Digicom Michelangelo Gateway User manual

http://www.digicom.it
ADSL MODEM

ADSL modem for PCI Bus

Asymmetric data speed

8Mbit/s full rate ADSL support

1,5Mbit/s G.Lite ADSL support
User's Guide
rev. 2.0 02/2002
MICHELANGELO PCI

PMICHELANGELO PCI Index
I
INDEX
PREFACE II
ENVIROMENTAL CONDITIONS II
CLEANING THE TERMINAL II
VIBRATIONS OR DROPPING II
WARNING II
DECLARATION CE OF CONFORMITY II
1. GENERALITY 1.1
1.1. PRODUCT FEATURES 1.1
2. HARDWARE INSTALLATION 2.1
3. SOFTWARE INSTALLATION 3.1
3.1. WINDOWS® XP, 2000, ME, 98 3.1
3.2. CHANGE THE INSTALLATION 3.4
3.3. CHANGE CONFIGURATION 3.5
3.3.1. LINE SETUP MENU 3.6
3.3.2. PROTOCOL SETUP MENU 3.7
4. UNINSTALL 4.1
5. ADSL SERVICE (PPPOA) 5.1

II
MICHELANGELO PCI Preface - Declaration CE of Conformity
PREFACE
All rights reserved; no part of this publication may be reproduced, stored in a retrieval
system, or trasmitted in any form or by any means, electronic, otherwise, without the
priorwritten permission of Digicom S.p.A. The contents of this booklet may be modified
withoutpriorpermission.Everypossiblecarehasbeentakenintestingandputtingtogether
all the documentation contained in this booklet, however Digicom can not take any
responsability brought by the use of this booklet.
The following installation rules should be respected in order to have the best
working order of the equipment and for the user’s safety.
ENVIROMENTAL CONDITIONS
ENVIROMENTAL TEMPERATURE RELATIVE HUMIDITY
from -5 to +45°Cfrom 20 to 80% n.c.
Rapid changes of temperature or humidity should be avoided (0,03°C/min).
This equipment, including cables, should be installed in an area free from:
Dust, humidity, heat from direct sun light.
Objects which irradiate heat. These could cause damage to the container
or other problems.
Objectswhich producea strongelecttromagnetic field(loudspeakers, etc.)
Liquids or chemical corrosive substances.
CLEANING THE TERMINAL
Use a clean and soft cloth. Wet the cloth with water or natural detergent if it
is necessary to remove any stains. Never use chemical products such as
petrol or solvents.
VIBRATIONS OR DROPPING
Caution against vibrations and dropping.
WARNING: THIS IS A CLASS B PRODUCT.
DECLARATION OF CONFORMITY
Digicom S.p.A. viaAlessandro Volta 39 21010 Cardano al Campo-Varese-
Thisproduct satisfiesthe basicrequirements ofthe belowindicated Directive:
1999/5/CE 9th March 1999 about the telecommunications equipment
89/336/CEE 3rd May 1989 about the electromagnetic compatibility
73/23/CEE 19th February 1973 about the security

MICHELANGELO PCI Generality
1.1
1. GENERALITY
Asymmetric Digital Subscriber Line (ADSL)
technologyprovides high-speed dataaccessover
regular phone lines. ADSL service is able to co-
existon thesame linewithyour telephoneservice.
TheADSLhas an unbalanced connection speed.
It means that you have a connection where data
arereceived atthe maximumspeedof 8Mbpsand
sent at the maximum speed of 1Mbps. The
unbalance allows to carry out connections with
top performance in Internet access or remote
accessapplications.Asymmetricoperationis ideal
for home and small office use where files and information are downloaded
more frequently than uploaded.
ADSLmodemsemployATM (AsynchronousTransferMode) framing. ATM is
aprotocol thatdividespackets intosmallfixed sizedcellsfor rapidtransmission
over high-speed networks. Several different protocols are used over ATM.
Michelangelo configuration depends on the equipment used by your service
provider:
Point to Point Protocol Over ATM (PPPoA)
Bridged/Routed Ethernet/IP overATM (PPPoE)
1.1. PRODUCT FEATURES
ADSL modem for PCI Bus
Asymmetric data speed
Downstream up to 8Mbps
Upstream up to 1Mbps
8 Mbps full rate ADSL support
1.5 Mbps G.Lite ADSL support
PC interface: PCI compliant with 2.2 specifications
ADSL interface: RJ11 connector
ADSLstandards : ANSIT1.413, ITUG.992.1 (G.dmt)eITUG.992.2 (G.lite)
RFC Supported:
RFC1483 (Bridged/Routed Ethernet/IP overATM)
RFC2516 (PPP over Ethernet)
RFC2364 (Point to Point Protocol Over ATM)

