CTC Union IGS+803SM-8PH User manual

1
Quick Installation Guide
[e-mail]
IGS+803SM-8PH
IGS+803SM-8PHE
Industrial 8 x 10/100/1000Base T(X) + 3 x 100/1000Base-X SFP Slots with
8 x PoE+ Managed Ethernet Switches (Hardened)

1
Version 1.2 March, 2020
2020 CTC Union Technologies Co., LTD.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
CTC Union Technologies Co.,Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60 Zhouzi St.,
Neihu, Taipei 114, Taiwan
T [phone]
F [phone]
E[email protected]m
Hwww.ctcu.com

2
LEGAL
The information in this publication has been carefully checked and is believed to be entirely accurate at
the time of publication. CTC Union Technologies assumes no responsibility, however, for possible errors
or omissions, or for any consequences resulting from the use of the information contained herein. CTC
Union Technologies reserves the right to make changes in its products or product specifications with the
intent to improve function or design at any time and without notice and is not required to update this
documentation to reflect such changes.
CTC Union Technologies makes no warranty, representation, or guarantee regarding the suitability of its
products for any particular purpose, nor does CTC Union assume any liability arising out of the
application or use of any product and specifically disclaims any and all liability, including without
limitation any consequential or incidental damages.
CTC Union products are not designed, intended, or authorized for use in systems or applications
intended to support or sustain life, or for any other application in which the failure of the product could
create a situation where personal injury or death may occur. Should the Buyer purchase or use a CTC
Union product for any such unintended or unauthorized application, the Buyer shall indemnify and hold
CTC Union Technologies and its officers, employees, subsidiaries, affiliates, and distributors harmless
against all claims, costs, damages, expenses, and reasonable attorney fees arising out of, either directly
or indirectly, any claim of personal injury or death that may be associated with such unintended or
unauthorized use, even if such claim alleges that CTC Union Technologies was negligent regarding the
design or manufacture of said product.
WARNING:
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and if not installed and used in accordance with
the instruction manual may cause harmful interference in which case the user will be required to correct
the interference at his own expense. NOTICE: (1) The changes or modifications not expressively
approved by the party responsible for compliance could void the user's authority to operate the
equipment. (2) Shielded interface cables and AC power cord, if any, must be used in order to comply
with the emission limits.
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.

4
Table of Contents
Introduction..................................................................................5
Package List.................................................................................5
Features........................................................................................5
Access to Command Line Interface (CLI)...................................6
CONSOLE CONNECTION ......................................................................................... 6
TELNET/SSH CONNECTION .................................................................................... 7
Access to Web-Based Management Interface............................8
Specifications...............................................................................9
ETHERNET INTERFACE............................................................................................ 9
OPTICAL............................................................................................................ 9
SWITCH FEATURES ............................................................................................... 9
POWER OVER ETHERNET ........................................................................................ 9
POWER ............................................................................................................. 9
MECHANICAL.....................................................................................................10
ENVIRONMENTAL................................................................................................10
CERTIFICATIONS .................................................................................................10
MTBF (MIL-HDBK-217) ...................................................................................10
Panels .........................................................................................11
LAN and Fiber Ports...................................................................12
PoE Ports....................................................................................12
RJ-45 ETHERNET PORT PINOUTS ............................................................................12
RJ-45 ETHERNET &POEPIN ASSIGNMENTS..............................................................12
CONSOLE Port ...........................................................................13
RJ-45 TO DB-9 SIGNAL MAPPING ..........................................................................13
Recommended Power, Alarm, Ground Wiring Scheme...........14
DC POWER CONNECTION .....................................................................................14
ALARM RELAY CONNECTION ..................................................................................15
EARTH GROUND CONNECTION ...............................................................................15
LED Indicators............................................................................16
Installation..................................................................................17

5
Introduction
IGS+803SM-8PH(E) models are managed industrial grade Gigabit
PoE (Power over Ethernet) switches that provide stable and reliable
Ethernet transmission. Housed in rugged DIN rail or wall mountable
enclosures, these switches are designed for harsh environments, such as
industrial networking and intelligent transportation systems (ITS) and
are also suitable for many military and utility market applications where
environmental conditions exceed commercial product specifications.
Standard operating temperature range models (-10°C~60°C) and wide
operating temperature range models (-40°C~75°C) are available to fulfill
the special needs of industrial automation applications.
Package List
IGS+803SM-8PH(E) Device
Console cable (RJ-45 to DB-9)
Protective caps for SFP slots
Din rail with screws
Terminal block
Features
Redundant dual 48VDC power
IP30 rugged metal housing & fanless
Isolated RS-232 console port
Wide temperature range -40°C~75°C (IGS+803SM-8PHE)
Support IEEE1588 PTPv2 for precise time synchronization
Console, Telnet, Web and SNMP management
4KV surge protection for UTP, PoE & fiber ports
UL60950-1, EN60950-1, CE, FCC, Railway Traffic EN50121-4, traffic
control NEMA TS2 certified

