Daewoo SDA1032 User manual

1
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Contents
Page No.
2 Contents
3 Reading and Storing the User Manual
3 Important Safety Instructions for Proper Use
5 Additional Safety Information
6 Explanation of Symbols
6 Introduction
7 Description of Parts
7 Using the accessories
8 Before First use of Your Air Fryer
9 Using Your Air Fryer
11 Increasing the Cooking Capacity of Your Air Fryer
12 Reference Table of time and temperature for cooking
13 Cooking Tips
14 Recipes to get you started
16 Cleaning and Maintenance
17 Troubleshooting Guide
17 Technical Specification
17 Customer Support
18 Plug Wiring Information
18 Recycling Information
19 Notes
Back Page Guarantee

3
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
Whilst using electrical appliances, basic safety precautions
should always be followed.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
•Always ensure that the voltage on the rating label
corresponds with the voltage of your home.
•Keep the appliance out of reach of children.
•DO NOT leave the appliance unattended whilst
operating.
•Disconnect the appliance from the mains after use.
•DO NOT pull the power cord.
•DO NOT wrap the power cord around the appliance in
use or during storage.
•Cleaning –Wipe clean with a damp cloth.
•Always disconnect the plug from the mains before
cleaning.
•DO NOT immerse this appliance in water or any other
liquids.
•Always allow the unit to cool before storing or cleaning.
•This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction
concerning use of the appliance in a safe way and
understand the hazards involved.
•Keep the appliance and its cord out of reach of children

4
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
less than 8 years.
•Children should be supervised to ensure that they do not
play with the appliance.
•Keep out of reach of children.
•For indoor use only.
•For domestic use only.
•Do not use accessories with this appliance other than
those recommended by the supplier.
•Do not use this product with an external programmer,
timer, separate remote control system or any other
device.
•DO NOT touch hot surfaces. Accessible surfaces are liable
to get hot during use. Always use the handles.
•Oven gloves should be used whilst using the warming
tray.
•Always use this appliance on a solid, level, non-
flammable surface.
•Never place the appliance near to flammable material or
high pressure containers.
•Do not use this appliance for anything other than its
intended use.
•Never place this appliance on an electric, gas, or any other
type of hob.
•WARNING do not attempt to move the Halogen Air Fryer
whilst it is hot or contains hot foods or liquids.
THIS APPLIANCE MUST BE EARTHED

5
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Additional Safety Information
•PLEASE NOTE: Before use, check the glass bowl and lid for any
signs of damage that may have been caused in transit such as
cracks or chipping.
•PLEASE NOTE: Before use, ensure that the Air Fryer is used in
an open, well ventilated area well away from other appliances
and other obstructions.
•Do not use the Air Fryer in front of, near or below combustible
materials such as plastics, curtains or cupboards, etc.
•Do not place the appliance against a wall or against other
appliances. Leave at least 10cm minimum free space on the
back and sides and 10cm minimum free space above the
appliance.
•Do not place anything on top of the appliance.
•Do not use metal utensils with this appliance as this may
damage the glass, only use wooden or plastic utensils.

6
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
Products labelled with this symbol conform to applicable provisions
of the European Economic Area.
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for recycling
advice or visit www.recycle-more.co.uk enter your postcode to find
your nearest recycling site.
WARNING!
This symbol provides useful additional information on the use of
this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface gets hot and care must be
taken.
Introduction
This household Halogen Air Fryer cooks using very little or no cooking oil for
healthier cooking.
If a little oil is required for extra browning for example, use a moderate amount
of spray type cooking oil.
WARNING! DO NOT fill your Air Fryer with cooking oil as this will cause a
fire and scalding hazard.
DO NOT use metal cooking tools with this Air Fryer as damage may occur to the
Glass Bowl. Only use wooden or plastic (nylon) tools with your Air Fryer.
This designates a hazard with moderate risk, which may
result in severe injury if not adhered to.

