DH Instruments HPMS A30000 User manual

T.O. 33A6-4-30-1
1 August 2000
©2000 DH Instruments, Inc.
RPM3/HPMS A30000/A6000-AF
Operation and Maintenance
Manual
NSN 6685-01-470-8667
(2 of 2)

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.
High pressure liquids and gases are potentially hazardous. Energy stored in these liquids and gases can
be released unexpectedly and with extreme force. High pressure systems should be assembled and
operated only by personnel who have been instructed in proper safety practices.
©2000 DH Instruments, Inc. All rights reserved.
Information in this document is subject to change without notice. No part of this document may be reproduced or
transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written
permission of DH Instruments, Inc. 4765 East Beautiful Lane Phoenix AZ 85044-5318 USA.
DH Instruments makes sincere efforts to ensure accuracy and quality of its published materials; however, no
warranty, expressed or implied, is provided. DH Instruments disclaims any responsibility or liability for any direct or
indirect damages resulting from the use of the information in this manual or products described in it. Mention of any
product does not constitute an endorsement by DH Instruments of that product. This manual was originally
composed in English and was subsequently translated into other languages. The fidelity of the translation cannot
be guaranteed. In case of conflict between the English version and other language versions, the English version
predominates.
DH Instruments, DH, DHI, AutoZ, CalTool, HGC, HPMS, OPG1, PPC, PPC2+, RPM3, SDS (Self Defense System)
are trademarks, registered and otherwise.
LabVIEW is a registered trademark of National Instruments Corporation.
Document No. 550115
000124
Printed in the USA.

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page i ©2000 DH Instruments, Inc.
T
TA
AB BL LE E O OF F C
CO
ON NT TE EN NT TS S
TABLE OF CONTENTS................................................................................i
TABLES....................................................................................................v
FIGURES .................................................................................................vi
ABOUT THIS MANUAL .............................................................................vii
1. INTRODUCTION ....................................................................................1
1.1 PRODUCT OVERVIEW .......................................................................................................................1
1.2 SPECIFICATIONS...............................................................................................................................2
1.2.1 GENERAL SPECIFICATIONS...............................................................................................................................2
1.2.2 PRESSURE MEASUREMENT SPECIFICATIONS...............................................................................................2
1.2.2.1 RPT MEASUREMENT SPECIFICATIONS (% FS OF ACTIVE RANGE)............................................3
1.2.2.2 ON-BOARD BAROMETER...................................................................................................................4
2. INSTALLATION.....................................................................................5
2.1 UNPACKING AND INSPECTION.........................................................................................................5
2.1.1 REMOVING FROM PACKAGING.........................................................................................................................5
2.1.2 INSPECTING CONTENTS.....................................................................................................................................5
2.2 SITE REQUIREMENTS........................................................................................................................6
2.3 INITIAL SETUP ...................................................................................................................................6
2.3.1 PREPARING FOR OPERATION...........................................................................................................................6
2.3.2 RPM3/HPMS FRONT AND REAR PANELS.........................................................................................................7
2.3.2.1 FRONT PANEL......................................................................................................................................7
2.3.2.2 REAR PANEL........................................................................................................................................8
2.3.2.3 SIDE VIEW ............................................................................................................................................8
2.3.3 RPM3 FRONT AND REAR PANELS....................................................................................................................9
2.3.3.1 FRONT PANEL......................................................................................................................................9
2.3.3.2 REAR PANEL......................................................................................................................................10
2.3.4 POWER CONNECTION.......................................................................................................................................10
2.3.5 FOOT SWITCH CONNECTION...........................................................................................................................11
2.3.6 TEST PORT CONNECTION................................................................................................................................11
2.3.6.1 THE RPM3 ATM PORT.......................................................................................................................11
2.3.7 SETTING UP FILE SEQUENCES .......................................................................................................................12
2.4 POWER UP AND VERIFICATION .....................................................................................................12
2.4.1 APPLY POWER ...................................................................................................................................................12
2.4.2 CHECK PROPER PRESSURE MEASUREMENT OPERATION.......................................................................12
2.4.2.1 CHECKING ABSOLUTE MODE PRESSURE MEASUREMENT.......................................................12
2.4.2.2 CHECKING GAUGE MODE PRESSURE MEASUREMENT.............................................................13
2.5 SHORT TERM STORAGE.................................................................................................................13
2.6 LONG TERM STORAGE AND SHIPPING .........................................................................................13
3. OPERATION ....................................................................................... 15
3.1 GENERAL/MANUAL OPERATION....................................................................................................15
3.1.1 KEYPAD LAYOUT AND PROTOCOL................................................................................................................15
3.1.2 MAIN RUN SCREEN............................................................................................................................................16
3.1.3 SOUNDS...............................................................................................................................................................17
3.1.4 SOFT [ON/OFF] KEY...........................................................................................................................................17
3.1.5 PRESSURE READY <*>/NOT READY (<↑
↑↑
↑> OR <↓
↓↓
↓>) INDICATION ................................................................18

