Dascom DP-540 User manual

DP-540 Quick Setup Guide
Use this guide to configure your new DP-540 printer prior to use.
* DP-540 printers may be operated directly from an external
power source without a battery present. If no battery is to be
used, battery charging may be skipped.
** Maximum battery capacity is reached only after completing
three complete charge and discharge cycles. Dascom
recommends completing three cycles before deploying your
printer for best results.
*** With media rolls of less than 4” width we recommend
addition of a second paper guide. See reverse for details.
More detailed instructions can be found in the Operator’s Manual, available at dascomamericas.com.
Setup utilities, printer drivers and the USB cable driver may be downloaded from dascomamericas.com
