D-Link DAP-1325 User manual

User Manual
DAP-1325
N300 Wi-Fi Range Extender
May 2018

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Contents
Chapter 1. Introduction..........................................4
Contents and Audience.......................................................4
Conventions.................................................................4
Document Structure..........................................................4
Chapter 2. Overview..............................................5
General Information.........................................................5
Specifications..............................................................
Product Appearance..........................................................8
Upper Panel...............................................................8
Bottom Panel..............................................................9
Delivery Package...........................................................10
Chapter 3. Installation and Connection..........................11
Before You Begin...........................................................11
Connecting to PC...........................................................12
PC with Ethernet Adapter.................................................12
Configuring IP Address in O Windows XP..................................12
Configuring IP Address in O Windows 7...................................15
PC with Wi-Fi Adapter....................................................20
Configuring Wi-Fi Adapter in O Windows XP...............................21
Configuring Wi-Fi Adapter in O Windows 7................................23
Connecting to Web-based Interface..........................................2
Web-based Interface Structure..............................................28
ummary Page.............................................................28
Menu ections............................................................30
Notifications............................................................31
Chapter 4. Configuring via Web-based Interface..................32
Initial Configuration Wizard...............................................32
electing Operation Mode.................................................34
Changing LAN IPv4 Address................................................35
Wi-Fi Client.............................................................36
Configuring Wireless Network.............................................38
Changing Web-based Interface Password....................................39
Statistics.................................................................40
Network tatistics.......................................................40
DHCP.....................................................................41
Clients..................................................................42
Multicast Groups.........................................................43
Connections Setup..........................................................44
LAN......................................................................44
IPv4...................................................................44
IPv6...................................................................47
Wi-Fi......................................................................49
Basic ettings...........................................................49
Client Management........................................................57
WP ......................................................................58
Using WPS Function via Web-based Interface.............................60
Using WPS Function without Web-based Interface.........................61
WMM......................................................................62
Client...................................................................65
Additional...............................................................68
MAC Filter...............................................................70
Page 2 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Advanced...................................................................72
DN ......................................................................72
Firewall...................................................................74
MAC Filter...............................................................74
System.....................................................................7
Configuration............................................................77
Firmware Update..........................................................79
ocal Update...........................................................80
Remote Update..........................................................81
Log......................................................................82
Ping.....................................................................84
Traceroute...............................................................85
Telnet...................................................................86
ystem Time..............................................................87
Chapter 5. Operation Guidelines.................................89
Safety Rules and Conditions................................................89
Wireless Installation Considerations.......................................90
Chapter . Abbreviations and Acronyms...........................91
Page 3 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Introduction
CHAPTE 1. INT ODUCTION
Contents and Audience
This manual describes the extender DAP-1325 and explains how to configure and operate it.
This manual is intended for users familiar with basic networ ing concepts, who create an in-home
local area networ , and system administrators, who install and configure networ s in offices.
Conventions
Example Description
text The body text of the manual.
Before You Begin A reference to a chapter or section of this manual.
“Quick Installation
Guide” A reference to a document.
Change A name of a menu, menu item, control (field, chec box, drop-down
list, button, etc.).
192.1 8.0.50 Data that you should enter in the specified field.
!Information An important note.
Document Structure
Chapter 1 describes the purpose and structure of the document.
Chapter 2 gives an overview of the extender's hardware and software features, describes its
appearance and the pac age contents.
Chapter 3 explains how to install the extender DAP-1325 and configure a PC in order to access its
web-based interface.
Chapter 4 describes all pages of the web-based interface in detail.
Chapter 5 includes safety instructions and tips for networ ing.
Chapter introduces abbreviations and acronyms used in this manual.
Page 4 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Overview
CHAPTE 2. OVE VIEW
General Information
The DAP-1325 device is a wireless extender designed to increase the operational range of your
wireless networ . The extender supports operation with wireless devices of the standards 802.11b,
802.11g, and 802.11n (at the rate up to 300Mbps).
The device supports multiple functions for the wireless interface: several security standards (WEP,
WPA/WPA2), MAC address filtering, different operation modes (repeater, client, access point),
WPS, WMM.
The wireless extender is equipped with one Fast Ethernet LAN port, which can be used to connect a
wired client to the extender or to connect DAP-1325 to a wired router.
The LED clearly shows the signal level of the wireless networ to which DAP-1325 is connected.
Due to this, you can easily find the best location for the extender.
You can configure the settings of the DAP-1325 device via the user-friendly web-based interface
(the interface is available in two languages – in Russian and in English).
The configuration wizard allows you to quic ly switch the extender to the access point, repeater, or
client mode and configure all needed settings for the selected mode in several simple steps.
Now you can simply update the firmware: when the Internet access is provided, the extender itself
finds approved firmware on D-Lin update server and notifies when ready to install it.