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page ii
3.1.6 MULTIPLE PRESSURE RANGES......................................................................................................................18
3.1.6.1 RANGES AND IDENTIFICATION.......................................................................................................19
3.1.7 AUTOMATED TEST/CALIBRATION SEQUENCES..........................................................................................19
3.1.8 HPMS (HIGH PRESSURE MOUNTING SYSTEM).............................................................................................20
3.2 DIRECT FUNCTION KEYS................................................................................................................22
3.2.1 DIRECT FUNCTION KEYS SUMMARY..............................................................................................................22
3.2.2 [RANGE]...............................................................................................................................................................24
3.2.3 [UNIT] ...................................................................................................................................................................26
3.2.4 [MODE].................................................................................................................................................................27
3.2.5 [UL] (UPPER LIMIT) ............................................................................................................................................28
3.2.5.1 OVER-PRESSURE FUNCTION (<PMAX!>) ......................................................................................30
3.2.5.2 LO RPT PROTECTION (<!!LO RPT ACTIVE!!>)................................................................................31
3.2.6 [RES] (RESOLUTION).........................................................................................................................................31
3.2.7 [DISPLAY]............................................................................................................................................................33
3.2.7.1 AVG (AVERAGE) ................................................................................................................................34
3.2.7.2 RATE....................................................................................................................................................36
3.2.7.3 DEV (DEVIATION)...............................................................................................................................36
3.2.7.4 RPT......................................................................................................................................................37
3.2.7.5 HI/LO....................................................................................................................................................39
3.2.7.6 FREEZE...............................................................................................................................................39
3.2.7.7 CLEAN.................................................................................................................................................40
3.2.8 [HEAD] .................................................................................................................................................................41
3.2.9 [SDS] (SELF DEFENSE SYSTEM).....................................................................................................................44
3.2.10 [AUTOZ]...............................................................................................................................................................44
3.2.10.1 RUNNING AUTOZ IN GAUGE MEASUREMENT MODE..................................................................44
3.2.10.2 RUNNING AUTOZ IN ABSOLUTE MEASUREMENT MODE............................................................45
3.2.11 [ENTER] RUN TEST SEQUENCE ......................................................................................................................49
3.2.11.1 TEST INITIALIZATION (QUICK SEQUENCE) ...................................................................................51
3.2.11.2 TEST EXECUTION (QUICK SEQUENCE AND FILE SEQUENCE)..................................................52
3.3 [SETUP] MENU KEY.........................................................................................................................54
3.3.1 HEAD....................................................................................................................................................................54
3.3.2 PRESU..................................................................................................................................................................55
3.3.3 READRT (READ RATE)......................................................................................................................................56
3.3.4 STAB (STABILITY)..............................................................................................................................................57
3.3.5 LEAK (LEAK CHECK).........................................................................................................................................59
3.3.6 SEQ.......................................................................................................................................................................60
3.3.6.1 SEQUENCE, DATA.............................................................................................................................61
3.3.6.2 SEQUENCE, FILESEQ.......................................................................................................................62
3.4 [SPECIAL] MENU KEY......................................................................................................................65
3.4.1 AUTOZ..................................................................................................................................................................66
3.4.1.1 AUTOZ ON/OFF..................................................................................................................................69
3.4.1.2 VIEW AUTOZ.......................................................................................................................................69
3.4.1.3 EDIT AUTOZ........................................................................................................................................70
3.4.2 SDS.......................................................................................................................................................................70
3.4.3 ATM ......................................................................................................................................................................70
3.4.4 REMOTE...............................................................................................................................................................71
3.4.5 RESET..................................................................................................................................................................72
3.4.5.1 RESET - SETS ....................................................................................................................................73
3.4.5.2 RESET - UNITS...................................................................................................................................74
3.4.5.3 RESET - SEQ......................................................................................................................................74
3.4.5.4 RESET - CAL.......................................................................................................................................74
3.4.5.5 RESET - ALL .......................................................................................................................................75
3.4.6 CAL.......................................................................................................................................................................75
3.4.7 INTERN.................................................................................................................................................................75
3.4.7.1 SCRSAV..............................................................................................................................................76
3.4.7.2 SOUND................................................................................................................................................76
3.4.7.3 TIME.....................................................................................................................................................77
3.4.7.4 ID..........................................................................................................................................................77
3.4.8 LEVEL...................................................................................................................................................................78
3.4.9 LOG ......................................................................................................................................................................81
4. REMOTE OPERATION ......................................................................... 82
4.1 OVERVIEW .......................................................................................................................................82
4.2 INTERFACING ..................................................................................................................................82
4.2.1 RS-232 INTERFACE............................................................................................................................................82