1.2
MICHELANGELO PCI Generality
Windows®Plug&Play
Flash upgradable
CE mark
Driver for Windows®XP/ME/2000/98

MICHELANGELO PCI Hardware Installation
2.1
2. HARDWARE INSTALLATION
Caution: Power off your computer and remove the plug before going on with
the following procedure:
Remove the computer cover.
Choose a free PCI bus slot.
Removethe slotcoverand keepthescrew.
Carefully insert Michelangelo PCI into the
selected slot.
Secure the bracket with the screw.
Close the computer cover and plug it.
Connect the telephone cable to the ADSL line.
For the next steps see the Software Installation section.

MICHELANGELO PCI Software Installation
3.1
3. SOFTWARE INSTALLATION
3.1. WINDOWS® XP, 2000, ME, 98
At the next reboot, Windows® (98/98SE, ME, 2000, XP) will automatically
detect a new hardware and start the driver installation process. Follow the
instructions.
For a right installation you have to cancel the driver installation and then
perform the configuration utility. This will automatically install the right driver
with your provider configuration.
Click on the “Cancel” button displayed in the PCI System Peripheral and
PCI ATM Controller windows.
In the MichelangeloPCI folder, present in the CD-Rom,
(D:\Utility\MichelangeloPCI) double click the “Setup.exe” file.
In the “Install the DSL Device” Windows click on the “Next>” button.

3.2
MICHELANGELO PCI Software Installation
You have to select the right configuration. Ask your Provider for the profile
to be used.
Name Protocols Default
PPPoA PPPoATM VCMUX (RFC2364) 
PPPoATM LLC (RFC2364)
PPPoE PPPoEthernet VCMUX (RFC2516)
PPPoEthernet LLCSNAP (RFC2516) 
EoA Bridge IP overATM VCMUX (RFC1483)
Routed IP overATM VCMUX (RFC1483)
Bridge IP overATM LLCSNAP (RFC1483) 
Routed IP overATM LLCSNAP (RFC1483)
Theinstallation willinstall the defaultprotocol. Inorder tochange theprotocol
refer to paragraph 3.3.
Click on the “Next” button to continue the installation.

MICHELANGELO PCI Software Installation
3.3
The utility configuration will now install and configure Michelangelo PCI. This
could take a few minutes. It’s possible that you have to restart the PC and
insert the CD-Rom of your operating system.

3.4
MICHELANGELO PCI Software Installation
Click on “Finish” to confirm the installation.
3.2. CHANGE THE INSTALLATION
To check the installation use the “Michelangelo Control Panel” utility.
By pressing the “ALT” and “A” key, you’ll see more informations.

MICHELANGELO PCI Software Installation
3.5
3.3. CHANGE CONFIGURATION
To change the configuration use the “Michelangelo Control Panel” utility ,
and press the “ALT” and “P” key.

3.6
MICHELANGELO PCI Software Installation
3.3.1. LINE SETUP MENU
If you experience any problem when connecting, you can change the setting
in Line Setup:
Chose the Line Setup window and change the ADSL Head End ENV.
parameter from No Line Driver (BNA) to Non-Specific.

MICHELANGELO PCI Software Installation
3.7
3.3.2. PROTOCOL SETUP MENU
With Protocol Setup menu you can change the VPI, VCI parameters and
Encapsulation Mode.

MICHELANGELO PCI Uninstall
4.1
4. UNINSTALL
To uninstall the modem use the “Digicom DSL Wizard” utility. You will find it
in Star Menu, Program and Michelangelo DSL.
Choose “Uninstall Michelangelo DSL”, click on the “Next” button, then
follow the instructions.

MICHELANGELO PCI ADSL Service
5.1
5. ADSL SERVICE (PPPoA)
Remote access connection
You can use the remote access connection if your ISP uses the RFC2364
(PPPoA) profiles. In this case Michelangelo PCI will be installed as Digicom
Michelangelo PCI ADSL WAN Adapter and you can choose it in RAS. You
can use the Michelangelo DSL utility (Shortcut on the desktop) to make an
easy connection. Just insert the User Name, the Password and Click on Dial
button.
If the User Name and Password fields are not present, you have to click on
Propertiesbutton, openthe Options windowand checkthe ”Promptfor name
and password…”

5.2
MICHELANGELO PCI ADSL Service
