Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro Table of Contents
6607290 D3673.201.01.03.02 3
Table of Contents
1Before you begin … ........................................................................................ 7
1.1 Structure of the document ............................................................................................. 9
1.2 Service life..................................................................................................................... 12
1.3 Trade names / registered trade marks of the manufacturers ........................................ 13
2Safety information........................................................................................... 14
3Technical description ...................................................................................... 17
3.1 Task............................................................................................................................... 17
3.2 Structure of Midwest Stylus® Plus ................................................................................ 18
3.3 Structure of Midwest® Phoenix ™ / Pro........................................................................ 19
3.4 Technical data ............................................................................................................... 20
3.5 Available high-speed handpiece connection types ....................................................... 26
6607290.book Seite 3 Mittwoch, 13. September 2017 9:53 09

Table of Contents Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
46607290 D3673.201.01.03.02
3.6 Product labeling............................................................................................................. 28
4Preparation ..................................................................................................... 30
4.1 Initial start-up and longer breaks in use ........................................................................ 30
4.2 Prior to starting the work day......................................................................................... 30
4.3 Before each patient ....................................................................................................... 31
5Operation ........................................................................................................ 32
5.1 Connecting the Dentsply Sirona quick coupling to the supply hose.............................. 34
5.2 Replacing the high-speed handpiece ............................................................................ 35
5.3 Inserting and removing burs.......................................................................................... 38
5.4 Adjusting the cooling spray ........................................................................................... 40
6Follow-up ........................................................................................................ 41
6.1 After each treatment session......................................................................................... 41
6607290.book Seite 4 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro Table of Contents
6607290 D3673.201.01.03.02 5
6.2 At the end of the work day............................................................................................. 42
7Conditioning.................................................................................................... 43
7.1 Conduct pre-disinfection................................................................................................ 43
7.2 Automated cleaning and disinfecting............................................................................. 44
7.3 Manual cleaning and disinfection .................................................................................. 46
7.4 Manual maintenance ..................................................................................................... 48
7.5 Sterilizing....................................................................................................................... 54
8Maintenance ................................................................................................... 57
8.1 Testing the FG clamping system................................................................................... 57
8.2 Servicing Dentsply Sirona quick coupling ..................................................................... 59
8.3 Servicing Midwest® quick coupling ............................................................................... 64
6607290.book Seite 5 Mittwoch, 13. September 2017 9:53 09

Table of Contents Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
66607290 D3673.201.01.03.02
9Spare parts and consumables ........................................................................ 66
10 Storage and transport conditions.................................................................... 70
11 Disposal .......................................................................................................... 71
6607290.book Seite 6 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro 1Before you begin …
6607290 D3673.201.01.03.02 7
1Before you begin …
The Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro high-speed
handpiece corresponds with the provisions of state-of-the-art
technology. The Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro high-
speed handpiece complies with the ISO 14457 standard. The Midwest
Stylus® Plus / Midwest® Phoenix ™ high-speed handpiece complies
with the ISO 9168 standard.
The units, the product is connected to, must comply with the
requirements of IEC 60601-1.
1. Read the operating instructions before using the Midwest Stylus®
Plus / Midwest® Phoenix ™ /Pro high-speed handpiece.
2. Use the Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro high-
speed handpiece only for the purposes described in the operating
instructions.
6607290.book Seite 7 Mittwoch, 13. September 2017 9:53 09

1Before you begin … Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
86607290 D3673.201.01.03.02
3. Follow the hygiene regulations, work safety regulations, and
accident prevention measures that apply to the Midwest Stylus®
Plus / Midwest® Phoenix ™ /Pro high-speed handpiece.
Intended use The high-speed handpieces of the Midwest Stylus® Plus / Midwest®
Phoenix ™ /Pro High-Speed Handpiece family are intended for:
● Preparation of cavities and crowns
● Removal of carious material
● Removal of fillings
● Processing of tooth and restoration surfaces
● Reducing hard tooth structure
Contraindications None
Target group This product is intended only for use by trained dental personnel in
dental practices and laboratories.
6607290.book Seite 8 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro 1Before you begin …
6607290 D3673.201.01.03.02 9
Scope of validity of operating instructions High-speed handpiece Midwest_High-speed handpiece Terminology These operating instructions are applicable for the following high-speed
handpieces:
Midwest Stylu Plus / Phoenix™/Pro = T2 mini
● Midwest Stylus® Plus
●Midwest
® Phoenix ™
●Midwest
® Phoenix ™ Pro
1.1 Structure of the document
1.1.1 Labeling of information
Warnings ➢ To prevent injuries, please observe the warnings.
Warnings are labeled as follows:
DANGER! indicates a danger leading to death or serious injury if not
avoided.
WARNING! indicates a danger that may lead to death or serious
injury if not avoided.
6607290.book Seite 9 Mittwoch, 13. September 2017 9:53 09

