PRODUCT FEATURES
Formats -
PCM at 32, 44.1 or 48 kS/s.
dCS 902E only: PCM at 88.2 or 96 kS/s.
Data formats supported are: AES/EBU (XLR), SPDIF (RCA Phono), SPDIF
optical (Toslink) and SDIF-2 (BNC).
dCS 902E only: Dual AES (XLR)
Syncing -
Master mode or can sync to Word Clock or AES reference.
Sync to video option available
Functions -
Very high performance ADC, free from gain ranging
Multichannel Sync capability
Noise shaping truncation (1st, 3rd, 9th order)
Test Generator -
High quality (160 dB) tone generator. Can be noise shaped truncated.
dCS 902E only: Variable tone frequency and level.
Ease of Use -
Remembers last settings
Lockouts
Software upgrade-able without opening the box
