DVP02TK-S / DVP02TU-S
Temperature Control Module Manual
Chapter 1 Introduction
1.1 Specification......................................................................................1-3
1.2 Dimensions (mm)..............................................................................1-7
1.2.1 DVP02TU-S.................................................................................. 1-7
1.2.2 DVP02TK-S.................................................................................. 1-8
1.3 Installation........................................................................................1-9
1.4 Terminal arrangement.......................................................................1-9
1.5 Wiring Diagram ...............................................................................1-10
1.6 LED Indicator Description................................................................1-13
1.7 RS-485 Communication for DVP02TK-S Series ................................1-13
Chapter 2 Control Register
2.1 Control Registers...............................................................................2-2
2.1.1 List of the Control Registers ........................................................... 2-2
2.1.2 Basic Setup Page.......................................................................... 2-3
2.1.3 PID Setup Page ............................................................................ 2-6
2.1.4 Program Control Setup Page........................................................... 2-8
2.1.5 Pattern0, 1 Setup Page.................................................................. 2-8
2.1.6 Pattern2, 3 Setup Page.................................................................. 2-9
2.1.7 Pattern4, 5 Setup Page................................................................ 2-10
2.1.8 Pattern6, 7 Setup Page................................................................ 2-11
2.2 Analog Input Description.................................................................2-12
2.3 Outputs ...........................................................................................2-13
2.3.1 The output value varies with the PV value. ..................................... 2-13
2.3.2 Alarm Outputs............................................................................ 2-13
2.4 ON/OFF Control Mode......................................................................2-15
2.5 PID Control Mode ............................................................................2-16
2.6 Programmable SV Control Mode ......................................................2-20
2.7 ERROR LED Indicator.......................................................................2-20

1-1
1
Chapter 1 Introduction
Table of Contents
1.1 Specification......................................................................................1-3
1.2 Dimensions (mm)..............................................................................1-7
1.2.1 DVP02TU-S..................................................................................1-7
1.2.2 DVP02TK-S.................................................................................. 1-8
1.3 Installation........................................................................................1-9
1.4 Terminal arrangement.......................................................................1-9
1.5 Wiring Diagram ...............................................................................1-10
1.6 LED Indicator Description................................................................1-13
1.7 RS-485 Communication for DVP02TK-S Series ................................1-13

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-2
_
1
Thank you for using Delta DVP02TK-S/DVP02TU-S Temperature Control Module. To ensure a successful installation and
for safety reasons, please read this manual carefully before operating.
This manual contains important safety instructions.
Cette notice contient des instructions importantes concernant la sécurité.
Disconnect all sources of supply before servicing.
Couper toutes les sources d’alimentation avant de faire l’entretien et les réparations.
For use in a controlled environment. Refer to manual for environmental conditions.
Pour utilisation en atmosphère contrôlée. Consulter la notice technique.
Warning: proper ventilation is required to reduce the risk of hazardous or explosive gas buildup during indoor charging.
Avertissement : une ventilation adéquate est nécessaire afin de réduire les risques d’accumulation de gaz dangereux
ou explosifs durant la recharge à l’intérieur.
The analog input circuits shall not be connected to MAINS CIRCUIT for measuring or sensing and limited to SELV
circuit only.
The supply voltage and transistor (analog) outputs are SELV circuit and limited energy.
This is an OPEN TYPE module and therefore should be installed in an enclosure free of airborne dust, humidity, electric
shock and vibration. The enclosure should prevent non-maintenance staff from operating the device (e.g. key or
specific tools are required for operating the enclosure) in case danger and damage on the device may occur. Do not
touch any terminal when the power is on.
This manual provides you with the introductions on the specifications, installation, basic operations, setups and
temperature measurements.
Read this manual carefully and follow the instructions to avoid danger and damage to people and property.
DVP02TK-S series includes DVP02TKR-S, DVP02TKN-S and DVP02TKL-S. DVP02TU-S series includes
DVP02TUR-S, DVP02TUN-S and DVP02TUL-S.

