FSW-2104W
4-Port Media Streaming
Plus 1 Fiber Port Switch

LEGAL
The information in this publication has been carefully checked and is believed to be entirely accurate at the time of
publication. CTC Union Technologies assumes no responsibility, however, for possible errors or omissions, or for any
consequences resulting from the use of the information contained herein. CTC Union Technologies reserves the right to
make changes in its products or product specifications with the intent to improve function or design at any time and
without notice and is not required to update this documentation to reflect such changes.
CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its products for any
particular purpose, nor does CTC Union assume any liability arising out of the application or use of any product and
specifically disclaims any and all liability, including without limitation any consequential or incidental damages.
CTC Union products are not designed, intended, or authorized for use in systems or applications intended to support or
sustain life, or for any other application in which the failure of the product could create a situation where personal injury
or death may occur. Should the Buyer purchase or use a CTC Union product for any such unintended or unauthorized
application, the Buyer shall indemnify and hold CTC Union Technologies and its officers, employees, subsidiaries,
affiliates, and distributors harmless against all claims, costs, damages, expenses, and reasonable attorney fees arising out
of, either directly or indirectly, any claim of personal injury or death that may be associated with such unintended or
unauthorized use, even if such claim alleges that CTC Union Technologies was negligent regarding the design or
manufacture of said product.
TRADEMARKS
Microsoft is a registered trademark of Microsoft Corp.
FCC Notice:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential environment. This equipment generates, uses, and can radiate radio frequency
energy and if not installed and used in accordance with the instruction manual may cause harmful interference in which
case the user will be required to correct the interference at his own expense. NOTICE: (1) The changes or modifications
not expressively approved by the party responsible for compliance could void the user's authority to operate the
equipment. (2) Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission
limits.
CISPR PUB.22 Class B COMPLIANCE:
This device complies with EMC directive of the European Community and meets or exceeds the following technical
standard. EN 55022 - Limits and Methods of Measurement of Radio Interference Characteristics of Information
Technology Equipment. This device complies with CISPR Class B.
CE NOTICE
Marking by the symbol CE indicates compliance of this equipment to the EMC directive of the European Community.
Such marking is indicative that this equipment meets or exceeds the following technical standards: EN
55022:1994/A1:1995/A2:1997 Class A and EN61000-3-2:1995, EN61000-3-3:1995 and EN50082-1:1997

CTC Union Technologies Co., Ltd.
Far Eastern Vienna Technology Center (Neihu Technology Park)
8F, No. 60, Zhouzi St.
Neihu, Taipei, 114
Taiwan
Phone: [phone]
FAX: [phone]
FSW-2104W
4-port 10/100M + 1-port 100Base-FX WAN
Web Smart Media Streaming Fiber Switch
* IGMP Snooping v1 / v2
* IGMP Proxy v1 / v2
* Web-Based Management
* Built-in wire speed NAT
* QoS Functions
* DHCP solutions
*SNMP v1 / v2
User Manual
Version 1.0 July 2009
This manual supports the following models:
FSW-2104W
This document is the current official release manual. Please check CTC Union's website for any updated manual or
contact us by E-mail at [email protected]. Please address any comments for improving this manual or to point out
omissions or errors to [e-mail]. Thank you.
©2009 CTC Union Technologies Co.,Ltd.
All Rights Reserved
The contents of this document are subject to change without any prior notice.

Contents
Chapter 1: About This Guide .................................................................................................7
Chapter 2: Introduction..............................................................................................................7
2.1 Product Description......................................................................................................7
2.2 Product Features...........................................................................................................7
Chapter 3: Connecting to Router.............................................................................................9
3.1 System Requirements..................................................................................................9
3.2 Installation Environment Requirements..................................................................9
3.3 Connecting the Router.................................................................................................9
Chapter 4: Fast Installation and Configuration....................................................................9
4.1 TCP/IP Configuration....................................................................................................9
Chapter 5: Configuring the Router........................................................................................11
5.1 login................................................................................................................................11
5.2 Status .............................................................................................................................11
5.3 LAN .................................................................................................................................12
5.4 WAN................................................................................................................................14
5.5 NAT .................................................................................................................................18
5.6 Firewall...........................................................................................................................19
5.7 QoS .................................................................................................................................20
5.8 IGMP ...............................................................................................................................21
5.9 SNMP..............................................................................................................................22
5.10 SNTP.............................................................................................................................23
5.11 VLAN Configuration .................................................................................................24
5.12 Port Configurations..................................................................................................24
5.13 Storm Control.............................................................................................................25
5.14 Tool...............................................................................................................................26
5.15 System Logs...............................................................................................................28
Appendix A: Glossary...............................................................................................................30