Page 5 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Overview
Specifications*
Hardware
Processor ·MT762 NN (5 0MHz)
AM ·64MB, DDR2 SDRAM
Flash ·MB, SPI
Interfaces ·10/100BASE-TX LAN port
LEDs ·POWER/WPS
·Wi-Fi Signal Strength
Buttons ·WPS button to set up wireless connection
·RESET button to restore factory default settings
Antenna ·Two external non-detachable antennas (2 dBi)
MIMO ·2 x 2
Power connector ·CEE 7/16 plug for AC power supply
Software
Network functions ·DHCP server
·DNS relay
Firewall functions ·MAC filter
Management ·Local and remote access to settings through TELNET/WEB (HTTP/HTTPS)
·Bilingual web-based interface for configuration and management
(Russian/English)
·Firmware update via web-based interface
·Automatic notification on new firmware version
·Saving/restoring configuration to/from file
·Support of logging to remote host
·Automatic synchronization of system time with NTP server and manual
time/date setup
·Ping utility
·Traceroute utility
Wireless Module Parameters
Standards ·IEEE 02.11b/g/n
Frequency range ·2400 ~ 24 3.5MHz
Wireless connection security ·WEP
·WPA/WPA2 (Personal/Enterprise)
·МАС filter
·WPS (PBC/PIN)
Advanced functions ·Support of client mode
·WMM (Wi-Fi QoS)
·Information on connected Wi-Fi clients
·Advanced settings
·Support of MBSSID
Wireless connection rate ·IEEE 02.11b: 1, 2, 5.5, and 11Mbps
·IEEE 02.11g: 6, 9, 12, 1 , 24, 36, 4 , and 54Mbps
·IEEE 02.11n: from 6.5 to 300Mbps (from MCS0 to MCS15)
* The device features are subject to change without notice. For the latest versions of the firmware and relevant
documentation, visit www.dlin .ru.
Page 6 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Overview
Wireless Module Parameters
Transmitter output power
The maximum value of the transmitter
output power depends upon the radio
frequency regulations applied in your
country
·02.11n (typical at room temperature 25 °C)
15dBm (+/-1.5 dB)
eceiver sensitivity ·02.11n (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)
HT20
- 2dBm at MCS0/
-79dBm at MCS1/9
-77dBm at MCS2/10
-74dBm at MCS3/11
-70dBm at MCS4/12
-66dBm at MCS5/13
-65dBm at MCS6/14
-64dBm at MCS7/15
HT40
-79dBm at MCS0/
-76dBm at MCS1/9
-74dBm at MCS2/10
-71dBm at MCS3/11
-67dBm at MCS4/12
-63dBm at MCS5/13
-62dBm at MCS6/14
-61dBm at MCS7/15
Physical Parameters
Dimensions (L x W x H) ·51 x 49 x 9 mm (2 x 1.91 x 3. 5 in)
Weight ·97 g (0.21 lb)
Operating Environment
Power ·Input: 110 to 240 V AC, 50/60 Hz
Temperature ·Operating: from 0 to 40 °C
·Storage: from -20 to 70 °C
Humidity ·Operating: from 10% to 90% (non-condensing)
·Storage: from 5% to 90% (non-condensing)
Page 7 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Overview
Product Appearance
Upper Panel
Figure 1. Upper panel view.
LED Mode Description
POWE /WPS
Solid red The device is being loaded.
Solid green The device is ready for use.
Blinking red Attempting to add a wireless device via the
WPS function.
o light The extender is powered off.
Wi-Fi Signal Strength
Solid red The device is not connected to a wireless
networ or the signal strength is poor.
Solid green Fair signal strength.
Solid green Good signal strength.
Solid green Excellent signal strength.
o light The extender's WLAN is off.
The Wi-Fi Signal Strength LED is a LED scale. It shows the signal strength of the wireless
networ to which DAP-1325 is connected. The more LEDs are on, the better the signal strength is.
To improve the signal strength, move the extender closer to the source of the signal.
Page 8 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Overview
The RESET and WPS buttons are located on the upper panel of the extender.
Button Description
ESET
A button to restore the factory default settings.
To restore the factory defaults, push the button (with the device turned
on), hold it for 10 seconds, and then release the button.
WPS
A button to set up a wireless connection (the WPS function).
To use the WPS function: with the device turned on, push the button,
hold it for 2 seconds, and release. The POWER/WPS LED should
start blin ing.
The device is also equipped with two external non-detachable Wi-Fi antennas.
Bottom Panel
Figure 2. Bottom panel view.
Port Description
LAN An Ethernet port to connect to a computer or a wired router.
Page 9 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Overview
Delivery Package
The following should be included:
•Extender DAP-1325
•“Quick Installation Guide” (brochure).