Chapter 1 Introduction
1-3
1
_
1.1 Specification
DVP02TK-S/DVP02TU-S
Supply voltage 24VDC
Max. rated power
consumption 2.4W, supplied by external power source in compliance with UL61010-2-201 \ IEC61131-2
Connector Type European standard removable terminal block (Pin pitch: 3.5mm)
Operation/storage
temperature
Operation: 0°C ~ 55°C (temperature), 5 ~ 95% (humidity), Pollution degree: 2
Storage: -25°C ~ 70°C (temperature), 5 ~ 95% (humidity),Attitude: up to 2000m;
For use in dry location only
Vibration/Shock
resistance International standards: IEC 61131-2, IEC 68-2-6 (TEST Fc) / IEC 61131-2 & IEC 68-2-27 (TEST Ea)
Connection to
DVP-PLC The modules are numbered from 0 to 7 automatically by their distance from DVP-PLC. Max. 8 modules are allowed to connect to DVP-PLC and will not occupy any digital I/O points.
I/O points 2 points of universals analog inputs (CH1, CH2), 2 analog outputs (OUT1, OUT2) or 4 digital
outputs (OUT1~OUT4)
General Analog Input
Input CH1,
CH2
Thermal resistance: Pt100, JPt100, Pt1000, Ni100, Ni1000, Cu50, Cu100, GNi1000
Thermocouple : J, K, R, S, T, E, N, B, U, L, TXK (L), C, PL II
Voltage input: 0~+50mV, 0~+5V, 0~+10V
Current input: 0mA~+20mA, 4~+20 mA
Hardware Resolution 16 bits
Distance 100 meters
Input disconnection
detection Supported by exceeded temperature input range
Analog / Digital Output
Analog OUT1~
OUT2 Analog output, 12-bit: 0~+10V, 0/4~+20mA
Digital OUT1~
OUT4
4 channels digital output, 250VAC, 60Hz/24VDC, 2A, Relay
4 channels digital output, Voltage pulse output, 24VDC, 300mA
A/D Function Specification
Analog / Digital Voltage Input
Maximum rated input 0V~10V 0V~5V
Overall accuracy
(normal temperature) 0.5%
Overall accuracy
(full temperature range) 1%
Hardware resolution 16 bits

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-4
_
1
Input impedance 650KΩ
Analog / Digital Current Input
Maximum rated input 0mA~20mA 4mA~20mA
Overall accuracy
(normal temperature) 0.5%
Overall accuracy
(full temperature range) 1%
Hardware resolution 16 bits
Input impedance 249Ω
Analog / Digital Temperature Input
Maximum rated input Thermocouple Thermistor
Overall accuracy
(normal temperature) 0.4%
Overall accuracy
(full temperature range) 0.8%
Hardware resolution 24 bits
Input impedance 2MΩ
Analog sampling time (by channel)
Analog input type AI Thermocouple Thermistor Quick AI (0~10V)*2
Setting time (ms) 80 80 160 3
Conversion time (ms) 50 50 100 2
Response time (ms) 130 130 260 5
Response time = setting time + conversion time
*1. Compared to the response time of the thermocouple temperature, it needs two times of time for the thermistor
temperature to respond, since the thermistor channels require a temperature compensation.
*2. Since there is only one channel used, the time to stabilize the circuit is not required.

Chapter 1 Introduction
1-5
1
_
DVP02TKL-S/DVP02TUL-S D/A Function Specification
Analog / Digital Voltage Output
Maximum rated input 0V~10V
Overall accuracy
(normal temperature) 0.5%
Overall accuracy
(full temperature range) 1%
Hardware resolution 12 bits
Allowable load impedance 1kΩ~ 2MΩat 0V~10V
Analog / Digital Current Output
Maximum rated output 0mA~20mA 4mA~20mA
Overall accuracy
(normal temperature) 0.5%
Overall accuracy
(full temperature range)
(average number of 100
times)
1%
Hardware resolution 12 bits
Allowable load impedance ≦550Ω
Analog setup time (by channel)
Analog output type Voltage Current
Setting time (µs) 100 250
Conversion time (µs) 500 500
Response time (µs) 600 750
Response time = setting time + conversion time