7
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Using the Accessories
1
2
3
5
7
1. Safety Interlock Switch
(Underneath Handle)
2. Thermostat
3. Heat Indicator
4. Lid
5. Extension Ring
6. High Rack
7. Low Rack
8. Mesh Baskets x2
9. Lid Stand
10.Base (with Handles)
11.Glass Bowl
12.Tongs
13.Oil Spray Bottle
14.Power Indicator
15.Timer
6
8
9
10
11
12
13
14
15
Lid stand showing
how to store the lid.
Using the tongs to
pick up a rack.
Using the tongs to
pick up a basket.
4

8
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
NOTE: Always use the tongs provided to remove the basket or rack from the
Glass Bowl (11) and use the supplied Lid Stand (9) for supporting the lid during
and immediately after cooking.
DO NOT use any other accessories with this appliance for example trays, bowls
or aluminium foil linings.
Before the First Use of Your Air Fryer
•Remove all packing materials and discard responsibly.
•Ensure all parts are present see Description of Parts above.
•Check that there is no damage to the mains cable or product.
•Ensure that you clean your Air Fryer before first and every use, wash the bowl
and accessories in hot soapy water with a sponge or soft cloth, rinse and dry
thoroughly.
The Extension Ring (5) is supplied packed around the Glass Bowl (11) inside the
Base (10) during transit. Ensure that the Extension Ring (5) is removed from
the Base (10) before use –failure to remove the Extension Ring (5) from
around the Glass Bowl (11) may cause damage to the Air Fryer and void your
Warranty.
WARNING! DO NOT immerse the lid/motor assembly in water or any
other liquid.
NOTE: During initial use you may notice a slight odour due to the burning off of
manufacturing residues. This is completely normal and will disappear after a short
time.
IMPORTANT! This appliance has a Safety
Interlock Switch (1) built into the carrying handle
which will prevent the appliance operating unless
the lid handle is in the fully folded down
(horizontal) position as shown right:
The Extension Ring (5) is stored in
transit around the Glass Bowl (11) and
must be removed before use.
DO NOT remove the silicon band from
around the outside of the ring. The
Silicon band provides heat protection
whilst handling the Extension Ring (5).

9
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using your Air Fryer
The Thermostat (2)
The Thermostat (2) allows you to set the cooking
temperature from 65˚C to 250˚C. Rotate the control
clockwise to increase the cooking temperature and
anticlockwise to reduce the temperature.
The Timer (15)
The Timer (15) is marked in minutes, rotate the timer
clockwise to increase the cooking time and anticlockwise to
reduce the cooking time. Once the timer has been set to
the desired cooking time, it will count down until a bell
sounds at the end of the cooking time.
Hints and Tips for using your Halogen Air Fryer
1. It is recommended to Pre-heat the Halogen Air Fryer before use by rotating the
Thermostat (2) at maximum and setting the Timer (15) for 3 minutes.
2. Always place food on the Racks (6 & 7) to ensure good air circulation.
3. Leave at least 1cm gap between food items on the same rack, again this ensures
good air circulation.
4. Once food is cooked it can be kept hot by turning the Thermostat (2) to 150˚C
until it is ready to serve.
5. This appliance has a Safety Interlock Switch (1) built into the carrying handle
which will prevent the appliance operating unless the lid handle is in the fully
folded down (horizontal) position and it clicks.
6. Whilst roasting, line the bottom of the bowl with cooking foil to cook more
evenly and to ease cleaning.
Using Your Halogen Air Fryer
1.The outer surface of the Glass Bowl (11) will become very hot during
cooking, place the Glass Bowl (11) in its Base (10) and on a solid, level
heatproof surface clear of all obstructions as described above.
Danger Hot Surface!.
2.Place the High Rack (6) or Low Rack (7) [see the below table for the correct
rack height] into the Glass Bowl (11) and place food on the rack leaving space
between the pieces of food for good air circulation. Place the food at least 1cm
away from the side of the bowl, again for the best air circulation.
3.Use the 2 Mesh Baskets (8) to hold food that is too fine for the racks and place
the Mesh Baskets (8) onto the High Rack (6) or Low Rack (7) as desired.

10
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
4.Place the Lid (4) onto the Glass Bowl (11).
5.Ensure the handle is fully pushed down until the
Safety Interlock Switch (1) clicks as shown left:
6.Insert the mains plug into the nearest socket
outlet.
7.Rotate the Thermostat (2) clockwise to the desired
temperature using the reference table below.
8.Set the Timer (15) using the reference table below as a
guide. The green Heat Indicator (3) and red Power
Indicator (14) lights will glow indicating that cooking has
started as shown:
The green Heat Indicator (3) and the internal Halogen lamp will go on and off
during cooking –this is quite normal.
9.Once the Timer (15) has returned to the ‘off’position at the end of the cooking
time a bell will sound and unit will switch off.

