CTC Union TSB1000 Series User manual

TSB1000 Series Modular Switch BoxTSB1000 Series Modular Switch Box
4 Channel4 Channel
Product ManualProduct Manual

2
• Introduction...................................................................3
• Product Description...........................................................3
• Product Dimensions & Diagram................................................4
• Mounting Instructions .........................................................5
• Conduit Entry .................................................................6
• Grounding ....................................................................7
• Installation of Sensor/Signal Input Cable.......................................8
• Post Installation Testing ..................................................... 11
• Warranty & Return Information .............................................. 13
T  C

3
I
CTC modular switch box solutions allow for the monitoring of remotely mounted
vibration sensors, which would otherwise be restricted to human access due to
safety considerations.
TSB1000 Series Modular Switch Box Overview: 4 switched triaxial sensor input
module for a total of 12 channels, fiberglass enclosure
CTC modular switch box solutions allow for the monitoring of remotely mounted
vibration sensors, which would otherwise be restricted to human access due to
safety considerations.
The TSB1000 Series 4 Switched Triaxial Channel fiberglass modular switch box
is used to convert the four-conductor input wiring of up to 4 remotely installed
triaxial accelerometers to switched BNCs and a switched four-pin connector for
data collection. Input wiring from each sensor is connected to the outputs via
quick-connect or screw terminal blocks. Each terminal block includes inputs for
signal/power on each axis, common and shield. The shield drain wire is earth
grounded via a ground stud that is mounted to the side of the fiberglass enclosure.
Additional switch box modules can be installed or removed after initial
manufacturing and onsite installation, using the quick-release DIN rail clip. Each
new module features a detachable plug for easy cable installation. If continuous
output is desired, select the TSB1001 Series. On all continuous output modules,
a quick disconnect Tplug is supplied to easily connect and disconnect the input
wiring.
Rated for NEMA 4X (IP66), the TSB1000/TSB1001 Series can withstand harsh
environments including temperatures ranging from -58 to 180 °F (-50 to 82 °C).
The box is also resistant to hose directed fluid and corrosion. A snap latch is
installed on the door allowing the box to be sealed from the elements when not
in use.

4
P D
Measurement
Location Card
Four-pin MIL
Output Connector
Switch
BNC Output
Connectors
Figure 1. Dimensions
Figure 2. Diagram
Side View Rear View

5
M I
Note: if you have purchased a modular switch box without cable entries provided,
you should add your own entry prior to mounting the modular switch box. CTC
does not recommend putting holes in the top of the enclosure due to access and
moisture concerns.
Mounting
Holes
0.33 in./8.38 mm
Figure 3. Modular Switch Box Rear View

6
C E
If you are running conduit to your enclosure, ensure the conduit cable entry
enters from the bottom of the enclosure when mounted.
Note: To ensure moisture will not flow into the enclosure, a hole should be drilled
at the lowest point in the conduit to provide drainage for any moisture.
Correct
Figure 4. Conduit Entry for Modular Switch Box
Incorrect
Drill Drain
Hole Here

7
G
Ensure the shield ground wire on the TSB1000 Series modular switch box is
grounded to earth ground.
A. Mounting to Earth Ground
When mounting TSB1000 Series modular switch boxes to earth ground (such as
an I-Beam), mount the shield ground wire using a mounting bolt through one of
the mounting brackets on the enclosure.
Figure 5. Proper Shield Grounding Technique

8
B. Mounting to non-grounded structure
When mounting the modular switch box to a non-grounded structure, ensure the
shield ground wire or customer supplied ground wire is tied to a source of earth
ground.
Figure 6. Ground Wire Placement
S I
Installation of sensors/signal input cable
1. Feed blunt end through the cable entry at the bottom of the enclosure.
Note: it is recommended that cables are marked on both ends.
For cord grip cable entry, take off the cord grip cover with bushing and run cable
into enclosure, hand tighten cord grip cover to base to prevent damage of cord
grip.