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page iii ©2000 DH Instruments, Inc.
4.2.1.1 COM1...................................................................................................................................................82
4.2.1.2 COM2...................................................................................................................................................83
4.2.2 IEEE-488 (GPIB) ..................................................................................................................................................83
4.3 REMOTE COMMAND SYNTAX AND STYLE.....................................................................................83
4.3.1 LOCAL AND REMOTE SETTING.......................................................................................................................83
4.3.2 COMMAND SYNTAX...........................................................................................................................................84
4.3.3 QUERIES AND REPLIES....................................................................................................................................84
4.3.4 MULTIPLE COMMANDS.....................................................................................................................................84
4.3.5 COMMAND PARAMETERS................................................................................................................................85
4.3.6 SUFFIXES ............................................................................................................................................................85
4.3.7 PROGRAMMING TIPS ........................................................................................................................................85
4.3.7.1 SCPI AND IEEE-488.2 ........................................................................................................................85
4.3.7.2 PROGRAMMING TECHNIQUE..........................................................................................................86
4.4 COMMANDS .....................................................................................................................................89
4.4.1 ERROR MESSAGES...........................................................................................................................................92
4.4.2 COMMAND DESCRIPTIONS..............................................................................................................................94
4.4.2.1 IEEE STD. 488.2 COMMON AND STATUS COMMANDS.................................................................94
4.4.2.2 MEASUREMENT SUBSYSTEM.........................................................................................................97
4.4.2.3 CALCULATE SUBSYSTEM..............................................................................................................102
4.4.2.4 CALIBRATION SUBSYSTEM ...........................................................................................................103
4.4.2.5 DISPLAY SUBSYSTEM....................................................................................................................105
4.4.2.6 SENSE SUBSYSTEM.......................................................................................................................106
4.4.2.7 STATUS SUBSYSTEM.....................................................................................................................108
4.4.2.8 SYSTEM SUBSYSTEM.....................................................................................................................116
4.4.2.9 UNIT SUBSYSTEM...........................................................................................................................122
4.5 STATUS SYSTEM...........................................................................................................................124
4.5.1 STATUS REPORTING SYSTEM.......................................................................................................................124
4.5.1.1 SCPI STATUS SUBSYSTEM............................................................................................................124
4.5.1.2 ERROR QUEUE................................................................................................................................124
4.5.1.3 STATUS BYTE REGISTER...............................................................................................................125
4.5.1.4 STANDARD EVENT REGISTER......................................................................................................127
4.5.1.5 RPT READY STATUS REGISTER...................................................................................................128
4.5.2 STATUS SUBSYSTEM......................................................................................................................................129
4.5.2.1 OPERATION REGISTER STRUCTURE..........................................................................................129
4.5.2.2 QUESTIONABLE REGISTER STRUCTURE...................................................................................132
5. MAINTENANCE, CALIBRATION AND REPAIR...................................... 136
5.1 INTRODUCTION .............................................................................................................................136
5.2 RPM3 MAINTENANCE....................................................................................................................137
5.2.1 AUTOZERO OF RPTS.......................................................................................................................................137
5.2.1.1 GAUGE MODE OPERATION ...........................................................................................................137
5.2.1.2 ABSOLUTE MODE OPERATION.....................................................................................................137
5.2.2 ADJUSTMENT OF ON-BOARD BAROMETER...............................................................................................138
5.2.3 RPM3 OVERHAUL.............................................................................................................................................138
5.3 RPM3 RPT CALIBRATION..............................................................................................................139
5.3.1 PRINCIPLE.........................................................................................................................................................139
5.3.1.1 PA/PM COEFFICIENTS....................................................................................................................140
5.3.1.2 SETTING ZNATERR.........................................................................................................................140
5.3.1.3 ORDER OF OPERATIONS...............................................................................................................141
5.3.1.4 AS RECEIVED/AS LEFT DATA........................................................................................................141
5.3.2 EQUIPMENT REQUIRED..................................................................................................................................141
5.3.3 SET-UP AND PREPARATION..........................................................................................................................142
5.3.4 RPT CALIBRATION USING RPM3 CALTOOL SOFTWARE..........................................................................142
5.3.5 EDITING AND VIEWING RPT CALIBRATION INFORMATION......................................................................143
5.3.6 SETTING ZNATERR..........................................................................................................................................144
5.3.7 RPT CALIBRATION/ADJUSTMENT WITHOUT RPM3 CALTOOL SOFTWARE...........................................145
5.4 RPM3 REPAIR ................................................................................................................................146
5.4.1 REMOVING AND REINSTALLING RPM3 IN THE HPMS................................................................................146
5.4.2 OPENING AND CLOSING THE RPM3 CASE..................................................................................................147
5.4.3 RELOADING RPM3 EMBEDDED SOFTWARE INTO FLASH MEMORY.......................................................148
5.4.4 RPM3 INTERNAL VIEW ....................................................................................................................................148
5.4.4.1 SDS MODULE...................................................................................................................................149
5.4.4.2 RPTS..................................................................................................................................................149
5.4.4.3 POWER SUPPLY..............................................................................................................................149