FSW-2104W Multimedia Residential Gateway
7
Chapter 1: About This Guide
Thank you for choosing the FSW-2104W FTTx Router.
This router provides dedicate solutions for Fiber to the Home networks for Triple-Play service.
To connecting your local network can share Internet access, files and fun for multiple PCs through one ISP
account. It is an easy, web-based setup for installation and management. This guide will configure the router
easy. Before installing the router, please look through this guide to get to know all the router’s functions.
Chapter 2: Introduction
2.1 Product Description
The FSW-2104W is a 4-port Web Smart switch with 1-port wire speed NAT-router. Its designed is dedicated to
IPTV Home Gateway network solutions. The FSW-2104W is intended for Multimedia applications in the Digital
Home, it supports the IGMP proxy,IGMP Snooping V1/V2 function, QoS function and wire speed NAT function.
The FSW-2104W provides flexible access control .It has built-in NAT and DHCP server supporting static IP
address distributing. It supports Virtual Server and DMZ host for Port Triggering needs, and remote
management and log so that network administrators can manage and monitor the network on real time. Support
Storm control Suppression. The priority features by IP Diffserv Application-Based of packets.
2.2 Product Features
•Complies with IEEE802.3, IEEE802.3u standards.
•Built in 4-port 10M/100M auto-detect Half/Full duplex switch ports with TX interfaces.
•Ethernet connection to WAN by fiber, 100Base-FX.
•For WAN port, support static IP, dynamic IP (DHCP client), PPPOE.
•Built-in wired speed 200Mbps NAT.
•DHCP server supports static IP address distributing.
•Supports MAC address auto-learning and auto-aging.
•Supports up to 2K Unicast addresses.
•Priority features by IP Diffserv Application-Based of packets.
•Four queues per port for QoS. The Priority Queue be set at WRR (Weighted Round Robin) assigns
guaranteed bandwidth to a queue.
•Broadcast/Multicast/Un-learned Unicast Storm Suppression.
•IGMP Snooping v1/v2.
•SNMP v1/v2.
•Access control to LAN connection.
•WAN IP filtering, Mac filtering.
•Dynamic routing and 3 static routing entries.
•Web-Based management.
•Supports firmware upgrade, automatic firmware upgrade.
•LED indicators for monitoring power, link, activity, speed mode.
•Plastic case, desktop or wall-mounting design
•External Power Adapter supply

FSW-2104W Multimedia Residential Gateway
8
2.3 Product Specifications
Standards IEEE802.3 10Base-T,
IEEE802.3u 100Base-TX, 100Base-FX
Topology Star
Protocol CSMA/CD,DHCP, TCP/IP、PPPoE、DHCP、NAT、ICMP、SNTP、
IGMP
Data Transfer Rate Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex)
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Duplex)
Network Media (Cable)
10Base-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
100Base-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
Number of Ports One 100Base-FX port. (Duplex SC or BiDi SC) Four 10/100M Auto-Negotiation LAN RJ45 ports supporting Auto
MDI/MDIX
LED indicators Power, Link/Act
Transfer Method Store-and-Forward
MAC Address Learning Automatically learning, automatically Update
Frame Filtering & Forward Rate 10Mbps: 14880pps, 100Mbps: 148800pps
Power Adaptor DC 5V 2A
Dimensions (W×D×H) 150*95*32(mm)
Environment
Operating Temperature: 0 C~40 C (32 F~104 F)
Storage Temperature: -40 C~70 C (-40 F~158 F)
Operating Humidity: 10%~90% non-condensing
Storage humidity: 5%~95% non-condensing

