Dell™3300MPProjectorUser'sGuide
Safety Instructions (Read before connecting the projector)
About Your Projector
Installation
Using Your Projector
Troubleshooting
Specifications
Regulatory Notices
Contacting Dell
Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your projector.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
Information in this document is subject to change without notice.
©2004 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP and Texas Instruments are trademarks of Texas Instruments
Corporation; Microsoft and Windows are registered trademarks of Microsoft Corporation; Macintosh is a registered trademark of Apple Computer, Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc.
disclaims any proprietary interest in trademarks and trade names other than its own.
Restrictions and Disclaimers
The information contained in this document, including all instructions, cautions, and regulatory approvals and certifications, is based upon statements
provided to Dell by the manufacturer and has not been independently verified or tested by Dell. Dell disclaims all liability in connection with any deficiencies
in such information.
All statements or claims regarding the properties, capabilities, speeds, or qualifications of the part referenced in this document are made by the
manufacturer and not by Dell. Dell specifically disclaims any knowledge of the accuracy, completeness, or substantiation for any such statements.
February2004Rev.A00
http://www.pureglare.com.au

Back to Contents Page
AboutYourProjector:Dell™3300MPProjector
Features
Equipment
Main Unit
Control Panel
Connection Ports
Remote Control

Features

Singlechip0.7"TexasInstrumentsDLP™technology
High contrast, double data rate (DDR) digital micro mirror device
True XGA (1024 x 768) native resolution
3.99 lbs (1.81 kg) lightweight compact design
1600 ANSI lumens brightness (Max)
1700:1 full on / full off contrast ratio
1.2x manual zoom lens
Built in 2W speaker
Auto image re-sizing (Auto-Sync) to 1024x 768 full screen with scaling compression compatibility for SXGA+, SXGA, XGA, SVGA,
VGA, MAC
Great connectivity -- Multiple PC and High Definition inputs (via M1-DA and RGB), S-Video, Composite Video (RCA), Component Video
Preset and user defined video modes for optimum video and graphic settings
LCD display for real time projector status
Self-diagnostic for video troubleshooting
State-of-the-art motion adaptive hardware de-interlacing with 3:2 and 2:2 pull down
180-watt user-replaceable P-VIP 3000-hour lamp
Eco Mode allows end user to extend lamp life to 5000 hours by reducing the lamp wattage and brightness.
Compatibility with Macintosh®computers
Compatibility with NTSC, NTSC4.43, PAL, PAL-M, PAL-N, SECAM, and HDTV (1080i, 720p, 576i/p, 480i/p)
High-definition TV compatibility
User-friendly, multi-language on-screen display (OSD)
Advanced auto vertical electronic keystone correction
Remote projector control from PC via RS232 port
User-friendly control panel with backlight buttons
Drop tested carrying case included
Plug and play for photo image display from the option for memory card reader (Memory card module sold separately)
Equipment
Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell if anything is missing.

Main unit
3.0m Power cord
1.8m M1-A to D-sub/USB cable
2.0m S-video cable
1.8m M1-A to HDTV cable
1.8m Composite Video cable
http://www.pureglare.com.au

Batteries (2)
1.8m RCA to Audio cable
1.8m 1/8" Mini Phone Jack cable
Remote control

Dell 3300MP Projector
User's Guide
Dell 3300MP Projector Quick Start
Card
Warranty Guide
Owner's Manual
Carrying case
Main Unit

1
Control panel
2
LCD status display
3
Zoom tab
4
Focus ring
5
Lens
6
IR Remote control receiver
7
Elevator button
Control Panel
http://www.pureglare.com.au


1
Power button
2
Source
3
Keystone adjustment
4
Re-sync
5
Four directional keys
6
Keystone adjustment
7
Menu
8
Lamp warning light
9
Temperature warning light
Connection Ports




1
Kensington lock hole
2
RS232 connector
3
Audio input connector
4
Composite video connector
5
S-video connector
6
M1-DA connector
7
VGA Out (monitor loop-through)
8
IR Receiver
Remote Control
http://www.pureglare.com.au


1
Light
11
Directional Pad
2
Power button
12
R-sync button
3
PU button (page up)
13
Source button
4
Laser pointer
14
PD button (page down)
5
Hide button
15
Keystone correction
6
Mute button
16
Color Mode button
7
Volume+-button
17
Menu button
8
Freeze button
18
4:3/16:9 (aspect ratio) button
9
Normal button
19
Slide Show button
10
Preview button
20
Rotate button
CAUTION: The remote control has a Class II laser that emits radiation. To reduce the risk of injury to the eyes, do
not look directly into the laser light on the remote control and do not point the laser light into anyone's eyes.
Battery Disposal: Your projector remote control uses zinc-manganese batteries. If you need to replace the batteries, see your Dell 3300MP
Projector Quick Start Card.
Do not dispose of used batteries along with household waste. Contact your local waste disposal agency for the address of the nearest battery
deposit site.
Back to Contents Page
http://www.pureglare.com.au

