CS Instruments DP 400 mobil User manual

DP 400 mobil V1.00 EN Seite 1 von 15
Installation- and operating instructions
portable dew point meter with
integrated pressure measurement
DP 400 mobil
EN –English

Foreword
DP 400 mobil V1.00 EN Seite 1 von 15
Foreword
Dear customer,
thank you very much for deciding in favour of the DP 400 mobil. Please read this
installation and operation manual carefully before mounting and initiating the device
and follow our advice. A riskless operation and a correct functioning of the DP 400
mobil are only guaranteed in case of careful observation of the described instructions
and notes

Inhaltsverzeichnis
DP 400 mobil V1.00 EN Seite 2 von 15
II. Inhaltsverzeichnis
II. Inhaltsverzeichnis ........................................................................................................2
1Safety instructions ..........................................................................................................3
1.1 General.................................................................................................................................... 3
1.2 Installation .............................................................................................................................. 4
1.3 Lithium Ion Batterie ............................................................................................................... 4
2Application area...............................................................................................................5
3Intended use.....................................................................................................................5
4Technical Data DP 400 mobil..........................................................................................6
5Input signals analogue sensors.....................................................................................7
6Cable cross-section.........................................................................................................7
6.1 Sensor circuit points/Output signal..................................................................................... 7
7Installation / Connection / Measurement.......................................................................8
7.1 User controls / connection.................................................................................................... 8
7.1.1 Dew point measurement.................................................................................................... 8
7.1.2 Display / Datalogger .......................................................................................................... 9
7.1.3 Sensor connections / Power supply connection................................................................ 9
7.2 Measurment dew point........................................................................................................ 10
7.2.1 Measurment test set up/ test procedure.......................................................................... 10
7.2.2 Display / data logger........................................................................................................ 11
8DP 400 mobil settings in idle state / storage...............................................................12
9Operation / setting display and datalogger(optional).................................................13
10 Cleaning Display.........................................................................................................14

Safety instructions
DP 400 mobil V1.00 EN Seite 3 von 15
1 Safety instructions
1.1 General
Please check whether this manual corresponds with the device type.
Please attend to all notes indicated in this instruction manual. It contains essential information
which has to be followed during installation, operation and maintenance. Therefore, this
instruction manual has to be read categorically by the technician as well as by the responsible
user/qualified personnel before installation, initiation and maintenance.
This instruction manual has to be available at any time at the operation site of the DS 400.
Regional and national regulations respectively, have to be observed in addition to this instruction
manual if necessary.
In case of any obscurities or questions with regard to this manual or the instrument please contact
CS Instruments GmbH & Co.KG
Warning!
Supply voltage!
Contact with supply voltage carrying non-insulated parts may cause an electric shock
with injury and death.
Measures:
•Note all applicable regulations for electrical installations (e.g. VDE 0100)!
•Carry out maintenance only in strain less state!
•All electric works are only allowed to be carried out by authorized qualified personnel.
Warning!
Inadmissible operating parameters!
Undercutting and exceeding respectively of limit values may cause danger to persons
and material and may lead to functional and operational disturbances.
Measures:
•Make sure that the DP 400 mobil is only operated within the admissible limit values indicated on
the
type label.
•Strict observance of the performance data of the DP 400 mobil in connection with the application.
•Do not exceed the admissible storage and transportation temperature.
Further safety instructions:
•Attention should also be paid to the applicable national regulations and safety instructions during
installation and operation.
•The DP 400 mobil is not allowed to be used in explosive areas.
Additional remarks:
•Do not overheat the instrument!
•Change of battery and SD-Card are only allowed to be carried out by authorized qualified personnel
and in strain less state
Attention!
Malfunctions at the DP 400 mobil!
Faulty installation and insufficient maintenance may lead to malfunctions of the DP 400
mobil which may affect the measuring results and which may lead to misinterpretations.

