D-MAX DSC-2000Si User manual

USER MANUAL
DSC
-
2000Si/Se
HIGH SPEED DOME CAMERA

2

1
1. CAUTION -------------------------------------------------------------------------------- 2
2. INTRODUCTION OF PRODUCT 4
1). DESCRIPTION AND FEATURES --------------------------------------------- 4
2). INSTALLATION AND CONNECTION ---------------------------------------- 5
2-1. NAME AND FUNCTION OF EACH PART ----------------------------- 5
2-2. INSTALLATION -------------------------------------------------------------- 6
2-3. BASIC CONNECTION ----------------------------------------------------- 8
2-4. CONNECTION DIAGRAM ------------------------------------------------ 9
3. DIRECTIONS FOR USE 10
1). DIP SWITCH SETTING ---------------------------------------------------------- 10
2). HOW TO CHANGE PROTOCOL ---------------------------------------------- 11
3). SETTING ADDRESS OF DIP SWITCHES ---------------------------------- 12
4). HOW TO USE OSD MENU ----------------------------------------------------- 13
4-1. HOW TO CONTROL OSD MENU --------------------------------------- 13
4-2. FUNCTIONAL DESCRIPTIONS ON EACH MENU ----------------- 14
4-3. FUNCTIONAL SETTING, OPERATION/DELETION THE
KEYBOARD-------------------------------------------------------------------
26
4-4. OSD MESSAGE DESCRIPTION ---------------------------------------- 29
4 TROUBLE SHOOTING --------------------------------------------------------------- 31
5 DIMENSION --------------------------------------------------------------------------- 32
6 ASSEMBLY --------------------------------------------------------------------------- 34
7 SPECIFICATION -------------------------------------------------------------------- 42
Table of contents

2
Thank you for purchasing our product. Please operate the product after being
fully aware of the manual.
Pease contact us if you have any queries.
Precaution
Note the following matters before the installation of the product.
Avoid the following places for the installation.
1.CAUTION
A high/low temperature: Using indoor-cameras
in the places of +50°C~ -10°C can cause
troubles and lower its capacity.
Snow, rain and wet: Humidity or water and
any liquid inside-camera can cause troubles.
Oil, gas: Oil and gas can damage the camera
as they go through the cameras.
Vibration, shock: They bring on problems or
errors of the camera.
Direct light, exposure to the air: In the case of
that sets indoor- cameras outside where the
weather is changeable, it can cause problems.
Closing to High frequency and electric power
lines: Setting the camera up around
electromagnetic units or power supplier can
cause problems.

3
Caution in Use
Do not disassemble the unit and put alien substances in the unit.
- Disassembling the unit or putting alien substances such as a metal can make the
camera defective.
- Make sure of power switch-off before the installation.
: Ensure power switch-off and check the voltage the camera before the installation.
- Do not give the unit a shock and an operation.
: Giving a strong shock or an excessive power on the button, terminal can cause
problem.
This product has been designed and manufactured in accordance with the harmonized
European standards, following the provisions of the below stated directives.
Electromagnetic Compatibility Directive 89/336/EEC
(EN60065:1998, EN61000-6-3:2001, EN61000-6-1:1997)
This devise complies with part 15 of the FCC rules operation is subject to the
following two conditions: (1) This device may not cause harmful interference and
(2) This device must accept any interference received including interference that
may cause undesired operation

4
1) DESCRIPTION AND FEATURES
This camera has been designed elegantly for buildings, department stores that
need to be in harmony with the interior as a high speed dome camera, including
various observation functions.
2. INTRODUCTION OF PRODUCT
☺30x Zoom lens
30x Optical zoom lens combined with an auto focus
system and digital zoom enable you to get maximum
300x great pictures.
☺A low light function
Surveillance with optimum picture is possible owing
to digital-slow-shutter function.
Digital-slow-shutter function is improving the CCD
sensitivity by electrically lengthening exposure time
so that it should be under surveillance on the
condition of 0.0007 Lux in B/W.
☺Various auto-surveillance functions
zPTZ trace
Track the registered manual operation for about 180
seconds.
zAuto swing
Repeat pan and tilt between two preset positions.
zGroup sequence
12 Preset positions are chained in one Group.
zTour sequence
Max 12 Groups are bound.
☺250 Preset positions
A maximum of 250 preset positions can be
programmed. The preset function enables to set
where you want on monitor at any time.
☺Smart pan/tilt function
zIt should be rotated pan travel by 360° endless.
zPan and tilt speed compensation function in proportion to
depth of zoom.
☺Day & Night function with filter
zIt allows to make surveillance in the night or low
illumination condition with motorized IR cut filter
system. (0.1 Lux)
zIn the darkness, it should be changed to black &
white mode automatically.
zWith DSS control, it allows watching on 0.0007
Lux.
☺8ch alarm inputs
It can be directly connected to sensor and used with
presets owing to built-in 8-channel sensor input
terminals. It can be also operated together with
other equipment owing to built-in alarm output. (2-
Relay normal output)
☺Auto flip function
The unit can track the moving object automatically
until 180° in vertical by using controller.
☺16 Privacy Masking Zones
For the privacy, it can be programmed for masking
zone up to 16 locations on the OSD menu screen.
☺OSD (On Screen Display) Menu
Provides character information displayed on the
monitor, such as the camera ID address, camera
name, preset number, sequence status, and sets
various functions of camera easily on the OSD
menu screen.