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page iv
5.4.4.4 COOLING FAN..................................................................................................................................149
5.4.4.5 MICRO BOARD.................................................................................................................................149
5.4.4.6 MAIN BOARD....................................................................................................................................149
5.4.4.7 ON-BOARD BAROMETER...............................................................................................................149
5.4.4.8 DISPLAY............................................................................................................................................149
5.5 HPMS MAINTENANCE....................................................................................................................150
5.5.1 HPMS OVERHAUL............................................................................................................................................150
6. TROUBLESHOOTING......................................................................... 152
6.1 OVERVIEW .....................................................................................................................................152
7. APPENDIX........................................................................................ 157
7.1 PRESSURE UNIT CONVERSIONS..................................................................................................157
7.2 WARRANTY STATEMENT..............................................................................................................158
8. GLOSSARY....................................................................................... 161

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page v©2000 DH Instruments, Inc.
T
TA
AB BL LE ES S
Table 1. RPM3/HPMS A30000/A6000-AF Supplied Items...................................................................5
Table 2. RPM3 Range Identification Summary..................................................................................19
Table 3. Summary of RPM3 Direct Function Key Operation..............................................................23
Table 4. PresU - Available Units .......................................................................................................56
Table 5. READRT - Display Update Rates........................................................................................56
Table 6. Functions - Security Levels .................................................................................................79
Table 7. RPM3 COM1 DB-9F Pin Designations ................................................................................82
Table 8. IBM PC/XT DB-9F, DB-9M Connections .............................................................................82
Table 9. RPM3 COM2 DB-9M Pin Designations................................................................................83
Table 10. Quick Programming Tips.....................................................................................................88
Table 11. Command Summary ...........................................................................................................89
Table 12. “SYSTEM:ERROR?” QUERY REPLY.................................................................................93
Table 13. 8 Bit Status Byte Register .................................................................................................125
Table 14. Standard Event Register ...................................................................................................127
Table 15. 8 Bit RPT Ready Status Register ......................................................................................128
Table 16. Troubleshooting Symptom/Probable Cause/Solution List...................................................152
Table 17. Pressure Unit of Measure Conversions .............................................................................157
Table 18. DH Instruments, Inc. Authorized Service Providers .........................................................159

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page vi
F
FI
IG GU UR RE ES S
