Dakota Digital VHX-68D-STD User manual

Manual # 650663
VHX-68D-STD
Dakota Digital VHX Instrument Installation
For 1968-70 Dodge/Plymouth B-Body Non-Rallye
Your new VHX-68D-STD kit includes:
Installation
Installation Manuals
Control Box
36” CAT5 Cable
Universal Sender Pack
VHX Display
1. Remove the lower dash pad and switch panel and retain the hardware for reassembly.
Switch Assembly
(4) ½” Oval Head Screws
(3) ½” Pan Head Screws

Manual # 650663
2. Remove the factory gauge cluster from the dash; also remove the gauge cluster bezel from the
gauge cluster. Retain all factory hardware for reassembly.
4. Attach the provided CAT5 cable to the back of the VHX system and carefully route the open
end to the control box mounting location as you mount the VHX system to the dash.
3. Mount the factory gauge bezel to the VHX system by reusing the nine (9) screws that held it to
the factory gauge cluster.

Manual # 650663
6. Re-install the lower dash pad using the three (3) provided pan head screws. Then mount the switch
panel to the dash using the factory hardware from disassembly. Refer to the main manual for wiring
instructions to complete the VHX installation.
5. Mount the VHX system to the dash using the two (2) factory screws from disassembly for the
upper mounts and the provided four (4) oval head screws for the lower mounts.

Manual # 650663