Back to Contents Page
Contacting Dell
To contact Dell electronically, you can access the following websites:
lwww.dell.com
lsupport.dell.com (technical support)
lpremiersupport.dell.com (technical support for educational, government, healthcare, and medium/large business customers, including Premier,
Platinum, and Gold customers)
For specific web address for your country, find the appropriate country section in the table below.
NOTE: Toll-free numbers are for use within the country for which they are listed.
When you need to contact Dell, use the electronic addresses, telephone numbers, and codes provided in the following table. If you need assistance in
determining which codes to use, contact a local or an international operator.


Country (City) International Access
Code Country Code City Code
Department Name or Service Area, Website and E-mail
Address
Area
Code
Local Numbers,and Toll-
Free Numbers
Anguilla
General Support
toll free:800-335-0031
Antigua and Barbuda
General Support
1-800-805-5924
Argentina (Buenos Aires)
International Access Code:00
Country Code:54
City Code:11
Technical Support and Customer Care
toll free: 0800 444 0733
Sales
toll free: 0810 444 3355
Tech Support Fax
11
4515-7139
Customer Care Fax
11
4515-7138
Website: www.dell.com.ar
toll-free:800-1578
Aruba
General Support

Australia (Sydney)
International Access Code:0011
Country Code:61
City Code:2
E-mail (Australia): [email protected]

E-mail (New Zealand): [email protected]

Home and Small Business
1-300-65-55-33
Government and Business
toll free: 1-800-633-559
Preferred Accounts Division (PAD)
toll free: 1-800-060-889
Customer Care
toll free: 1-800-819-339
Corporate Sales
toll free: 1-800-808-385
Transaction Sales
toll free: 1-800-808-312
Fax
toll free: 1-800-818-341
Austria (Vienna)
International Access Code:900
Country Code:43
City Code:1
Switchboard
01
491 040
Home/Small Business Sales
01
795676-02
Home/Small Business Fax
01
795676-05
Home/Small Business Customer Care
01
795676-03
Preferred Accounts/Corporate Customer Care
0660-8056
Home/Small Business Technical Support
01
795676-04
Preferred Accounts/Corporate Technical Support
0660-8779
Website: support.euro.dell.com

E-mail: [email protected]

Bahamas
General Support
toll-free:1-866-278-6818
Barbados
General Support
1-800-534-3142
Belgium (Brussels)
International Access Code:00
Country Code:32
City Code:2
Technical Support
02
481 92 88
Customer Care
02
481 91 19
Home/Small Business Sales
toll free: 0800 16884
Corporate Sales
02
481 91 00
Fax
02
481 92 99
http://www.pureglare.com.au

Switchboard
02
481 91 00
Website: support.euro.dell.com

E-mail: [email protected]

E-mail for French Speaking Customers:
support.euro.dell.com/be/fr/emaildell/

Bermuda
General Support
1-800-890-0748
Bolivia
General Support
toll free: 800-10-0238
Brazil
International Access Code:00
Country Code:55
City Code:51
Customer Support, Technical Support
toll free: 0800 90 3355
Technical Support Fax
51
481-5470
Customer Care Fax
51
481-5480
Sales
toll free: 0800 90 3390
Website: www.dell.com/br

British Virgin Islands
General Support
toll-free:1-866-278-6820
Brunei
Country Code:673
General Support
604
633 4966
Customer Service (Penang, Malaysia)
604
633 4949
Transaction Sales (Penang, Malaysia)
604
633 4955
Canada (North York, Ontario)
International Access Code:011
Automated Order-Status System
toll free: 1-800-433-9014
AutoTech (Automated technical support)
toll free: 1-800-247-9362
Customer Care Home & Home Office & Small Business
1-800-847-4096
Customer Care Medium, Large, Commercial, Government (100+
Employees)
1-800-326-9463
Technical Support Home & Home Office & Small Business
1-800-847-4096
Technical Support Medium, Large, Commercial, Government (100+
Employees)
1-800-387-5757
Sales (direct-from outside Toronto)
1-800-387-5752
Sales (direct-from within Toronto)
416-758-2200
Sales (federal government, education, and medical)
1-800-567-7542
Tech Fax
toll free: 1-800-950-1329
Cayman Islands
General Support
1-800-805-7541
Chile (Santiago)
Country Code:56
City Code:2
Sales, Customer Support, and Technical Support
toll free: 1230-020-4823
China (Xiamen)
Country Code:86
City Code:592
Tech Support website: support.ap.dell.com/china