5
2) INSTALLATION AND CONNECTION
2-1. Name and function of each part
Connect it
with cover
housing or
bottom cover,
then combine
with bracket.
It protects inside
the camera, and
built-in pan
makes the heat
cool when using
of long time.
It is a part to be
connected with power,
video, data.
It is a part to set
Dip switch.
It combines with cover housing,
and the bubble rubber is useful
for the water proof outdoors
It is a bubble
cover for indoor
camera
INDOOR TYPE OUTDOOR TYPE

6
2-2. Installation
Open the cover with unscrewing 5 bolts, then
separate the camera body from the cover
housing with turning it as the same direction in
the picture
(the bolt of the bubble cover is not separated
completely)
Unlock the device of the bottom cover, then
separate the camera body cover from the
bottom cover with turning it as the same
direction in the picture.
INDOOR TYPE OUTOOR TYPE

7
LOCK DEVICE :
Check the direction when it connects
with camera body case,
And lock it with DSC-1000Si
AC24V INPUT
Use AC24V power and
use either terminal
power connect or jack
power connect.
POWER LED :
Power LED is turned
when the power is ON
DATA IN ( RS-485) :
Never connect the power into
here.
It is cause of a breakdown

8
2-3. Basic Connection
Connect the video line of a
monitor
DC12V 1A adaptor and junction box are
provided on a purchase. Junction box
consists of 2 data ports (each data port
can be connected with maximum up to
128 cameras and sub keyboard terminal.
User can control maximum up to 255
cameras connected by using the
exclusive control keyboard.
User can connect it maximum up to
1.2km when using twist pair shield
cable as a connecting cable.

9
2-4. Connection diagram
Must use AC24V power source. The current value must be 1.5A
or more and use a double winding transformer.
Alarm output is tangency output of
relay non-load. It can be used up to AC
220V/10A by connecting with the load.
The switch is automatically turned on
when the sensor works and it is
possible to cancel by using the
controller after the regular time
The sensor
Can be connected up to 8 channels and the
camera can be moved automatically to the
point by preset mode, if there is any
problems
DATA
Can be processed by RS 485 and connected in
parallel to use a large quantity of cameras.

10
1). DIP SWITCH SETTING
Set the camera numbers in the state of
ADDR, set communication speed, protocol
in the state of INIT.
This part is each address of camera.
-Termination Resistor (DIP SW NO1)
-Turn the last camera on the data line as a switch
to turn on/off the terminal resistor on. Turn the
DIP SW of some of the farthest cameras on in the
case of the data lines distributed to
* The first default is off.
-RS485RS422 SELECT (DIP SW NO2)
-Turn on or off for the suitable data system
between RS485 and RS422.
* The first default is off.
-Address /Initial select (DIP SW NO3)
-Set the DIP SW up in the ADDRESS.
*The first default is ADDRESS.
-Set the communication speed and Protocol
(Demand for the technical inquiry) up in the
state of the INITAIL.
-Internal/External (DIP SW NO5)
-Use it when selecting Internal and external.
* The first default is INTERNAL
3. DIRECIONS FOR USE

11
2) HOW TO SET PROTOCOL
Change No.3 at S2 to INIT if user wants to change Protocol.
①Please the power off.
②Switch on the Protocol that you want to change on as above table.
③The power on, then the set Protocol and Baud rate are appeared.
④The power off, if every setting is right. Then the change of Protocol is finished.
⑤Change No.3 at S2 to ADDR before the power on, then the power on after setting the address of
the camera.
⑥Try it again with the information as above the table, if something is wrong.
Set this part up Do not necessary to set it up
The switch to select baud rate The switch to select protocol