Safety instructions
DP400 mobil V1.00 EN Seite 4 von 15
r
1.2 Installation
NOTE!
The plug of the power supply unit (charger) is used as a separator.
This separator must be clearly recognisable and easily accessible by the user. A
plug connector with a CEE7/7 system is necessary.
NOTE!
Only the supplied power supply may be used.
1.3 Lithium Ion Batterie
Warning!
Battery!
The replacement of the battery must only be carried out by authorised and
skilled personnel, and when the device is de-energised.
Only the original battery of the manufacturer with built-in protection circuit
may be used.
Do not use any other power supply for charging the Li-Ion battery as the provided.
Do not charge the battery under conditions that are not specified in the manual.
Do not charge the battery in an environment with flammable substances. Never charge the
battery unattended.
Transport
The contained lithium ion batteries are subject to the Dangerous Goods Legislation requirements. The user
can transport the batteries by road without further requirements.
When being transported by third parties (e.g.: air transport or forwarding agency), special requirements on
packaging and labelling must be observed. For preparation of the item being shipped, consulting an expert
for hazardous material is required.
Please also observe possibly more detailed national regulations.
Disposal
The datalogger, rechargeable batteries, accessories and packaging should be sorted for
environmental friendly recycling.
Do not dispose of power tools and batteries/rechargeable batteries into household waste!
Only for EC countries:
According to the European Guideline 2012/19/EU, power tools that are no longer
usable, and according to the European Guideline 2006/66/EC, defective or used
battery packs/batteries, must be collected separately and disposed of in an environmentally
correct manner.
Batteries no longer suitable for use can be directly returned at:
CS Instruments GmbH & Co.KG
Zindelsteiner Str. 15
D-78052 VS-Tannheim
CS Instruments GmbH & Co.KG
Am Oxer 28c
D-24955 Harrislee

Application area
DP 400 mobil V1.00 EN Seite 5 von 15
2 Application area
The portable dew point measuring device in a robust case has been specially developed for field
applications. The device has a high-precision digital dew point sensor. In addition to the dew point
(pressure dew point), the temperature, relative humidity, absolute humidity (g / m³) as well as other
moisture values are measured. Integrated pressure measurement up to 16 bar.
The measuring gas / compressed air is connected via PTFE hose to the 6mm plug connections.
The operation is carried out via the clear 3.5 "touch screen. The optional data logger enables the
recording of all measured values over hours, days or weeks (100 million measured values of storage
capacity)
Any analogue sensors (0/4 - 20 mA, 0 - 1/10/30 V), pulse) are easy and fast to configure. Digital
sensors can be connected via RS 485, Modbus RTU.
Optional:
Network-capable and data transmission worldwide via Ethernet, integrated web server.
3 Intended use
The dew point measuring device with data logger DP 400 mobile is designed for portable data
acquisition and storage of analog and digital input signals.
The DP 400 mobil is designed and designed exclusively for the intended use as described herein and
may only be used accordingly.
The user must check whether the device is suitable for the selected application. Ensure that the medium
is compatible with the media-bearing parts. The technical data in the data sheet are binding.
Incorrect handling or operation outside the technical specifications is prohibited. Claims of any kind due
to improper use are excluded.

Technical data DP 400 mobil
DP 400 mobil V1.00 EN Seite 6 von 15
4 Technical Data DP 400 mobil
Dimensions of housing
270x225x156 mm
Weight
3,2 kg
Case Material
impact resistant HDPE/HWU –plastic (ABS).
Sensor inputs
Sensor inputs (digital / analogue) depending on configuration
Digital sensors RS 485/ModBus RTU
Analogue third-party sensors 0/4 –20 mA, 0 - 1/10/30 V, pulse,
Pt100/Pt1000.
Measuring ranges
Dew point: -80 … +50°Ctd
Temperature: -20 …70°C
Humnidity: 0 …100% RH
Pressure: 0 ...16 bar
Accuracy dew point
± 1°C for 20...-20°Ctd
± 2°C for -20...-50°Ctd
± 3°C for -50...-80°Ctd
Accuray pressure
± 0,5 %
Power supply for sensors
Output voltage:: 24 VDC ± 10%
Output current : a.) Digital board 120 mA continuous operation
b.) Analogue board: 60mA
Interfaces
USB-Stick,
Ethernet RTU/TCP optional,
WEB-Server optional
Memory card
Speichergröße 4 GB-Memorycard-Standard
Power supply
Li-Ion Battery,
Power Supply 100 –240 VAC/50 –60 Hz with output 12VDC
Colour screen
3.5“-Touchpanel TFT transmissive, graphics, curves, statistics
Operating temperature
0 –50 °C
Storage temperature
-20 to +70°C
Process connection
6mm plug-in connection
Optionally
Ethernet Modbus TCP
Optionally
Webserver
Optionally
Mathematics calculation function

