Digital Projection M-Vision LED+IR series User manual

Rev D July 2014
USER GUIDES
INSTALLATION AND QUICK-START GUIDE
CONNECTION GUIDE
OPERATING GUIDE
REMOTE COMMUNICATIONS GUIDE
112-564D
M-Vision LED+IR series
High Brightness Digital Video Projector
16:10 widescreen display

Rev D July 2014
M-Vision LED+IR series
High Brightness Digital Video Projector
16:10 widescreen display
INSTALLATION AND QUICK-START GUIDE
112-158D
BOOK CONTENTS
INSTALLATION AND
QUICK-START GUIDE
About this Guide
Symbols used in this guide
Warnings

Digital Projection M-Vision LED+IR series CONTENTS Installation and Quick-Start Guide
Rev D July 2014
CONTENTS
About this Guide ...................................................................................Inst_1
Symbols used in this guide..................................................................Inst_1
Warnings .......................................................................................Inst_1
Notes.............................................................................................Inst_1
Product revision....................................................................................Inst_1
What’s in the Box?...............................................................................Inst_2
Getting to Know the Projector....................................................Inst_3
Front and rear views .............................................................................Inst_3
Remote control......................................................................................Inst_3
Control panel and indicators................................................................Inst_4
Error codes....................................................................................Inst_4
Positioning the Screen and Projector....................................Inst_5
Operating the Projector...................................................................Inst_6
Switching the Projector On .................................................................Inst_6
Selecting an Input Signal or Test Pattern ...........................................Inst_6
Input signal....................................................................................Inst_6
Test pattern ...................................................................................Inst_6
Adjusting the Lens................................................................................Inst_7
Zoom.............................................................................................Inst_7
Focus ............................................................................................Inst_7
Shift...............................................................................................Inst_7
Adjusting the Image..............................................................................Inst_8
Orientation.....................................................................................Inst_8
Aspect Ratio..................................................................................Inst_8
Picture...........................................................................................Inst_8
Switching the Projector Off..................................................................Inst_8

Digital Projection M-Vision LED+IR series ABOUT THIS GUIDE Installation and Quick-Start Guide
Page Inst_1
Rev D July 2014
About this Guide
Please read this guide carefully before using the projector, and keep it handy for future reference.
A serial number is located on the side of the projector. Record it here:
Symbols used in this guide
Warnings
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
Notes
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice. Projectors built prior to this revision of the Operating Guide may therefore not include all the features described.

Digital Projection M-Vision LED+IR series WHAT'S IN THE BOX? Installation and Quick-Start Guide
Page Inst_2
Rev D July 2014
What’s in the Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
You should save the original box
and packing materials, in case you
ever need to ship your Projector.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control
(109-685)
2x AAA batteries
User Manual on disc
(115-759)
Important Information
(110-287)
Power cable 10A, United Kingdom
(102-180)
Power cable 10A, Europe
(102-163)
Power cable 13A, North America
(102-165)
Projector
5mm Allen wrench

Digital Projection M-Vision LED+IR series GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide
Page Inst_3
Rev D July 2014
Getting to Know the Projector
Front and rear views
Notes
The projector uses the standard
MVision series infra-red remote
control.
Some of the controls are duplicated
on the projector control panel, as
shown on the next page.
For full details of how to use the
controls and the menu system, see
the Operating Guide.
Lens
Connection
panel
Mains
input
Control
panel
Adjustable
feet
Front
infra-red
window
Rear
infra-red
window
Remote control
Infra-red
reception
40°
40°
Air
inlets
Air
inlet
Lens shift
controls
Focus
adjustment
Zoom
adjustment
Air
outlets

Digital Projection M-Vision LED+IR series GETTING TO KNOW THE PROJECTOR Installation and Quick-Start Guide
Page Inst_4
Rev D July 2014
Control panel and indicators
Some of the controls from the remote control are duplicated on the projector control panel, as
shown here.
The yellow Standby indicator will light when the projector is in standby. The blue Power
indicator will ash when the projector is cooling down or warming up. It will be steady when
the projector is in normal running mode, as shown in the chart below.
Error codes
If the projector detects an error, the red Issue indicator will ash, as shown in the chart below.
For example, if the fan fails, the red indicator will ash twice followed by a pause, then the
sequence will repeat until the error condition is corrected.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.