FSW-2104W Multimedia Residential Gateway
9
Chapter 3: Connecting to Router
3.1 System Requirements
•Broadband Internet Access Service (FTTx)
•One single mode fiber connection using dual fiber or single fiber (WDM)
•Each PC on the LAN needs a working Ethernet Adapter and an Ethernet cable with RJ45 connectors
•TCP/IP protocol must be installed on each PC
3.2 Installation Environment Requirements
•Not in direct sunlight or near a heater or heating vent
•Not cluttered or crowded. There should be at least 2 inches (5 cm) of clear space on all sides of the router
•Well ventilated (especially if it is in a closet)
•Operating temperature: 0°~40°C (32°~104°F)
•Operating Humidity: 10%~90%RH, Non-condensing
3.3 Connecting the Router
Please install the router according to the following steps.
Please pull out the power plug and keep your hands dry.
Steps:
1. Power off your PC(s) and the router.
2. Connect the PC(s) and all Switches/Hubs on your LAN to the LAN Ports on the router.
3. Connect the fiber from provider to fiber WAN port on the router.
4. Connect the AC power adapter to the AC power socket on the router, and the other side into an electrical
outlet. The router will start to work automatically.
5. Power on your PC(s) and Cable/DSL modem.
Chapter 4: Fast Installation and Configuration
This chapter describes how to configure the basic functions of your FSW-2104W Cable/DSL router. You may
access the Internet via the router immediately after it has been successfully configured.
4.1 TCP/IP Configuration
•The default IP address of the FSW-2104W Cable/DSL Router is 192.168.123.211, and the default Subnet
Mask is 255.255.255.0. These values can be seen from the LAN, and can be changed as your desire.
•Connect the local PCs to the LAN ports on the router. There are then two means to configure the IP address
for your PCs.
•Configure the IP address manually
1) Set up the TCP/IP Protocol for your PC(s).
2) Configure the network parameters. The IP address is 192.168.123.xxx ("xxx" is from 1 to 254 except 211),
Subnet Mask is 255.255.255.0, and Gateway is 192.168.1.211(The router's default IP address)
•Obtain an IP address automatically
1) Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on
your PC(s).
2) Power off the router and PC(s). Then turn on the router, and restart the PC(s).
The built-in DHCP server will assign IP addresses for the PC(s).You can run the Ping command in the
command prompt to verify the network connection between your PC(s) and the router.
The following example is under Windows XP environment:
Open a command prompt, and type ping 192.168.123.252, press Enter.

FSW-2104W Multimedia Residential Gateway
Figure 4-1 Successful result of Ping command
If the result displayed is same as to what is shown in figure 4-1, the connection between your PC and the router
has been established.
Figure 4-2 Fail result of ping command
If the result displayed is similar to what shown in figure 4-2, it means that your PC has not connected to the
router. If so, refer to the following steps for a solution.
1. Is the connection between your PC and the router correct?
Note: The Link/Act LEDs of LAN port on the router and LEDs on your PC's adapter should be lit.
2. Is the TCP/IP configuration for your PC correct?
Note: If the router's IP address is 192.168.123.211, your PC's IP address must be within the range of
192.168.123.1 ~ 192.168.123.254 but not 192.168.123.211 which is the gateway’s IP.
10

FSW-2104W Multimedia Residential Gateway
Chapter 5: Configuring the Router
5.1 login
Enter the User name and password correctly and click OK button (shown in figure 5-1). After your successful
login, you can configure and manage the router.
There are fourteen main menus are: Status, LAN, WAN, NAT, Firewall, Qos, IGMP, SNMP, SNTP, VLAN
config, Port config, Storm Control, Tool, System Logs. On the right of the web-based utility, there are the
detailed explanations and instructions for the corresponding page. To apply any settings you have altered on the
page, please click the Save button.
Detailed explanations for each web page's key functions are showing below:
User name and
password : admin
Figure 5-1 login
5.2 Status
The Status page displays the router's current status and configuration.
5.2.1 Information
This field displays the system information, including Current Status, Working Time, Network Time, Hardware
Version, Firmware Version and Compile Date.
5.2.1.1 WAN Status
These parameters apply to the WAN port of the router, including Connected Type, Connected Status, IP
Address, Subnet Mask, WAN MAC, Gateway, Primary DNS, and Secondary DNS
If PPPoE is chosen as the WAN connection type, the Disconnect button will be shown here while you are
accessing the Internet. You can also cut the connection by clicking the button. If you have not connected to the
Internet, a Connect button will be shown, you can then establish the connection by clicking the button.
11

