Dancover ST03810 User manual

21-05-2015
8m Series
TITANIUM TENT

Safety Advice
Attention
In some countries approval is needed to set up a marquee/tent larger than 75 m2. It
is your responsibility to comply with local rules and regulations and to ensure that
the marquee/tent is assembled correctly.
In case of bad weather conditions, it is your responsibility to ensure the
marquee/tent is safely secured and that the marquee/tent does not cause damage
to others.
close to the tent.
The marquee/tent must be safely secured. We recommend you secure your
marquee/tent with straps and pegs as soon as it is assembled.
Make sure to check if the marquee/tent is covered by your home contents insurance.
Marquees/tents must be evacuated under extreme weather conditions.
In the event of snow always remove snow from the roof of the marquee/tent
regularly to prevent snow from building on the roof as heavy snow can cause the
marquee/tent to collapse.
In the event of rain there is a risk of rain puddles building up on top of the roof of the
marquee/tent. Heavy rain puddles can cause the roof to collapse. It is your responsi-
bility to ensure rain puddles do not build up. As a precaution, make sure theroof of
the marquee/tent is stretched out properly and adequately over the side frames of
the marquee/tent and remove rain water regularly.
Please always check our website for the latest safety advice and manuall.

Assembly Illustration
For “User Friendly” assembly we have identied each
individual component with our part code number as
indicated in the part list.
Please refer to the part code numbers and drawings
to ensure problem free assembly.

Part list for 8m series Titanium
21-05-2015
Part No. Descrip on
1 Curved roof tube(top) at two ends &tube size:1341mm 2 2
2 Curved roof tube(top) in the middle &tube size:1341mm 4 8
3 Straight roof tube at two ends & tube size:1790mm 4 4
4 Straight roof tube in the middle & tube size:1790mm 8 16
5 Curved roof tube(side) at two ends & short tube size:751mm ,long tube:1320mm 4 4
6 Curved roof tube(side) in the middle & short tube size:751mm ,long tube:1320mm 8 16
7 Standing leg(in the middle) with base flange &tube size:2100mm 8 16
8 Standing leg(at two ends) with base flange &tube size:2100mm 4 4
9A-1 Upper standing leg in front panel &tube size:1920mm 2 2
9A-2 Upper standing leg in back panel &tube size:1920mm 2 2
9B Lower standing leg in front panel with base flange &tube size:2100mm 2 2
9C Lower standing leg in back panel with base flange &tube size:2100mm 2 2
10 Roof purlin and horizontal wall at both sides &tube size:1711.7mm 85 153
11A Horizontal tube(at two ends) in front and back panel & tube size:2144mm 12 12
11B Horizontal tube (in the middle )in front and back panel. &tube size:1725.50mm 8 8
12A Tensioning cross tubes in top roof &tube size:1727.50mm 12 16
12B Door dropping tube & tube size:1850mm 2 2
12C Steel rope (with rolling head) for fixing frame 12 12
13 Slant suppor ng tube &tube size:1952mm 8 8
14 Roof cover 1 1
15 Front cover 1 1
16 Back cover 1 1
17 Stake peg &dia:16x700mm 32 48
18 Rope for fixing cover
19 Bolt and nuts M14x30 224 404
M14x70 40 70
M12x50 28 28
M14x50 38 38
20 Inner joint for horizontal tube &tube size:178mm 9 9
21 Inner joint for part 11B and part 12. &tube size:400mm 2 2
Qty(pcs.)

21-05-2015
Part drawings for 8m series Titanium

Figure 2
Figure 3 Figure 4
8x16,2x3x5m8x9x3x5m

Illustration for installation and tensioning for both sides of the roof cover
Hint for tensioning front and rear
folds. Put the ropes in the roof
cover pocket through the rings
and pull hard the ropes. At the
same time tidy rumple on the fold
gradually. When the cover is well
on the folds tie a knot with the
ropes on the rings.
8x9x3x5 used for this illustration

Hint for tensioning cover to frame
Bothsides and top part of rear coverare tightenedto the frame byrope.
The bottom part of rear cover is fastened to the tensioning tube by rope.
M14x30mm bolt with nut