9
1. Strip outer jacket of cable back 1¼ in. and remove all of the shielding.
2. Separate the internal wires from the shield.
3. Strip red and black insulation back ¼ in.
Figure 8. Bottom View
Figure 7. Front View
4. Locate the appropriate plug (identified by channel number), remove it, and
install the wires using a small flathead screwdriver. Push plug back into location.
Orientation is as follows:
a. Green insulated conductor wire is connected to Channel X.
b. Red insulated conductor wire is connected to Channel Y.
c. White insulated conductor wire is connected to Channel Z.
d. Black insulated conductor wire is connected to (-).
e. Shield drain wire is connected to ground (GND).
Figure 9. Stripped Wire
(-) Common
Shield / Drain wire
(+) Channel Y
(+) Channel X
(+) Channel Z

10
5. Insert plug into the appropriate PC board connector and double check to ensure
that the cable is going to the correct channel.
6. Mark the Measurement Location Card located on the inside front cover with a
description of each measurement location.
Figure 11. Connecting Cables to Modular Switch Box (TSB1001)
Figure 10. Connecting Cables to Modular Switch Box (TSB1000)
X
Y
Z
-
GND
SENSOR #1
SENSOR #2
SENSOR #3
SENSOR #4
X
Y
Z
-
GND
X
Y
Z
-
GND
X
Y
Z
-
GND
Sensor Inputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
Grey = Shield (Ground)
Sensor Outputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
X
Y
Z
-
GND
SENSOR #1
SENSOR #2
SENSOR #3
SENSOR #4
X
Y
Z
-
GND
X
Y
Z
-
GND
X
Y
Z
-
GND
Sensor Inputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
Grey = Shield (Ground)
Sensor Outputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
X
Y
Z
-
GND
SENSOR #1
SENSOR #2
SENSOR #3
SENSOR #4
X
Y
Z
-
GND
X
Y
Z
-
GND
X
Y
Z
-
GND
Sensor Inputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
Grey = Shield (Ground)
X
Y
Z
-
GND
SENSOR #1
SENSOR #2
SENSOR #3
SENSOR #4
X
Y
Z
-
GND
X
Y
Z
-
GND
X
Y
Z
-
GND
Sensor Inputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
Grey = Shield (Ground)
Sensor Outputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
X
Y
Z
-
GND
SENSOR #1
SENSOR #2
SENSOR #3
SENSOR #4
X
Y
Z
-
GND
X
Y
Z
-
GND
X
Y
Z
-
GND
Sensor Inputs
Green = Signal/Power X Axis
Red = Signal/Power Y Axis
White = Signal/Power Z Axis
Black = Common
Grey = Shield (Ground)
InputsInputs
Inputs Inputs

11
P I T
The TM1018 Accelerometer Verification Meter can be used to verify cable
conductivity, sensor location and proper wiring connections. The Verification
Meter will indicate if the sensor, cable and/or junction box is in working condition.
It will also confirm bias voltage of the accelerometer, which will inform you of the
operation of the internal accelerometer amplifier.
Testing Method:
1. Utilizing two personnel, Person A will be located at the modular switch box, while
Person B will be located at the measurement location.
2. Once positioned, Person A will connect the TM1018 to the data collector
output to the modular switch box and turn the Channel Selector to the channel
that corresponds to the referenced measurement. Person A should observe a
“NORMAL” LED reading.
3. Person B disconnects the cable from the accelerometer, and the TM1018 should
respond with an “OPEN” LED. Reconnect the cable to the accelerometer, and
the TM1018 should respond with a “NORMAL” LED.
4. Repeat for each measurement location to verify that accelerometer location is
properly identified at the modular switch box.
Figure 12. TM1018 Accelerometer Verication Meter

12
The following LED Readout indicates the circuit integrity:
1. Green LED: Normal. Indicates proper connection and an output bias will be given,
indicating the health of the sensor (4 – 16 V indicates a healthy accelerometer).
2. Yellow LED: Open Circuit. Indicates one of the following:
a. Cable connector is not connected to accelerometer.
b. Cable is open circuit (broken or not connected @ one end).
c. Accelerometer is not functioning correctly
3. Red LED: Short Circuit. Indicates one of the following:
a. Water or contamination in the connector.
b. Reverse Wiring ((+) and (-) leads are reversed).
c. Wires in modular switch box or cable connector (+) & (-) are touching.

13
W  R
Warranty
All CTC products are backed by our unconditional lifetime warranty. If any CTC
product should ever fail, we will repair or replace it at no charge.
Refund
All stock products qualify for a full refund if returned in new condition within 90
days of shipment. Build to order products qualify for a 50% refund if returned in
new condition within 90 days of shipment. Custom products are quoted and built
specifically to the requirements of the customer, which may include completely
custom product designs or private labeled versions of standard products for
OEM customers. Custom products ordered are non-cancellable, non-returnable
and non-refundable.