Digital Projection M-Vision LED+IR series POSITIONING THE SCREEN AND PROJECTOR Installation and Quick-Start Guide
Page Inst_5
Rev D July 2014
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
Ensure that there is at least
30cm (12in) of space between the
ventilation outlets and any wall,
and 10cm (4in) on all other sides.
Do not stack more than 3
projectors.
Positioning the Screen and Projector
• Install the screen, ensuring that it is in the best position for viewing by your audience.
• Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll the screen. Set the adjustable feet so that
the projector is level, and perpendicular to the sceen.
• The dimension drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling mounting.

Digital Projection M-Vision LED+IR series OPERATING THE PROJECTOR Installation and Quick-Start Guide
Page Inst_6
Rev D July 2014
Operating the Projector
Switching the Projector On
• Connect the power cable between the mains supply and the projector. Switch on at the switch next to the power connector.
• Wait until the self-test has completed and the Standby indicator on the projector control panel shows amber. The lamp will be off and the
projector will be in STANDBY mode.
• Press POWER on the control panel or on the remote control, and hold for 3 seconds.
The Power indicator on the control panel will ash blue for a few seconds whilst the lamp comes up to full brightness. When the projector
is ready for use, the Power indicator will show steady blue.
Selecting an Input Signal or Test Pattern
Input signal
• Connect an image source to the projector. The signal should be automatically detected by the projector, and should be displayed within a
two or three seconds.
• If more than one signal is connected, then select the image you want to display:
Select from ve of the inputs using to on the remote control,
or press SOURCE on the control panel to cycle through all the inputs.
or use Source Select in the General menu.
Test pattern
If you have no image source connected to the projector, then you can display a test pattern instead:
Select a Test Pattern from the General menu.
Notes
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector
For full details of how to connect an
image source to the projector, see
the Connection Guide.
For full details of how to use the
controls and the menu system, see
the Operating Guide.

Digital Projection M-Vision LED+IR series OPERATING THE PROJECTOR Installation and Quick-Start Guide
Page Inst_7
Rev D July 2014
Adjusting the Lens
Zoom
• Turn the smooth ring on the lens, closest to the case, to adjust the zoom so that the image lls the screen.
Focus
• Turn the knurled ring at the outer end of the lens, to adjust the focus until the image is sharp.
Shift
• Use the 5mm allen wrench to adjust the horizontal and vertical position of the image.
Notes
 Iftheprojectoristtedwiththexed
0.73:1 lens then there are no lens
shift controls.
Horizontal
shift
Vertical
shift
Focus
adjustment
Zoom
adjustment

Digital Projection M-Vision LED+IR series OPERATING THE PROJECTOR Installation and Quick-Start Guide
Page Inst_8
Rev D July 2014
Adjusting the Image
Orientation
• Use the Rear Projection and Ceiling Mode settings, in the Setup Menu.
Aspect Ratio
• Press the button on the remote control to cycle through all the available settings.
or use the Aspect Ratio setting in the Image Menu.
• Press or on the remote control to set the Brightness and Contrast, using or to adjust the sliders.
or use the Brightness or Contrast settings in the Image Menu.
Switching the Projector Off
• Press POWER on the control panel or on the remote control, then press the button a second time to conrm your intention to
switch off.
The lamp will go off, the Standby indicator on the control panel will show amber and the projector will be in Standby mode.
• Switch off at the switch next to the power connector. Disconnect the power cable from the projector.
Notes
For full details of how to use the
controls and the menu system, see
the Operating Guide.
Always allow the lamp to cool for
5 minutes before:
- disconnecting the power
- moving the projector

Rev D July 2014
M-Vision LED+IR series
High Brightness Digital Video Projector
16:10 widescreen display
CONNECTION GUIDE
112-159D
BOOK CONTENTS
CONNECTION GUIDE
About this Guide
Symbols used in this guide
Warnings
Notes