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-6
_
1
DVP02TKR-S/DVP02TUR-S/DVP02TKN-S/DVP02TUN-S DO Function Specification
Model
Item
DVP02TKR-S
DVP02TUR-S
DVP02TKN-S
DVP02TUN-S
Output points 4 4
Connector Type Removable terminal block
Output point type Relay-R Transistor-T (NPN)
Voltage specification Below 250VAC, 30VDC 12~30VDC
Maximum load Resistive 2A/1point
(3A/COM)*1
0.3A/1 point
(0.6A/COM)*1
Inductive Life curves*2, 4 7.2W (24VDC)*3
Maximum output
frequency
Resistive 1Hz 100Hz
Inductive 0.5Hz 0.5Hz
Lamp 1Hz 10Hz
Maximum
response time
OFF→ON 10ms 0.5ms
ON→OFF
*1. Complied with UL61010-2-201 & IEC61131-2(AC or DC resistance)
*2. Complied with UL61010-2-201 & IEC61131-2 (AC/DC general-use or AC pilot duty)
Rated making capacity: 7.5A; rated breaking capacity: 0.75A; 2.5A thermal continuous at 240VAC
DC pilot duty; rated making capacity: 0.22A; rated breaking capacity: 0.22A; 1A thermal continuous at 30VDC
*3. Complied with IEC/UL61010-2-201 (DC general-use)
*4. Life curves
Disconnect power before servicing to avoid the risk of electric shock.
Utilisez relay est sous tension. Risque de choc électrique, couper le courant avant l’entretien.
Contact Current(A)
20
0.5
0.1 0.2
30
50
0.3 0.7 1 2
200
300
500
100
1000
2000
3000
Operation(X10)
3
120VAC Resistive
30VDC Inductive(t=7ms)
240VAC Inductive(cos 0.4) ψ =
120VAC Inductive(cos =0.4) ψ
30VDC
Inductive
(t=40ms)

Chapter 1 Introduction
1-7
1
_
1.2 Dimensions (mm)
1.2.1DVP02TU-S
8
DVP-02TU
1
2
3
4
6
5
7
3.40
60.00
90.00
25.20 60.00 3.00
3.00
3.00
Description
1 Run/Error indicator
2 Model name
3 Removable terminal block
4 I/O terminal layout
5 I/O module clip
6 I/O module connection port
7 Label
8 DIN rail clip

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-8
_
1
1.2.2DVP02TK-S
8
1
2
3
4
6
7
3.40
60.00
90.00
25.20 60.00 3.00
3.00
3.00
5
9
10 11
Description
1 Run/Error indicator
2 Model name
3 Removable terminal block
4 I/O terminal layout
5 Run/Stop switch
6 I/O module clip
7 I/O module connection port
8 Label
9 DIN rail clip
10 Power connection port
11 RS-485 communication port

Chapter 1 Introduction
1-9
1
_
1.3 Installation
Users can connect DVP02TU-S series modules to the right side of the DVP02TK-S series modules as the image shown
below. Up to DVP02TU-S can be connected.
DV
P
0
2
T
U
-
S
DVP02TK-S
1.4 Terminal arrangement
DVP02TKR-S/DVP02TKN-S
DVP02TUR-S/DVP02TUN-S DVP02TKL-S/DVP02TUL-S
CH1
CH2
L+
I+
．
．
OUT1
L-
I-
L+
I+
L-
I-
SLD
OUT2
C0
．
OUT3
OUT4
C1
L+
I+
．
．
VO
L-
I-
L+
I+
L-
I-
SLD
IO
AG
．
VO
IO
AG
CH1
CH2
OUT1
OUT2
Warning: DO NOT connect wires to the terminals with No Connection (marked by a dot symbol ).

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-10
_
1
Mounting Arrangements and Wiring Notes
Please install PLC in an enclosure with sufficient space around it to allow heat dissipation as shown in the figure.
DVP
MP
D
D
DD
D > 50 mm
Warning: shock hazard. Only for mounting in a rack or enclosure fully enclosing all live parts.
Avertissement : risque d’électrocution. Ne doit être installé que dans un bâti ou un boîtier recouvrant entièrement toutes
les pièces sous tension.
1.5 Wiring Diagram
22-16AWG
<1.5mm
1. Use 22-16AWG (1.5mm) single or multiple core wire on I/O wiring terminals. The specification of the terminal is
shown in the figure above. The PLC terminal screws shall be tightened to 1.95 kg-cm (1.7 in-lbs).
2. DO NOT place the I/O signal wires and power supply wire in the same wiring duct.
3. Warning: use conductors with insulation rated for at least 75 °c
Avertissement : employer des conducteurs pour au moins 75 °c.
4. For use with copper conductors only (excluding thermocouplers).
destiné à être utilisé avec des conducteurs en cuivre seulement (sauf thermocouples).
How to install DIN rail
DVP-PLC can be secured to a cabinet by using the DIN rail of 35mm in height and
7.5mm in depth. When mounting PLC to DIN rail, be sure to use the end bracket to
stop any side-to-side movement of PLC and reduce the chance of wires being
loosen. A small retaining clip is at the bottom of PLC. To secure PLC to DIN rail,
place the clip onto the rail and gently push it up. To remove it, pull the retaining clip
down and gently remove PLC from DIN rail, as shown in the figure.

