D-MAX 650 TVL User manual

High Resolution / Day&Night
COLOR BOX CAMERA
사용 설명서
용서
650TVL
MANUAL

The lightning flash with an arrowhead symbol, within an equilateral
triangle is intended to alert the user to the presence of uninsulated
dangerous voltage within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with limits for a
Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
CAUTION : To prevent electric shock and risk of fire hazards:
Do NOT use power sources other than that specified.
Do NOT expose this appliance to rain or moisture.
This installation should be made by a qualified service person and should conform to all
local codes

3
The camera needs periodic inspection.
Contact an authorized technician for inspection.
Stop using your camera when you find a malfunction.
If you use your camera around smoke or unusual heat for a long time,
fire may be caused.
Do not Install the camera on a surface that can not support it.
Unless the surface is suitable, it could cause falling or other hazards.
Do not hold plug with wet hands.
It could cause an electric shock.
Do not disassemble the camera.
It may result in fire, electric shock or other hazards.
Do not use the camera close to a gas or oil leak.
It may result in fire or other hazards.
■ Warning

4
1.Features
---------------------------------
2. Components
---------------------------------
3. Names and functions of parts
---------------------------------
4. Installation
---------------------------------
5. Setup Menu Operation
---------------------------------
6. Troubleshooting
---------------------------------
7. Specifications
---------------------------------
■Contents

5
☺Horizontal Resolution 650 TVLines
Clear image quality has been achieved by employing a SONY CCD with 410,000
pixels, which provides a horizontal resolution of 620 TV lines.
☺DAY & NIGHT
This camera has a function that automatically selects the mode that is appropriate for
daytime or night-time conditions The COLOR mode operates in daytime conditions to
provide optimum colors, and BW mode operates in nighttime conditions to enhance the
definition of the image.
☺Electronic IRIS
The electronic IRIS function enables continuous automatic control of the shutter between
1/60~1/120,000 seconds.
☺White Defect restoration
When the camera has white defect in the CCD with ages, User can restore it using OSD
menu.
☺PRIVACY Function
The PRIVACY function conceals the areas you do not wish to appear on the screen.
☺High Sensitivity
The built-in high sensitivity SONY COLOR CCD enables a clear image even in
0.1Lux
☺Controlled by OSD Menu
The camera can be controlled by selecting text displayed on the monitor screen.
☺Additional Functions
MOTION DETECTION, MIRROR, SHARPNESS functions are also available.
1. Features

6
1) COLOR CAMERA -------------
2) AUTO IRIS LENS CONNECTION
PLUG
-------------
3) C-MOUNT ADAPTOR -------------
4) L-WRENCH -------------
4) MANUAL -------------
2. Components

7
1) Front
① Lens protection cap
Please cover the lens when not using it.
② CS-Mount lens adaptor
Please attach the CS-Mount lens here.
③ Back Focus clamp screw
Please loosen the clamp screw with a screwdriver before adjusting the Back Focal
length.
☞Mounting bracket screw hole
Please use the screw hole when fixing the
camera onto the mounting bracket. Please use
the clamp screw as specified picture.
☞The mounting bracket can be separated and attached to the top of the camera.
In this instance please do not tighten the screw to a depth of more than 5mm,
otherwise serious damage can occur to the inside of the camera.
3. Names and Functions of Parts

8
2) Back
⑥
① Auto iris lens connector
This is the connection terminal for the auto iris lens.
② Video output terminal
Sends video signals and connects to the video input terminal of the monitor.
③ Power lamp
Lights up when the correct power is supplied to the camera.
④ Setting button
SETUP button : Used for the menu display. This button can be used to confirm
settings after changing the value of the selected function or current conditions.
UP & DOWN buttons : Used for selecting items by moving the cursor up or down on
the menu screen.
LEFT & RIGHT buttons : Used when changing item values, by moving the cursor to
the left or right on the menu screen.
⑤ Power input terminal
Connects to the power appropriate to each power requirement.
⑥Auto Iris Switch
Video or DC
☞Make sure that user can’t use video type lens using high voltage camera.

9
1) Lens
Lenses are sold separately. Lenses such as auto iris lens, CS-Mount lens and C-Mount
lens can be used.
Note)
• Use of the DC auto iris lens is recommended to achieve the best results for operating this
product effectively.
• Please keep the lens clean.
• Any foreign objects and finger marks on the lens can cause inferior image quality in low
light level conditions.
①When using an auto iris lens
- Please peel off about 8mm of the outer skin of the auto iris lens cable.
- Please peel off about 2mm of the outer skin of the insulated conductor inside the
lens cable
- Please remove the cover of the auto iris lens connection plug and solder the lens
cable to the connector pin in the plug.
4. Installation

10
Pin No. LENS
DC VIDEO
No.1 Pin Damping- Red(power)
No.2 Pin Damping+ NC
No.3 Pin Drive+ White(video signal)
No.4 Pin Drive- Black(GND)
- Please replace the auto iris lens connection plug cover and take off the lens
protection cap, and then attach the auto iris lens to the camera by screwing it in
clockwise.
- Please insert the connection plug that is connected to the auto iris lens cable into
the auto lens connector, which is located on the back of the camera
- Please set the lens selection switch, located on the back of the camera, to DC or
VIDEO depending on the type of auto iris lens which is being used.