1Before you begin … Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
10 6607290 D3673.201.01.03.02
CAUTION! indicates a danger that may lead to injury if not avoided.
Instructions for use ➢ To prevent material damage and additional expenses, please
observe all instructions for use.
Instructions for use are labeled as follows:
NOTICE! indicates measures for the prevention of material damage.
IMPORTANT: indicates information on the avoidance of additional
expenses and other important information.
Tip: indicates information for facilitating work.
6607290.book Seite 10 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro 1Before you begin …
6607290 D3673.201.01.03.02 11
1.1.2 Formats and symbols
The formats and symbols used in this document have the following
meaning:
✔ Prerequisite
1. First action step
2. Second action step
or ➢Alternative action
Result
➢Individual action step
Requests you to do something.
Use of formats and symbols [ →
11].
Identifies a reference to another
text passage and specifies its
page number.
● List Identifies a list.
6607290.book Seite 11 Mittwoch, 13. September 2017 9:53 09

1Before you begin … Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
12 6607290 D3673.201.01.03.02
1.2 Service life
When used as intended:
● Non-moving parts have a typical service life of 5 years
● Moving parts have a typical service life of 3 years
No warranty claim can be inferred here, as wear may occur earlier or
later than indicated above depending on use, frequency of sterilization,
and frequency of maintenance.
Replacing elastomers
Elastomers, e.g. O-rings, must be replaced depending on their degree
of wear.
Werkzeughaltesystem_High-speed handpiece
Check the clamping system of friction grip burs on a monthly basis [ →
57].
6607290.book Seite 12 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro 1Before you begin …
6607290 D3673.201.01.03.02 13
1.3 Trade names / registered trade marks of the
manufacturers
The designations used in this operating instruction with reference to the
instruments are trade names or registered trade names of the
manufacturers:
KaVo, Biberach, Germany:
● MULTIflex LUX.
NSK, Tochigi-ken, Japan:
● MachLite
6607290.book Seite 13 Mittwoch, 13. September 2017 9:53 09

2Safety information Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
14 6607290 D3673.201.01.03.02
2Safety information
Obligations of the user ● Use only fault-free materials that do not deviate from the specified
data [ → 20].
● Protect yourself, patients, and others against any foreseeable
dangers. To do this, follow the safety information.
● Comply with the Intended use of the equipment.
● You should always keep these operating instructions within reach for
further reference.
Preventing the spread of infections and cross
contamination
Sterilization
Prevent the spread of infections and cross contamination between
patients, users, and third parties. Sterilize equipment after each patient.
Take the appropriate hygiene measures, e.g. wear protective gloves.
Prevention of eye damage The LED is in risk class 2 according to the IEC 62471:2006 standard.
The LED emits optical radiation that is potentially hazardous and may
be harmful to the eyes! Potential damage to the retina from the blue light
emission. Do not stare at the LED for longer periods of time while in
operation.
6607290.book Seite 14 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro 2Safety information
6607290 D3673.201.01.03.02 15
Malfunction or damage Discontinue use immediately in case of malfunction, unusual or different
sounds or damage. Damaged high-speed handpieces may cause
injury. Notify the dental depot or the manufacturer.
Potential explosion hazard Do not use this product in areas subject to explosion hazards.
Repair Do not attempt to repair the high-speed handpiece yourself.
The replacement of bearings can lead to sudden failures and injuries to
patients due to the different levels of wear of the newer and older
components. Safe operation is not guaranteed when repairs are
performed incorrectly. For repairs, contact the dental dealer or the
manufacturer.
Spare and accessory parts Use only original Midwest parts or parts approved by Midwest. Safe
operation is not guaranteed for parts that have not been approved by
Midwest.
6607290.book Seite 15 Mittwoch, 13. September 2017 9:53 09

2Safety information Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
16 6607290 D3673.201.01.03.02
First aid measures in the case of lubricant
accidents
T1 Spray _ Hersteller Homepage
For details download the Midwest® Plus Aerosol Spray Material Safety
Data Sheet from the Midwest homepage: www.dentsplysirona.com
If you have any questions, please contact your dental depot or the
manufacturer.
General information: Immediately remove any clothing soiled
by the product.
After inhalation: Supply fresh air; consult doctor in case of
complaints.
After skin contact: If skin irritation continues, consult a
doctor.
After eye contact: Rinse opened eye for several minutes
under running water.
After swallowing: If symptoms persist consult doctor.
6607290.book Seite 16 Mittwoch, 13. September 2017 9:53 09

Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro 3Technical description
6607290 D3673.201.01.03.02 17
3Technical description
3.1 Task
The Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro high-speed
handpiece is used to power dental instruments with an FG shank.
The quick coupling is used for media supply and connection to the
supply hose and features convenient swivel.
6607290.book Seite 17 Mittwoch, 13. September 2017 9:53 09

3Technical description Operating Instructions Midwest Stylus® Plus / Midwest® Phoenix ™ /Pro
18 6607290 D3673.201.01.03.02
3.2 Structure of Midwest Stylus® Plus
F
E
D
C
B
A
A High-speed handpiece head
B Push button
C Cooling spray outlet
D Opening of chuck system
E Light aperture
F Handpiece sleeve
6607290.book Seite 18 Mittwoch, 13. September 2017 9:53 09
