1
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety
instructions. Failure to do so may result in personal injury or
damage to the product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions should
always be followed.
Only use the product as described in this user manual. Any other use is
considered improper and may result in damage to property or persons.
The manufacturer or vendor cannot be held liable for damages or injury
incurred through improper or incorrect use.
Read and familiarise yourself with all operating instructions before
using this deep fat fryer.
Before plugging your deep fat fryer into the mains, visually check that it
is intact and has not suffered any transit damage.
Check the voltage indicated on the data plate corresponds with that of
the local network before connecting the appliance to the mains power
supply.
DO NOT use this appliance with a programmer, timer, separate remote
control system or any other device.
DO NOT immerse this appliance in water or any other liquids.
Cooking appliances should be positioned in a stable location with the
handles if any positioned to avoid spillage of liquids.
This appliance shall not be used by children from 0-8 years. This
appliance can be used by children from 8 years if they are continuously
supervised. This appliance can be used by people with reduced
physical, sensory or mental capabilities or lack of experience or
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the
hazards involved. Keep the appliance and cord out of reach of children
less than 8 years. Cleaning and user maintenance shall not be made by
children.
DO NOT leave the appliance unattended during use.

3
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
DO NOT leave the appliance unattended whilst connected to the mains
supply.
Always use this appliance on a solid, level, heat resistant surface.
Always unplug the power cord after the appliance has been used,
before it is cleaned and whilst being repaired.
If the supply cord is damaged it must be replaced by the manufacturer,
it’s service agent or similarly qualified persons in order to avoid a
hazard.
DO NOT operate the appliance with a damaged plug or cord, after a
malfunction or after being dropped or damaged in any way.
Regular periodic checks should be carried out on the mains cable to
ensure no damage is evident. Should there be any signs of damage the
appliance should not be used.
DO NOT allow the mains cable to hang over sharp edges or come into
contact with hot surfaces.
DO NOT run the mains cable under carpets, rugs etc.
Allow the unit to cool before storage.
Never place the appliance near to flammable material or high pressure
containers.
This appliance is intended for household use only and should not be
used for industrial or commercial purposes.
DO NOT use this appliance for anything other than its intended use.
DO NOT push objects into any openings as damage to the appliance
and/or electric shock may occur.
Ensure the appliance is situated in an open area, do not allow it to
come into contact with cupboards, curtains, wall coverings, clothing or
other flammable materials.
Unplug after each use, grasp the plug not the cord.
Never place this appliance on an electric, gas or any other type of hob.
Never fill the fryer more than its capacity-ensure the oil level is
between the min and max marks
Always close the lid during use.
WARNING! Do not attempt to move the fryer whilst the oil is hot.
Only use cooking oil with this fryer.
CAUTION: The outside surface of this fryer will get hot
during use

4
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to
applicable provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not
be disposed of with normal household waste and not sent
to landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.
This symbol provides useful additional information on
the use of this product.
This symbol indicates that the supply uses an alternating
current mains supply.
This symbol indicates that the surface is gets hot and care
must be taken.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

5
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Description of Parts
Before the first time you use your Deep Fat Fryer
Remove all packing materials and discard responsibly.
Before using this fryer for the first time, carefully clean the Lid (1), oil reservoir
and frying basket with a soft clean cloth and soapy water and dry thoroughly
afterwards. Do not use harsh detergents, metal or nylon brushes/scourers as
these may damage the unit.
2
3
4
1
1. Lid with Filter
2. Display
3. Cooking Guides
4. Heat Indicator
5. Temperature Dial
5

6
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Instructions for Use
Place the fryer on a solid, level, non-flammable surface.
Attach the Handle to the Basket by squeezing the two lower arms and inserting
them into the two loops on the inside of the basket and pulling back until it locks
into place as in the image below:
Fill the Oil Reservoir with cooking oil to the desired level ensuring that the level
is above the MIN mark and below the MAX mark.
Insert the mains plug (with dry hands) into the mains socket.
The Display (2) will illuminate, showing ‘POWER’ to indicate the unit is
connected to the mains.
Rotate the Temperature Dial (5) clockwise to the required temperature
according to the type of food you wish to cook (refer to the table below).
The Heat Indicator (4) will now illuminate to show that the cooking oil is now
being heated.
Once the Heat Indicator (4) has gone out, the oil has reached the cooking
temperature and the Basket can now be slowly lowered into the cooking oil.
Care must be taken whilst lowering food into hot cooking oil to
avoid hot splashes of oil. The use of oven gloves is recommended.
Once the Basket has been lowered into the hot cooking oil, place the Lid (1)
down onto the fryer.
The Heat Indicator (4) will go on and off during the cooking process to show that
the oil temperature is being maintained to the set temperature – this is quite
normal.
After the cooking time has been completed, turn the Temperature Dial (5) anti
clockwise to the off position, the Heat Indicator (4) will go out and the Display
(2) will also go out. Remove the plug from the mains socket and allow contents
to cool.
Open the Lid (1), carefully lift the food basket and drain any excess oil from the
food before serving.