12
3) SETTING ADDRESS OF DIP SWITCHES.
Use DIP switches No.1 to No.8 for address, it can be set 1 program to 255 program.
DIP SWITCH (HEX) DIP SWITCH (HEX)RX
NO 1 2 3 4 5 6 7
RX
NO 1 2 3 4 5 6 7
1 ON OFF OFF OFF OFF OFF OFF 33 ON OFF OFF OFF OFF ON OFF
2 OFF ON OFF OFF OFF OFF OFF 34 OFF ON OFF OFF OFF ON OFF
3 ON ON OFF OFF OFF OFF OFF 35 ON ON OFF OFF OFF ON OFF
4 OFF OFF ON OFF OFF OFF OFF 36 OFF OFF ON OFF OFF ON OFF
5 ON OFF ON OFF OFF OFF OFF 37 ON OFF ON OFF OFF ON OFF
6 OFF ON ON OFF OFF OFF OFF 38 OFF ON ON OFF OFF ON OFF
7 ON ON ON OFF OFF OFF OFF 39 ON ON ON OFF OFF ON OFF
8 OFF OFF OFF ON OFF OFF OFF 40 OFF OFF OFF ON OFF ON OFF
9 ON OFF OFF ON OFF OFF OFF 41 ON OFF OFF ON OFF ON OFF
10 OFF ON OFF ON OFF OFF OFF 42 OFF ON OFF ON OFF ON OFF
11 ON ON OFF ON OFF OFF OFF 43 ON ON OFF ON OFF ON OFF
12 OFF OFF ON ON OFF OFF OFF 44 OFF OFF ON ON OFF ON OFF
13 ON OFF ON ON OFF OFF OFF 45 ON OFF ON ON OFF ON OFF
14 OFF ON ON ON OFF OFF OFF 46 OFF ON ON ON OFF ON OFF
15 ON ON ON ON OFF OFF OFF 47 ON ON ON ON OFF ON OFF
16 OFF OFF OFF OFF ON OFF OFF 48 OFF OFF OFF OFF ON ON OFF
17 ON OFF OFF OFF ON OFF OFF 49 ON OFF OFF OFF ON ON OFF
18 OFF ON OFF OFF ON OFF OFF 50 OFF ON OFF OFF ON ON OFF
19 ON ON OFF OFF ON OFF OFF 51 ON ON OFF OFF ON ON OFF
20 OFF OFF ON OFF ON OFF OFF 52 OFF OFF ON OFF ON ON OFF
21 ON OFF ON OFF ON OFF OFF 53 ON OFF ON OFF ON ON OFF
22 OFF ON ON OFF ON OFF OFF 54 OFF ON ON OFF ON ON OFF
23 ON ON ON OFF ON OFF OFF 55 ON ON ON OFF ON ON OFF
24 OFF OFF OFF ON ON OFF OFF 56 OFF OFF OFF ON ON ON OFF
25 ON OFF OFF ON ON OFF OFF 57 ON OFF OFF ON ON ON OFF
26 OFF ON OFF ON ON OFF OFF 58 OFF ON OFF ON ON ON OFF
27 ON ON OFF ON ON OFF OFF 59 ON ON OFF ON ON ON OFF
28 OFF OFF ON ON ON OFF OFF 60 OFF OFF ON ON ON ON OFF
29 ON OFF ON ON ON OFF OFF 61 ON OFF ON ON ON ON OFF
30 OFF ON ON ON ON OFF OFF 62 OFF ON ON ON ON ON OFF
31 ON ON ON ON ON OFF OFF 63 ON ON ON ON ON ON OFF
32 OFF OFF OFF OFF OFF ON OFF 64 OFF OFF OFF OFF OFF OFF ON
-No.1 is changed to No.64 and the last No.64 is changed No.128 when No.7 DIP SW is on.
-No.1 is changed to No.129 when No.7 DIP SW is off and No.8 DIP SW is on.
-No.1 is changed to No.193 and user can set up to maximum 255 ADDRESS when No.7, 8 DIP SW are on.