11
Caution
Make sure that user can’t use video type lens using high voltage camera.
② When using a CS-Mount lens
Please take off the lens protection cap and attach the CS-Mount
lens to the camera by screwing it in clockwise.
③ When using a C-Mount lens
- Please take off the lens protection cap and attach the C-mount adaptor.
- Please attach the C-Mount lens to the camera by screwing it in clockwise.

12
-
Note)
• Please use the specified lens connection parts as shown in the picture below.
The use of the wrong sized parts may cause damage to the inside of the camera or result
in poor fitting.
• Use of a lens which is too heavy affects the balance of the camera and may cause a
malfunction. Please use a lens that weighs less than 450g.
2) Connecting to a monitor
Please connect the video output terminal located on the back of the camera to the monitor.
• The connection method varies depending on the type of monitor and accessories.
Please refer to the user's manual for each instrument.
• Please turn off the power when connecting.
3) Connecting to power
DC Power Type (DC 12V, 500mA), Dual Type, Free Voltage Type

13
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY& NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
EXPOSURE
SHUTTER 1/60
BRIGHTNESS --|------ 050
AGC MIDDLE
D-WDR OFF
RETURN RET
•Please press the SETUP button to set OSD menu. The SETUP menu is displayed like
under the picture on the monitor.
•if it has been selected. You may move up/down to use another function by up/down
buttons and change the status by pressing left/right buttons.
•After finishing all desired setting, Please select 'EXIT.
Note) If ‘ ’ appears at the mode you wish to operate, it means that there is a sub-menu
which can be selected by pressing the SETUP button.
LENS
This menu is used to select kind of the lens.
•DC / VIDEO / MANUAL
1. DC : Please select, when you use DC
auto iris lens
2. VIDEO : please select, when you use
video iris lens
3. MANUAL : please select, when you use
manual lens
EXPOSURE
You can set up Exposure here.
→
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY& NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
SETUP
1.LENS DC
2. EXPOSURE
3.WHITEBAL ATW
4.BACKLIGHT OFF
5. DAY & NIGHT COLOR
6.DPC
7. SPECIAL
8. RESET
9.EXIT
5. Setup Menu Operation

14
When the SETUP menu screen is displayed, select EXPOSURE by using the Up and
Down buttons so that the indicates EXPOSURE.
Select a desired mode using the UP and DOWN buttons.
①SHUTTER
You can select either auto or manual shutter.
• FLK: Select this when you experience picture flicker, which can happen when there is a
clash with the frequency of the installed lighting.
• MANUAL: The shutter speed can be controlled manually.
• 1/50, AUTO, FLK, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/5000, 1/10000, 1/100000
selectable.
• AUTO: Select this to control the shutter speed automatically. The shutter speed is
automatically controlled depending on the ambient illumination of the subject.
②BRIGHTNESS
You can adjust BRIGHTNESS.
• Level: 1 ~ 255
③AGC (Auto Gain Control)
The higher the gain, the brighter the screen But it make a lot of noise.
• OFF: Deactivates the AGC function.
• LOW: Allows automatic gain control to 14 dB
• MIDDLE: Allows automatic gain control to 28dB
• HIGH: Allows automatic gain control to 32dB
④DWDR (Digital WDR)
When there are both bright and dark areas at the same time, this mode makes both areas
distinctive.
• OFF: Deactivates the WDR function
• ON: Digital WDR function will operate like below pictures.

15
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY& NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
WHITE BALANCE
The screen color can be adjusted by using the WHITE BALANCE function.
Please select the mode you wish to operate by pressing the LEFT or RIGHT button.
①ATW1: This automatically finds white color from color temperature between
2000~18,000°K.
②ATW2: This automatically finds white color from temperature between 4000~12,000°K.
③AWC->SET: To find the optimal setting for the current luminance environment
in this mode, set the point the camera towards a sheet of white paper and press the
SET button. If the environment changes, read just it.
④MANUAL : Select this to fine-tune White Balance manually.
Set White Balance first by using the ATW mode.
After that switch to MANUAL mode, fine-tune the White Balance and then press the SET
button.
▶INDOOR: Fixed setting, adjusting white balance by 3,200°K.
▶OUTDOOR: Fixed setting, adjusting white balance by 6,300°K.
WBL MANUAL
COLOR TEMP
BLUE IIIIIIIIIIIIIIIIIIIII 126
RED IIIIIIIIIIIIIIIIIIIII 95
RETURN RET