Chapter 1 Introduction
1-11
1
_
Sensor input wiring
CurrentOutput
AG
ADC
AG
INA
Shielded
cable*1 CH1 L+
L-
I-
SLD
2-Wire
I+
SLD
3-Wire
L+
L-
I-
I+
Pt100/JPt100
/Pt1000 CH2
Ni100/Ni1000/
LG-Ni1000/Cu50/Cu100
Pt100/JPt100/Pt1000
Shielded
cable*1
Voltage/Current input wiring
AG
ADC
AG
INA
CH1
CH2
0mV~50mV,
0V~+5V,
0V~+10V
+
-
L+
L-
I-
SLD
I+
0mA~+20mA,
4mA~+20mA
+
-
L+
L-
I-
SLD
I+
Current Output
Shielded
cable*1

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
1-12
_
1
Thermocouple input wiring
AG
ADC
INA
+
-
L+
L-
I-
SLD
I+
Thermocouple Current Output
DVP02TKN-S/DVP02TUN-S Output point wiring
2
4VDC
+
D: 1N4001
Diode or equivalent component
D
OUT1
C0
OUT2
D
OUT3
C1
OUT4
2
4VDC
+
D: 1N4001
Diode or equivalent component
DVP02TKR-S/DVP02TUR-S Output point wiring
OUT3
C1
OUT4
240VAC
OUT3
C1
OUT4
24VDC

Chapter 1 Introduction
1-13
1
_
DVP02TKL-S/DVP02TUL-S Output point wiring
OUT2
AG
OUT1
AG
CH1
CH2
VO
IO
AG
0V~+10V
VO
IO
AG
0mA~+20mA,
4mA~+20mA
RS-485 Wiring
D+ D- SG D+ D- SG SG D+ D-
Mast
e
rSlave Slave
Terminal
impedaance
(120 ohm)
Shielded
c
abl
e
*
1
Shielded
c
abl
e
*
1
1.6 LED Indicator Description
LED Indicator LED Color Description
POWER Green Power status
A/D Green Operating status
ERROR Red Error display
OUT1~OUT4 Red Output status
1.7 RS-485 Communication for DVP02TK-S Series
Data Transmission
Speed 9,600; 19,200; 38,400; 57,600; 115,200bps
Communication
Format Stop bit: 1, 2 Parity bit: None, Odd, Even Data bit: 7, 8
Communication
Protocool MODBUS ASCII/RTU

2-1
2
Chapter 2 Control Register
Table of Contents
2.1 Control Registers...................................................................... 2-2
2.1.1 MODBUS Address List for DVP02TK-S Series ................................2-2
2.1.2 MODBUS Hex Address List for DVP02TK-S Series ..........................2-2
2.1.3 List of the Control Registers.......................................................2-3
2.1.4 Basic Setup Page......................................................................2-5
2.1.5 PID Setup Page........................................................................2-9
2.1.6 Program Control Setup Page .................................................... 2-11
2.1.7 Pattern0, 1 Setup Page ........................................................... 2-12
2.1.8 Pattern2, 3 Setup Page ........................................................... 2-13
2.1.9 Pattern4, 5 Setup Page ........................................................... 2-15
2.1.10 Pattern6, 7 Setup Page......................................................... 2-16
2.2 Analog Input Description........................................................ 2-17
2.3 Outputs .................................................................................. 2-19
2.3.1 The output value varies with the PV value.................................. 2-19
2.3.2 Alarm Outputs ....................................................................... 2-19
2.4 ON/OFF Control Mode............................................................. 2-21
2.5 PID Control Mode ................................................................... 2-22
2.6Programmable SV Control Mode ............................................. 2-24
2.7 ERROR LED Indicator.............................................................. 2-25
2.8 RS-485 Communication Setup for DVP02TK-S ........................ 2-25
2.8.1 MODBUS Communication Protocol............................................. 2-25
2.8.2 Restore to Factory Settings...................................................... 2-25
2.8.3 RS-485 Communication Setup.................................................. 2-25
2.9 TK Wizard – Connection Setup................................................ 2-28
2.9.1 Restore to Factory Settings for DVP02TK-S ................................ 2-28
2.9.2 COMMGR Set Up .................................................................... 2-28
2.9.3 Settings in TKSoft .................................................................. 2-28
2.9.4 TKSoft – Scan the Connected Devices ....................................... 2-29