11
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
10.Carefully remove the Lid (4) and place it onto the Lid Stand (9), remove the food
and using the Tongs (12), remove the Mesh Baskets (8) and place them onto a
heat resistant surface or trivet before serving. Food can be kept hot by turning
the Thermostat Dial down to 150˚C until ready to serve.
Increasing the Cooking Capacity of your Halogen Air Fryer
1. To cook larger foods (such as Turkey, a large joint of Meat, etc. the size/capacity
of the Air Fryer can be increased by placing the Extension Ring (5) on top of the
Glass Bowl (11) and then placing the Lid (4) on top of the Extension Ring (5) as
shown below:
4
5
10
11
Left: How the Extension Ring (5)
is used to increase the capacity
of the Halogen Air Fryer.

12
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Reference Table of Time and Temperature for Cooking
Food Type
Cooking Time
(minutes)
Temperature
Rack Position
Roast meat
Beef
16 mins per 1lb + 20 mins
180-1900C
Low rack
Lamb
16 mins per 1lb + 20 mins
180-1900C
Low rack
Pork
24 mins per 1lb + 20 mins
180-1900C
Low rack
Steak
Rare
3 mins each side
2500C
High rack
Medium
5 mins each side
2500C
High rack
Well done
7 mins each side
2500C
High rack
Other meats
Sausage
5-8 mins each side
2500C
High rack
Pork chop
6-8 mins each side
2500C
High rack
Lamb chop
6-8 mins each side
2500C
High rack
Chicken
35-40 mins
190-2000C
Low rack
Chicken portions
15-20 mins
190-2000C
Low rack
Cake
One layer
20-25 mins
2000C
Low rack
Loaf
35-40 mins
1500C
Low rack
Frying and roasting
Potatoes (roast,
small cut) (Par boil
for approx. 8 min,
depending on size)
25-40 mins
190-2100C
High rack (use with the
basket for smaller
cuts)
Homemade chips
(Par boil for approx.
8 mins depending
on size)
18-25 mins
180-2000C
High rack with basket
Frozen Chips
20-25 mins
180-2000C
High rack with basket

13
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking Tips
How to Roast
Place meat directly onto the wire rack.
Cooking time may vary depending on cut size and degree of cooking. Consult the
cooking guide provided.
How to Bake
Place food on a metal or ceramic baking pan of a diameter no more than 12”
(300mm) to leave enough room for air to circulate around the food being cooked.
Follow cooking guidelines on the table provided.
How to Fry/Roast
You can get the effect of deep frying without all the oil by spraying the food lightly
with oil. The food will need to be turned regularly during cooking.
Thawing Food
The Halogen Air Fryer will thaw most foods, simply place the food onto one of the
wire racks, set the thermostat to thaw and allow approximately 40 minutes per
kilogram. Large items such as meat joints should be turned at least once during
the thawing process.
NOTE: After thawing food in the Halogen Air Fryer always ensure to thoroughly
wash the bowl, racks, baskets and tongs etc. before re-using to prevent bacterial
cross-contamination.

14
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Recipes to get you Started
Rolled ribs Roast
4lbs rolled rib of beef
2 tablespoons red wine
2 tablespoons water
2 tablespoons flour
Salt and pepper
Trim excess fat from the meat, sprinkle with salt and pepper and rub in well. Place
meat in a greased baking dish and pour wine and water over the meat Marinade
for 4 hours
Place on the lower rack and cook for 1 hour at 160˚C
Turn the meat and cook at 175˚C for a further 40 minutes for rare, 50 minutes for
medium and 60 minutes for well done.
Serves 6.
Chinese roast Chicken
3lbs chicken breast/wings/drumsticks
½ cup of soy sauce
1 tablespoon of honey 1 teaspoon 5 spice
1 teaspoon crushed garlic
1 teaspoon finely grated ginger
1 tablespoon sesame oil
Marinade the chicken pieces in a mixture of all the other ingredients for at least 2
hours, turning the pieces occasionally.
Place chicken pieces on the lower rack and cook at 200˚C for
approximately 20 minutes, turning during cooking.
Serves 6.
Fillet steak Supreme
2lbs whole fillet steak Garlic, salt and pepper
½ cup of red wine
1 tablespoon cream or sour cream Rind of one lemon (grated)
Rind of one orange (grated)
1 large onion (chopped)
1 tablespoon chopped parsley 2 grated carrots
Marinade the fillet steak with garlic, salt, pepper and red wine in a
covered dish for 4 hours, basting and turning occasionally.

