Daewoo SDA1032 User manual

Halogen Air Fryer
SDA1032
User Manual
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to
the product. Carefully save this instruction manual for future reference.
Ensure the user manual is included when passing the product on to any
third parties.
Explanation of symbols
The below symbols are used in this User Manual
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment
identies products conforming to UK statutory
requirements.
Products marked with the WEEE symbol indicates:
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling
advice.

MPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed. These instructions should be saved for future
reference:
• Read and familiarise yourself with all operating instructions before
using this Halogen Air Fryer.
• Do not touch hot surfaces. Use the handles provided.
• Always ensure that the voltage on the rating label corresponds with
the voltage in your home.
• Keep the appliance out of the reach of children.
• Keep the mains lead away from the body of the Halogen Air Fryer.
• Do not leave the appliance unattended whilst operating.
• Disconnect the appliance from the mains after use.
• To disconnect the appliance grip and pull the mains plug. DO NOT pull
the power cord.
• Do not wrap the power cord around the appliance in use or during
storage.
• Always disconnect the plug from the mains before cleaning. Wipe
clean only, do not immerse the unit, plug or cord in water or any other
liquid.
• Always allow the unit to cool before storage or cleaning.
• Retain the instruction manual for future use and reference.
• There are no user serviceable parts, if the unit fails, consult a qualied
electrician, a repair centre or contact the supplier if the unit is under
warranty.
• If the supply cord is damaged, it must be replaced by the
manufacturer, it’s service agent or similarly qualied persons in order
to avoid a hazard.
• It is recommended that this appliance should not be operated in
conjunction with an electrical extension lead.
• Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Do not use accessories with this appliance other than those
recommended by the supplier.
Halogen Air Fryer
SDA1032
User Manual

• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
• For indoor use only.
• Keep away from splashes of water or damp conditions.
• For domestic use only.
• Do not use this product with an external programmer, timer, separate
remote control system or any other device.
• DO NOT touch hot surfaces. Accessible surfaces are liable to get hot
during use. Always use the handles.
• Oven gloves should be used when using this appliance.
• Hot steam may be released when opening and closing the lid during
use - Risk of scalding!
• Avoid moving the appliance whilst it is still hot or contains hot food or
liquids. Turn the appliance o󰀨 and disconnect from the mains and let it
cool su󰀩ciently before moving it.
• Always carry the appliance with both hands using the handles
provided - Burn hazard!
THIS APPLIANCE MUST BE EARTHED
NOTE: Before use, check the glass bowl and lid for any signs of
damage that may have been caused in transit such as cracks or
chipping.
Halogen Air Fryer
SDA1032
User Manual

Safety Interlock Switch
(Underneath Handle)
Timer
Power Indicator
Extension Ring
Oil Sprayer
Tongs
Removable
Glass Bowl
Base with
Handles
Lid Stand
2 x Mesh Baskets
Low Rack
High Rack
Heat Indicator
Thermostat
Using the accessories
Lid stand showing
how to store the lid
Using the tongs to pick
up a rack
Using the tongs to pick
up a basket
Halogen Air Fryer
SDA1032
User Manual

NOTE: Always use the tongs provided to remove the basket or rack
from the cooking bowl and use the supplied lid stand for supporting
of the lid during and immediately after cooking.
DO NOT use any other accessories with this appliance for example
trays, bowls or aluminium foil linings.
Using your Halogen Air Fryer for the rst time
1. Remove the appliance carefully from its packaging. Remove all labels
and tags from the product. Important Do Not remove the Hot Surface
Warning label:
2. Wash the bowl and accessories in hot soapy water with a sponge or
cloth, rinse thoroughly and dry.
Unpacking the Extension Ring –
3. NB the Extension Ring (arrowed) is supplied packed around
the Glass Bowl inside the Base. Ensure the Extension Ring is
removed from the Base before use. See below:
The Extender Ring is
stored in transit around
the glass bowl and must
be removed before use.
DO NOT remove the
silicon anti slip band
from around the ring.
IMPORTANT: DO NOT IMMERSE THE LID/MOTOR ASSEMBLY IN
WATER OR ANY OTHER LIQUID
Note: During initial use you may notice a slight odour due to the
burning o󰀨 of manufacturing residues. This is completely normal and will
disappear after a short time.
Halogen Air Fryer
SDA1032
User Manual

Using your Halogen Air Fryer
Thermostat
The thermostat allows you to set the cooking
temperature from 65˚C to 250˚C. Rotate the control
clockwise to increase the cooking temperature and
anticlockwise to reduce the temperature.
Timer
The timer dial is marked in minutes, rotate the timer
clockwise to set the cooking time. The timer will count
down and return to the o󰀨 position at the end of the
cooking period and sound a bell.
Hints and tips on using your Halogen Air Fryer
1. Pre-heat the Halogen Air Fryer with the Thermostat at maximum for 3
minutes before use.
2. Always place food on the racks to ensure good air circulation.
3. Leave at least 1cm gap between food items on the same rack, again
this ensures good air circulation.
4. Once food is cooked it can be kept hot by turning the thermostat down
to 150˚C until it is ready to serve.
5. This appliance has a safety interlock built into the carrying handle
which will prevent the appliance operating unless the lid handle is in
the fully folded down (horizontal) position and it clicks.
6. Whilst roasting, line the bottom of the bowl with cooking foil to cook
more evenly and to ease cleaning.
Halogen Air Fryer
SDA1032
User Manual

