Denver MCI-101 User manual

MP3/CD/Radio
Micro System with iPhone Docking
I N S T R U C T I O N M A N U A L
MCI-101

WARNING
1. WARNING：Please refer the information on exterior bottom enclosure for electrical and safety
information before installing or operating the apparatus.
2. WARNING：To reduce the risk of fire or electric shock, do not exposethis apparatus to rain or
3. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat
such as sunshine, fire or the like.
4. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain
readily operable.
5. Invisible laser radiation when open and interlocks defeated. Avoid exposure to beam of laser.
6. Correct Disposal of this product. This marking indicates that this product should not be disposed
with other household wastes throughout the EU. To prevent possible harm tothe environment or
human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To return your used device, please use the return and collection systems
or contact the retailer where the product was purchased. They can take this product for environmental
safe recycling.
7. No naked flame sources, such as lighted candles, should be placed on the apparatus.
8. Attention should be drawn to environmental aspects of battery disposal.
9. Use of the apparatus in moderate climates.
10. The rating and marking information are located at the bottom of the unit.
11. Excessive sound pressure from earphone and headphones can cause hearing loss.
12. The mains plug of unit should be obstructed or should be easily accessed during intended use.
13. To be completely disconnect the power input, the mains plug of apparatus shall be disconnected from the mains.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
CAUTION
moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on apparatus.

WARNING
E-1
TO PREVENT FIRE OR SHOCK HAZARD DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
WARNING : SHOCK HAZARD-DO NOT OPEN
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
LIGHTNING FLASH WITH ARROWHEAD SYMBOL -
within an equilateral triangle, is intended to alert the
user to the presence of uninsulated dangerous
voltage within the products enclosure that may be of
sufficient magnitude to constitude a risk of electric
shock to persons.
EXCLAMATION POINT - within an equilateral triangle,
is used to indicate that a specific component shall be
replaced only by the component specified in that
documentation for safety reason.
The following label has been affixed to the unit, listing the proper procedure for working with the laser beam:
CLASS 1 LASER PRODUCT LABEL -
This label is attached to the place as illustrated to inform that the
apparatus contains a laser component.
WARNING LABEL INFORMING OF RADIATION -
This label is placed inside the unit. As shown in the illustration. To
warn against further measures on the unit. The equipment contains
a laser radiating laser rays according to the limit of laser product of
class 1.
CLASS 1 LASER PRODUCT
KLASS 1 LASER APPARAT
LUOKEN 1 LAISERLAITE
KLASSE 1 LASER PRODUKT

SAFETY INSTRUCTIONS
E-2
1. READ INSTRUCTIONS - All the safety and operating instructions should be read before the appliance is operated.
2. RETAIN INSTRUCTIONS - The safety and operating instruction should be retained for future reference.
3. HEEDWARNINGS - All warnings on the appliance and in the operating instructions should be adhered to.
4. FOLLOW INSTRUCTIONS - All operating instructions should be followed.
5. WATER AND MOISTURE- The appliance should not be used near water, for example, near a bathtub, washbowl,
.tnemesabtewaniroloopgnimmiws,butyrdnual,knisnehctik
6. VENTILATION - The appliance should be situated sothat its location or position does not interfere with its proper
ventilation. Do not place on bed, sofa, rug or similar surface that may block the ventilation openings, in a built-in
installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.
7. HEAT - The appliance should be situated away from heat sources such as radiators, stoves, or other appliances
(including amplifiers) that produce heat.
8. POWERSOURCE- The appliance should be connected to power supply only of the type described in the
operating instructions or as marked on the appliance.
9. POWER CORD PROTECTION- Power supply cords should be routed sothat they are not likely to be walked
on or pinched by items placed upon or against them.
10. POWERLINES -An outdoor antenna should be located away from power lines.
11. OBJECT and LIQUID ENTRY - Care should be taken so that objects do not fall and liquids are not spilled into
the enclosure through openings.
12. ESDWARNING - The display does not function properly or no reaction to operation of any the control may due
to the electrostatic discharge. Switch off and unplug the set. Reconnect after a few seconds.
13. DAMAGE REQUIRING SERVICE -The appliance should be serviced by qualified service personnel when:
a. The power-supply cord or plug has been damaged.
b. Objects have fallen into, or liquid has been spilled into the appliance enclosure.
c. The appliance has been exposed to rain.
d. The appliance has been dropped, or the enclosure damaged.
e. The appliance does not appear to operate normally.
14. SERVICING -The user should not attempt to service the appliance beyond that described in the user operating
instructions. All other servicing should be referred to qualified service personnel.
Notes:
a. Dirty or scratched CD may cause a skipping problem. Clean or replace the CD.
b. If an error display or malfunction occurs, disconncet the AC cord and remove all the batteries. Then turn the power
back on.
BEFORE OPERATION
Notes: CONCERNING COMPACT DISCS.
Since dirty, damaged or warped discs may damage the appliance, care should be taken of the followings items:
a. Usable compact discs. Use only compact disc with the mark shown below.
b. CD compact disc only with digital audio signals.

