CTEK MUS 4.3 User manual

CTEK MUS 4.3
4.3A
NUWE
GENERASIE
BATTERYLAAIERS
5
YEAR
WARRANTY
5
YEAR
WARRANTY
5
YEAR
WARRANTY
5
YEAR
WARRANTY
AUTO
Fully automatic for optimal charging
For all lead-acid batteries
fully charged battery
Maintenance charging
For charging in cold conditions
and AGM batteries
Recondition of deeply discharged batteries
NEW GENERATION TECHNOLOGY
AVAILABLE FOR THE CONSUMER
CTEK MUS 4.3
The MUS 4.3 is a charger that offers state of the art technology that
was previously only found in CTEK’s professional product range. The
charger can solve a broad range of battery-related problems and
is the perfect charger for those with high demands. The MUS 4.3
offers features such as battery diagnosis that shows if a battery can
receive and retain a charge, a special reconditioning function that
restores stratified and deeply discharged batteries, unique mainte-
nance charging, a mode for optimised charging during cold winter
days and the charging of demanding AGM batteries (i.e. Optima).
The unique display allows the user to follow the entire charging pro-
cess.
The MUS 4.3 is a fully automatic 8-step charger that delivers se-
lectable 0.8 A or 4.3 A to 12 V batteries from 1.2–110 Ah and
is suitable for maintenance charging up to 160 Ah. The charger is
splash and dust proof, designed to protect vehicle electronics and
non-sparking, reverse polarity protected and short-circuit proof. It is
delivered with a 5-year warranty.
TECHNICAL DATA
CHARGING VOLTAGE 14.4/14.7/15.8 V
CHARGING CURRENT Max 4.3 A
TYPE OF CHARGER 8 step, fully automatic charging cycle
TYPE OF BATTERY 12 V lead-acid batteries
BATTERY CAPACITY 1.2–110 Ah, up to 160 Ah for maintenance
ARTICLE NO 56-864

www.ctek.com
4.3A
CTEK MUS 4.3
CTEK MUS 4.3
CTEK COMFORT CONNECT–clamp
CTEK COMFORT CONNECT
–eyelet ¼” (M6)
•Fully automatic charging and maintenance in 8 steps
maximizes battery life and performance
•Numerous accessories simplifies using the same charger
for multiple batteries
•One charger for the car, motorcycle, lawn mower, snowmobile,
sump pump and tractor
•Water-resistant so that the solution could be taken to the problem
even if it rains or snows
•Patented maintenance charge for a unique combination
of maximized life and performance
•Recondition of deep discharged batteries
•Patented desulphation that extends the battery life
•No sparks, short-circuit proof and reverse-polarity protected
for untroubled usage
•Automatic detection of end-of-life batteries that eliminates surprises
CONNECT AND FORGET
MODE
RECOND 12V/0.8‒4.3A
MUS 4.3
1
1
2
3
1. Connect the charger to the battery.
2. Connect the charger to the wall socket.
Power-on lamp lights
3. Press the MODE-button to select charging program.
Small sized batteries
Medium sized batteries
Charging in cold conditions and AGM batteries requiring
14.7 V charging
Reconditioning of deeply discharged batteries
4. … and ready.
1STEP 1 DESULPHATION
Pulsing voltage removes sulphates from the lead plates of the battery
restoring the battery capacity.
2STEP 2 SOFT START
Tests if the battery can accept charge. Charging begins if the battery
is OK.
3STEP 3 BULK
Charging with maximum current until approximately 80 % battery capacity.
4STEP 4 ABSORPTION, READY TO USE
Charging with declining current to maximize up to 100 % battery
capacity.
5STEP 5 ANALYSE
Tests if the battery can hold charge. Batteries that cannot hold charge
may need to be replaced.
6STEP 6 RECOND
Reconditioning function for deeply discharged batteries.
7STEP 7 FLOAT, FULLY CHARGED
Maintaining the battery voltage at maximum level by providing a
constant voltage charge.
8STEP 8 PULSE, MAINTENANCE CHARGING
Maintaining the battery at 95–100 % capacity. The charger monitors
the battery voltage and gives a pulse when necessary to keep the
battery fully charged.
GUARANTEED QUALITY WITH CTEK
CTEK customer support is available to answer any questions related to
charging and CTEK chargers. Safety, simplicity and flexibility character-
izes all products and solutions developed and sold by CTEK. CTEK sup-
ply chargers to more than 60 countries throughout the world. CTEK is also
a reliable OEM supplier to many of the world’s most prestigious car and
motorcycle manufacturers.
Contact customer support: [email protected]
CTEK POWER, INC.
2374 EDISON BLVD. TWINSBURG, OH 44087-2376, UNITED STATES
20017507A US
CTEK’s UNIQUE 8 STEP CHARGING