Operating the Halogen Air Fryer
1. The outer surface of the bowl will become very hot during cooking,
be sure to place the bowl in its Insulated Base and on a solid, level
heatproof surface. Danger Hot Surface
2. Place the low or high rack (see the below table for the correct rack
height) into the bowl and place food on the rack leaving space
between the pieces of food for good air circulation. Place the food
at least 1cm away from the side of the bowl again for the best air
circulation.
3. Cover the bowl with the lid/motor assembly ensuring that it is correctly
seated.
4. Ensure the handle is fully pushed down until
the safety interlock switch clicks.
5. Insert the mains plug into the nearest wall socket and
set the thermostat to the desired temperature.
6. Set the timer using the reference table as a guide.
The red heat and green power indicator lights will glow
indicating that cooking has started as below:
7. To increase the capacity of
the Halogen Air Fryer, place the
extension ring (arrowed) on top of
the bowl and then place the lid on
top of the extension ring
Halogen Air Fryer
SDA1032
User Manual

Reference table of time and temperature for cooking
Food Type Cooking Time
(Minutes)
Temperature Rack Position
Roast meat
Beef 16 mins per 1lb + 20
mins
180-1900C Low rack
Lamb 16 mins per 1lb + 20
mins
180-1900C Low rack
Pork 24 mins per 1lb + 20
mins
180-1900C Low rack
Steak
Rare 3 mins each side 2500C High rack
Medium 5 mins each side 2500C High rack
Well done 7 mins each side 2500C High rack
Other meats
Sausage 5-8 mins each side 2500C High rack
Pork chop 6-8 mins each side 2500C High rack
Lamb chop 6-8 mins each side 2500C High rack
Chicken 35-40 mins 190-2000C Low rack
Chicken portions 15-20 mins 190-2000C Low rack
Cake
One layer 20-25 mins 2000C Low rack
Loaf 35-40 mins 1500C Low rack
Frying and roasting
Potatoes (roast, small
cut) (Par boil for approx
8 min, depending on
size)
25-40 mins 190-2100C High rack (use
with the basket for
smaller cuts)
Homemade chips (Par
boil for approx 8 mins
depending on size)
18-25 mins 180-2000C High rack with
basket
Frozen Chips 20-25 mins 180-2000C High rack with
basket
Halogen Air Fryer
SDA1032
User Manual

Cooking tips and recipes
How to roast
Place meat directly onto the wire rack.
Cooking time may vary depending on cut size and degree of cooking.
Consult the cooking guide provided.
How to bake
Place food on a metal or ceramic baking pan of a diameter no more than
12” (300mm) to leave enough room for air to circulate around the food
being cooked.
Follow cooking guidelines on the table provided.
How to fry/roast
You can get the e󰀨ect of deep frying without all the oil by spraying the
food lightly with oil. The food will need to be turned regularly during
cooking.
Thawing food
The Halogen Air Fryer will thaw most foods, simply place the food
onto one of the wire racks, set the thermostat to thaw and allow
approximately 40 minutes per kilogram. Large items such as meat joints
should be turned at least once during the thawing process.
NOTE: After thawing food in the Halogen Air Fryer always ensure to
thoroughly wash the bowl, racks, baskets and tongs etc before re-using
to prevent bacterial cross-contamination.
Halogen Air Fryer
SDA1032
User Manual

Recipes to get you started
Rolled ribs roast
4lbs rolled rib of beef
2 tablespoons red wine
2 tablespoons water
2 tablespoons our
Salt and pepper
Trim excess fat from the meat, sprinkle with salt and pepper and rub in
well. Place meat in a greased baking dish and pour wine and water over
the meat Marinade for 4 hours
Place on the lower rack and cook for 1 hour at 160˚C
Turn the meat and cook at 175˚C for a further 40 minutes for rare, 50
minutes for medium and 60 minutes for well done.
Serves 6
Chinese roast chicken
3lbs chicken breast/wings/drumsticks
½ cup of soy sauce
1 tablespoon of honey 1 teaspoon 5 spice
1 teaspoon crushed garlic
1 teaspoon nely grated ginger 1 tablespoon sesame oil
Marinade the chicken pieces in a mixture of all the other ingredients for at
least 2 hours, turning the pieces occasionally.
Place chicken pieces on the lower rack and cook at 200˚C for
approximately 20 minutes, turning during cooking.
Serves 6
Halogen Air Fryer
SDA1032
User Manual