AC POWER
You can power your appliance by plugging the AC power cord at the back of the appliance into a wall
AC power outlet. Check that the rated voltage of your appliance matches your local voltage.
POWER SOURCE
LOCATION OF CONTROL
E-3
1
2
3
9
4
17
5
6
7
8
16
15
14
12
13
19
18
10
11
20
1.) LCD DISPLAY
2.) CLOCK
3.) TIMER
4.) EQ
5.) MONO / STEREO
6.) MEMORY / MODE
7.) FOLDER -
8.) FOLDER +
9.) PLAY / PAUSE
10.) STOP
11.) STANDBY
12.) VOLUME CONTROL
13.) REMOTE SENSOR
14.) SKIP -
15.) SKIP +
16.) FUNCTION
17.) SPEAKER JACKS ( L / R )
18.) AC POWER CORD
19.) FM ANTENNA
20.) iPHONE DOCK

BATTERY INSTALLATION
Insert 2 x “AAA” size batteries into the battery compartment. Be sure that the batteries are inserted
correctly to avoid damage to the remote control. Always remove the batteries when the remote
control will not be used for a long period of time, as this will cause leakage to the batterie s and
subsequently damage to your set.
Notes:
- Use batteries of the same type. Never use different types of batteries together.
- If the distance required between the remote control and the appliance decreases, the batteries
are exhausted. In this case replace the batteries with new one.
SENSOR WINDOW OF THE RECEIVER
- Even if the remote control is operated within the effective range, its operation may be impossible if
there are any obstacies between the appliance and the remote control.
- If the remote control is operated near other appliances which generate infrared rays, or if other
remote control devices using infrared rays are used near the appliance, it may operate incorrectly.
REMOTE CONTROL
E-4
1
20
21
22
23
24
25
11
26
23
45
67
8
9
10
12
13
14
15
17
16
18 27
19
28
1. CLOCK
2. STANDBY
3. PRE - DN
4. TIMER
5. SNOOZE
6. SLEEP
7. FOLDER +
8. FOLDER -
9. MONO / ST.
10. INFO
11. SKIP -
12. REPEAT
13. VOLUME +
14. PLAY / PAUSE
15. VOLUME -
16. MENU
17. EQ
18. MENU DN
19. ENTER
20. MUTE
21. PRE-UP
22. INTRO
23. MEMORY
24. RANDOM
25. SKIP +
26. FUNCTION
27. MENU UP
28. STOP

RADIO OPERATION
E-5
AUTOMATIC TUNING
MANUAL TUNING
It is for selecting stations, which cannot be tuned automatically. (manual selection)
To tune a channel manually.
- Press the function button to select “TUNER” mode.
- Press the “SKIP +” or “SKIP -” button is pressed momentarily (0.5 second or less),
the frequency changes by a fixed step:
FM: 0.05 MHz steps
1. Press the “FUNCTION” button to select “TUNER” mode.
2. Press and hold the “SKIP +” or “SKIP -” button for 2 sec. to start automatic tuning process.
3. When a station is tuned in the tuning process, it will stop automatically and you can listen to
your desired station.
MEMORY PRESET
1. Repeat step 1 to 3 in the AUTOMATIC TUNING procedures.
2. Press the “MEMORY / MODE” button to start the preset process.
3. Display will show the memory sequence number and a flashing “1”.
4. Press the “PRE-DN” or “PRE-UP” button or the “MEMORY / MODE” button of front panel to
determine the preset station number.
5. Press again the “MEMORY / MODE” button to preset your desired station.
6. Once all the stations were preset, press the “PRE-DN” or “PRE-UP” button on remote to listen to
your desired station.
MONO / STEREO
Press the “MONO / ST.” button to achieve the best frequency.