Inputsignals
DP 400 mobil V1.00 EN Seite 7 von 15
5 Input signals analogue sensors
6 Cable cross-section
6.1 Sensor circuit points/Output signal
ODU Medi-Snap, AWG26 cable cross-sections: 0,14 mm2
Input signal
Current signal
(0 –20 mA / 4 –20 mA)
internal or external
power supply
Measuring range
0 –20 mA / 4 –20 mA
Resolution
0,0001 mA
Accuracy
0,03 mA 0,05 %
Input resistance
50 
Voltage signal
(0 - 1V)
Measuring range
0 - 1 V
Resolution
0,05 mV
Accuracy
0,2 mV 0,05 %
Input resistance
100 k
Voltage signal
(0 - 10 V / 30 V)
Measuring range
0 - 10 V/30 V
Resolution
0,5 mV
Accuracy
2 mV 0,05 %
Input resistance
1 M
RTD
Pt100
Measuring range
-200 - 850 °C
Resolution
0,1 °C
Accuracy
0,2 °C at -100 - 400 °C
0,3 °C (further range)
RTD
Pt1000
Measuring range
-200 - 850 °C
Resolution
0,1 °C
Accuracy
0,2 °C at -100 - 400 °C
0,3 °C ( further range )
Pulse
Measuring range
minimal pulse length 100 μ s
frequency 0 - 1 kHz
max. 30 VDC

Installation / Connection / Measurement
DP 400 mobil V1.00 EN Seite 8 von 15
7 Installation / Connection / Measurement
7.1 User controls / connection
7.1.1 Dew point measurement
Plug in connection
Medium closed with
red seal plug.
Medium output
Control Medium on/off
Control dry container on/off Access dry container

Installation / Connection / Measurement
DP400 mobil V1.00 EN Seite 9 von 15
7.1.2 Display / Datalogger
To switch on / off the DS400 mobile you have to press ( >= 3sec) the on / off knob.
A short press of the on / off knob during operation opens a popup with indication of the remaining
operation time.
The data logger is operated via the touchpanel integrated in the display.
7.1.3 Sensor connections / Power supply connection
NOTE!
Only the supplied power supply may be used.
USB
Display with integrated
touchpanel
On- / Off- Switch
Power supply input
Sensor Input (Digital/Analog)
according configuration, see label
on front panel

Installation / Connection / Measurement
DP400 mobil V1.00 EN Seite 10 von 15
7.2 Measurement dew point
7.2.1 Measurement test set up/ test procedure
The maximum operating pressure is 15 bar.
It is important that the media connections are correctly plugged in and the
connection hoses are correctly installed.
Otherwise, the pressure tightness / strength of the device is compromised.
Before disconnecting the DP 400 mobile from the gas line, it is necessary to vent
the system to atmospheric pressure, otherwise serious injuries may occur.
Note:
At delivery, the dew point measuring device is designed in such a way that the sample gas is
introduced via the medium inlet (6 mm plug input) and with a direct flow out at the medium outlet, see
figure.
For applications of gases other than compressed air, it is mandatory to change the
media outflow (gas out) and to lead out it safely via a suitable line.
S“Gas Out“ direct flow out