15
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Remove the steak from the marinade and wrap in cooking foil with the
carrot, lemon and orange rinds, onion and parsley.
Place on the lower rack and cook for 30 minutes at 190˚C then remove foil
and cook for a further 30 minutes.
Remove meat and keep warm, to remaining marinade add the cooked
onion, parsley and rinds and cook to reduce, add the cream and simmer for
1 minute, serve over sliced meat.
Jacket Potatoes
Medium sized washed potato (per person) Soft Butter
Garlic Salt
Ground black pepper
Wash and dry potatoes, removing any eyes/bruises etc. Rub a little butter
onto the potato and place on cooking foil. Sprinkle with salt, garlic and
pepper to taste.
Seal the potato in the cooking foil and place on the high rack. Cook for 45
minutes at 190˚C
Serve with Sour cream, cheese, beans etc.

16
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cleaning and Maintenance
•For light cleaning of the Glass Bowl, place approximately 3cm of water in the
bowl and add a squirt of washing liquid/mild detergent, place the lid/motor
assembly on the bowl and set the temperature dial to WASH and the timer to 10
mins, fully fold the handle down, the heater and turbo fan will operate to warm
the water and stir it, cleaning the bowl.
•At the end of the cycle remove the plug from the socket and place the lid on the
lid stand, empty rinse and dry the bowl.
•To clean the lid ensure that it is cool and use a damp cloth with a mild
detergent, NEVER IMMERSE THE LID/MOTOR ASSEMBLY IN WATER OR ANY
OTHER LIQUID.
•Always ensure the Halogen Air Fryer is unplugged and the timer is in the OFF
position before storing away.
•Ensure the halogen oven has cooled completely before storing.
WARNING !
1. NEVER PUT THE GLASS BOWL IN THE REFRIGERATOR AS THIS MAY CAUSE IT TO
CRACK.
2. NEVER USE THE GLASS BOWL FOR COOKING, OTHER THAN AS RECOMMENDED
BY THE MANUFACTURER AS LAID OUT IN THIS GUIDE.
3. NEITHER THE GLASS COOKING BOWL NOR THE ACCESSORIES ARE DISHWASHER
SAFE AND SHOULD BE CLEANED BY HAND WITH WARM SOAPY WATER.

17
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Unit does not power up.
No power to the Air
Fryer.
Check that the mains plug is
inserted into the socket and the
socket is switched on (if
applicable).
Fuse has blown in the
mains plug.
Check by substitution.
Food is cold
Thermostat Dial is set
too low.
Check cooking temperature
control dial and increase
accordingly.
Food is overcooked
Thermostat Dial is set
too high.
Check cooking temperature
control dial and decrease
accordingly.
Technical Specification
Rated Voltage
220-240V ~ AC 50/60Hz
Rated Power
1200-1400W
Model Number
SDA1032
Protection Class
I (This appliance must be earthed)

18
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Rewireable Mains Plug
If your appliance is supplied with a non-rewireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician who will be pleased to do this for you. If you need to remove the plug
–DISCONNECT FROM THE MAINS –and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into
a socket outlet as there is a danger of electric shock.
Recycling Information
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the Product
You should now recycle your waste electrical goods and in doing
so help the environment. This symbol means waste electrical
products at the end of their useful life should not be disposed of
with normal household waste. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk
enter your postcode to find your nearest recycling site.

19
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Notes

20
17 Litre Halogen Air Fryer
Model No. SDA1032
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in addition to your 1
year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
The product must becorrectly installed and operated in accordance with the
requirements contained in the instruction manual.
The product must beused solely for domestic purposes.
It does not cover general wear and tear, damage, misuse or any consumable parts.
The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at:
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS UK
EU Rep: EuroSonic Magppie (ESM) Ltd. Ireland D05 X006
www.esgltd.com