Tech Support E-mail: [email protected]

Tech Support Fax
818-1350
Projector Technical Support Phone
toll free: 800 858 2920
Customer Experience
toll free: 800 858 2060
Home and Small Business
toll free: 800 858 2222
Preferred Accounts Division
toll free: 800 858 2062
Large Corporate Accounts North
toll free: 800 858 2999
Large Corporate Accounts North Government and Education
toll free: 800 858 2955
Large Corporate Accounts East
toll free: 800 858 2020
Large Corporate Accounts East Government and Education
toll free: 800 858 2669
Large Corporate Accounts Queue Team
toll free: 800 858 2572
Large Corporate Accounts South
toll free: 800 858 2355
Large Corporate Accounts West
toll free: 800 858 2811
Large Corporate Accounts GCP
toll free: 800 858 2055
Large Corporate Account Key Accounts
toll-free:800-858-2628
Large Corporate Accounts Spare Parts

toll free: 800-858--2621
Colombia
General Support

980-9-15-3978
http://www.pureglare.com.au

Costa Rica
General Support

0800-012-0435
Czech Republic (Prague)
International Access Code:00
Country Code:420
City Code:2
Technical Support
02
22 83 27 27
Customer Care
02
22 83 27 11
Fax
02
22 83 27 14
TechFax
02
22 83 27 28
Switchboard
02
22 83 27 11
Website: support.euro.dell.com


E-mail: [email protected]


Denmark (Horsholm)
International Access Code:00
Country Code:45
Technical Support

70230182
Customer Care(Relational)

70230184
Home/Small Business Customer Care

32875505
Switchboard (Relational)

32871200
Fax Switchboard (Relational)

32871201
Switchboard (Home/Small Business)

32875000
Fax Switchboard (Home/Small Business)

32875001
Website: support.euro.dell.com


E-mail Support (portable computers): [email protected]


E-mail Support (desktop computers): [email protected]


E-mail Support (servers): [email protected]


Dominica
General Support

toll free: 1-866-278-6821
Dominican Republic
General Support

toll free: 1-800-156-1588
Ecuador
General Support

toll-free 999-119
El Salvador
General Support

01-889-753-0777
Finland (Helsinki)
International Access Code:990
Country Code:358
City Code:9
Technical Support
09
253 313 60
Technical Support Fax
09
253 313 81
Relational Customer Care
09
253 313 38
Home/Small Business Customer Care
09
693 791 94
Fax
09
253 313 99
Switchboard
09
253 313 00
Website: support.euro.dell.com


E-mail: [email protected]


France (Paris) (Montpellier)
International Access Code:00
Country Code:33
City Code:(1)(4)
Home and Small Business


Technical Support
0825
387 270
Customer Care
0825
823 833
Switchboard
0825
004700
Switchboard (calls from outside of France)
04
99 75 40 00
Sales
0825
004 700
Fax (calls from outside of France)
04
99 75 40 001
Website: support.euro.dell.com

E-mail: support.euro.dell.com/fr/fr/emaildell/

Corporate

Technical Support
0825
004 719
Customer Care
0825
338 339
Fax
01
55 94 71 01
Switchboard
01
55 94 71 00
Sales
01
55 94 71 00
Germany (Langen) International
Access Code:00 Country Code:49
Technical Support
06103
766-7200
Home/Small Business Customer Care

0180-5-224 400
Global Segment Customer Care
06103
766-9570
Preferred Accounts Customer Care
06103
766-9420
Large Accounts Customer Care
06103
766-9560
Public Accounts Customer Care
06103
766-9555
http://www.pureglare.com.au

Switchboard
06103
766-7000
Website: support.euro.dell.com


E-mail: [email protected]


Grenada
General Support

toll free:1-866-540-3355
Guatemala
General Support

1-800-999-0136
Guyana
General Support

toll free:1-877-440-6511
Hong Kong
International Access Code:001
Country Code:852
TechnicalSupport(Dimension™andInspiron™)

296-93188
TechnicalSupport(OptiPlex™,Latitude™,andDellPrecision™)

296-93191
Customer Service (non-technical, post-sales issues)

