Daymak Rickshaw User manual

Rickshaw Mobility Scooter
User Manual

2
Preface
Thank you for choosing Daymak’s Rickshaw mobility scooter. The Rickshaw is the latest
innovation in electric mobility providing absolute safety; for both its rider and the environment. In
the age of environmental conscience, the Rickshaw produces no pollution, no noise, and
requires nothing more than a household outlet to charge.
This product features a sleek design while maintaining safety standards that are required of
any mobility scooter. Its internal components have been designed to provide optimal
performance while maintaining high-efficiency. The Rickshaw also includes multiple features that
increase overall functionality, yet simple to manage. These include: lights, turn signals, an alarm
system, horn, an easily accessible charging port and much more.
In order to get the most out of your Rickshaw, please read the instructions before operation.

3
Safety and Operation
1. Safe Operation
- Please be careful while operating the Rickshaw: the motor is fairly strong so be cautious
while engaging the throttle.
- While wearing a helmet is not
- Please do not allow children to operate this machine.
required, it is still advised for safety precaution.
- While operable in bad weather conditions, please be cautious while driving in rain or
snow.
2. Driving
- The Rickshaw turns on simply by inserting the key into and then turning the ignition. You
will know it has turned on once the “POWER” signal on the dashboard lights up.
- This scooter is operated via a throttle. The motor will engage once the throttle is turned:
the more the throttle is engaged,the more the power is sent to the motors. Please turn the
throttle slowly before operation to allow yourself to get use to it. Pulling the throttle all the
way immediate may be dangerous.
- Reverse is available and is simple to operate: there is a red switch on the right handlebar
with the letters F (forward) and R (reverse) on it. While in reverse, the scooter will emit
consistent beeps indicating that the bike is set to reverse.
- Similar to the throttle, the brakes (located directly in front of both handles) function
according to pressure applied: the harder your press the brakes, the faster you will come
to a stop. This scooter features a function that will disable all motor function once brakes
are applied: the throttle will not
- The turn signals operate according tothe location of the switch: Left, Neutral, or Right. To
disengage the turn signal, simply return the switch tothe neutral position.
work so long as the brakes are held down.
- Your battery’s voltage is available on the dash: H (high) being full and L (low) being near
empty.
3. Extra Functions
- There is a button to operate the horn on the left handlebar, just under the turn signals.
- To turn on the lights, simply operate the switch on the right handlebar. High beam is also
available and can be adjusted on the left handlebar (just above the turn signal).
- The alarm can be armed while the scooter is turned off. Simply press the button below the
light switch on the right handle bar while the scooter is off and you should hear some
beeps indicating the alarm has been armed.

4
4. Special Note
- Since this is a battery operate vehicle, it is important to learn habits that can increase your
battery’s overall life and performance.
-If you are not using the scooter for long periods of time, please ensure that it is fully
charged at least once every half month.
- Please do not leave the scooter on charge for long period of time after it is fully charged.
Also, please try to use all the power of the scooter before charging the battery to increase
battery life.
Maintenance
Please ensure that the scooter is periodically maintained. Try to maintain a daily check to
ensure optimal functionality of your scooter.
oCheck that the head-lights and turn signals are functional.
oCheck that the brake works at a comfortable level.
oCheck the bolts on the wheels, brakes and seat is tight and secured.
oCheck for any loose parts on the scooter
oPeriodically apply grease (or lubricant) to the front and back axels and the brakes.

5
1. Plug (to scooter) 2. Indicator 3. Charge Indicator 4. Charger 5. Plug (to outlet)
1. Speedometer 2. Battery Indicator

6
Specifications
Model：Rickshaw
Dimensions(mm)：1740X450X1000
Battery Capacity：48V20AH
Input voltage of battery: 220V
Motor Power: 500W
Recharge time: 300
Charging period: 6-8 hours
Speed: 20-25km/h
Range:50km
Diameter of front wheel: 10"
NW: ≤40kg
