CYP CLUX-41W User manual

CLUX-41W
4 by 1 HDMI 1.3 Switcher
Operation Manual
CLUX-41W

Revision History
Version No. Date Summary of Change
V1 20090514 Preliminary Release
Precaution
Failure to follow the precautions described below may cause damage to
4 by 1 HDMI 1.3 Switcher and void the warranty.
 DO NOT open the case. Doing so will void the warranty. If you find
problem with it, please return back to your retailer or seller who will
assist you or provide you with solution.
 DO NOT use third-Party AC adapter or power cord. Doing so may
damage 4 by 1 HDMI 1.3 Switcher.
 DO NOT bump, jar or drop contents of the products as it may
damage it and result in warranty void.
 DO NOT set any liquids or beverages on the drive as they may
damage 4 by1 HDMI 1.3 Switcher.

Table of Contents
1
1
1
1
2
3
3
3
4
4
5
1. Introduction…………………………………………………........……….
2. Application…………………………………………………................….
3. Contents……………………………………………….........................…
4. System Requirement…………………………………….…….......…….
5. Features…………………………………………….......……........………
6. Operation Controls and Functions…………………………………….
6.1 Top Panel .................................................................................
6.2 Front Panel………………………………………….........….….…
7. Remote Control.....................…………………………….........……..…
8. Connection and Installation…………………………….........……..…
9. Specications……………………………………………...........………..

1. Introduction
This is a high performance HDMI v1.3 Switcher with remote control. It allows
various HDMI sources to share a HDTV display. Simply press the button
to select your desire HDMI source for display on the HDTV. The device is
compatible to HDMI v1.3 specifications, and can define to support Deep
Color transfer (10-bit and 12-bit) video and new lossless compressed (Dolby
TrueHD, Dolby Digital Plus and DTS-HD Master Audio) digital audio, with a high
bandwidth up to 225MHz.
2. Application
 Showroom display control
 Educational demo
 Installation usage
 Advertising display
3. Contents
 4 by 1 HDMI 1.3 Switcher
 Remote Controller
 Power adaptor
 Operational Manual
4. System Requirement
Input source equipments with HDMI cable and output displayer with HDMI
cable.
1

5. Features
 HDMI 1.3, HDCP1.1 and DVI1.0 compliant.
 Deep color video up to 12bit, 1080p@60Hz.
 Four HDMI sources to connect up to a HDMI display simultaneously.
 Supports DVI source and DVI display by using HDMI to/from DVI adaptor
cable.
 Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master
Audio transmission (32-192kHz Fs sample rate).
 Supports a wide range of PC and HDTV resolutions from VGA to UXGA and
480i to 1080p.
 Full HDCP Compliant.
 HDMI cable distance test with 1080p/8-bit resolution, the input/output
can run up to 15/15 meters. If 1080p/12-bit, the input/output source can
run up to 10/15 meters.
 Support xvYCC.
 Support CEC bypass.
 Support Sys. Reset function with hot key switch to reset the system within
8~10 minutes into factory mode.
2

① DC 5V: Plug the 5VDC power
supply into the unit and connect
the adaptor to AC wall outlet.
①
6.2 Front Panel
① HDMI OUTPUT: Connect your LCD
TV or HD monitor with HDMI cables.
② Power LED: Red LED will illuminate
when the Power is On.
③ Power switch: Switch to ON to
turn on the device or switch to
OFF to set the device standby. The
factory default is OFF.
④ Sys. Reset: System reset function.
It is suggested having this function
switch OFF always except when
doing system reset. By switching
to ON, the system will reset HDMI
output to HDMI input1gradually
within 8~10 minutes and therefore
HDMI input 1 should be connected.
Switching to OFF means CEC
bypass. Factory default is OFF.
Note: The system reset function will
only functioning when the display is
built with CEC function.
⑤ INPUT: Input button for selecting
input channel.
1~4: Input LED, the blue LED will
illuminate with selected input
channel.
⑥ IR: IR Receiver.
⑦ HDMI INPUT: Connect the
equipments to the HDMI input ports
such as DVD player, Blue Ray, PS3
and or other sources with HDMI
cable. The factory default is on
input 1.
6. Operation Controls and Functions
6.1 Top Panel
③
④
①
⑤
⑥
⑦
②
LUX-41W
INPUT
HDMI OUT
INPUT
1
2
3
4
Power
Sys.Reset
ON
OFF
ON
OFF
4X1 HDMI V1.3 Switcher
LUX-41W
DC 5V
1
2
3
4
3

7. Remote Control
① Power button: Press to switch On the device,
press it again to set the device in standby
mode.
② 1~4: Press the desire input button to select the
input source.
8. Connection and Installation
2
1
30˚30˚
3 M
7 M
3 MBlue Ray
DVD
PS3
LCD TV
4

20090519 MPM-CLUX41W
Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
9. Specications
Frequency bandwidth 2.25Gbps (single link)
Input port 4 x HDMI Female ports
Output port 1 x HDMI Female port (single link)
HDMI output resolution 480i~1080p 50/60, 1080p24, VGA~UXGA
Power Supply 5VDC / 1A (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 93(W) x 148 (D) x 31 (H)
Weight (g) 210
Chassis Material Aluminum
Silk Skin Color Silver
Operating Temperature From 0 ºC ~ 40 ºC
Power Consumption 2W