16
BACKLIGHT
When there is a strong backlight behind the object, clear images of the background as well
as the object can still be obtained by using the BLC or HLC function.
①OFF: Not being used
②BLC
You have to select desired area from a picture to run BLC function in advance and then
can see the area more clearly.
• AREA SEL – Can select areas up to 2 area
• ARA STATE – if STATE is ON, BLC function operates
• GAIN – Adjust GAIN of BLC area.
(LOW, MIDDLE, HIGH)
• HEIGHT – Adjusting height of up-down in BLC area
• WIDTH – Adjusting left-right width in BLC area
•LEFT/RIGHT - Moving left-right in BLC area.
•TOP/BOTTOM – Moving up-down in BLC area.
BLCON BLCOFF
③HLC
If there is a high light where camera was installed in a certain place such as parking
garage or gas station, removing the high light makes it possible to view car plate.
•LEVEL: 1~255
•MODE: ALL DAY / NIGHT OMLY
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY& NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
BLC
AREASEL. AREA1
ARA STATE ON
GAIN MIDDLE
HEIGHT IIIIIIIIIIIIIIIIIIIII 3
WIDTH IIIIIIIIIIIIIIIIIIIII 4
LEFT/RIGHT IIIIIIIIIIIIIIIIIIIII 2
TOP/BOTTOM IIIIIIIIIIIIIIIIIIIII 3
RETURN RET

17
DAY & NIGHT
You can display pictures in color or black and white.
When the SETUP menu screen is displayed, select ‘DAY/NIGHT’ by using the UP and
DOWN buttons so that the arrow indicates “DAY NIGHT”.
Please select the mode you wish to operate by pressing the LEFT or RIGHT button.
①COLOR : The picture is always displayed in color.
②AUTO : The mode is switched to ‘Color’ in a normal environment, but switches to ‘B/W’
mode when ambient illumination is low.
• DELAY – you can select delay time about changing the day/night mode
• LEVEL – you can select changing level from color to B/W or from B/W to color
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY &NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
DAY NIGHT AUTO
D→N LEVEL IIIIIIIIIIIIIIIIIIIIIIII 1~255
D→N DELAY IIIIIIIIIIIIIIIIIIIIIIII 1~30
N→D LEVEL IIIIIIIIIIIIIIIIIIIIIIII 1~255
N→D DELAY IIIIIIIIIIIIIIIIIIIIIIII 1~30
RETURN RET↙

18
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY& NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
③B/W : This mode allows you to apply B/W mode.
• burst: If it cannot be synchronizing video on the monitor in the BW mode of camera, it
turns on. (When the camera in B/W mode, the WHITE BALANCE is deactivated.)
If DAY NIGHT mode is AUTO, the AGC is fixed HIGH.
•IR SMART
When the IR camera uses, this function can suppresses saturation of the picture that
happens in the short distance from object.
And you can set area up that you want area.
•IR LEVEL
Adjust IR level as IR light strength.
④EXT: This mode allows you to apply a desired filter to external signals.
DPC
When the camera has white defect in the CCD with ages, user can restore it using OSD
menu.
- Before pressing the Start menu, you have to cover camera lens using lens cap
B/W
BURST OFF
IRSMART OFF
IR LEVEL LOW
RETURN RET

19
SETUP
CAM TITLE OFF
MOTION OFF
PRIVACY OFF
PARKLINE OFF
IMAGE ADJ. ↙
VERSION
RETURN
SETUP
LENS DC
EXPOSURE
WHITEBAL ATW
BACKLIGHT OFF
DAY& NIGHT COLOR
DPC
SPECIAL
RESET
EXIT
SPECIAL
CAM TITLE OFF
MOTION OFF
PRIVACY OFF
PARKLINE OFF
IMAGE ADJ. ↙
VERSION
RETURN
SPECIAL
Select ‘FUNCTION’ key from SETUP menu and press Set key to change ‘FUNCTION’
setup.
①CAM TITLE
If the TITLE is input, the camera TITLE appears on the monitor
- Please position the arrow to point to 'CAMERA TITLE' by using the UP or DOWN
button.
- Please select 'ON' by pressing the LEFT or RIGHT button.
- Please press the SET button.
- Up to 15 letters can be used for the ID.
- Please move the cursor to the letter you wish to choose by using the UP and
DOWN button.
- Select an ID from A,B~Y,Z, 0,1~8,9 by using the UP, DOWN,LEFT and
RIGHT buttons.
- Please lock in the letters by using the SETUP button.
When the letter is locked in, the cursor moves to the next space.
- Please repeat the above to input the ID.
Note) If the wrong name has been input.....

20
• If you press the SETUP button after moving the cursor to CLR, all the letters will be
erased. If you want to correct a letter, please move the cursor to the arrow at the bottom
left of the screen and press 'SET'.
• Please position the cursor above the letter you wish to correct, and then move the cursor
on to the letter you wish to choose and press the SETUP button.
- When a name has been chosen, please select a position for the name display.
▪Please move the cursor onto 'POS' and then press the SETUP button.
▪The name will appear at the top left corner.
▪Please find the position you wish to display the name by using the 4 directional buttons,
and then press the SETUP button.
- Please select 'END' and then press the SETUP button to complete ID input.
②MOTION
Motion detection function allows more effective observation. When any movement is
detected, signal is generated.