6
Access to Command Line Interface (CLI)
IGS+803SM-8PH(E) models are managed Gigabit PoE switch
devices. Initial configuration (assignment of IP address) may be
accomplished via the RS-232 console and a PC or laptop running
terminal emulation software or via RJ45 Ethernet port running Telnet or
SSH.
Accessing the switch via CONSOLE or Ethernet port allows the user
to use Command Line Interface (CLI) to manage and configure the device.
This management method is relatively useful when you lose the network
connection to the device. In most configuration scenarios, the console
will only be used to initially configure the IP address, so that the device
may be accessed via the other methods which require working TCP/IP.
See below for useful information for accessing the device via console
and Telnet/SSH connection.
Console Connection
Use the provided accessory cable to connect the "CONSOLE" port
to the PC terminal communications port (DB9). Run any terminal
emulation program (HyperTerminal, PuTTY, TeraTerm Pro, etc.) and
configure the communication parameters as follows:
Speed:
115,200
Data:
8 bits
Parity:
None
Stop Bits:
1
Flow Control:
None
From a cold start, the following screen will be displayed. At the
"Username" prompt, enter “admin”with no password.
To change the default IP address to your desired one (for example,
192.168.0.10/24), issue the following commands:
For complete CLI operation, please refer to the operation manual.
#
# config terminal
(config)# interface vlan 1
(config-if-vlan)# ip address 192.168.0.10 255.255.255.0
Press ENTER to get started
Username: admin
Password:
#

7
Telnet/SSH Connection
To use Command Line Interface (CLI), you can also choose to
access the device through a Telnet/SSH connection via TCP/IP network
over Ethernet ports. For initial operation, use the default TCP/IP settings
(10.1.1.1) to login to the device.
Default TCP/IP settings:
IP Address:
10.1.1.1
Subnet Mask:
255.255.255.0
Username:
admin
Password:
No password (Press "Enter"
key)
To change the default IP address to your desired one (for example,
192.168.0.10/24), issue the following commands:
Once the desired IP address has been configured, a web browser
can be accessed and used to configure the device through a more easy-
to-use GUI (graphical user interface). For complete CLI operation, please
refer to the operation manual.
#
# config terminal
(config)# interface vlan 1
(config-if-vlan)# ip address 192.168.0.10 255.255.255.0

8
Access to Web-Based Management Interface
To enter the web-based management interface for the first time
or after returning the device back to factory defaults, input the default IP
address “10.1.1.1”in your web browser. Then, a standard login prompt
will appear depending on the type of browser used. The example below
is with Firefox browser.
Enter the factory default username “admin”with no password.
After successfully entering the web based management, the Port State
page will appear. For complete Web GUI operation, please refer to the
operation manual.

9
Specifications
Ethernet Interface
Standards: IEEE802.3 (10Base-T), 802.3u (100Base-TX), 802.3ab
(1000Base-T)
RJ-45 (shielded) Ports: 8 ports
Speed: 10/100/1000M (Auto)
Optical
Standards: IEEE80802.3u (100Base-FX), 802.3z (1000Base-X)
SFP-Based Slots: 3 slots
Speed: 100/1000M (Manual)
Switch Features
Store & Forward Switch
Supports IEEE802.3x Flow Control
Auto MDI/MDI-X
Duplex: Full/Half (Auto-negotiation per IEEE802.3u)
Switching Fabric: 22Gbps (Non-blocking)
Memory Buffer: 512K Bytes
MAC Table: 8K
MTU: 64~9600 bytes
Power over Ethernet
8 PoE enabled ports, End Span Alternate A Mode
Support IEEE802.3af 15.4watts PoE per port
Support IEEE802.3at 30watts PoE+ per port
Total 240W power budget (maximum), 30W per port
Positive (V+) pins 1,2; Negative (V-) pins 3,6; Data 1, 2, 3, 6, 4, 5, 7, 8
Power
Redundant dual DC 48V (44V~57VDC)
(50V~57V is recommended for IEEE802.3at PoE 30W applications)
Support Power Input Reverse Polarity Protection
Support Dual Power Inputs
Removable terminal block connectors
Power Consumption:
Items
Input Voltage
Total Power
Consumption
Device Power
Consumption
PoE Budget
50VDC
255.5W
15.5W
240W

10
Mechanical
Water & Dust Proof: IP30 Protection
Dimensions: 106 mm (D) x 72 mm (W) x 152 mm (H)
Mounting: DIN-Rail, Wall Mount (Optional)
Weight: 850 g
Environmental
Operating Temperature: -10°C~60°C (IGS+803SM-8PH); -40°C~75°C
(IGS+803SM-8PHE)
Storage Temperature: -40°C~85°C
Humidity: 5%~95% (Non-condensing)
Certifications
EMC: CE (EN55024, EN55032)
EMI (Electromagnetic Interference): FCC Part 15 Subpart B Class A, CE
EN55022 Class A
Railway Traffic: EN50121-4
Traffic Control: NEMA TS2
Immunity for Heavy Industrial Environment: EN61000-6-2
Emission for Heavy Industrial Environment: EN61000-6-4
EMS (Electromagnetic Susceptibility) Protection Level:
EN61000-4-2 (ESD) Level 3, Criteria B
EN61000-4-3 (RS) Level 3, Criteria A
EN61000-4-4 (Burst) Level 3, Criteria A
EN61000-4-5 (Surge) Level 3, Criteria B
EN61000-4-6 (CS) Level 3, Criteria A
EN61000-4-8 (PFMF, Magnetic Field) Field Strength: 300A/m,
Criteria A
Safety: UL60950-1, EN60950-1
4KV surge protection for UTP, PoE & fiber ports
Shock: EN60068-2-27
Freefall: EN60068-2-32
Vibration: EN60068-2-6
MTBF (MIL-HDBK-217)
487,189 Hours