The “User Manual” and “Quick Installation Guide” documents are available on D-Lin website
(see www.dlin .ru).
!Using a power supply with different parameters than those indicated on the device will
cause damage and void the warranty for this product.
Page 10 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
CHAPTE 3. INSTALLATION AND CONNECTION
Before You Begin
Please, read this manual prior to installing the device. Ma e sure that you have all the necessary
information and equipment.
Operating System
Configuration of the wireless extender DAP-1325 (hereinafter referred to as “the extender”) is
performed via the built-in web-based interface. The web-based interface is available from any
operating system that supports a web browser.
Web Browser
The following web browsers are recommended:
•Apple Safari 8 and later
•Google Chrome 48 and later
•Microsoft Internet Explorer 10 and later
•Microsoft Edge 20.10240 and later
•Mozilla Firefox 44 and later
•Opera 35 and later.
For successful operation, JavaScript should be enabled on the web browser. Ma e sure that
JavaScript has not been disabled by other software (such as virus protection or web user security
pac ages) running on your computer.
Wired or Wireless NI (Ethernet or Wi-Fi Adapter)
Any computer that uses the extender should be equipped with an Ethernet or Wi-Fi adapter (NIC).
If your computer is not equipped with such a device, install an Ethernet or Wi-Fi adapter prior to
using the extender.
Wireless onnection
Wireless wor stations from your networ should be equipped with a wireless 802.11b, g, or n NIC
(Wi-Fi adapter). In addition, you should specify the values of SSID, channel number and security
settings defined in the web-based interface of the extender for all these wireless wor stations.
Page 11 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
Connecting to PC
PC with Ethernet Adapter
1. Connect an Ethernet cable between the Ethernet port of the extender and the Ethernet port of
your PC.
2. Plug the device into an electrical outlet or power strip.
Now you need to configure an IP address for the Ethernet adapter of your PC.
Conguring IP Address in OS Windows XP
1. Clic the Start button and proceed to the Control Panel > Network and Internet
Connections > Network Connections window.
2. In the Network Connections window, right-clic the relevant Local Area Connection
icon and select the Properties line in the menu displayed.
Figure 3. The Net ork Connections window.
Page 12 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
3. In the Local Area Connection Properties window, on the General tab, select the
Internet Protocol (TCP/IP) line. Clic the Properties button.
Figure 4. The Local Area Connection Properties window.
Page 13 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
4. Select the Use the following IP address radio button and enter the value
192.1 8.0.51 in the IP address field. The Subnet mask field will be filled in
automatically. Clic the OK button.
Figure 5. The Internet Protocol (TCP/IP) Properties window.
5. Clic the ОК button in the connection properties window.
Now you can connect to the web-based interface of DAP-1325 for configuring all needed
parameters. To gain access to an external networ (to the Internet), you also need to specify the
default gateway and the addresses of DNS servers.
Page 14 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
Conguring IP Address in OS Windows 7
1. Clic the Start button and proceed to the Control Panel window.
2. Select the Network and Sharing Center section. (If the Control Panel has the category
view (the Category value is selected from the View by drop-down list in the top right
corner of the window), choose the View network status and tasks line under the
Network and Internet section.)
Figure 6. The Control Panel window.
Page 15 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
3. In the menu located on the left part of the window, select the Change adapter settings
line.
Figure 7. The Net ork and Sharing Center window.
Page 16 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
4. In the opened window, right-clic the relevant Local Area Connection icon and select
the Properties line in the menu displayed.
Figure 8. The Net ork Connections window.
Page 17 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
5. In the Local Area Connection Properties window, on the Networking tab, select the
Internet Protocol Version 4 (TCP/IPv4) line. Clic the Properties button.
Figure 9. The Local Area Connection Properties window.
Page 18 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
6. Select the Use the following IP address radio button and enter the value
192.1 8.0.51 in the IP address field. The Subnet mask field will be filled in
automatically. Clic the OK button.
Figure 10. The Internet Protocol Version 4 (TCP/IPv4) Properties window.
7. Clic the OK button in the connection properties window.
Now you can connect to the web-based interface of DAP-1325 for configuring all needed
parameters. To gain access to an external networ (to the Internet), you also need to specify the
default gateway and the addresses of DNS servers.
Page 19 of 92

DAP-1325 N300 Wi-Fi Range Extender
User Manual Installation and Connection
PC with Wi- i Adapter
1. Plug the device into an electrical outlet or power strip.
2. Turn on your Wi-Fi adapter. As a rule, modern noteboo s with built-in wireless NICs are
equipped with a button or switch that turns on/off the wireless adapter (refer to your PC
documents). If your PC is equipped with a pluggable wireless NIC, install the software
provided with your Wi-Fi adapter.
Now you should configure your Wi-Fi adapter.
Page 20 of 92