Figure 1. RPM3/HPMS Front Panel .....................................................................................................7
Figure 2. RPM3/HPMS Rear Panel......................................................................................................8
Figure 3. RPM3/HPMS Side View........................................................................................................8
Figure 4. RPM3 Front Panel ................................................................................................................9
Figure 5. RPM3 Rear Panel...............................................................................................................10
Figure 6. RPM3 Keypad.....................................................................................................................15
Figure 7. RPM3/HPMS Front Panel ...................................................................................................21
Figure 8. RPM3/HPMS Internal Schematic.........................................................................................22
Figure 9. Status Byte Register .........................................................................................................125
Figure 10. Illustration of this Structure Duplicated for Each of the OPERation, INSTrument, and
ISUMmary Registers.........................................................................................................130
Figure 11. Relationship of the OPERation Register and Its Support Registers....................................131
Figure 12. Illustration of this Structure Duplicated for Each of the OPERation, INSTrument, and
ISUMmary Registers.........................................................................................................133
Figure 13. Relationship of the QUEStionable Register and Its Support Registers...............................134
Figure 14. RPM3/HPMS Side View....................................................................................................147
Figure 15. RPM3 Internal View ..........................................................................................................148

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page vii ©2000 DH Instruments, Inc.
A
AB
BO OU UT T T
TH
HI IS S M
MA
AN NU UA AL L
This manual provides the user with the basic information necessary to operate an RPM3/HPMS
A30000/A6000-AF Reference Pressure Monitor with High Pressure Mounting System. It also
includes a great deal of additional information provided to help you optimize use of the instrument
and take full advantage of its many features and functions.
Before using this manual, take a moment to familiarize yourself with the Table of Contents structure.
All first time users should read Chapter 2. Chapter 3 provides a comprehensive description of
general RPM3/HPMS operating principles. Section 3.1.7 describes the automated Sequence
function used to run calibrations and verifications of typical instruments under test. This is the way
the instrument is typically used. Chapter 4 is for remote operation from an external computer.
Chapter 5 provides maintenance and calibration information. Chapter 6 is a quick troubleshooting
guide. Use it to troubleshoot unexpected RPM3/HPMS behavior based on the symptoms of that
behavior. Certain words and expressions have specific meaning as they pertain to this product. The
Glossary is useful as a quick reference for exact definition of specific words and expressions as they
are used in this manual.
RPM3/HPMS A30000/A6000-AF is usually delivered as part of an HGC-30000-AF system which
includes an OPG1 hydraulic pressure generator/controller. The OPG1 has its own Operation and
Maintenance Manual.
FOR THOSE OF YOU WHO “DON’T READ MANUALS”, GO DIRECTLY TO SECTION 2.3 TO SET UP YOUR
RPM3/HPMS AND THEN 2.4 FOR POWER UP AND VERIFICATION. THIS WILL GET YOU RUNNING
QUICKLY WITH MINIMAL RISK OF CAUSING DAMAGE TO YOURSELF OR YOUR NEW RPM3. THEN…
WHEN YOU HAVE QUESTIONS OR START TO WONDER ABOUT ALL THE GREAT FEATURES YOU
MIGHT BE MISSING, GET INTO THE MANUAL!
Manual Conventions
(CAUTION) is used throughout the manual to identify user warnings and cautions.
(NOTE) is used throughout the manual to identify operating and applications advice and
additional explanations.
[ ] indicates direct function keys (for example [RANGE]).
< > indicates RPM3 screen displays (for example <1yes>).