FSW-2104W Multimedia Residential Gateway
5.2.1.2 LAN Status
This field displays the current settings or information for the LAN, including the MAC address, IP address and
Subnet Mask.
Figure 5-2 Router Status
5.3 LAN
Figure 5-3 the LAN menu
There are two submenus under the LAN menu (shown in figure 5-3): LAN, DHCP Clients. Click any of them,
and you will be able to configure the corresponding function.
12

FSW-2104W Multimedia Residential Gateway
5.3.1 LAN
Please configure the IP parameters of the LAN on this page.
Figure 5-4 LAN Setup and DHCP Setup
•IP Address - Enter the IP address of your router in dotted-decimal notation (factory default:
192.168.123.252).
•Subnet Mask - An address code that determines the size of the network. Normally use 255.255.255.0 as the
subnet mask.
•MAC Address - The physical address of the router, as seen from the LAN. The value can't be changed.
•DHCP Server - Enable or Disable the DHCP server. If you disable the Server, you must have another DHCP
server within your network or else you must manually configure the computer.
•IP PC Starting - This field specifies the first of the addresses in the IP address pool. 192.168.123.50 is the
default start address.
•IP PC Ending - This field specifies the last of the addresses in the IP address pool. 192.168.123.100 is the
default end address.
•IP Lease Time - The IP Lease Time is the amount of time. A network user will be allowed connection to the
router with their current dynamic IP address.
•Choose the time in box, which the user will be "leased" this dynamic IP address. The default value is 1 Day.
Note:
a. If you change the IP address of the LAN, you must use the new IP address to login to the router.
b. If the new LAN IP Address you set is not in the same subnet, the IP Address pool in the DHCP sever will not
take effect, until they are re-configured.
c. If the new LAN IP Address you set is not in the same subnet, the Virtual Server and DMZ Host may change
accordingly at the same time, you’d better re-configure it as well.
13

FSW-2104W Multimedia Residential Gateway
5.3.2 DHCP Clients
This page shows Host IP Address, Host IP Address for each DHCP Client attached to the router (figure
5-5):
Figure 5-5 DHCP Clients
•NO. - The index of the DHCP Client
•Host IP Address - The name of the DHCP client
•Host MAC Address - The MAC address of the DHCP client
You cannot change any of the values on this page. To update this page and to show the current attached
devices, click on the Refresh button.
5.4 WAN
Figure 5-6 the WAN menu
There are two submenus under the LAN menu (shown in figure 5-6): WAN Connection, Bridge Convert. Click
any of them, and you will be able to configure the corresponding function. The detailed explanations for each
submenu are provided below.
14

FSW-2104W Multimedia Residential Gateway
5.4.1 WAN Connection
You can configure the WAN port parameters on this page.
First, please choose the WAN Connection Type (Dynamic IP/Static IP / PPPoE ) to the
Internet. The default type is PPPoE. If you aren’t given any login parameters (fixed IP address, logging ID, etc),
please select Dynamic IP. If you are given a fixed IP (static IP), please select Static IP. If you are given a user
name and a password, please select PPPoE. If you are not sure which connection type you use currently,
please contact your ISP to obtain the correct information.
1. If you choose Dynamic IP, the router will automatically get IP parameters from
your ISP. You can see the page as follows (figure 5-7):
Figure 5-7 WAN - Dynamic IP
This page displays the WAN IP parameters assigned dynamically by your ISP,
including IP address, Subnet Mask, Default Gateway, etc. Click the Renew button in Status menu to renew
the IP parameters from your ISP. Click the Release button to release the IP parameters.
If your ISP gives you one or two DNS addresses, select [DNS List] button in DNS Setup and enter the
primary and secondary addresses into the correct fields. Otherwise, the DNS servers will be assigned
dynamically from ISP.
Note: If you get ‘Address not found' errors when you go to a Web site, it is likely that your DNS servers are
set up improperly. You should contact your ISP to get DNS server addresses.
15

