Definox Sorio Basic 3EV User manual

NI-268 index 1 June 2021
Cam
INSTALLATION GUIDE Sorio® Basic 3EV control unit
www.definox.com
DEFINOX SAS
3 Rue des Papetiers - Z.A.C. de Tabari 2
44190 Clisson - France

:
[phone]

:
[phone]
E-Mail: [email protected]
 Recommendations
IMPORTANT
For any intervention or configuration change, see the
maintenance manual (NM-278) available on the website:
http://www.definox.com/
AIR QUALITY
•Dry and filtered air at 10µm (DIN ISO 8573-1)
•Operating pressure: 5 to 7 bars
ELECTRIC
M16 x 1.5 cable gland or M12 connector
Digital terminal block version:
•Operating voltage:
Digital 24 VDC only _ +/- 5%.
•Conductor section: 0.5mm² recommended and 0.75mm²
max.
•Ø cable : 4 to 10 mm.
IMPORTANT
For disassembly and handling of the unit, provide a minimum
clearance of 50 mm above the cover.
 Locking and unlocking the cover
Cover locked
Cover unlocked
•Turn the cover counterclockwise to bring the fin to the
stop, then remove the cover by pulling it up.
 Mounting the cam
•Screw the cam and tighten with a tool according to the table (tightening torque: ≥2N.m or 20Kgf.cm).
Reference
Cam
Visual
Tools
7162010
M6
A
Allen spanner 2.5
≥2 Nm
7162011
M8
A
Allen spanner 2.5
≥2 Nm
7162012
M10
B
Open
-
end spanner 17
7162013
M12
B
Open
-
end spanner 17
7162014
M16
B
Open
-
end spanner 17
7162138
M6 Female
C
Allen spanner 2.5
≥2 Nm
7162189
M5 Female
C
Allen spanner 2.5
≥2 Nm
 Assembling the actuator base
•Position the base by aligning the indexing pin to the 1/8
Gas hole.
• Screw in the two non-detachable CHC screws [A] to fix
the base on the actuator and tighten them (tightening
torque: ≥1N.m or 10Kgf.cm).
A
C
B
A
Indexing pin
1/8 Gas Hole

NI-268 index 1 June 2021
 Assembly Cable / Cable gland
•
Unscrew the nut [B] from the cable gland [C].
• Pass the connection cable inside the nut, then the cable gland to connect it to the terminal block [D].
• Tighten the nut [B].
• Connect the connections to the terminal block.

Reassembling the cover
•Position the cover in the notch on the base. Fin in the alignment above.
•Press the cover onto the base.
• Lock by turning the cover clockwise until the fins of the cover and the base are aligned.
 Pneumatic connexion on VEOX  Sorio® Basic 3EV unit 
EV1: Solenoid valve
EV2: Solenoid valve
EV3: Solenoid valve
1: Main actuator air inlet
2: Upper valve actuator air inlet
3: Lower valve actuator air inlet
E: Exhaust
P: Air pressure
ACT: Exhaust or air intake
•Apply pressure to the channel [P].
•Connect channel [1] of the main actuator to channel
[1] of the unit.
•Connect the channel [2] of the upper valve actuator to
the channel [2] of the unit.
•Connect channel [3] of the unit to channel [ACT] of
the unit for the bottom valve actuator.
•Put a pierced plug on the channel [E] of the unit.
EV2
EV1
3
2
EV3
P
ACT
E
1
B
D
Cover fin
Cover fin
Cover fin
Base fin
3
P
Pierced
plug
2
ACT
1
C
Sensor
High Position
Sensor
Low Position
Terminal
block 3EV
D
B
