Cyklos CFM 600 User manual

Issue No. 3
No. of sheets 8
Operating Manual
Paper Folding Machine
CFM 600
Warning
This document including the attachments is exclusive intellectual property of Cyklos Choltice (producer
cooperative). Any other use (copying, distribution or sale) is possible only with approval of the chairman of
the cooperative.
Effective from serial no.:
14011061

Operating Instructions | CFM 600
2
Content
1. INSTALATION AND OPERATION INFORMATION..................................................................................3
2. TECHNICAL PARAMETERS....................................................................................................................4
3. MACHINE DESCRIPTION........................................................................................................................5
4. OPERATING INSTRUCTIONS.................................................................................................................6
4.1 Automatic paper feeding......................................................................................................................6
4.2 Stops adjustment, fold type setting......................................................................................................6
5. TROUBLESHOOTING..............................................................................................................................7
6. MACHINE DISPOSAL ..............................................................................................................................7

Operating Instructions | CFM 600
3
1. INSTALATION AND OPERATION INFORMATION
a) The folder is designed only for folding paper specified in parameters.
b) It is forbidden to fold foils, sheets and similar materials.
c) The machine may be utilized only in a closed room (office, shop).
d) It is forbidden to utilize the machine outdoors.
e) It is forbidden to utilize the machine with damaged feeding cord.
f) It is forbidden to utilize the machine, if unusual sounds are heard.
g) It is forbidden to operate the machine under a voltage different from the voltage specified on the
type label.
h) Prior to the machine utilization, definitely read all instructions.
i) To reduce the risk of injury, an inspection shall be essential, if the product utilized in the vicinity of
children.
j) It is forbidden to insert fingers or hands to the product after the feeding cord connecting.
k) If the machine blocked, it shall be first necessary to disconnect the machine from the mains supply,
and then remove the cause of blocking.
l) It is forbidden to replace faulty fuse by another type, or by a fuse with different power

Operating Instructions | CFM 600
4
2. TECHNICAL PARAMETERS
a) Folding speed 70 - 120 listů / min. ± 15 % (A4)
b) Types of folds standard letter
concertina
single
double parallel (<160 g/m²)
brochure
half concertina
c) Sheet size A3 , (B4), A4 , (B5), A5 .
d) Input capacity 200 sheets (80 g/m²)
e) Machine dimensions Working position: l = 770 mm
w = 445 mm
h = 490 mm
Transport position: l = 435 mm
w = 445 mm
š = 350 mm
f) Paper grammage 80 - 160 g / m²
g) Machine weight 23 kg
h) Voltage / frequency 230 V / 50 Hz
i) Electric input 50 W
j) Electric current 520 mA ± 15 %

Operating Instructions | CFM 600
5
3. MACHINE DESCRIPTION
1 start/stop button
2 speed control button
3 feeding tray
4 tilting board
5 feeding board arrestment lever
6 light bulb control
7 delivery drawer
8 stop X
9 stop Y
10 ruler
11 side guides
12 front cover
13 arrestment button
14 feeding wheel
15 table of folds
16 main switch socket
1
2
3
4
5
6
10
8
11
7
14
13
15
12
16
9

Operating Instructions | CFM 600
6
4. OPERATING INSTRUCTIONS
4.1 Automatic paper feeding
Insert the feeding board arrestment lever 5into its lower position. Feed the paper on the tilting board 4 –
being tilted away at the moment, placing it between side guides 11 which are set approximately to the
required paper width.
Then push the side guides towards the paper. Release the arrestment lever, which allows the feeding board
to lift up the stack of paper underneath the feeding wheel 14.
Turn on the machine with using the power switch 16. If the machine is ready to work the red LED 6shines
continuously. If the LED light is blinking, either the stops are in incorrect position, or there is a paper
missing on the feeding tray:
a) LED blinks 1 x – incorrect position of stop X
b) LED blinks 2 x – incorrect position of stop Y
c) LED blinks 3 x – missing paper on feeding tray
In case paper jams in the machine, the motor turns off automatically and LED light starts blinking
intermittently 4 x. In such case it is necessary to remove the paper from the machine and restart it – to tur
nit off and on again.
After pressing the “start/stop” button 1, the paper will be fed automatically from the pile of paper and folded
into the waste box. The folding speed is regulated by the button of control speed 2. When the last sheet
leaves the machine, the machine turns off automatically.
4.2 Stops adjustment, fold type setting
Types of foldes
Each type of paper folding requires the precise setting of the sheet stop rider 13 at the X and Y stops,
following the information in the table of folding options 15. ‘Single’ folding requires that the Y stop is inserted
in the machine in the opposite way. After of the stops the machine turns off automatically.
The Y stop turned 180° for
1/2 fold

Operating Instructions | CFM 600
7
5. TROUBLESHOOTING
Paper jams in the machine: Both stops must be removed from the machine and the sheet must be
removed so that the rollers can turn over spontaneously.
LED light is blinking: the stops are in incorrect position or there is a paper missing on the feeding tray, or
the paper got stuck in the machine
6. MACHINE DISPOSAL
When the lifespan expires, it is forbidden to dispose of the machine into the common waste. The machine
must be disassembled and metallic, non-metallic, plastic, rubber and electronic parts sorted. These parts
are disposed of in the relevant points of recycling. Some parts of the machine can contain dangerous
substances that are harmful to the environment and health.
