CTC Union IFS-803GSM User manual

Installation
The switch comes with both wall mount and DIN rail hardware
brackets. When installing the DIN rail bracket, be sure to correctly
align the orientation pin.
Figure 7. DIN Rail Figure 8. Wall Mount
The switch with DIN Rail bracket has a steel spring in the upper
rail of the bracket. This spring is compressed for mounting and
un-mounting by applying downward force.
Figure 9. Mounting Figure 10.Un-mounting
Introduction
IFS-803GSM(-E) are managed industrial grade Fast Ethernet
switches that provide stable and reliable Ethernet transmission.
Housed in rugged DIN rail or wall mountable enclosures, these
switches are designed for harsh environments, such as industrial
networking and intelligent transportation systems (ITS) and are
also suitable for many military and utility market applications
where environmental conditions exceed commercial product
specifications. Standard operating temperature range models
(-10°C to 60°C) and wide operating temperature range models
(-40°C to 75°C) fulfill the special needs of industrial automation
applications.
Features
Redundant dual DC inputs 12/24/48VDC
IP30 rugged metal housing
Wide temperature range -40°C~75°C (IFS-803GSM-E)
Supports many advanced Ethernet L2 functions
Console, Telnet (ssh), Web and SNMP management
Industrial grade EMS, EMI, UL60950-1, EN50121-4,
EN61000-6-2, EN61000-6-4
Specifications
Ethernet Interface
Standards: IEEE802.3 (10Base-T), 802.3u (100Base-TX)
RJ-45 (shielded) Ports: 8 ports
Speed: 10/100M
Optical Interface
Standards: IEEE802.3u (100Base-FX), 802.3z (1000Base-X),
802.3ab (1000Base-T)
3 ports, SFP based
Speed: 100/1000M (Manual)
Switch Features
Store & Forward Switch
Supports IEEE802.3x Flow Control
Auto MDI/MDI-X
Duplex: Full/Half (Auto-negotiation per IEEE802.3u)
Switching Fabric: 7.6Gbps (Non-blocking)
Packet Buffer: 1Mb
MAC Table: 8K
MTU: 64~9600 bytes
Quick Installation Guide
IFS-803GSM
IFS-803GSM-E
Industrial Grade Managed Fast Ethernet Switches
Specifications (cont.)
Power
Absolute Input Range: 9.6VDC~60VDC
Reverse Polarity Protection: Yes
Dual Power Inputs: Yes
Connector: Removable terminal block
Consumption: 7.7W
Mechanical
Water & Dust Proof: IP30 Protection
Dimensions: 116 mm (D) x 64 mm (W) x 152 mm (H)
Mounting: DIN-Rail, Wall Mount (Kits included)
Weight: 790 g
Environmental
Operating Temperature: -10°C~60°C (IFS-803GSM)
-40°C~75°C (IFS-803GSM-E)
Storage Temperature: -40°C~85°C
Humidity: 5%~95% (Non-condensing)
Certifications
EMC: CE
EMI (Electromagnetic Interference): FCC, FCC Part 15 Subpart
B Class A, CE EN55022 Class A
Railway Traffic: EN50121-4
Immunity for Heavy Industrial Environment: EN61000-6-2
Emission for Heavy Industrial Environment: EN61000-6-4
EMS (Electromagnetic Susceptibility) Protection Level:
EN61000-4-2 (ESD) Level 3, Criteria B
EN61000-4-3 (RS) Level 3, Criteria A
EN61000-4-4 (Burst) Level 3, Criteria A
EN61000-4-5 (Surge) Level 3, Criteria B
EN61000-4-6 (CS) Level 3, Criteria A
EN61000-4-8 (PFMF, Magnetic Field) Field Strength:
300A/m, Criteria A
Safety: UL60950-1
Shock: EN60068-2-27
Freefall: EN60068-2-32
Vibration: EN60068-2-6
MTBF: 409,312 hours (MIL-HDBK-217)
[email protected]
- 1 -
- 2 -
V1.0
- 7 -
To download this QIG or a more complete user manual, please visit
http://www.ctcu.com/Industrial/
T+886-2-26591021
F+886-2-26590237
E[email protected]
CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60 Zhouzi St., Neihu District, Taipei 114
Taiwan
© 2014 CTC Union Technologies Co., Ltd.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