CD / MP3 OPERATION
E-6
GENERAL OPERATION
PLAY / PAUSE Press to start playing CD / MP3 disc.
Press again to stop playing CD / MP3 operation temporarily.
Press again to resume playback.
SKIP + & Press to go to the next track or back to the previous track.
SKIP - Press and hold while playing until you find the point you want to play.
STOP Press to stop all CD / MP3 operation.
PLAYBACK
3. Press the “FUNCTION” button to select “CD / MP3” mode.
1. Open the CD door and place a CD / MP3 disc with the label up in the CD compartment.
2. Close the CD door.
4. Focus search is performed if disc is inside.
Playback will start automatically from the first track.
5. Adjust the “VOLUME” control to the desired level.
6. Press the “PLAY / PAUSE” button when you want to stop playback temporarily.
7. Press the “STOP” button when finished.
FOLDER SELECT
Press the “FOLDER +” or “FOLDER -” button to select folder. ( Folder select function can only operate
if disc store with at least 2 directories / files. )

MODE
Press the “MEMORY / MODE” button of panel or “REPEAT” key of remote control during
1 - REPEAT 1
2 - REPEAT ALBUM ( *MP3 ONLY )
3 - REPEAT ALL
4 - NORMAL PLAYBACK
REPEAT 1
REP REP
ALBUM
REP
ALL
REPEAT
ALBUM
REPEAT
ALL
NORMAL
PLAYBACK
CD / MP3 OPERATION
E-7
PROGRAM
Be sure to press the “STOP” button before use.
2. Select desired track by using the “SKIP +” or “SKIP -” button. (For MP3, select a desired album by
pressing “FOLDER +” or “FOLDER -” button. And press “MEMORY / MODE” button to confirm
4. Repeat step 2 and 3to enter additional tracks into the program memory.
5. When all the desired tracks have been programmed, press the “PLAY / PAUSE” button to play the
disc in the order you have programmed.
6. Press the “STOP” button twice to terminate programmed playback.
1. For CD disc, press the “MEMORY / MODE” button, the display will show “00 P-01”.
For MP3 disc, press the “MEMORY / MODE” button, the display will show “F00 P-01”.
3. Press the “MEMORY / MODE” button again to confirm desired track into the program memory.
folder number. Too will appear to select desired track by using the “SKIP +” or “SKIP -” button.)
playing CD / MP3 disc, each press switches the mode function as follows:

PLAYBACK
CHARGING
1. Press the “FUNCTION” button to select “iPhone” mode.
2. When iPhone is docked, the system will initialize the communication with iPhone.
3. Power Oncommand is sent tothe iPhone to wake up it.
4. Play command is sent afterward to auto play the iPhone.
5. Corresponding command is sent to iPhone when key is pressed.
6. Playback starts automatically. You can select available features (such as paly/pause, skip track,
fast forward/backward, menu selection) during playback.
Charging iPhone battery using the dock.
-In DOCK mode, directly dock your iPhone portable player on the cradle for charging.
GENERAL OPERATION
PLAY / PAUSE Press to start playing tracks from the iPhone.
Press again to stop playing iPhone operation temporarily.
Press again to resume playback.
SKIP + & Press to go tothe next track or back tothe previous track.
SKIP - Press and hold while playing until you find the point you want to play.
STOP Press to stop all iPhone operation.
E-8
iPHONE DOCK

ID3 TAG (FOR MP3 ONLY)
1. Press once “INFO” button, ID3 text will show on display.
2. Press again to terminate ID3 mode.
Notes:
Due to various solutions, ID3 text function may not be played.
OTHER FEATURES
EQ
Press the “EQ” button on remote control, each press switch the EQ function as follows:
1 - CLASSIC
2 - ROCK
3 - POP
4 - JAZZ
5 - FLAT (NORMAL)
INTRO
1. Press the “INTRO” button during play disc to play each song for 10 seconds.
2. Press the “INTRO” button again to resume normal playback.
3. Not available on memory playback.
MUTE
1. Press the “MUTE” button to stop the sound during playing disc.
2. Press the “MUTE” button again to resume the sound.
Notes:
- The player not responsible for playability of MP3 in any case. Due to recording condition such as PC
performance, writing software, media ability or etc.
- For CD-RW, CD-R, it may not be played according to the type of this disc.
E-9