Installation / Connection / Measurement
DP400 mobil V1.00 EN Seite 11 von 15
Test procedure:
1.) Both controls , Medium and dry container, have to be closed completely
2.) Remove red seal plug and connect the gas input line at „ Gas In“.
3.) For measurements with gases, except compressed air, the „Gas out“ is to change to a suitable
line output.A secure gas flow out is to ensure.
4.) The tightness of all connections is to be checked and ensured.
5.) Switch on the display / datalogger. (to press switch on/off button >=3 sec )
6.) Slowly open the control "Medium", max. until the red mark is visible.
7.) Allow the gas to flow until the display shows a stable reading.
8.) Switch off the unit after completing the measurement
9.) Before disassembling the connections, the system must be vented to atmospheric pressure.
The measuring point should be as close as possible to the critical measuring point in order to obtain a
truly representative measurement. The length of the DP 400 mobile cable should be as short as
possible. Only use PTFE piping (supplied) or stainless steel.
7.2.2 Display / data logger
The display of the DP 400 mobils is at time of delivery already preconfigurated.
In addition to the pressure up to 16bar, the dew point (pressure dew point), the temperature, relative
humidity, absolute humidity (g / m³) as well as other moisture values are measured
The humidity values are indicated in display channel A1 as well as the pressure on channel B1.
The DP 400 mobile provides an optional data logger for recording the measured values. (Storage
capacity 100 million measured values)
For more details, see instruction manual DS 400 mobil chapter data logger.
Download Link: Instruction manual DS 400 mobile
SControl Medium (1) open,
Rmax. until red marking is visible
Control dry container (2)closed.
(completely screwed in)
2
1

Installation / Connection / Measurement
DP400 mobil V1.00 EN Seite 12 von 15
8 DP 400 mobil settings in idle state / storage
The existing drying container should be activated between the measurements or especially during
longer periods of interruption and storage. This is to protect the moisture sensor from excessively high
moisture and thus to ensure fast response times.
SControl dry container (2) open.
R(red marking straight visible)
Control Medium (1) closed.
(completely screwed in)
Red seal plug mounted again.
1
2

Operation / Setting Display and Datalogger /
DP 400 mobil V1.00 EN Seite 13 von 15
9 Operation / setting display and datalogger(optional)
The operation is largely self-explanatory and menu-driven via the touch panel.
The selection of the respective menu items occur via short "tapping" with the finger or a soft round pen.
Attention: Please use no pens or other objects with sharp edges!
The foil can be damaged!
The DP 400 mobile is pre-configured, i.e.the pressure dew point, temperature, pressure as well as rel.
humidity are displayed directly on the start screen. Configuration is freely definable, up to 5 different
values can be displayed.
-51,41
22.33 °C
12.19 bar-65.86 °Ctd
RDP
The data logger option must be ordered and enabled separately.
For a detailed description of the operation, use of datalogger, the free digital and analog inputs etc.,
please refer to the operating manual DS 400 mobile.
Download Link: Instruction manual DS 400 mobile

Cleaning
DP 400 mobil V1.00 EN Seite 14 von 15
10 Cleaning Display
Note:
The DP 400 mobil has a cleaning-function which protects the display against
unintentional operation in the event of cleaning measures
Cleaning of the DP 400 mobil must be undertaken using a slightly damp (not wet) cotton cloth or one-
way wipe, and mild, commercially available cleaner/soap.
For decontamination, spray the cleaner on an unused cotton cloth or one-way wipe, and wipe the
component comprehensively. Perform the final drying with a clean cloth or by air drying.
In addition, the local hygiene provisions need to be observed.
Warning!
Damage possible!
A too high degree of humidity and hard and pointed objects, as well as
aggressive cleaners, cause damage to the data logger and to the integrated
electronic components.
Measures
•Never clean with a soaked cloth.
•Do not use aggressive cleaners.
•Do not use pointed or hard objects for cleaning.
