TMG TMG-DT50FW8 User manual

►www.tmgindustrial.com 0/12 TOLL FREE: 1-877-761-2819

►www.tmgindustrial.com 1/12 TOLL FREE: 1-877-761-2819
MAIN SPECIFICATIONS :
Overall assembled size : W15.24 x H7.8 (m) / W50x H25.6 (ft)
Width : 15.24 m / 50ft
Height : 7.8 m / 25.6ft
Front door : 4.6x3.85 (m) / 15.1x12.6 (ft)
PRIOR TO ASSEMBLY
Please read the instructions carefully before installation. It is very important to follow your local safety regulations and
industry standards during installation. Regulations may include but are not limited to:
- Safety helmets, protective eyewear, and clothing
- Safety harnesses for all elevated workers
- Proper ladder, cage, and safety operation
Check all components and parts before installation. All parts are marked with a part number, please refer to the parts
list to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind. Do not make any alterations to the structure.
Do not hang any weights on the frame during installation, including parts. We are not responsible for any damages or
injuries caused by inappropriate installation, unauthorized modifications or extreme weather.
This building is not intended for human occupancy.
It is recommended to tape or add foam/rubber on the frame where joints connect and where it touches the cover. This
will help extend the life span of the cover.

►www.tmgindustrial.com 2/12 TOLL FREE: 1-877-761-2819
TMG-DT50FW8 PART LIST
NO.
DESCRIPTION
LENGTH
QTY
7
Baseplate
W150xL200mm
2
7A
Baseplate
W150xL200mm
2
7B
Baseplate of front door frame
W150xL200mm
2
8A
Side vertical tube
L2693mm
1
8B
Lower vertical tube
L2307mm
1
8C
Lower vertical tube
L2307mm
1
8D
Side vertical tube
L2693mm
1
9
Middle vertical tube
L1990mm
2
9B
Side door left tube
L2027mm
1
9C
Side door right tube
L2027mm
1
9D
Side door
W925xL2005mm
1
10B
Transverse tube
L2461mm
2
10C
Middle transverse tube
L2362mm
2
10D
Side door upper tube
L2369mm
1
10L
Front vertical door rail
(left side lower part)
L2625mm
1
10R
Front vertical door rail
(right side lower part)
L2625mm
1

►www.tmgindustrial.com 3/12 TOLL FREE: 1-877-761-2819
11L
Front vertical door rail
(left side upper part)
L1720mm
1
11R
Front vertical door rail
(right side upper part)
L1720mm
1
12A
Front roll up door dropping tubes (to
connect #12B)
L2356mm
7
12B
Front roll up door dropping tubes (to
connect #12A)
L2359mm
7
14A
Front door hand winch crossing tube
L2362mm
1
15
Bottom tension bar
L2310mm
3
15D
Bottom tension bar
L640mm
2
18
Tube clamps
φ58
6
18A
Front vertical door rail end plate (floatable
to keep door rail straight)
L220mm
2
18B
Right pulley system for front door
L150mm
1
18C
Left pulley system for front door
L150mm
1
18D
Front vertical door rail connection plate
L240mm
2
19
Tube end water plug
φ32
10
20
Braided rope
100m
1
22
Front truss fabric cover panel
W15.1xL8m
1
22B
Front roll up door cover panel
W4550xL4520mm
1
23A
Roll up door hand winch
(1200 lb)
1

►www.tmgindustrial.com 4/12 TOLL FREE: 1-877-761-2819
23B
Wire rope for front door hand winch
15m
1
24A
Front fabric tarp secure pin
L200m
1
25
Expansion bolts
φ16x150mm
16
25A
Pressing plate
L2000mm
6
25B
Pressing plate
L1000mm
1
27
Self locking bolt and nuts
M8x70mm
12
29
Hex bolt and nuts
M10x80mm
32
30
Hex bolt and nuts
M10x50mm
8
31
Hex bolt and nuts
M10x100mm
4
32
Tapping screw
#12x25mm
62

►www.tmgindustrial.com 5/12 TOLL FREE: 1-877-761-2819
STEP 1 : REVIEW THE WHOLE STRUCTURE AND CHOOSE THE PROPER INSTALLATION SITE.
Place the containers making sure they are parallel and the correct width apart the diagonal X and Y must be
equal. Baseplates must be bolted firmly with expansion bolts, It is concrete expansion bolt.
Installation diagram of expansion bolt.
NO.
PART
QTY
NO.
PART
QTY
7
2
7B
2
7A
2
25
12

►www.tmgindustrial.com 6/12 TOLL FREE: 1-877-761-2819
STEP 2 : FRONT TRUSS TO COMPLETE.

►www.tmgindustrial.com 7/12 TOLL FREE: 1-877-761-2819
NO.
PART
QTY
NO.
PART
QTY
8A
1
14A
1
8B
1
15
3
8C
1
15D
2
8D
1
18
6
9
2
18A
2
9B
1
18B
1
9C
1
18C
1
9D
1
18D
2
10B
2
19
10
10C
2
25
4
10D
1
27
12
10L
1
29
30
10R
1
30
8
11L
1
31
4
11R
1
32
10

►www.tmgindustrial.com 8/12 TOLL FREE: 1-877-761-2819
STEP 3 : INSTALL FRONT COVER PANEL.
Lift up (#22) cover panel, starting from the center point of the frame (highest ridge point) use ropes (#20)
through the grommets to tie the panel to the truss firmly. All grommets need to be tied to the frame as shown.
NO.
PART
QTY
ROPE SHEAR SIZE
22
1
20
Qty
A
15m
2
B
7m
7
C
4m
2
D
3m
2

►www.tmgindustrial.com 9/12 TOLL FREE: 1-877-761-2819
Install the front door metal strip.
NO.
PART
QTY
NO.
PART
QTY
25A
6
32
52
25B
1

►www.tmgindustrial.com 10/12 TOLL FREE: 1-877-761-2819
STEP 4 : INSTALL MECHANICAL ROLL UP DOORS.
Door curtain installation.
NO.
PART
QTY
NO.
PART
QTY
12B
7
22B
1
12A
7

►www.tmgindustrial.com 11/12 TOLL FREE: 1-877-761-2819
Front door installation, please look at the door from inside.
The hand winch (#23A) comes with a shorter cable, we call it cable (#B).
NO.
PART
QTY
ROPE SHEAR SIZE
23A
1
20
Qty
23B
1
E
7m
1
24A
1
29
2

►www.tmgindustrial.com 12/12 TOLL FREE: 1-877-761-2819
AFTER THE INSTALLATION
Walk around and inspect the shelter periodically to make sure all components are still firmly secured and the whole
shelter is well supported. Check all bolts and nuts as well as all connection points to make sure they are all in good
position. Check the base plates, adjust the ropes and tie downs if required and clean the cover regularly.
Snow accumulating on the fabric cover must be removed as soon as possible. If snow becomes solid ice on the cover, it
will increase the weight on the roof and may collapse the shelter or reduce the life span.
Keep the shelter on a dry ground most of the time. Do not keep the fabric dirt skirt under water all the time, otherwise
the fabric will deteriorate.
We strongly recommend you remove any snow from the roof immediately. Do not leave any snow load on the roof
overnight. Keep 3 feet of clearance on all sides at all times. Do not allow snow to accumulate and pile up on the sides of
the building. Otherwise the pressure from the sides will push inwards and could lead to a collapse.
