Decon wheel Rehatec Galileo MED3300 User manual

2020-04-27
Assembly instructions for Rehatec Galileo
MED3300
1. Remove wheels on both sides.
2. Remove sleeves and anti-tip devices from the wheelchair.
3. Check the correct placement for the stop pin and that the battery box is removed.

2020-04-27
4. Assembly the plate (right side) according to picture.
Parts pair mounting set for right side:
Item No. Part Number Qty Description
1 HW051 1 Sleeve M16X1
2 100 400 007 1 Spacer
3 100 400 014 1 Spacer
4 100 400 001 1 Spacer
5 405239 1 Nordlock M16 Washer
6 XSM8X40 1 Screw Round M8 x 40
7 XSM8ML 1 Nut Self-Locking M8
8 XSM8BR 1 Plain Washer M8
9 XSM16M 1 Nut M16 x1
10 XSM16FJ 1 Singel Coil Washer M16
11 MED2000 1 Bracket
12 100 400 017 1 Spacer
Back rested battery bag 1 Battery Bag
5. Assemble the back rested battery bag on the wheelchair.

2020-04-27
Attendant control with joystick (left and right side)
Item No. Part Number Qty Description
1 XOC-48110-A1 1 Joystick
2 MED1316 1 Plate with pin
3 XSM6X16 2 Screw M6 x 16
4 MC6SM6X35 1 Screw M6 x 35
5 XSM6BR 3 Plain Washer 6,4
6 XSM6ML 3 Locknut M6
7 MED1317 1 Bracket
8 Xklamma2 1 XClamp2
9 100 400 044 1 Spacer
Move this
too the
other side,
if you
assemble
the joystick
on the left
side.

2020-04-27
Alternative attendant control (only right side)
Item No. Part Number Qty Description
1 XSM6TG 1 Thorn Washer 6,4
2 Xklamma2 1 XClamp2
3 MC6SM6X20 1 Screw M6 x 20
4 XSM6BR 1 Plain Washer 6,4
5 MED1200 1 Attendant control

2020-04-27
Åtdragningsmoment / Tightening torque
Metriska grovgängor, stål.
Metric coarse threads, steel.
Gänga / Thread
Åtdragningsmoment / Tightening
torque
M3
1,2 Nm
M4
3 Nm
M5
6 Nm
M6
10 Nm
M8
25 Nm
M10
50 Nm
M12
85 Nm
Navhylsor.
Sleeves.
Gänga / Thread
Åtdragningsmoment / Tightening
torque
M16x1
30 Nm
M18x1
40 Nm