13
4) HOW TO USE OSD MENU
4-1. How to control OSD menu
●OSD (ON SCREEN DISPLAY) CONTROL
It is the function to call up the Menu
＊User can not only set Preset, Group, Tour, Swing, Trace functions of the camera up by the menu, but also set
them up by shortening keys. (Refer to 3-3 content)
●Accessing OSD MENU
(1) The menu is displayed on the screen with the key tone when user presses No.1 and menu key.
●OSD Menu Control.
Right and Left
moving of Cursor
Feed letters into system.
Selection of up and
down menu
Change of setting.
●Cancellation of OSD MENU

14
4-2. Functional Descriptions of each Menu.
1. ID SET.
It is the function to set ID of the camera.
Move to No.1 menu and the screen moves as following when user
presses F/F key.
User can choose letters that they want, if user control a joystick up
/ down / right / left, and user can reselect the previous letters, if
user presses Z/I, Z/O or turn the head of the joystick to right/left.
“•” is not displayed on the screen as a blank letter,
user can input letters in Japanese and in Chinese
If user moves the joystick down continuously.
2. OSD DISPLAY.
Set up whether user sets ID and STATUS to display on the
screen in normal operating.
●ID + Status: ‘ID’ and ‘Status’ displayed on the screen
●ID only: Only ‘ID’ displayed on the screen
●Status only: Only ‘Status’ displayed on the screen
●All off: Nothing displayed on the screen
3. BACK LIGHT
Set up backlight compensation mode.
●On: It compensates a dark subject to a light subject by
BACK LIGHT function.
●Off: Cancellation of BACK LIGHT compensation mode.

15
4. AGC LEVEL
AGC(Automatic Gain Control)- It adjusts the amount of video
amplification to maintain a full 1-volt peak-to-peak video signal
output automatically.
▶Range : Auto, 8Db, 10Db, ----- 38dB
5. SHUTTER SPEED
As a setting shutter speed mode, it can be distinguished a fast
moving subject easily by means of shutter speed up.
※Attention-The illumination of the camera decreases if shutter
speed is up.
※The state of first default is ‘AUTO’.
※It can be worked in the state of Flickerless ‘off’
▶Range : Auto, 1/125, 1/150, 1/200, --- 1/10000
6. SHARPNESS LEVEL
Compensation of the shape of a subject
▶Range : 0 ~ 14, Default : 10
7. BRIGHTNESS
Control brightness of a screen.
The screen gets dark because an iris is closed as the numerical
value is low, whereas the screen gets bright because an iris
is opened as the numerical value is high.
▶Range: 0~99, Default: 50

16
8. FLICKERLESS
Tremble on the screen is removed in the state of FLICKERLESS
‘ON’, the shutter speed, at the same time, is fixed in 1/120sec in
NTSC and in 1/100sec in PAL.
※Move the joystick down then choose “NEXT MENU PAGE” on
the screen to move next page.
9. SSNR level
It can remarkably reduce noise of minimum illumination by super
noise removable technique and also file size becomes smaller
while DVR is being recorded by the effective reduction of noise.
▶Off, Low, Middle, High
10. WHITE BALANCE
It prevents from that white color is changed as illumination, user
can set it up in 2 ways.
▶ Indoor, Outdoor

17
11. FOCUS MODE
Change Focus Mode to hand-worked or auto.
▶OneShot : Auto Focusing mode works during non-working
after zoom is worked.
▶Auto : It adjusts the focus automatically as it monitors the
screen.
▶Manual : User can control the focus by hand-worked.
12. ZOOM MAX Limit
It is used when user corrects and limits the extensional range
of the focus as a function to set the maximum value of zoom.
▶ Off, 60X ~ 300X
The camera is reset when user is out of Menu mode after end
the setting, and the changed magnification is registered in
the camera
13. DSS CONTROL
An object becomes clear as the field value gets higher in
illumination, whereas a moving object becomes dim.
▶Range : Off, 2 ~ 1 128 fields
14. DAY& NIGHT
The function is used to distinguish an object clearly in the dark
condition.
▶ Auto : DAY & NIGHT mode is worked automatically,
ifitisdark.
▶ On : Change into DAY & NIGHTY mode by hand-worked
▶ Off : Set DAY & NIGHTY mode ‘off’

18
15. STABILIZ On/Off
There is some tremble as zoom magnification is high, the function
can compensate the tremble.
▶On / Off
16. Motion Detection
Set Motion ‘On’ after move the camera where user wants.
It displays the message ‘Motion Detected’ on the screen
when the moving of an object is sensed on the same screen.
17. PRESET SET & RUN PAGE
It is a function to set and operate Preset, Group, Tour.
User can see the screen when moves the joystick to Right/Left
after fixing the cursor on the menu.
<<PRESET SETUP PAGE>>
①Preset set CH :
User can set Preset No. and title on this menu.
- Preset No. set : Set it by moving the joystick to Right/Left
- Preset title set : User can see the menu “SET ID” when
presses F/F key after setting Preset No.
※The setting steps are the same as “ID Set” at page 14