7
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking Timings, Temperatures and Quantity
Temperature °C
Food Product
Maximum basket Quantity
Cooking Time (Minutes)
Fresh or Defrosted
Deep Frozen
Fresh or Defrosted
Deep Frozen
160 °C
Home-made chips
(first frying cycle)
300g
--
4-5
--
170 °C
Fresh fish
250g
--
5-7
--
Chicken wings
3-4
3-4
12-15
15
Cheese croquettes
5
4
4-5
20
Small potato fritters
--
4
--
6-7
Fried vegetables
(mushrooms, cauliflower)
10-12
--
2-3
3-4
Home –made chips
(second frying cycle) max.175°C
300g
--
3-4
--
Deep Frozen Chips max.175°C
--
550g
--
5-6
180 °C
Spring rolls
3
2
6-7
10
Chicken nuggets
10-12
10
3-4
12
Mini snacks
10-12
10
3-4
4-5
Meat balls (small)
8-10
--
3-4
Fish fingers
8-10
8
3-4
4-5
Mussels
15-20
15
3-4
4-5
Coated squid rings
10-12
10
3-4
4-5
Fish in Batter
10-12
10
3-4
4-5
Shrimps
10-12
10
3-4
4-5
Apple Rings
5
--
3-4
4-5
190 °C
Potato chips
300g
300g
7-8
5-6
Aubergine slices
250g
--
3-4
--
Potato croquettes
4-5
4-5
7-8
10
Meat/Fish croquettes
4-5
4
4-5
6-7
Doughnuts
2-3
--
5-6
--
Baked
2-4
--
2-3
--
Camembert (breaded)
1
--
6-7
--
Cordon bleu
1
--
5-6
--
Cooking Tips
Use a maximum of 300g of French fries per 0.75 litres of oil.
Always shake off excessive ice from frozen products and allow to dry on a paper
towel before frying.
Always thoroughly dry potatoes after washing starch off them before frying to
avoid the oil spitting
Deep fry chips and French fries in two stages;
First stage (Pre frying): 5 to 10 minutes at 170˚C.
Second stage (Final frying) 2 to 4 minutes at 190˚C
Food containing too much water may cause the oil to spit and/or
overflow –danger of scalding!

8
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Safety thermal cut out
In the event of overheating, the built in thermal cut out will automatically switch
off the fryer.
This can occur if the fryer is not filled sufficiently with oil or the oil has solidified
around the element.
If the thermal trip has operated disconnect the appliance from the mains and
simply insert a small screw driver into the hole on the rear of the unit and press
the reset button to restore normal operation.
Cleaning your Deep Fat Fryer
Always disconnect the fryer from the mains power supply before cleaning.
Remove the element assembly before cleaning by grasping the rear of the
assembly and pulling upwards.
Do not clean any part of your fryer in a dishwasher.
Do not submerge any part of the element assembly, mains cable or main body
in water or any other liquids.
Wipe clean the outside of the main body and element assembly with a soft
damp cloth.
Wipe excess oil from the inner pan with kitchen roll or similar.
Wash the basket in warm soapy water and dry thoroughly afterwards.
Do not pour old cooking oil down the drain; it must be disposed of at a local
waste facility.
Never clean any part of the fryer with harsh or abrasive cleaners.
Replacing Cooking Oil
Ensure the fryer AND cooking oil have fully cooled before and
the fryer is unplugged from the mains socket before replacing the oil.
For best frying results the oil should be changed regularly or at least after every
10th use.
DO NOT mix old oil with new oil.
Discard old oil in an environmentally friendly way. Do not pour down the drain or
in the general waste bin.
Please discard using guidelines provided by your waste disposal service or local
government agency.
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug fitted to the mains lead and
should the fuse need replacing, you must use an ASTA approved one (conforming
to BS 1362 of the same rating). If in doubt, consult a qualified electrician who will
be pleased to do this for you. If you need to remove the plug –DISCONNECT
FROM THE MAINS –and then cut it off the mains lead and immediately dispose of
it safely. Never attempt to reuse the plug or insert it into a socket outlet as there is
a danger of electric shock.

9
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Technical Data
Rated Voltage
220-240V AC 50-60Hz
Rated Power
840W
Protection Class
I (This appliance must be earthed)
Model Number
SDA2324
Disposal of the Packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service
Disposal of the Product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and sent to landfill. Please ensure it is taken to a
suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or visit www.recycle-more.co.uk, enter
your postcode to find out your nearest recycling site.

10
1L Deep Fat Fryer
Model No. SDA2324
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
• The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
• Theproduct must be used solely for domestic purposes.
• It does not cover general wear and tear, damage, misuse or any consumable parts.
• The guarantee will berendered invalid if the product is re-sold or has been damaged through
inexpert repair.
• The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
https://help.daewooelectricals.com
or
Contact Us (daewooelectricals.com)
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by
ESG Ltd. Manchester M3 1JS
EU Rep: Euromagppie Ireland Ltd. D05 X006
www.esgltd.com