Fillet steak supreme
2lbs whole llet steak Garlic, salt and pepper
½ cup of red wine
1 tablespoon cream or sour cream Rind of one lemon (grated)
Rind of one orange (grated) 1 large onion (chopped)
1 tablespoon chopped parsley 2 grated carrots
Marinade the llet steak with garlic, salt, pepper and red wine in a
covered dish for 4 hours, basting and turning occasionally.
Remove the steak from the marinade and wrap in cooking foil with the
carrot, lemon and orange rinds, onion and parsley.
Place on the lower rack and cook for 30 minutes at 190˚C then remove
foil and cook for a further 30 minutes.
Remove meat and keep warm, to remaining marinade add the cooked
onion, parsley and rinds and cook to reduce, add the cream and simmer
for 1 minute, serve over sliced meat.
Jacket potatoes
Medium sized washed potato (per person) Soft Butter
Garlic Salt
Ground black pepper
Wash and dry potatoes, removing any eyes/bruises etc. Rub a little butter
onto the potato and place on cooking foil. Sprinkle with salt, garlic and
pepper to taste.
Seal the potato in the cooking foil and place on the high rack. Cook for 45
minutes at 190˚C
Serve with Sour cream, cheese, beans etc.
Halogen Air Fryer
SDA1032
User Manual

Cleaning and Maintenance
For light cleaning of the bowl, place approximately 3cm of water in
the bowl and add a squirt of washing liquid/mild detergent, place the
lid/motor assembly on the bowl and set the temperature dial to WASH
and the timer to 10 mins, fully fold the handle down, the heater and turbo
fan will operate to warm the water and stir it, cleaning the bowl.
At the end of the cycle remove the plug from the socket and place the lid
on the lid stand, empty rinse and dry the bowl.
To clean the lid ensure that it is cool and use a damp cloth with a mild
detergent, NEVER IMMERSE THE LID/MOTOR ASSEMBLY IN WATER
OR ANY OTHER LIQUID.
Always ensure the Halogen Air Fryer is unplugged and the timer is in the
OFF position before storing away. Ensure the halogen oven has cooled
completely before storing.
WARNING
1. NEVER PUT THE GLASS BOWL IN THE REFRIGERATOR AS THIS
MAY CAUSE IT TO CRACK.
2. NEVER USE THE GLASS BOWL FOR COOKING, OTHER THAN AS
RECOMMENDED BY THE MANUFACTURER AS LAID OUT IN THIS
GUIDE.
3. NEITHER THE GLASS COOKING BOWL NOR THE ACCESSORIES
ARE DISHWASHER SAFE AND SHOULD BE CLEANED BY HAND
WITH WARM SOAPY WATER.
Halogen Air Fryer
SDA1032
User Manual

Halogen Air Fryer
SDA1032
User Manual
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug tted to the
mains lead and should the fuse need replacing, you must use an ASTA
approved one (conforming to BS 1362 of the same rating). If in doubt,
consult a qualied electrician who will be pleased to do this for you. If
you need to remove the plug – DISCONNECT FROM THE MAINS –
and then cut it o󰀨 the mains lead and immediately dispose of it safely.
Never attempt to reuse the plug or insert it into a socket outlet as there is
a danger of electric shock.

Voltage 220-240V ~ 50/60Hz
Rated power 1200-1400W
Protection Class I (This Appliance must be earthed)
Model Number SDA1032
Technical Data
Customer Support
Should you require any product information,
replacement parts or accessories, please contact our
customer care team at [email protected] or
call 0161 831 7879.
• Replacement parts and accessories are guaranteed
for 1 year from the date of purchase.
• It is important to note that your warranty becomes
invalid should non Daewoo parts or accessories be used
with this appliance
Halogen Air Fryer
SDA1032
User Manual
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not
be disposed of with normal household waste. Please ensure
it is taken to a suitable facility for disposal. Check with your
Local Authority or retailer for recycling advice or Visit www.
recycle-more.co.uk, click on “bank locator” and enter your
postcode to nd out your nearest recycling site.

Thank you for purchasing your Daewoo product.
As part of our commitment to quality we are offering you an extra 2 years warranty in addition to your
1 year guarantee.
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof of purchase or
receipt. If any defects should arise due to faulty workmanship or material, your faulty product should be returned
to the place of purchase, replacement or refund is at the discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the requirements contained
in the instruction manual.
• The product must be used solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The Guarantee is rendered invalid if the product has been resold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your individual product upon
registration. (Note: products must be registered individually and covers the main body and housing) If you do not
register your product within 28 days of the original purchase date, your product will only be guaranteed for 1
year.
To validate your extended 2 year warranty* please register your purchase online within 28 days of the original
purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and
subject to the conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by ESG Ltd
ESG Ltd
Manchester M3 1JS
www.esgltd.com
WARRANTY