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-2
_2
2.1 Control Registers
2.1.1 MODBUS Address List for DVP02TK-S Series
MODBUS Address Description
H0000 TK series, CR#0: starting address
H1000 The 1st module on the right side of TK series, CR#0: starting address
H2000 The 2nd module on the right side of TK series, CR#0: starting address
H3000 The 3rd module on the right side of TK series, CR#0: starting address
H4000 The 4th module on the right side of TK series, CR#0: starting address
H5000 The 5th module on the right side of TK series, CR#0: starting address
H6000 The 6th module on the right side of TK series, CR#0: starting address
H7000 The 7th module on the right side of TK series, CR#0: starting address
H8000 The 8th module on the right side of TK series, CR#0: starting address
2.1.2 MODBUS Hex Address List for DVP02TK-S Series
Address
(Hex) Attribute Name Description Default
0F00 R X
Number of connected
extension modules
Detecting number of the extension modules
connected to the right side of the TK series --
0F01 R X Code of the 1st module
Code of the 1st module on the right side of
TK series --
0F02 R X Code of the 2nd module
Code of the 2nd module on the right side of
TK series --
0F03 R X Code of the 3rd module Code of the 3
rd
module on the right side of
TK series --
0F04 R X Code of the 4th module
Code of the 4th module on the right side of
TK series --
0F05 R X Code of the 5th module
Code of the 5th module on the right side of
TK series --
0F06 R X Code of the 6th module
Code of the 6th module on the right side of
TK series
--
0F07 R X Code of the 7th module
Code of the 7th module on the right side of
TK series --
0F08 R X Code of the 8th module
Code of the 8th module on the right side of
TK series
--
0F09 R/W O RS-485 communication setup
Refer to sections for setting up the RS-485
communication mode K0
0F0A R/W X Reserved
0F0B R/W O RS-485 communication format 0：ASCII / 1：RTU K0
0F0C R/W O TK station number TK station number setup K1
0F0D R/W X TK operation 0：Stop / 1：Run --

Chapter 2 Control Register
2-3
2_
2.1.3 List of the Control Registers
TU
CR#
TK
Add.
(Hex) Attribute Name Description Default
#0 000 R O Model
By default, users can see the model name in the
program and determine whether there is any
extension module.
DVP02TUL-S: H014F
DVP02TUN-S: H024F
DVP02TUR-S: H034F
DVP02TKL-S: H044F
DVP02TKN-S: H054F
DVP02TKR-S: H064F
--
#1 001 R O Firmware version Hexadecimal, displaying the current firmware version, for example the current firmware is 1.02 and
it will display H’0102. --
#2 002 R O CH1 PV Channel current value --
#3 003 R O CH2 PV
#4 004 R/W O CH1 SV setups Channel target value K0
#5 005 R/W O CH2 SV setups
#6 006 R/W X CH1
setups to
run/stop an operation K0: stop
K1: run
K2: pause (programmable) K0
#7 007 R/W X
CH2 setups to
run/stop an operation
#8 008 R/W X CH1 Auto tuning K0: Auto control mode
K1: Auto adjust mode, after adjusting it will switch to
the auto control mode and input the most suitable
parameters, e.g., Kc_Kp, Ti_Ki, Td_Kd and Tf.
K0
#9 009 R/W X CH2 Auto tuning
#10 00A R/W X
Setups to switch
pages
CR#11~CR#42: Definitions may vary according to
different setups on the specific page.
K0: Basic setup page for CH1
K1: PID setup page for CH1
K2: Program control setup page for CH1
K3: Pattern 0, 1 setup page for CH1
K4: Pattern 2, 3 setup page for CH1
K5: Pattern 4, 5 setup page for CH1
K6: Pattern 6, 7 setup page for CH1
K10: Basic setup page for CH2
K11: PID setup page for CH2
K12: Program control setup page for CH2
K13: Pattern 0, 1 setup page for CH2
K14: Pattern 2, 3 setup page for CH2
K15: Pattern 4, 5 setup page for CH2
K0

