Denon DN-350MP User manual

User Guide English ( 3 – 10 )
Guía del usuario Español ( 11 – 18 )
Guide d’utilisation Français ( 19 – 26 )
Guida per l’uso Italiano ( 27 – 34 )
Benutzerhandbuch Deutsch ( 35 – 42 )
A
ppendix English ( 43 )

2

3
User Guide (English)
Introduction
Box Contents
DN-350MP
Remote Bluetooth Antenna
Remote Control
Rack Ears (2)
Euroblock Connector
Power Cable
User Guide
Safety & Warranty Manual
Support
For the latest information about this product (documentation, technical
specifications, system requirements, compatibility information, etc.) and product
registration, visit denonpro.com.
For additional product support, visit denonpro.com/support.

4
Features
Front Panel
1. Power Button: Push to turn the power on and off.
2. Smartphone Shelf: Store your smartphone here.
3. Aux In: Connect an optional device to this input using a 1/8” (3.5mm) TRS
cable. See Operation > Playing Audio from an External Device for more
information.
4. USB Flash Drive Port: Connect a USB flash drive to this port. Also, connect a
smartphone or tablet here to charge it.
5. USB Charging Port: Connect a smartphone or tablet here to charge it (5V,
2.1A).
6. Display: This screen indicates the unit’s current operation. See Display for
more information.
7. Bluetooth Pairing: Press and hold this button for 3 seconds to put the unit in
pairing mode. Press and hold this button to disconnect from a paired Bluetooth
device.
8. Media: Press this button to change between USB, Bluetooth, and Aux input
modes.
9. Previous Track/Search Backward: In USB mode, press and release this
button to go to the previous track. Hold this button to quickly rewind through a
track. After holding the button over 200ms, the search speed increases to 16x
normal speed.
10. Track Advance/Search Forward: In USB mode, press and release this button
to go to the next track. Hold this button to quickly fast-forward through a track.
After holding the button over 200ms, the search speed increases to 16x normal
speed.
11. Stop: In USB mode, press this button to stop playback.
12. Play/Pause: In USB and Bluetooth modes, press this button to play or pause.
13. Select Knob: Rotate this knob to select between options in the menu or the
tracks stored on the USB flash drive. Press the knob to select the current
highlighted option.
14. Menu: Press this button to go into the menu on the display.
1
2
3
4
5
6
7
1
2
78 9
10
10
11
11
12
12
13
13
6
4 5 3
14
14

5
Rear Panel
1. Bluetooth BNC Connector: Connect the detachable remote antenna here for
Bluetooth signal reception.
2. RCA Output: These outputs send the audio signals from a paired Bluetooth
device, CD, USB flash drive, and a device connected to the Aux In. Use RCA
cables to connect these outputs to a sound system, external speakers, etc.
3. XLR Balanced Output: These outputs send the audio signals from a
Bluetooth-paired device, USB flash drive, and device connected to the Aux In.
Use XLR cables to connect these outputs to a sound system, external
speakers, etc.
4. Amp Level: Adjust this knob to control the output level of the amplifer.
5. Amplifier On/Off: Adjust this switch to turn the amplifier on or off.
6. Amplifier Output: Connect the included Euroblock to the applicable amp
output: 4 Ohm, 70V, and 100V.
7. AC Input: Connect the included power cable here.
1
2
789
10 11 12 13
6
45314
1
2
34
5
6
7
