
MENU
EXECUTE
F=1525 G=+10.0
MUTEREMOTE POWER
LCD DISPLAY
Display shows frequency in MHz
and Gain in dB
S1 - MENU/EXECUTE BUTTON
Press this to get into Program mode
and to execute any changes.
DS6 - POWER LED
Green LED indicates
presence of DC power.
DS1 - REMOTE LED
Yellow LED indicates
remote operation.
S2 - VERT. TOGGLE
Vertical toggle switch that controls
values in the Menu items when in
program mode. Does not function in the
normal display mode
S3 - HORIZ. TOGGLE
Horizontal toggle switch that
controls which values are being
adjusted. Does not function in the
normal display mode
ALARM
DS5 - UP MUTE LED
Yellow LED indicates
upconverter mute.
DS2 - UP ALARM LED
Red LED indicates
upconverter alarm.
FIGURE 2.2 2015-05 Front Panel Controls and Indicators
2015-05 Manual, Rev F Page 11 05/20/10

2.4 Installation / Operation
2.4.1 Installing and Operating the 2015-05, Upconverter Section
1. Connect a -10 dBm to -40 dBm signal to IF IN, J4 (Figure 2.1).
2. Connect the RF OUT, J5, to the external equipment.
3. Connect 100-240 ±10% VAC, 47 - 63 Hz to AC1 on the back panel.
4. Set the desired output frequency (See Section 2.5 Menu Settings).
5. Set the input level (See Section 2.5 Menu Settings).
6. Set the gain for -10 to +30 dB. Make sure the output stays within -20 to 0 dBm with the gain selected
and the input level provided. The firmware will prevent setting gain and input level outside this range.
(See Section 2.5 Menu Settings).
7. Be sure DS6 (green, DC Power) is on and DS2 (red, Alarm) is off (Figure 2.2).
8. AC Fuse - The fuse is a 5 mm X 20 mm, 2 amp slow blow (Type T) and is inserted in the far slot in the
drawer below the AC input as shown in Figure 2.3. There is a spare fuse in the near slot. If a fuse
continues to open, the power supply is most likely defective.
FUSE DRAWER
SPARE FUSE DRAWER
AC Fuse - 2 amp slow blow (Type T 2A GDC),
5 mm X 20 mm
~
INPUT
100-240± 10%VAC
47-63 Hz
2A MAX
FUSE
TYPE T 2A GDC
250 VOLT
FOR 100 - 240 V~
~
FIGURE 2.3 Fuse Location and Spare Fuse
2015-05 Manual, Rev F Page 12 05/20/10

2.5 Menu Settings
2.5.1 Functions - This section describes operation of the front panel controls. There are three operator
switches, the LCD display and alarm indicator LEDs. All functions for the equipment are controlled by these
components. The functions are (see Figure 2.4):
Power Up
Normal Display
Power Up
Normal Display
Menu 1 Frequency in MHz
Menu 2 Input Level (Set from -40 to -10)
Menu 3 Gain (-10 to +30, 1dB steps (0.1dB steps, option Z))
Menu 4 Up Mute
Menu 5 Set Unit to Remote Operation
Menu 6 Select External 10 MHz Ref (option E)
Menu 7 Select Reference Out (option E)
Menu 8 Set Remote mode (option Q)
Menu 9 Set RS-485 address (option Q)
Menu 10 View PCB Temperature (option T)
Menu 11 View SSPB Current (option V)
Save Menu When go to end
Alarm indications appear on the LEDs (see figure 2.2).
All program changes must start with the operation of the Menu/Execute switch and must also end with the
operation of the Menu/Execute switch verified by the “Save Settings?” Menu. If this sequence is not followed,
none of the changes will take effect. If programming is initiated and no operator action takes place for
approximately 12 seconds (before the final press of the Menu/Execute switch) the display will revert to its
previous status and you will need to start over.
2015-05 Manual, Rev F Page 13 05/20/10

2.5.2. Power On Settings
NOTE:The last status of a unit is retained even when power is removed. When power is restored, the unit
will return to it's previous settings.
When power is first applied, the LCD display goes through three steps.
1.The LCD goes black to show all segments are functioning.
2.The software version will be displayed.
R E V 1 . 0 0
3.The present frequency and gain of the upconverter is shown.
F = 14 5 0 G = + 1 0
The unit is now operational and ready for any changes the operator may desire.
2.5.3 Control Switches
1. Menu/Execute - Any change to the programming of the unit must be initiated by pressing the
Menu/Execute switch and completed by pressing the Menu/Execute switch.
2. Horizontal Switch - This switch is mounted so its movement is horizontal and moves the cursor left or
right.
3. Vertical Switch - This switch is mounted so its movement is vertical and has two functions:
a. During frequency , gain changes, the vertical movement will raise or lower the number in
the direction of the arrows.
b. For other functions such Mute on/off, the vertical switch will alternately turn the function on or
off regardless of the direction operated.
2015-05 Manual, Rev F Page 14 05/20/10

