Crosswater Berea 11-19-T User manual

15122860-B
Adjustable PliersAdjustable Wrench
Tools You Will Need
Screwdriver
For ease of installation you will need:
ƔTo read all the installation completely before beginning.
ƔTo read all warnings, care, and maintenance information.
ƔTo complete the valve rough-in prior to installing this trim kit.
Berea Trim for Dual-handle Thermostatic Valve
with Volume Control
11-19-T
Installation Instructions
Before beginning installation, check for any damage
that may have occurred during transport.
Note: Damage claims cannot be made during or
after installation.

11-19-T
Installation Instructions
15122860-B 2
5
12
4
Slide on top plate on the finished
sleeve. If the top plate does not
engage the finished sleeve an
extension kit is necessary.
Please contact your Crosswater
London dealer.
Ensure that the valve is
installed correctly. Turn off the water supply and remove
the mud guard.
Install escutcheon with 2 screws.
Do not overtighten the screws.
3
Thread on finished sleeve.
Slide on temperature control
escutcheon engaging the stem
making sure the temperature
override button facing straight up.
Secure with screw.
Set the volume control handle and
escutcheon at 12 o'clock and place
on the top stem and nipple. Rotate
the escutcheon clockwise to secure
the assembly to the plate.
6
Align the handle at 6 o' clock position
and slide handle into escutcheon
and secure with set screw.
79
Turn on the water supply. Remove
the shower head and turn on the
volume control handle to flush the
system.
8

11-19-T
15122860-B 6
Applicable Standards/Codes
Installation Dimensions
15122860-B3
IAPMO certified to meet or exceed the following:
$60($&6$%
8QLIRUP3OXPELQJ&RGH
1DWLRQDO3OXPELQJ&RGHRI&DQDGD
$'$&RPSOLDQW
Rotate the cartridge stem to adjust
safety temperature. Rotate clockwise
to reduce temperature while rotate
counterclockwise to increase
temperature. Once the temperature
is 100ºF go to step #13.
Turn off the water supply. Remove
temperature control handle and
escutcheon.
100
o
F
Safety
Temperature
10
Turn on the water supply, with the
temperature control handle in the
default position, measure the
temperature of the water. If the
temperature is 100ºF, go to step #14,
if not go to step #11.
100
o
F
Safety
Temperature
12
11
13
Reinstall the temperature control
handle and escutcheon making sure
the temperature override button is on
top and the handle is set at 6 o'clock.
Turn off the water supply. Remove
handle, escutcheon.
The valve maximum temperature is
set at 107ºF. Should your customer
like to change this go to step #15.
If not go to step #20.
107
o
F
Hottest
Temperature
15
14
Rotate the inner white temperature
range control ring to adjust
temperature. Rotate clockwise to
reduce temperature while rotate
counterclockwise to increase
temperature.
17
Remove the inner white temperature
range control ring.
16
Reinstall the inner white temperature
range control ring.
18
- ʾ
- ʾ
- ʾ
- ʾ
4 ʾ
 ʾ
- ʾ   ʾ
-1 ʾ  -1/4"
6-1/4" - - ʾ
137

11-19-T
15122860-B 4
Cleaning Instructions
Replacement Parts
Ɣ2QO\XVHDVRIWGDPSHQHGVSRQJHRUFORWKWRFOHDQDQGSROLVKWKHIL[WXUH
Ɣ:LSHIL[WXUHVDQGWKHLPPHGLDWHDUHDVFOHDQDQGULQVHFRPSOHWHO\ZLWKZDWHULPPHGLDWHO\DIWHULQVWDOODWLRQDQGDIWHU
applying any cleaner.
Ɣ,I\RXDUHXVLQJDFOHDQLQJFRPSRXQGRQRUFORVHWRWKHSURGXFWSOHDVHWHVWWKHFRPSRXQGRQDKLGGHQDUHDRIWKH
trim to ensure it will not damage the finish.
Ɣ'RQRWDOORZFOHDQHUVWRVRDNDQ\ZKHUHRQWKHSURGXFW
15122860-B5
NO. Description Part NO.
4 Screw M4X80 5T0F0266NT
5 Extension kit 9Q242000
1Spring
˂
Button
˂
Pin 9Q1112
2 Handle Assembly 9Q1253
Hex Set Screw 9Q1356NT3
6 Temperature Range Control Ring 5K202720PL
19
Installation completed.
20
Reinstall handle, escutcheon.
1
2
3
4
56
Ordered Separately if needed
Rinse away any traces of soap and gently dry with a clean, soft cloth after each use. Rinse
completely with water and dry any overspray. This will maintain the finish and avoid water
spotting.
To remove mineral deposits, use a 50/50 solution of white vinegar and water. Do not allow the
solution to soak on the product.
Simichrome Polish® contains a protective film to enhance maintenance and is helpful in
preventing water spot buildup. Follow instructions to ensure optimum results.
Never use an abrasive material such as a brush or scouring pad to clean the surface. The use
of abrasive cleaners, cleansers or disinfectants will alter the surface finish and void the
warranty.
Do not allow certain materials such as toothpaste, cologne, shaving cream, nail polish remover,
vinegar, wine, drain and glass cleaners to remain on the surface. Prolonged contact will alter
surface finishes and void the warranty.
We DO NOT recommend using any household cleaners as many can cause damage to
the finish.
Please see the website for care instructions for specific finishes.
Cleaning Instructions
Warranty - This Crosswater London product is covered by a limited lifetime warranty. For full details, terms and conditions please visit our website.