Digital Projection M-Vision LED+IR series CONTENTS Connection Guide
Rev D July 2014
CONTENTS
About this Guide ................................................................................Conn_1
Symbols used in this guide............................................................... Conn_1
Warnings ....................................................................................Conn_1
Notes..........................................................................................Conn_1
Product revision................................................................................. Conn_1
Signal Inputs and Outputs .......................................................... Conn_2
HDMI 1 and 2....................................................................................... Conn_2
RGB ..................................................................................................... Conn_2
S-Video ................................................................................................ Conn_2
Composite Video ................................................................................ Conn_2
Component 1 and 2............................................................................ Conn_2
SCART................................................................................................. Conn_2
Supported Signal Input Modes................................................. Conn_3
Control Connections .......................................................................Conn_5
Wired Remote Control ....................................................................... Conn_5
LAN...................................................................................................... Conn_5
RS232 .................................................................................................. Conn_5
Wiring Details.......................................................................................Conn_6
Signal inputs....................................................................................... Conn_6
HDMI..........................................................................................Conn_6
RGB ...........................................................................................Conn_7
S-Video ......................................................................................Conn_7
Composite Video........................................................................ Conn_7
Component 1.............................................................................. Conn_8
Component 2.............................................................................. Conn_8
SCART .......................................................................................Conn_8
Control connections .......................................................................... Conn_9
Wired Remote control connection.............................................. Conn_9
Serial control input and output ................................................... Conn_9
LAN connection........................................................................ Conn_10
Setting the LAN IP conguration.............................................. Conn_11

Digital Projection M-Vision LED+IR series ABOUT THIS GUIDE Connection Guide
Page Conn_1
Rev D July 2014
About this Guide
Please read this guide carefully before using the projector, and keep it handy for future reference.
A serial number is located on the side of the projector. Record it here:
Symbols used in this guide
Warnings
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
Notes
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice. Projectors built prior to this revision of the Operating Guide may therefore not include all the features described.

Digital Projection M-Vision LED+IR series SIGNAL INPUTS AND OUTPUTS Connection Guide
Page Conn_2
Rev D July 2014
Signal Inputs and Outputs
HDMI 1 and 2
• Connect to either of the 4-pin HDMI connectors.
RGB
• Set Color Space in the Advanced menu to Auto, or RGB PC if necessary.
S-Video
• Connect to the 4-pin mini-DIN connector.
Composite Video
• Connect to the single Video phono connector.
Component 1 and 2
YPbPr/YCbCr
• Connect to Component 1 or Component 2.
• Set Color Space in the Advanced menu to Auto, or REC709 or REC601 if necessary.
RGsB
• Connect to Component 1 or Component 2.
• Set Color Space in the Advanced menu to Auto, or RGB Video if necessary.
RGBS
• Connect the RGB cables to Component 1, and the Sync cable to Video.
• Select SCART in the Source Select menu.
SCART
• Using a SCART to RGBS adaptor, connect the RGB cables to Component 1, and the
Sync cable to Video.
• Select SCART in the Source Select menu.
Component 1/
SCART
HDMI 1
RGB
Notes
For a complete listing of pin
congurationsforallsignaland
control connectors, see Wiring
Details later in this Guide.
Component
2
HDMI 2
Video
S-Video
When the SCART input is enabled,
the Video and Component 1 inputs
will be disabled.
SCART adaptors

Digital Projection M-Vision LED+IR series SUPPORTED SIGNAL INPUT MODES Connection Guide
Page Conn_3
Rev D July 2014
Supported Signal Input Modes
Signal Resolution Frame
Rate
( Hz )
VIDEO
S-VIDEO
SCART
COMPONENT
RGB (RGBHV)
RGB (RGsB)
HDMI RGB
HDMI YUV 8 bit
HDMI YUV 10 bit HDMI YUV 12 bit
PC 640 x 480 59.94 ü ü
640 x 480 74.99 ü ü
640 x 480 85 ü ü
800 x 600 60.32 üüü
800 x 600 75 ü ü
800 x 600 85.06 ü ü
848 x 480 47.95 ü ü
848 x 480 59.94 ü ü
1024 x 768 60 ü ü
1024 x 768 75.03 ü ü
1024 x 768 85.03 ü ü
1024 x 1024 59.92 üüü
1024 x 1024 59.999 ü ü
1024 x 1024 60 ü ü
1280 x 720 47.95 ü ü
1280 x 1024 60.02 üüü
1280 x 1024 75.02 üüü
1280 x 1024 85.02 ü ü
1400 x 1050 60 üüü
1600 x 900 60 üüü
1600 x 1200 60 ü ü
1920 x 1080 47.95 ü ü
1680 x 1050 59.94 ü ü
1920 x 1200 60 ü ü
Apple Mac 640 x 480 66.59 ü ü
continued on next page...