DVP02TK-S/DVP02TU-S Temperature Control Module Manual
2-4
_2
TU
CR#
TK
Add.
(Hex) Attribute Name Description Default
K16: Pattern 6, 7 setup page for CH2
#11~
#42 -- R/W X
According to each
setup page Please refer to each setup page. K0
-- 00B R/W -- Page0 Basic setup page for CH1 --
-- 02B R/W -- Page1 PID setup page for CH1 --
-- 04B R/W -- Page2 Program control setup page for CH1 --
-- 06B R/W O Page3 Pattern 0, 1 setup page for CH1 --
-- 08B R/W O Page4 Pattern 2, 3 setup page for CH1 --
-- 0AB R/W O Page5 Pattern 4, 5 setup page for CH1 --
-- 0CB R/W O Page6 Pattern 6, 7 setup page for CH1 --
-- 0EB R/W O Page10 Basic setup page for CH2 --
-- 10B R/W O Page11 PID setup page for CH2 --
-- 12B R/W O Page12 Program control setup page for CH2 --
-- 14B R/W O Page13 Pattern 0, 1 setup page for CH2 --
-- 16B R/W O Page14 Pattern 2, 3 setup page for CH2 --
-- 18B R/W O Page15 Pattern 4, 5 setup page for CH2 --
-- 1AB R/W O Page16 Pattern 6, 7 setup page for CH2 --
#43 24B X Error code Please refer to error code descriptions. K0
#45 24D R/W X User-defined
0x0501: Restore to defaults
0x0502: Settings written on flash
0x0504: RS-485 mode and latched
(parameter/mode/station number)
0x51CC: Manually export
0x51DD：Auto export
(the PID will be invalid after switching to manually
export mode.)
CR control can be set up by the analog output of
DVP02TUL-S/DVP02TKL-S and the digital output of
/DVP02TUN-S/DVP02TKR-S/DVP02TKN-S.
DVP02TUL-S/DVP02TKL-S：
CR#4: CH1 analog output value range K0~K4000
CR#5: CH2 analog output value range K0~K4000
DVP02TUR-S/DVP02TUN-S/DVP02TKR-S/DVP02
TKN-S：
CR#4 (bit0/bit1): CH1 digital output Y0/Y1
CR#5 (bit0/bit1): CH2 digital output Y2/Y3
K0
#46 24ER O CH1 display value The display value is the measured value after being
rounded off or the value set to be displayed for the
channels.
#47 24FR O CH2 display value
Symbols: O: Latched. X: Non-latched.

Chapter 2 Control Register
2-5
2_
TU
CR#
TK
Add.
(Hex) Attribute Name Description Default
R: Able to read data by FROM instruction. W: Able to write data by TO instruction.
Error Code 1 0
Bit0 Power Supply abnormal Abnormal Normal
Bit1 Hardware abnormal Abnormal Normal
Bit2 CH1 conversion error Abnormal Normal
Bit3 CH2 conversion error Abnormal Normal
Bit4 CH1 circuit control abnormal Abnormal Normal
Bit5 CH2 circuit control abnormal Abnormal Normal
Bit6 Manually / Auto Output Manually Output Auto Output
Bit7-15 Reserved
2.1.4 Basic Setup Page
TU
CR#
TK CH1
Page0
Add. (Hex)
TK CH2
Page10
Add. (Hex) Attribute Name Description Default
#11 00B 0EB R/W O Sensor type
K-1: Channel closed
K0: 0 ~ 5V
K1: 0~10V
K2: 0 ~ 20mA
K3: 4 ~ 20mA
K4: 0 ~ 50mV
K5: Pt100
K6: JPt100
K7: Pt1000
K8: J
K9: K
K10: R
K11: S
K12: T
K13: E
K14: N
K15: B
K16: L
K17: U
K18: TXK
K19: C
K20: PL II
K0