800-93-8291
Transaction Sales

toll free: 800 96 4109
Large Corporate Accounts HK

toll free: 800 96 4108
Large Corporate Accounts GCP HK

toll free: 800 90 3708
India
Technical Support

1600-33-8045
Sales

1600-33-8044
Ireland (Cherrywood)
International Access Code:16
Country Code:353
Ireland Technical Support
1850
543 543
UK Technical Support (dial within UK only)
1870
908 0800
Home User Customer Care
01
204 4095
Small Business Customer Care
01
204 4444
Corporate Customer Care
01
204 4003
UK Customer Care (dial number within UK only)
0870
906 0010
Ireland Sales
01
204 4444
UK Sales (dial within UK only)
0870
907 4000
Sales Fax
01
204 0144
Fax
01
204 5960
Switchboard
01
204 4444
Website: support.euro.dell.com


E-mail: [email protected]


Italy (Milan)
International Access Code:00
Country Code:39
City Code:2
Home and Small Business


Technical Support
02
577 826 90
Customer Care
02
696 821 14
Fax
02
696 821 13
Switchboard
02
696 821 12
Website: support.euro.dell.com


E-mail: support.euro.dell.com/it/it/emaildell/


Corporate


Technical Support
02
577 826 90
Customer Care
02
577 825 55
Fax
02
577 035 30
Switchboard
02
577 821
Website: support.euro.dell.com


E-mail: support.euro.dell.com/it/it/emaildell/


Jamaica
General Support (dial from within Jamaica only)

1-800-404-9205
Japan (Kawasaki)
International Access Code:001
Country Code:81
Web site: support.jp.dell.com


Technical Support
44
toll free: 0120-981-690
Technical Support Outside of Japan
44
556-3468
Customer Care
44
556-4240
Korea (Seoul)
International Access Code:001
Country Code:82
City Code:2
Technical Support

toll free: 080-200-3800
Sales

toll free: 080-200-3600
Customer Service (Penang, Malaysia)

toll free: 604-633-4949
Customer Service (Seoul, Korea)

080-200-3800
Fax

2194-6202
http://www.pureglare.com.au

Switchboard

2194-6000
Latin America
Customer Technical Support (Austin, Texas, U.S.A.)
512
728-4093
Customer Service (Austin, Texas, U.S.A.)
512
728-3619
Fax (Technical Support and Customer Service) (Austin, Texas,
U.S.A.)
512
728-3883
Sales (Austin, Texas, U.S.A.)
512
728-4397
Sales Fax (Austin, Texas, U.S.A.)
512
728-4600 or 728-3772
Luxembourg International Access
Code:00 Country Code:352
Technical Support (Brussels, Belgium)
02
481 92 88
Home/Small Business Sales (Brussels, Belgium)
toll free: 080016884
Corporate Sales (Brussels, Belgium)
02
481 91 00
Customer Care (Brussels, Belgium)
02
481 91 19
Switchboard (Brussels, Belgium)
02
481 91 00
Fax (Brussels, Belgium)
02
481 92 99
Website: support.euro.dell.com


E-mail: [email protected]


Macao
Country Code:853
Technical Support

toll free: 0800 582
Customer Service (Penang, Malaysia)

604 633 4949
Transaction Sales

toll free: 0800 581
Malaysia (Penang)
International Access Code:00
Country Code:60
City Code: 4
Technical Support

toll free: 1 800 888 298
Customer Service
4
633 4949
Transaction Sales

toll free: 1 800 888 202
Corporate Sales

toll free: 1 800 888 213
Mexico
International Access Code:00
Country Code:52
Customer Technical Support

001-877-384-8979 or 001-
877-269-3383
Sales

50-81-8800 or 01-800-888-
3355
Customer Service

001-877-384-8979 or 001-
877-269-3383
Main

50-81-8800 or 01-800-888-
3355
Montserrat
General Support

toll free:1-866-278-6822
Netherlands Antilles
General Support

001-800-882-1519
Netherlands (Amsterdam)
International Access Code:00
Country Code:31
City Code:20
Technical Support
20
674 4500
Home/Small and Medium Business
20
674 5500
Home/Small and Medium Business Fax
20
674 4775
Home/Small and Medium Business Customer Care
20
674 4200
Corporate
20
674 5000
Corporate Fax
20
674 4779
Corporate Customer Care
20
674 4325
Website: support.euro.dell.com

E-mail: support.euro.dell.com/nl/nl/emaildell/

New Zealand
E-mail (New Zealand): [email protected]


E-mail (Australia): [email protected]


Home and Small Business

0800 446 255
Government and Business

0800 444 617
Sales

0800 441 567
Fax

0800 441 566
Nicaragua
General Support

001-800-220-1006
Norway (Lysaker)
International Access Code:00
Technical Support

671 16882
Relational Customer Care

671 17514
Home/Small Business Customer Care

231 62298
http://www.pureglare.com.au