FSW-2104W Multimedia Residential Gateway
2. If you choose Static IP, you should have fixed IP parameters specified by your ISP.
The Static IP settings page will appear, shown in figure 5-8:
Figure 5-8 WAN - Static IP
Please type the following parameters into the spaces provided:
•IP Address - Enter the IP address in dotted-decimal notation provided by your ISP.
•Subnet Mask - Enter the subnet Mask in dotted-decimal notation provided by your ISP, usually is
255.255.255.0.
•Default Gateway: (Optional) Enter the gateway IP address in dotted-decimal notation provided by your ISP.
•Primary DNS - (Optional) Type the DNS address in dotted-decimal notation provided by your ISP.
•Secondary DNS - (Optional) Type another DNS address in dotted-decimal notation provided by your ISP if
provided
16

FSW-2104W Multimedia Residential Gateway
3. If you choose PPPoE, you should enter the following parameters (figure 5-9):
Figure 5-9 WAN – PPPoE
•User Name/Password - Enter the User Name and Password provided by your ISP. These fields are
case-sensitive.
•Auto Connect - Connect automatically after the router is disconnected. To use this option, click the radio
button.
•Manual Connect - You can configure the router to make it connect or disconnect manually.
NOTICE: Click the Connect button to connect immediately, Click the Disconnect button to disconnect
immediately, the Connect button and Disconnect button are in the Status menu.
5.5.2 Bridge Convert
Figure 5-10 Mode Configuration
There are two choices you can select. The system default is NAT Mode, In this Mode, you can use FSW-2104W
as a router. If you select Bridge Mode, the FSW-2104W will be used as a switch. After you select the Bridge
Mode, some functions about router is disable. Such as WAN, firewall.
17

FSW-2104W Multimedia Residential Gateway
5.5 NAT
Figure 5-11 The NAT menus
There is one submenu under the NAT menu (shown in figure 5-11): Virtual Server.
Click it, and you will be able to configure the corresponding function. The detailed explanations for each
submenu are provided below :
5.5.1 Virtual Server
Virtual server can be used for setting up public services on your LAN, such as DNS,
Email and FTP. A virtual server is defined as a service port, and all requests from
Internet to this service port will be redirected to the computer specified by the server IP. Any PC that was used
for a virtual server must have a static or reserved IP address because its IP address may change when using the
DHCP function. You can set up virtual servers on this page, shown in figure 5-12:
Figure 5-12 Virtual Server Configurations
•Dest Port - The Port which the internal server use.
•Local Port - The Port which you type as the service port. All requests from Internet to this service port will be
redirected to the computer specified by the server IP and Dest Port.
•Server IP- The IP address of the PC running the service application.
•Protocol Type- The protocol used for this application, TCP Port, UDP Port, or TCP&UDP (all protocols
supported by the router).
•Enable - The Enable checkbox to enable the virtual server entry and click OK button.
18

FSW-2104W Multimedia Residential Gateway
5.6 Firewall
Figure 5-13 Firewalls
There are two submenus under the Firewall menu (shown in figure 5-13): WAN IP Filter and LAN MAC Filter.
5.6.1 WAN IP Filter
Using The Wan IP Filtering feature allows you to control Internet Access by WAN IP addresses. The IP Address
Filtering is set on this page,( shown in figure 5-14) :
Figure 5-14 Wan IP Filter
5.6.2 LAN Mac Address Filter
The LAN MAC Address Filter page (shown in figure 5-15), allows you to control access to the Internet by users
on your local network based on their MAC addresses.
Figure 5-15 LAN Mac Address Filter
19

FSW-2104W Multimedia Residential Gateway
5.7 QoS
Figure 5-16 QoS
There are two submenus under the Tools menu (shown in figure 5-16):
Qos Priority, Qos(DSCP) Configuration. Click any of them, and you will be able to configure the
corresponding function.
5.7.1 QoS Priority Configuration
Figure 5-17 QoS Priority Configuration
•QOS Mode：there are 2 options: Disable, ToS/Dscp Priority. Select ToS/Dscp Priority, It make TOS/DSCP
priority function in use.
5.7.2 ToS /DSCP/ QoS
Figure 5-18 QoS (DSCP) Configuration
•ToS/DSCP：Description of the received packets’ IP head ToS/DSCP field value. The latter 0-63 denotes the
priority value of bit in the ToS field.
•Priority：Bandwidth will be distributed according to the transmission ratio when transmitting.
20