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page viii
N
NO
OT TE ES S

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page 1 ©2000 DH Instruments, Inc.
1. INTRODUCTION
1.1 PRODUCT OVERVIEW
RPM3/HPMS A30000/A6000-AF is the combination of an RPM3 A5000/A6000-AF reference
pressure monitor and an HPMS High Pressure Mounting System. The combination of an
RPM3/HPMS A30000/A6000-AF and an OPG1-AF oil pressure generator make up the
HGC-30000-AF hydraulic gauge calibrator. The OPG1-AF has its own Operation and Maintenance
manual.
RPM3 A30000/A6000-AF is a stand-alone, microprocessor driven, reference pressure monitor
intended to accurately measure oil pressure in a variety of pressure calibration, measurement and
testing applications. It has been designed to provide very high performance and extensive features
combined with maximum versatility and ease of use. RPM3 A30000/A6000-AF is a special version of
the standard DHI RPM3 product configured specifically for the USAF HGC-30000-AF hydraulic
gauge calibrator.
The HPMS mounts the RPM3 at a convenient viewing angle and contains the hardware to isolate the
RPM3’s low pressure transducer (A6000) when the high pressure transducer (A30000) is in use.
RPM3 A30000/A6000-AF uses two high accuracy reference pressure transducers (RPTs) and an on-
board barometer to measure pressure.
RPM3 A30000/A6000-AF is controlled locally by the operator using its front panel display, keypad
and foot pedal or remotely by a computer using ASCII character command strings over its RS-232
and IEEE-488 interfaces.
RPM3 A30000/A6000-AF has six pressure measurement ranges from 0 to 2 000 psi (7 MPa) to 0 to
30 000 psi (200 MPa) in gauge and absolute measurement modes.
RPM3/HPMS A30000/A6000-AF is usually delivered as part of an HGC-30000-AF system which
includes an OPG1 hydraulic pressure generator/controller. The OPG1 has its own Operation and
Maintenance Manual.

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page 2
1.2 SPECIFICATIONS
1.2.1 GENERAL SPECIFICATIONS
Power Requirements: 85 to 264 VAC, 47 to 440 Hz, 18 VA max consumption
Operating Temperature Range: 15 to 45 °C
Storage Temperature Range: -20 to 70 °C
Weight: RPM3: 3.5 kg (7.7 lb)
HPMS: 5.8 kg (12.8 lb)
RPM3/HPMS: 9.3 kg (20.5 lb)
Dimensions: 21.5 cm H x 29 cm W x 38 cm D
(8.5 in. x 11.5 in. x 15.0 in.) approx.
Microprocessor: Motorola 68302, 16 MHz
Communication Ports: RS-232 (COM1), RS-232 (COM2), IEEE-488
Pressure Ranges: 2 000 psi (14 MPa), 4 000 psi (28 MPa), 6 000 psi
(42 MPa), 10 000 psi (70 MPa), 18 000 psi (126 MPa),
30 000 psi (200 MPa) gauge and absolute.
Operating Medium: Oil (Di-ethyl hexyl sebacate)
Pressure Connections:
Test port (RPT > 10 000 psi): DH500 (gland and collar type for coned and left hand
threaded tube, equivalent to AE F250C, HIP HF4, etc.)
Pressure Limits:
Maximum working pressure:
Maximum pressure w/o damage: 30 000 psi (214 MPa) 37 000 psi (255 MPa)
1.2.2 PRESSURE MEASUREMENT SPECIFICATIONS
RPM3 A30000/A6000-AF is configured with two reference pressure transducers (RPT).
Each transducer has three ranges. The RPTs are of the absolute pressure type with an
evacuated, permanently sealed reference. Absolute RPTs measure both absolute and
gauge pressure. Gauge pressures are defined by offsetting atmospheric pressure
dynamically with compensation for atmospheric changes using an on board barometer.