Digital Projection M-Vision LED+IR series SUPPORTED SIGNAL INPUT MODES Connection Guide
Page Conn_4
Rev D July 2014
...continued from previous page
Signal Resolution Refresh
Rate
( Hz )
VIDEO
S-VIDEO
SCART
COMPONENT
RGB (RGBHV)
RGB (RGsB)
HDMI RGB
HDMI YUV 8 bit
HDMI YUV 10 bit HDMI YUV 12 bit
NTSC NTSC (M, 4.43) 59.94 ü ü
PAL PAL (B,G,H,I) 50 ü ü
PAL (N) 50 ü ü
PAL (M) 59.94 ü ü
SECAM SECAM (M) 50 ü ü
SDTV RGBS 50 ü
480i 59.94 ü
576i 50 ü
EDTV 480p 59.94 üüüüüüü
576p 50 üüüüüüü
HDTV 1035i 60 üüüüüüü
1080i 50
1080i (Aus) 50 üüüüüüü
1080i 59.94 üüüüüüü
1080i 60 üüüüüüü
720p 50 üüüüüüü
720p 59.94
720p 60 üüüüüüü
1080p 23.98 üüüüüüü
1080p 24 üüüüüüü
1080p 25 üüüüüüü
1080p 29.97 üüüüüüü
1080p 30 üüüüüüü
1080p 50 üüüüüüü
1080p 59.94 üüüüüüü
1080p 60 üüüüüüü

Digital Projection M-Vision LED+IR series CONTROL CONNECTIONS Connection Guide
Page Conn_5
Rev D July 2014
Control Connections
Wired Remote Control
• If infrared signals from the remote control cannot reach the projector due to excessive
distance or obstructions such as walls or cabinet doors, you can connect an external
IR repeater to the Remote control input, and position its IR sensor within range of the
operator.
Note that plugging in the remote control cable will disable the infra-red.
LAN
• All of the projector’s features can be controlled via a LAN connection, using the text
strings described in the Remote Communications Guide.
• The default LAN IP address is 192.168.0.100. For information about how to change this,
see Setting the LAN IP conguration, later in this guide.
Each projector can be given a unique System ID, and this can be be used to control
them individually or simultaneously. For more information about this, see the Remote
Communications Guide.
RS232
• All of the projector’s features can be controlled via a serial connection, using the control
strings described in the Remote Communications Guide.
• Projectors can be connected in a daisy chain, connecting the RS232 OUT of one
projector to the RS232 IN of the next. Each projector can be given a unique System
ID, and this can be be used to control them individually or simultaneously. For more
information about this, see the Remote Communications Guide.
Notes
For a complete listing of pin
congurationsforallsignaland
control connectors, see Wiring
Details later in this Guide.
Only one remote connection should
be used at any one time.
RS232
IN
Wired
Remote LAN
RS232
OUT
RS232
OUT
IN
OUT
IN
OUT
IN

Digital Projection M-Vision LED+IR series WIRING DETAILS Connection Guide
Page Conn_6
Rev D July 2014
Wiring Details
Signal inputs
HDMI
19 way type A connector
1 TMDS Data 2+
2 TMDS Data 2 Shield
3 TMDS Data 2-
4 TMDS Data 1+
5 TMDS Data 1 Shield
6 TMDS Data 1-
7 TMDS Data 0+
8 TMDS Data 0 Shield
9 TMDS Data 0-
10 TMDS Clock+
11 TMDS Clock Shield
12 TMDS Clock-
13 CEC
14 not connected
15 SCL (DDC Clock)
16 SCA (DDC Data)
17 DDC/CEC Ground
18 +5 V Power
19 Hot Plug Detect
Notes
For full details of all input settings,
see the Advanced menu in the
Operating Guide.
pin view of panel connector

Digital Projection M-Vision LED+IR series WIRING DETAILS Connection Guide
Page Conn_7
Rev D July 2014
RGB
15 way D-type connector
1 R
2 G
3 B
4 unused
5 Digital Ground (H Sync)
6 R Ground
7 B Ground
8 G Ground
9 +5v
10 Digital Ground (V Sync/DDC)
11 unused
12 SDA
13 H Sync
14 V Sync
15 SCL
S-Video
4 pin mini-DIN
1 Y Ground
2 C Ground
3 Luminance (Y)
4 Chrominance (C)
Composite Video
RCA Phono
Notes
For full details of all input settings,
see the Advanced menu in the
Operating Guide.
pin view of female connector
pin view of female connector