SLEEP
1. Press the “SLEEP” button on remote control, display will show “SLEEP 90”. That means, after 90
minutes, appliance will automatically turn to standby mode.
2. Press the “SLEEP” button again to select the automatically turn off time, from 90, 80, 70, 60, 50,
40, 30, 20, 10 minutes.
3. Press the “SLEEP” button to “SLEEP 00” to cancel sleep function.
RANDOM
1. Press the “RANDOM” button again to terminate random mode.
2. Press the “RANDOM” button on remote control during playing disc, the appliance will select and
play a track randomly.
3. The function is not available on program playback.
OTHER FEATURES
E-10

TIMER SETTING
Timer setting must be after completed clock setting.
1. Press the “STANDBY” button to switch unit at standby mode.
2. Press the “TIMER” button to entry timer set mode.
3. The display will show “TIMER ON”, and AM 12:00 or PM 12:00 if 12H format is set or 00:00 if
4. Adjust hour by pressing the “SKIP +” or “SKIP -” button, press the “TIMER” button to confirm.
5. Adjust minute by pressing the “SKIP +” or “SKIP -” button, press the “TIMER” button to confirm.
6. The display will show “TIMER OFF”, and AM 12:00 or PM 12:00 if 12H format is set or 00:00 if
7. Adjust hour by pressing the “SKIP +” or “SKIP -” button, press the “TIMER” button to confirm.
8. Adjust minute by pressing the “SKIP +” or “SKIP -” button, press the “TIMER” button to confirm.
9. The display show input source by pressing “SKIP +” or “SKIP -” (Chose CD, USB, CARD, i-Pod
or Tuner). Chose the input and press “TIMER” button to confirm the selection.
10.The display show volume level pressing “SKIP +” or “SKIP -” to adjust the volume level and press
“TIMER” button to confirm the selection.
11.After confirmation the unit display show “TIMER ON TIME”, “TIMER OFF TIME”, “INPUT SOURCE”
and “VOLUME LEVEL” and unit go to standby mode.
12.Press the “TIMER” button to activate timer on / off function.
13.If you want to adjust the timer, press and hold “TIMER” button for 2 sec. It go to timer setting mode.
Follow steps from 4.
14.Press and hold the “PLAY / PAUSE” button over 5 sec. to cancel all timer setting.
Follow steps from 4.
OTHER FEATURES
CLOCK SETTING
1. Press the “STANDBY” button to switch unit at standby mode.
2. Press the “CLOCK” button once to entry clock set mode. The display will show “24H” and
flashing.
3. Adjust time format ( 12H / 24H ) by pressing the “SKIP +” or “SKIP -” button.
4. Press the “CLOCK” button to confirm time format, display will show “AM 12:00” or “PM 12:00” if
12H format is set or “00:00” if 24H set.
5. Adjust hour by pressing the “SKIP +” or “SKIP -” button, press the “CLOCK” button to confirm.
6. Adjust minute by pressing the “SKIP +” or “SKIP -” button, press the “CLOCK” button to confirm.
Notes:
Because clock setting is at standby mode, the display is dim.
E-11

MENU / ENTER / MENU DN / MENU UP
MENU / ENTRE / MENU DN / MENU UP button is only for iPod / iPhone.
- When playing iPod / iPhone, press the “MENU” button to back to previous menu.
- Press the “ENTER” button to menu selection.
- Press the “MENU DN” or “MENU UP” to select next menu.
- Press the “ENTER” button again to select a desired menu or track.
- When All the desired tracks have been selected, pree the “ENTER” button to play.
OTHER FEATURES
SNOOZE
SNOOZE must be after completed timer setting.
When the timer is triggered. You may press the “SNOOZE” button to delay the alarm for another
9 minutes.
E-12

Instructions on environment protection
WWW.DENVER-ELECTRONICS.COM
Electric and electronic equipment and included batteries contains materials, components and
substances that can be hazardous to your health and the environment, if the waste material
(discarded electric and electronic equipment and batteries) is not handled correctly.
Electric and electronic equipment and batteries is marked with the crossed out trash can symbol,
seen below. This symbol signifies that electric and electronic equipment and batteries should not be
disposed of with other household waste, but should be disposed of separately.
As the end user it is important that you submit your used batteries to the approriate and designated
facility. In this manner you make sure that the batteries are recycled in accordance with legislature
and will not harm the environment.
All cities have established collection points, where electric and electronic equipment and batteries
can either be submitted free of charge at recycling stations and other collection sites, or be collected
from the households. Additional information is available at the technical department of your city.
ALL RIGHTS RESERVED
DENVER ELECTRONICS A/S
E-11