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page 3 ©2000 DH Instruments, Inc.
1.2.2.1 RPT MEASUREMENT SPECIFICATIONS (% FS OF ACTIVE RANGE)
Transducer Type: Oscillating quartz resonator
Warm Up Time: 30 minutes for operation within specifications
Resolution: To 1 ppm, user settable by individual range
Overpressure Limits:
Without effect on calibration:
Without permanent damage: 115 % of Range 3 125 % of Range 3
Temperature Effect: ± 0.008 % maximum temperature effect in normal
ambient operating range of 15 to 45 °C
Acceleration Affect: ± 0.008 % /g maximum, worst axis
Precision1:Range: H3: 0.0150 %
Ranges H1, H2: 0.0125 %
Ranges L1, L2, L3: 0.010 %
Stability2:
Gauge Mode (w/Autozero):
Absolute Mode (w/Autozero):
All Ranges
0.008 %
0.008 %
Measurement Uncertainty3:
Gauge Mode (w/Autozero):
Absolute Mode (w/Autozero):
H3 H2, H1 L1, L2, L3
0.017 % 0.015 % 0.013 %
0.017 % 0.015 % 0.013 %
1Precision: Combined linearity, hysteresis, repeatability of measurements made by the
reference pressure transducer. When using an absolute RPT for gauge mode
measurement add ±2.5 Pa (0.00035 psi) to the precision specification to take into
account the resolution and short term stability of the on-board barometer used for
dynamic atmospheric pressure compensation.
2Stability: Maximum change in zero and span over 180 days for typical transducer used
under typical conditions. As stability can only be predicted and varies from transducer to
transducer, stability for a specific RPT should be established from experience.
3Measurement Uncertainty: Combined precision, stability, temperature effect.

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page 4
1.2.2.2 ON-BOARD BAROMETER
Sensor Technology: Micro-machined silicon
Warm Up Time: None required
Resolution: 1.25 Pa (0.00018 psi)
The on-board barometer is NOT used as a source of absolute accuracy. It is used
only to measure changes in atmospheric pressure for dynamic compensation of the
atmospheric pressure offset when using an absolute reference pressure transducer
to make gauge pressure measurements (see Section 3.4.1, Gauge Mode with an
Absolute RPT, Dynamic Compensation for Atmospheric Pressure).

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page 5 ©2000 DH Instruments, Inc.
2. INSTALLATION
2.1 UNPACKING AND INSPECTION
RPM3/HPMS A30000/A6000-AF is usually delivered as part of an HGC-30000-AF system which
includes an OPG1 hydraulic pressure generator/controller. The OPG1-3000-AF is shipped in a
separate corrugated container and has its Operation and Maintenance Manual.
2.1.1 REMOVING FROM PACKAGING
RPM3/HPMS A30000/A6000-AF is delivered, along with its accessories, in a reusable
molded plastic, shipping container with polyurethane inserts to hold it in place.
Remove the RPM3/HPMS A30000/A6000-AF and its accessories from the shipping container
and remove each element from its protective plastic bag.
Retain the shipping container for repacking the RPM3/HPMS A30000/A6000-AF when it is
shipped for recalibration of repair.
2.1.2 INSPECTING CONTENTS
Check that all items are present and have NO visible damage.
A standard RPM3/HPMS A30000/A6000-AF includes all items listed in Table 1.
Table 1. RPM3/HPMS A30000/A6000-AF Supplied Items
DESCRIPTION PART NO.
RPM3/HPMS A30000/A6000-AF Reference Pressure Monitor/High Pressure
Mounting System 401604
Transport case (with inserts) (used for original shipment) 123122
Foot Switch Assembly 401613
Operation and Maintenance Manual, RPM3/HPMS A30000/A6000 550115
Calibration Certificate 550100
Test Report, HGC-30000-AF (if RPM3/HPMS delivered as part of HGC-30000-AF
system) 550116
Accessories: 401605
Power Cord (7.5 ft.) 100770
General Accessories Disk (Important: Includes system support software and
documentation) 102987
RPM3 CalTool Manual 550106