2.5.4 Frequency Changes
At any time during the modification process, if you have made a mistake and do not wish to save the changes
you have made, do not press the Menu/Execute switch; simply do nothing for approximately 12
seconds, and the system will return to the normal operating mode or scroll to “R” and push the
menu/Execute switch and select “NO” in the “SAVE SETTINGS?” window.
To change the FREQUENCY:
Operate the Menu/Execute switch until you get to the menu item you want to change see Figure 2.4 for
the sequence of menu options. The following display is for changing the upconverter frequency:
F R E Q = 1 4 5 0 R
Pressing the Up/Down switch down will toggle the display to:
F R E Q = 1 3 5 0 R
By using the horizontal rocker switch the cursor can be moved left or right .
F R E Q = 1 3 5 0 R
NOTE: CHANGES DO NOT TAKE PLACE ON FREQUENCY UNTIL YOU GO TO THE
SAVE MENU AND INDICATE YOU WANT TO SAVE THE CHANGES.THE CARRIER IS
MUTED WHEN FREQUENCY IS CHANGED.
When the display indicates the value desired you can push the Menu/Execute switch to the next item:
U P I N L V L = - 2 0 R
OR you can scroll to “R”, push the Menu/Execute switch to get to:
S A V E S E T T I N G S ? Y N
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings.
Pushing the Menu/Execute switch then takes you to the :
F = 13 5 0 G = + 1 0
Figure 2.4 gives the menu items and how to make changes
2015-05 Manual, Rev F Page 15 05/20/10

2.5.5 Gain Changes
When you get to this menu note that the gain changes will be made as you make them but if you do not wish to
save the changes you have made, scroll to “R” and push the menu/Execute switch and select “NO” in the
“SAVE SETTINGS?” window or do not press the Menu/Execute switch; simply do nothing for
approximately 12 seconds, and the system will return to the normal operating mode.
To change the UPCONVERTER GAIN, first push the Menu/Execute switch until you get to the gain setting:
The following display is for changing the upconverter input level. This is an important setting to
optimize spurious and should be made as accurately as possible:
U P I N L V L = - 2 0 R
NOTE: CHANGES TAKE PLACE ON LEVEL AND GAIN IMMEDIATELY BUT DO NOT GET
SAVED UNTIL YOU GO TO THE SAVE MENU AND INDICATE YOU WANT TO SAVE THE
CHANGES.
Press the Up/Down switch to change the level in 1 dB steps and then push the Menu/Execute switch to
get to the Gain setting:
G A I N = + 2 0 R
Pressing the Up/Down switch to change the gain in 1 or 10 dB steps and then push the Menu/Execute
switch to get to the Gain setting:
G A I N = + 2 0 R
By using the horizontal rocker switch the cursor can be moved left or right .
Pressing the Up/Down switch down will toggle the display digit selected until you have the desired gain.
NOTE: THE GAIN WILL BE CHANGED AS YOU ADJUST THE NUMBERS. HOWEVER, THE
VALUE WILL NOT BE STORED UNTIL YOU INDICATE YES IN THE SAVE SETTINGS
WINDOW. DO NOT SET A GAIN THAT WOULD EXCEED 0 dBm OR HAVE LESS THAN -20 dBm
OUTPUT LEVEL. THE FIRMWARE PREVENTS YOU FROM THIS.
When the display indicates the value desired you can push the Menu/Execute switch to the next item OR
you can scroll to “R”, push the Menu/Execute switch to get to:
S A V E S E T T I N G S ? Y N
Selecting Ywill save the new settings. Selecting Nwill revert to the previous settings.
Pushing the Menu/Execute switch then takes you to the :
F = 13 5 0 G = + 2 0
Figure 2.4 gives the menu items and how to make changes
2015-05 Manual, Rev F Page 16 05/20/10

2.5.5 Alarm Indications
An alarm condition for will occur if any local oscillator phase lock loop (PLL) comes out of lock.
The Mute LED will light if you select Mute and the Remote LED will light when you select the Remote mode.
ON POWER UP
NORMAL DISPLAY
PUSHING MENU/EXECUTE SEQUENCE
REV 1.00
F = 1450 G = +10.0
F = 1450
SCROLL <>
SCROLL
PUSH BUTTON
OTHER? Y N
REMOTE OFF
EXT REF OFF
UP MUTE OFF
SCROLL <>
SCROLL
PUSH BUTTON
SCROLL <>
SCROLL
PUSH BUTTON
SCROLL <>
SCROLL
PUSH BUTTON
SCROLL <>
SCROLL
PUSH BUTTON
PUSH BUTTON
Power Up
Normal Display
Menu 1 Frequency
Menu 2 Input Level (Set from -40 to
-10)
Menu 3 Gain (-10.0 to +30.0)
Menu 4 Up Mute
Menu 5 For Other Settings (below)
Menu 6 Set Unit to Remote
Operation
Menu 7 Select External 10 MHz
Reference (option E)
Menu 8 Select 10MHz Reference
Out (option E)
Menu 9 Set Remote Mode
(option Q)
Menu 10 Set RS-485 Address
(option Q)
Menu 11 View PCB temperature
(option T)
Menu 12 View SSPB current (option
V)
Save? When “R” is selected from
any above menu or at the end
UP INLVL = -20
G = +10.0
SCROLL <>
SCROLL
PUSH BUTTON
SCROLL <>
SCROLL
PUSH BUTTON
SSB DC = 1.86 A
SAVE SETTINGS? Y N
SCROLL <>
PUSH BUTTON
TEMP = 35 DEG
R
R
R
R
R
R
R
R
R
REF OUT OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
RS 485 OFF
SCROLL <>
SCROLL
PUSH BUTTON
R
ADDRESS = 00
SCROLL <>
SCROLL
PUSH BUTTON
R
SCROLL <>
PUSH BUTTON
SCROLL <>
PUSH BUTTON
FIGURE 2.4 Menu Display and Sequences
2015-05 Manual, Rev F Page 17 05/20/10

CROSS TECHNOLOGIES, INC.
6170 Shiloh Road
Alpharetta, Georgia 30005
[phone]
FAX [phone]
Toll Free 888-900-5588
WEB www.crosstechnologies.com
E-MAIL [email protected]
2015-05 Manual, Rev F Page 18 05/20/10