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page 6
2.2 SITE REQUIREMENTS
The RPM3/HPMS A30000/A6000-AF is typically delivered as part of an HGC-30000-AF hydraulic
gauge calibrator that includes an OPG1-30000-AF that has its own Operation and
Maintenance Manual. See the OPG1-30000-AF Operation and Maintenance Manual for information
on site requirements for the HGC-30000-AF.
Install RPM3/HPMS A30000/A6000-AF on any stable surface at a convenient height. Consider the
placement of the FOOT SWITCH which may need to be accessed frequently while
running calibrations.
Support facilities required for RPM3/HPMS A30000/A6000-AF include an electrical power source of
85 to 264 VAC, 47 to 440 Hz.
2.3 INITIAL SETUP
2.3.1 PREPARING FOR OPERATION
To prepare RPM3/HPMS A30000/A6000-AF for check out and operation:
•Remove the plastic plug from the RPM3/HPMS A30000/A6000-AF rear panel
TEST connection.
•Remove the protective plastic sheet from the RPM3 front panel display.
•Familiarize yourself briefly with the RPM3 and HPMS front and rear panels (see Sections
2.3.2, 2.3.3).

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page 7 ©2000 DH Instruments, Inc.
2.3.2 RPM3/HPMS FRONT AND REAR PANELS
2.3.2.1 FRONT PANEL
1. Lo RPT Shut Off Valve Position LED
2. Lo RPT Shut Off Valve Knob
3. Lo RPT Active Valve Position LED
4. Caution Lo RPT Active LED
5. RPM3 A30000/A6000-AF Reference Pressure Monitor
Figure 1. RPM3/HPMS Front Panel
21
3
4
5

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page 8
2.3.2.2 REAR PANEL
1. Foot switch (Remote [ENTER]) cable connection
2. TEST port (DH500 F)
Figure 2. RPM3/HPMS Rear Panel
2.3.2.3 SIDE VIEW
1. Lo RPT Isolation Valve Control Knob 5. TEST port (DH500 F)
2. RPM3 A30000/A6000-AF Reference Pressure Monitor 6. Electrical Power Connector (IEC320-C13)
3. Lo RPT Pressure Relief Valve 7. Foot switch (remote [ENTER]) connector
4. Oil Collection Cup (from Relief Valve)
Figure 3. RPM3/HPMS Side View
1
2
4765 East Beautiful Lane
PhoenixAZ 85044-5318
USA
Tel [phone]
Fax [phone]
[e-mail]
www.dhinstruments.com
Made in USA
DH Instruments, Inc.
DO NOT
EXCEED
30000 psi
(200 MPa)
!
TEST
FOOT
SWITCH
1
3
2
5
6, 7
4

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
Page 9 ©2000 DH Instruments, Inc.
2.3.3 RPM3 FRONT AND REAR PANELS
2.3.3.1 FRONT PANEL
1. Display 4. RPT designator label
2. Multi-Function Keypad 5. Soft ON/OFF key and indicator
3. Remote Indicator
Figure 4. RPM3 Front Panel
2
1
345

RPM3/HPMS A30000/A6000-AF Operation and Maintenance Manual
©2000 DH Instruments, Inc.Page 10
2.3.3.2 REAR PANEL
1. Accessories Connection Cable (connects to HPMS 4. ATM Post (On-Board Barometer)
Rear panel FOOT SWITCH and HPMS LEDs) (10-32 UNF)
2. Electrical Power Connector (IEC320-C13) 5. Label, Product (on bottom of case)
3. LO TEST Port (A5000 RPT) (1/8 in. NPT F) 6. HI TEST Port (A30000 RPT) (DH500 F)
Figure 5. RPM3 Rear Panel
2.3.4 POWER CONNECTION
•Connect the power cable to the RPM3 rear panel electrical power connector.
•Do NOT connect the other end of the power cable to a power source yet.
RPM3 is always powered and active when power is supplied through the rear panel
power connector. The front panel ON/OFF key controls a soft ON/OFF (see Section 3.1.4).
3
4
12
5
6
